Odys 350 User manual

ODYS Multi Pocket TV 350
1
DE
Table of contents
1Safety instructions...................................................................................2
2Product properties...................................................................................5
3Quick Start Guide....................................................................................6
3.1 Language Setting .....................................................................................6
3.2 DVB-T installation – channel search.........................................................6
4Controls ..................................................................................................8
4.1 Buttons on the main unit...........................................................................9
4.2 Buttons on the Remote Control ................................................................9
5Connecting the Multi Pocket TV 350.....................................................11
5.1 Connecting to a television set.................................................................11
5.2 Connecting Headphones (not included in the package)..........................11
5.3 Connecting Additional DVB-T-Antenna...................................................12
5.4 Power supply Unit...................................................................................12
6Rechargeable battery............................................................................13
6.1 Notes on using rechargeable batteries ...................................................13
7Mode selection......................................................................................14
8Digital TV ..............................................................................................15
8.1 DVB-T Installation – channel search.......................................................16
8.2 TV- Channel Selection............................................................................16
8.3 Short-Key Menu .....................................................................................17
8.4 Settings for DVB-T Mode........................................................................19
8.4.1 Channel Organizer ..................................................................... 19
8.4.2 Installation(channel search) ....................................................... 20
8.4.3 Grouping Stations.......................................................................20
8.4.4 Delete All..................................................................................... 21
9Multimedia ............................................................................................22
9.1 Photo playback.......................................................................................24
9.2 Video and MP3 playback ........................................................................24
10 Games ..................................................................................................25
11 Configuration ........................................................................................26
11.1 TV Display..............................................................................................26
11.2 OSD Settings..........................................................................................27
11.3 Time Settings .........................................................................................27
11.4 Parental Lock .........................................................................................28
11.5 System Information.................................................................................28
12 Troubleshooting ....................................................................................29
13 Specifications........................................................................................30
14 Warranty conditions ..............................................................................31

ODYS Multi Pocket TV 350
2
DE
1 Safety instructions
Thank you for choosing our product. Please read this manual carefully and observe all
safety and operating instructions. Store the manual in a safe place for later reference.
The flash symbol displayed in a triangle warns the user of dangerous electrical
voltages inside the device that could lead to electrical shocks with harmful effects
to health if the device is used incorrectly.
or
The exclamation point displayed in a triangle in the documentation
indicates dangers when using and maintaining the device.
The information symbol in the documentation indicates useful information and tips
for using and maintaining the device.
Power supply
Connect the power supply cable to the DC 12V IN jack on the right side of the
device. Connect the power plug to an earthed socket AC 100-240 V. If you have
problems when plugging the mains plug into the socket, rotate the plug by 180°
and plug it in again.
Tips regarding environmental protection
At the end of its operating life, this product may not be disposed of by
way of your normal household waste. Instead it must be delivered to a
collection point for recycling electrical and electronic equipment. The
icon on the product, in the operating instructions or on the packaging,
indicates this.
The materials used in manufacturing this product are recyclable,
depending on their identifying markings. By recycling this equipment,
by recycling its components, or through other procedures of re-using
outdated equipment, you are making an important contribution to
protection our environment. Please ask you local municipal
administration for the location of the corresponding recycling point.

ODYS Multi Pocket TV 350
3
DE
Caution
Read, keep and follow these instructions and heed all warnings.
•Do not open the casing of the device under any circumstances, and do not attempt to
repair or modify the device. Malfunctions, damage, electric shocks and fires can occur as
a result.
•Never expose the device to rain, moisture or humidity. Malfunctions, damage and electric
shocks can occur as a result.
•When cleaning the device, do not use any volatile substances, such as solvents. To
avoid damaging the surface, clean the device only using a soft, dry cloth.
•Ensure adequate air circulation around the device. Do not place the device on soft
furniture, carpets or other materials while in operation, as this may restrict the air from
properly circulating around the device.
•The device may not be excessively heated or operated near heat sources (e.g. heaters).
Malfunctions, damage, smoke and fires can occur as a result.
•Connect the device only to mains sockets that are properly earthed (protective earth).
The mains voltage must correspond to the operating voltage of the device indicated on
the device housing. When connecting the device to other electric devices, always follow
the manufacturer's instructions.
•Insure that the cables are not damaged, stretched or twisted and that no short circuits
occur.
•Use only accessories specified or supplied by the device manufacturer. This also applies
to any attachments and fasteners.
•Place the device in a secure spot where it cannot shift or fall. If used in a
vehicle, the device must be securely fastened to avoid injuries or accidents
resulting from the device shifting or falling down.
•During a thunderstorm, disconnect the device from the mains. Do not use the
device during a thunderstorm. Malfunctions, damage and electric shocks may occur as a
result. Disconnect the power plug from the socket when you do not use the device for an
extended period of time. Keep the device in a clean, dry location where it is not exposed
to direct sunlight.
Caution
•In case of malfunctions or damage, maintenance or repair work may be required. Do not
use the device if there is visible damage to it. All maintenance and repair should be
conducted by qualified service technicians only.
•Do not place any heavy objects and objects that contain liquids, such as vases, on top of
the device...
•Make sure that no objects or fluids can penetrate into the device though openings or
venting slots. This could lead to short circuits, damage, electric shocks and fires.
•Do not touch the TFT LCD screen with your bare hand.
•Observe the safety instructions on rechargeable batteries in chap. 5.1.

ODYS Multi Pocket TV 350
4
DE
Operating the device in a vehicle
•Please note that the device may not be used while the vehicle is in motion. It may only be
used when the vehicle is parked!
•When operating the device in a vehicle, insure that it does not inhibit the driver's forward
or rear view and that it does not interfere with the safe operation of the vehicle. Otherwise
injuries or accidents may result. The driver must not operate the device or look at the
screen while driving. Do not allow your children to loosen or disengage their safety belts
to operate the device.
•Do not place the device near airbags in the vehicle, thus avoiding functional disorders.
When the airbag deploys, the device or accessories may be flung through the vehicle and
thus can cause injuries and accidents.
•Install the cables so that they do not present an obstacle to operating the vehicle or to
getting into or out of the vehicle. Make sure that no cables can accidentally wrap around
the steering wheel, the pedals or any passenger's feet. Tie the cables together.
•If operating the device inside a vehicle, do not set the volume level too high to insure that
sounds occurring on the inside and outside of your vehicle may be heard. Otherwise
accidents may occur.
Battery Recycling
In order to ensure the environmentally friendly disposal of batteries, please do
NOT dispose of used batteries through normal household waste. Please take the
batteries to your local retail or community collection point for recycling.
The following may be an indication of a discharged battery: The device cannot
be switched on. The device switches off automatically and "Battery Empty" is
shown in the display. The device and or battery do not function properly.

ODYS Multi Pocket TV 350
5
DE
2 Product properties
•AV Out: Analogue audio/video output
•DVB-T Receiver
•Supports Multimedia File Formats: MP3, WMA, JPEG, AVI, MPG
•3.5" TFT - Color Display
•Switchable power supply unit:
Automatic adjustment to different voltages in different countries.
•Multi-Language On-screen menu
Special features:
•Build-in rod Antenna
•SD/MMC card slot
•USB Host
•Remote control
•Integrated Game
Support
URL: http://www.odys.de
See our website for the latest information on this DVD player, on other products by our
company and on our company itself. If you have questions or problems, please read
the FAQs on our website or contact our customer support service [e-mail].

ODYS Multi Pocket TV 350
6
DE
3 Quick Start Guide
3.1 Language Setting
1. Switch on your Multi Pocket TV 350.
2. Press the Menu Key on the remote control.
3. Select the Menu „Configuration“ using the key.
4. Press the „Enter“ Key to enter Configuration.
5. Select the „OSD Setting“ option using the key and Enter key.
6. Move to „OSD Language“ using the key.
7. Highlight your desired language using key in the language list.
8. Confirm the language selection using the „Enter“ key.
9. Use the „Return“ key to go back in the main menu.
3.2 DVB-T installation – channel search
1. Switch on your Multi Pocket TV 350.
2. Press the Menu Key on the remote control.
3. Select the Menu „Digital TV“ (DVB-T) using the key.
4. Press the „Enter“ Key to enter Digital TV.
5. Select the Menu option „Installation“ using the keys and the Enter Key.
6. Choose your desired search method for the channel search using the
keys and Enter Key.
7. It is strongly recommended to choose the Option „Country scan “.
8. Press the „Enter“ Key to enter „Country scan “.
9. Using the Keys move between the Country selections.
10. Highlight your desired Area setting using the Keys.
11. Press the „Enter“ key two times to start the channel search.
12. Use the „Return“ key to return to the main menu.
Note
Whether and how many DVB-T channels may be received by Multi Pocket TV 350,
strongly depends on the operational area and the DVB-T signal strength.
DVB-T radio in particular is very limited and not available in most locations
Please note that using the DVB-T after changing locations may require a new
channel search as the channel frequencies may vary from region to region.

ODYS Multi Pocket TV 350
7
DE
Contents of package
1 x MP-TV 350 1 x Remote control 1x additional Antenna
1 x Power Supply 1 x Audio/Video-cable 1 x Battery for remote
control
1 x users manual
Note
Do to technological progress, accessories and their corresponding part numbers
are subject to change without notice.

ODYS Multi Pocket TV 350
8
DE
4 Controls
4.1 The Main Unit
Note
Charge the battery with the device switched off. This will shorten the charging time
and extend the life of the battery.
Charge the battery fully before using for the first time.
CH+
CH-
VOL+
VOL-
MENU
ENTER
ON OFF
Rea
r
View
Power on/off switch Interne Antenna
additional Antenna
connection jack
up, next Station/Titel
down, last station/Titel
right, Volume increase
left, Volume decrease
Main Menu, return
select, confirm, sort-key menu
in DVB-T Mode
Status indicator light
speaker
LCD Display
SD/MMC card slot
Power supply connection
and USB Host interface for
external
s
torage unit
Headphone jack
A
/V out
p
ut
j
ack
Bracket

ODYS Multi Pocket TV 350
9
DE
4.2 The Remote Control
1. switch on/off
2. up, next channel
3. mute (switches the sound off)
4. Direction left, decrease Volume
5. select, short-key menu
6. Direction right, increase Volume
7. Enter main menu, return to main menu
8. down, last Channel
9. one menu level backwards, return to last viewed channel
10. Numerical buttons to directly select the corresponding station number or for entering
the page number of Videotext.
11. previous Title
12. next Title
Preparation of the Remote Control
Place the remote control on an even surface and insert the supplied cell battery into
the remote control as follows.
1Refer to the drawing and remove the empty
battery receptacle.
2Insert the battery into the receptacle. Make
sure the polarity matches the marks inside the
component.
1
2
3
4
5
7
6
8
9
10
11 12

ODYS Multi Pocket TV 350
10
DE
3Insert the receptacle into the remote control.
Cell Battery Data
Battery type: CR2025 , 3 V
Service life: approximately 1 year (for normal use and room temperature)
Using the Remote Control
Point the remote control towards the main unit when operating. The remote control works
best at a distance less than 5 m and at an angle of up to 30° to the front of the unit. No
obstacles should be in the way of the remote control and the infrared sensor. Do not place
the remote control in direct sunlight. If the remote control unit fails to work even when it is
operated near the player, replace the battery.
Note:
If the remote control is not used for a long period of time, please remove the
battery from the compartment.
Do not heat batteries or dispose of in fire.
Do not dismantle, deform or modify batteries.

ODYS Multi Pocket TV 350
11
DE
Black
yellow
red
Signal path
A
/V cable
TV
White
5 Connecting the Multi Pocket TV 350
•The DVB-T player, the television set and any other electric devices to be connected to
the DVB-T player must be switched off and disconnected from the mains.
•Observe the colour coding when connecting audio and video cables.
5.1 Connecting to a television set
Audio/Video-Connection
Using the A/V cable, connect the Multi Pocket TV 350 to the AV input of the television
set as shown in the illustration.
5.2 Connecting Headphones (not included in the
package)
Connect the headphones to the headphone/AV jack on the left side of the device, the
loudspeaker is automatically deactivated.
CH+
CH-
VOL+
VOL-
MENU
ENTER
CH+
CH-
VOL+
VOL-
MENU
ENTER

ODYS Multi Pocket TV 350
12
DE
Caution
Excessively high volume can damage your hearing. Turn the volume down before
connecting the headphones and then turn the volume up to a moderate level.
5.3 Connecting Additional DVB-T-Antenna
Connect the DVB-T-Antenna to the DVB-T-Antenna connection jack.
Note
Depending on your region and building structure, a stronger antenna may be
required in order to receive DVB-T stations. Using an antenna with coaxial(IEC)
connection, an appropriate adapter(not included in the package) will be required.
The Multi Pocket TV uses a MMCX Antenna connection.
5.4 Power supply Unit
The DVB-T player is delivered with a power supply unit.
Connect the power supply cable to the USB Jack on the left side of the device as
shown below. Connect the power plug to an earthed socket. The power supply
indicator lamp lights up red..
Illustrations may vary
CH+
CH-
VOL+
VOL-
MENU
ENTER
CH+
CH-
VOL+
VOL-
MENU
ENTER

ODYS Multi Pocket TV 350
13
DE
6 Rechargeable battery
Fully charge the battery before using the device for the first time. Normally it takes
about five hours for the battery to be charged. When the rechargeable battery is fully
charged, the device may be operated for about 2 – 2.5 hours. Fully charge the battery
when not be used for an extended period of time.
6.1 Notes on using rechargeable batteries
¾When using a new rechargeable battery, fully charge it prior to use.
¾Use rechargeable batteries only in temperatures between 0°C and 40°C. Do not expose
rechargeable batteries to high temperatures or direct sunlight.
¾Do not throw the battery into water or fire.
¾Ensure adequate air circulation around the device. Do not place the device on soft furniture,
carpets or other materials while in operation, as this may restrict the air from properly circulating
around the device.
¾Do not disassemble the rechargeable battery.
¾While the battery is being charged, the battery status indicator lamp lights up red; when the
battery is fully charged, the indicator lamp lights switches off.
¾When the state of charge reaches a low level, an empty battery symbol is flashed on the LCD
Screen, Some minutes later the Multi Pocket TV 350 turns off automatically..
.
Note:
Charge the battery with the device switched off. This will shorten the charging
time and extend the life of the battery.
Charge the battery fully before using for the first time.

ODYS Multi Pocket TV 350
14
DE
7 Mode selection
Use the main menu to access the various operation modes and Settings:
1Press the MENU Key to switch to the main menu (as shown above).
2Use the CH+/and CH-/keys to move between the options.
3 Confirm your selections using the ENTER Key.
Available Functions:
Digital TV - Change various Settings for DVB-T Mode.
Multimedia - Playback for Music, Image or Movie files from an
SD card or USB storage unit.
Games - 3 integrated games
Configuration - Change various system settings

ODYS Multi Pocket TV 350
15
DE
8 Digital TV
Note
To avoid distortion, it may me necessary to switch the display to 4:3 or 16:9 which
ever best suites the current station. Refer to Chapter 9
Please note that movies using the 21:9 format may cause black margins on the
upper and lower margins of the display.
Note
Insure that DVB-T reception is available for your area. DVB-T radio in
particular is very limited and not available in most locations.
Depending on your region and building structure, a stronger antenna may be
required in order to receive DVB-T stations. The antenna provided is only
designed for reception when close to the DVB-T transponder.
Metal buildings and the geographic location of the transponder may have
great effect on the reception. Please note that this is not a device defect;
merely specific specifications for the reception of DVB-T.
The Multi Pocket TV uses a MMCX Antenna connection.
Appropriate antennas may be obtained from your local specialty stores.
For the use of an antenna with coaxial(IEC) connection an appropriate
adapter is required, which may be obtained from your local specialty stores.

ODYS Multi Pocket TV 350
16
DE
8.1 DVB-T Installation – channel search
1. Switch on your Multi Pocket TV 350.
2. Press the „Menu" Key on the remote control.
3. Select the menu „Digital TV“ (DVB-T) using the key.
4. Press the „Enter“ Key to enter Digital TV.
5. Select the menu option „Installation“ using the keys and the Enter Key.
6. Select the desired search method for the channel search using the keys
and „Enter" Key.
7. It is strongly recommended to select the Option „Country scan “.
8. Press the „Enter“ Key to enter „ Country scan “.
9. Use the Keys to move between the country selections.
10. Use the Keys to move between the Area selections.
11. Highlight your desired Area setting using the Keys.
12. Press the „Enter“ key two times to start the channel search.
13. Use the „Return“ key to go back to the main menu.
Note
Whether and how many DVB-T channels may be received by the Multi Pocket TV
350 strongly depends on the operational area and the DVB-T signal strength.
DVB-T radio in particular is very limited and not available in most locations.
8.2 TV- Channel Selection
1Press the MENU or Return Key to exit your current mode or to switch on the Multi
Pocket TV 350. The DVB-T Mode is the standard mode of the device and will start
automatically.
2Use the number buttons 0-9 on the remote control to select the desired TV station.
3 Switch to the stored TV channels, going both forwards and backwards in
succession, using the  or CH+ and CH- buttons.
4 Set the suitable volume using the Vol+ und Vol- buttons.
5 Press the ENTER Key to open the short-key menu.

ODYS Multi Pocket TV 350
17
DE
8.3 Short-Key Menu
1Press the ENTER key on the remote control.
2 The short-key menu appears on the display with several Options.
3Use the keys to move between the options. Press the ENTER key to confirm.
Subtitles
Press the ENTER Key to open the short-key menu. Select „Subtitle" and press the
ENTER key to open the sub menu. Activate or deactivate the use of subtitles and
press Enter" to confirm your selection.
Note
This function is only available when the appropriate information is received from
the TV channel.
EPG(electronic program guide)
Press the ENTER Key to open the short-key menu. Use the/keys to highlight the
option „EPG“ and confirm using the „ENTER" key. Refer to the illustration below.
Use the ///Keys to view the EPG information from different channels.

ODYS Multi Pocket TV 350
18
DE
Videotext (TTX)
1Press the ENTER Key to enter the short-key menu and select the option TTX.
2 Press the ENTER Key again to open the Videotext window, the first page of the
Text content from current TV channel will be shown.
3Use the number keys 0-9 to input the number of your desired Videotext page.
4 You can also use the direction buttons to browse the Videotext contents as
following:
(Vol-) 100 pages down
(VOL+) 100 pages up
(CH+) one page up
(CH-) one page down
5 Press the RETURN button to return to the TV-Mode.
Multi-Audio
Press the ENTER Key to open the short-key menu and select the option Multi-audio.
Use the CH+/CH- Key to select the desired Audio language.
Note
The Multi-audio function will only have an effect when receiving stations that
have been transmitted in more than one language.
Program info.
Press the ENTER Key to open the short-key menu and select the option program info,
the information of the current program will be shown on the display.
Note
You can adjust the length of time the Program information is to be shown on the
display while in the system settings (Configuration – OSD - OSD Timeout).
TV/Radio
Press the ENTER Key to open the short-key menu and select the option TV/Radio to
switch between DVB-T TV and DVB-T Radio mode.
Note
DVB-T radio in particular is very limited and not available in most locations.

ODYS Multi Pocket TV 350
19
DE
Program List
Press the ENTER Key to open the short-key menu and select
the option Program list. Select the desired TV channel using the
/Keys and confirm by pressing the ENTER Key. Use the
/Keys to switch between the classified TV channels (see
channel organizer/channel grouping).
Note
To use the classification function, you must first add the available channels into
the exiting classes.
8.4 Settings for DVB-T Mode
8.4.1 Channel Organizer
Press the MENU key to enter the main menu, select
„Digital TV“ and confirm by pressing the ENTER key.
Select the option „Channel Organizer“ and confirm
again with ENTER.
Use the /keys to highlight a channel.
You can determine now, how this channel is to be
treated in the future. Use the /keys to select one
function.
Skip or Lock
Press the ENTER Key, to assign the selected function to the channel.
Note
For the function Lock, you must enter the password from Parental Lock
Setting..
On original delivery status is the Password „0000“.
Skip - The Channels which are marked to be skip will be jumped over
when switching the channels up and down. You may however
select these channels by directly entering the program number on
the remote control.
Lock - This function blocks the individual channels with a pre-defined
password. The blocked channels are than only selectable by input
of this password. Please refer to chapter 11 – Parental Lock.

ODYS Multi Pocket TV 350
20
DE
8.4.2 Installation(channel search)
Press the MENU key to enter the main menu. Select „Digital TV“ and confirm by
pressing the ENTER key. Select the Option „installation“ and confirm again with
ENTER.
The channel search can be performed with (Area Search), (Manual Search) or (Auto
Search).
Country Scan
Move to „Country Scan“ and press the ENTER Key to enter the country selection page.
Use the /keys to move between the country selection.
Select your country and confirm by pressing the ENTER key.
Press the ENTER key again to start the channel search.
Manual Scan
With the Manual Scan you can search for channels manually
Auto Scan
With Auto Scan you can determine the bandwidth and start and end frequency to
search the channels automatically, based on these Parameters.
8.4.3 Grouping Stations
Press MENU to enter the main menu. Choose „Digital TV“ and confirm using the
ENTER button. Choose „Channel Organizer“ and confirm with ENTER again.
You may separate and sort the saved stations into 8 Groups.
You may choose the following groups:
1 None, 2 News, 3 Science, 4 Sport, 5 Movie, 6 Kids, 7 Music and 8 Fashion.
Use the /keys to choose the desired station. Set the stations group by using the
/keys.
Confirm using the ENTER button.
