OEM Tools 24666 Service manual

UNPACKING
After unpacking unit, inspect carefully for any damage
that may have occurred during transit. Check for loose,
missing, or damaged parts. If any damage is observed,
a shipping damage claim must be filed with carrier.
DO NOT use the OEMTOOLS™Impact Wrench if broken,
bent, cracked or damaged parts (including labels) are
noted. Any Impact Wrench that appears damaged in
any way, operates abnormally or is missing parts should
be removed from service immediately. If you suspect
that the Impact Wrench was subjected to shock load
(a load that was dropped suddenly, unexpectedly, etc.)
immediately discontinue use until it has been checked
by a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24666
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar
with this product before you begin using it. This product is designed for certain applications only. OEMTOOLS™
cannot be responsible for issues arising from modification. We strongly recommend this product is not modified and/
or used for any application other than that for which it was designed. If you have any questions relative to a particular
application, DO NOT use the product until you have first contacted customer service to determine if it can or should be
performed on the product.
WARNING:This product can expose you to chemicals, including lead, which are known to the State of California to
cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
1/2" DRIVE IMPACT WRENCH
1
11/18
2018 OEMTOOLS™
The following safety information is provided as a guideline to help you operate your Impact Wrench under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe
handling instructions are not known or not followed. The following safety instructions are to provide the user with the
information necessary for safe use and operation. Please read and retain these instructions for the continued safe use
of your tool. Failure to follow instructions listed below may result in serious injury. In addition, make certain that anyone
who uses the equipment understands and follows these safety instructions as well.
WARNING

2
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
POWER TOOL SAFETY
WARNING:
1. Read all safety warnings and instructions. Failure to
follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
2. Save all warnings and instructions for future reference.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. DO NOT operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never modify
the plug in any way. DO NOT use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges, and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
3. DO NOT expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. DO NOT abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges, or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of a ground fault circuit
interrupter (GFCI) reduces the risk of electric shock.
7. When operating a power tool outside, use an outdoor
extension cord marked "W-A" or "W".
PERSONAL SAFETY
1. Stay alert, watch what you are doing, and use common
sense when operating a power tool. DO NOT use a
power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in
the OFF position before connecting to power source
and/or battery pack, picking up or carrying the tool.
4. Carrying power tools with your finger on the switch or
energizing power tools that have the switch ON invites
accidents.
5. Remove any adjusting key or wrench before turning
the power tool ON. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
6. DO NOT overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
7. Dress properly. DO NOT wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
8. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
9. DO NOT use this Impact Wrench for tasks it is not
designed to perform.
POWER TOOL USE AND CARE
1. DO NOT force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.
2. DO NOT use the power tool if the switch does not turn
it ON and OFF. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/ or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
4. Store idle power tools out of the reach of children and
DO NOT allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.

3
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Use the power tool, accessories and tool bits, etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
7. Hold power tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a
"live" wire will make exposed metal parts of the tool
"live" and shock the operator.
8. Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable
and may lead to loss of control.
9. DO NOT use this Impact Wrench for tasks it was not
designed to perform.
10. Never lay workpiece on hard surfaces like concrete,
stone, etc.
11. The Impact Wrench is wired at the factory for 110–120V
operation. It must be connected to a 110–120V, 15A
time delayed fuse or circuit breaker. To avoid shock or
fire, replace power cord immediately if it is worn, cut or
damaged in any way.
12. Avoid accidental starting. Be sure switch is OFF before
plugging in.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
WARNING:
1. Know your Impact Wrench. Read the Owner’s Manual
carefully. Learn the tool’s applications and limitations,
as well as the specific potential hazards related to this
tool. Following this rule will reduce the risk of electric
shock, fire, or serious injury.
2. Always wear eye protection. Any power tool can throw
foreign objects into your eyes and cause permanent
eye damage. ALWAYS wear safety goggles (not
glasses) that comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant lenses.
They ARE NOT safety glasses. Glasses or goggles not
in compliance with ANSI Z87.1 could cause serious
injury when they break.
3. Always use hearing protection when operating the
Impact Wrench.
4. Hold power tool by insulated gripping surfaces when
performing an operation where the fastener may
contact hidden wiring or its own cord. Fasteners
contacting a "live" wire may make exposed metal parts
of the power tool "live" and could give the operator an
electric shock.
5. Use only impact sockets and accessories that are
designed for use with an Impact Wrench. DO NOT use
chrome plated sockets and accessories. Chrome plated
sockets and accessories are designed for hand use only
and MUST NOT be used with an Impact Wrench. They
may shatter and possibly cause serious injury.
6. Before each use, check the impact sockets and
accessories for excessive wear or cracks. Worn or
damaged sockets or accessories may shatter and
possibly cause serious injury. Worn accessories may
allow the socket to come off during operation of the
Impact Wrench.
7. Never use the Impact Wrench as a torque wrench.
Always use a torque wrench to adjust the fastener to
the specified torque.
8. Keep the Impact Wrench handle and body clean and
free of oil and grease. Always use a clean dry cloth
when cleaning. DO NOT use solvents, brake fluid,
gasoline or other petroleum products to clean the tool.
They will damage the tool.
9. DO NOT wear neckties or loose clothing.
10. When wearing gloves, they must be tight fitting and slip
resistant type. Leather gloves offer the best protection.
11. Always use two hands when operating the Impact
Wrench. Use one hand on the handle and the other on
the front of the tool body.
12. Never place your hand so it is touching the socket or
accessory when the tool is turned ON. Your hand could
be seriously injured.
13. Always remove the plug from the power source before
installing or removing any socket or accessory.
14. Be ready for components to shift when removing any
fastener. The speed of the fastener removal could
cause unexpected shifting of the components.
15. DO NOT disassemble the Impact Wrench. Take it to a
qualified professional when service or repair is required.
16. Never hold the workpiece in one hand and the tool in
the other hand when in use.

4
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
WARNING:Disconnect the plug from the power
source before making any adjustments, changing
accessories or storing the tool.
To avoid electrical hazards, fire hazards or damage to the
Impact Wrench, use proper circuit protection.
WARNING: Before use, read and understand all
warnings, safety precautions, and instructions as outlined
in the manual.
Important Safety Instructions
The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions and
situations that may occur. The operator must understand
that common sense and caution are factors which cannot
be built into this product, but must be supplied by the
operator.
DISPOSAL
At the end of the useful life of the OEMTOOLS™Impact
Wrench, dispose of the components according to all
state, federal, and local regulations.
PURPOSE
The OEMTOOLS™½" Drive Impact Wrench is designed
to deliver high torque to tighten or loosen threaded
fasteners. No other use is permitted.
PRODUCT SPECIFICATIONS
Square Drive Size: 1/2" with Hog Ring
Motor: 120V AC, 60Hz, 8.5A
Speed: 2,200 RPM (no load)
Impact Speed: 3,000 IPM
Max. Torque: 400 Ft/Lbs.
Tightening Torque: 320 Ft/Lbs.
Weight: 8.3 Lbs.
Cord: 8 Ft.
Rocker Switch: Forward/Reverse
WARNING: Double insulated tools are equipped
with a polarized plug (one blade is wider than the other).
This plug will fit in a polarized plug only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician to install
a polarized outlet. DO NOT change the plug in any way.
Double insulation eliminates the need for the three wire
grounded power cord and grounded power supply
system.
WARNING:If any part is missing or damaged, DO NOT
plug the Impact Wrench into the power source until the
missing or damaged part is replaced.
WARNING:To avoid fire or toxic reaction, never use
gasoline, naphtha, acetone, lacquer thinner or similar
highly volatile solvents to clean the tool.
EXTENSION CORD SAFETY
WARNING:
1. Keep the extension cord clear of the work area.
Position the cord so that it will not get caught on the
workpiece, a tool, or any other obstruction while the
power tool is in use.
2. If an extension cord is used with this impact wrench,
verify that it is in good condition. When using an
extension cord, be sure to use one that is heavy
enough to carry the current that the tool will draw. An
undersized cord will cause a drop in line voltage, which
will result in a loss of power and overheating.
3. The following table shows the correct size to use
according to cord length and the amperage rating that
is listed on the tool’s nameplate.
4. When in doubt, use the next heavier gauge. The smaller
the gauge number, the heavier the cord.
5. Verify that the extension cord is properly wired and
in good condition. Replace a damaged extension
cord immediately, or have it repaired by a qualified
electrician before using it. Keep the extension cord
away from sharp objects, excessive heat, and damp or
wet areas.
6. Use a separate electrical circuit for power tools. This
circuit must consist of not less than 14 gauge wire, and
should be protected by either a 15 Amp. time-delayed
fuse or a circuit breaker. Before connecting the power
tool to the outlet, verify that the switch is in the OFF
position, and that the voltage of the power source is
the same as the voltage that is indicated on the tool’s
nameplate. Running this Impact Wrench at lower
voltage will damage the motor.
MINIMUM GAUGE (AWG) EXTENSION
CORDS (120V use only)
Amperage rating Total length
More
than
Not
more
than
25'
(7.5 m)
50'
(15 m)
100'
(30 m)
150'
(45 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Applicable
LUBRICATION
All of the bearings in this tool are lubricated with a
sufficient amount of high-grade lubricant for the life of the
unit under normal conditions.
Therefore, no further lubrication is required.

5
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
ASSEMBLY AND OPERATION
INSTALL SOCKET
WARNING:Use only impact sockets and acces-
sories that are designed for use with an Impact Wrench.
DO NOT use chrome plated sockets and accessories.
Chrome plated sockets and accessories are designed for
hand use only and MUST NOT be used with an Impact
Wrench. They may shatter and possibly cause serious
injury.
To install a socket, press the square portion of the socket
(1) onto the square drive (2) of the Impact Wrench (see Fig.
1). NOTE: Slide the socket fully onto the square drive so
the socket retainer (3) will hold the socket firmly in place.
FORWARD/REVERSE SWITCH
This Impact Wrench is equipped with a rocker style
forward/reverse switch (1) (see Fig. 2).
1. To operate the Impact Wrench in the forward direction,
press and hold the bottom part of the switch (2). This
direction of rotation will tighten the fastener.
2. To operate the Impact Wrench in the reverse direction,
press and hold the top part of the switch (3). This
direction of rotation will loosen the fastener.
Figure 2
REMOVING FASTENERS
1. Install the correct size of impact socket on the Impact
Wrench.
2. Plug the Impact Wrench power cord into an appropriate
power source.
3. Grasp the Impact Wrench handle with one hand and
the front housing of the Impact Wrench with the other
hand.
4. Place impact socket onto the fastener.
NOTE: Make sure the socket is fully engaged with the nut
to avoid potentially damaging the socket or the wheel
nut.
5. While holding the tool with a firm grasp, pull on the top
part of the forward/reverse switch.

6
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
Figure Description Qty.
1 Self-Tapping Screw ST4.9 x 50 4
2 Spring Washer 4
3 Washer 4
4 Front Housing 1
5 Washer 1
6 Bushing 1
7 Washer 1
8 Anvil 1
9 Ball 2
10 Impactor 1
11 Ball 19
12 Washer 1
13 Spring 1
14 Inner Shaft 1
15 Gear 1
16 Washer 1
17 Bushing 1
18 Washer 1
19 Washer 1
20 Double Connect Gear 1
21 Airproof Washer 1
22 Pin 1
23 Felt Seal 1
24 Bearing Seat 1
25 Washer 1
26 Spacer 1
Figure Description Qty.
27 Bearing 6000-2RS 1
28 Retaining Clip 1
29 Fan 1
30 Rotor Assembly 1
31 Bearing Sleeve 1
32 Magnetic Ring 1
33 Baffle Plate Rear 1
34 Pendulum Plate 1
35 Self-Tapping Screw ST3.9 x 70 2
36 Stator 1
37 Switch Assembly 2
38 Housing 1
39 Decorative Plate 4
40 Carbon Brush 1
41 Brush Holder 1
42 Carbon Brush Cap 2
43 Back Cover 1
44 Self-Tapping Screw ST3.9 x 20 4
45 Front Handle 1
46 Self-Tapping Screw ST3.9 x 20 3
47 Self-Tapping Screw ST3.9 x 14 2
48 Cord Clamp 1
49 Terminal Block 1
50 Cord 1
51 Cord Guard 1
PARTS DESCRIPTION
NOTE: Not all components of the Impact Wrench are replacement items, but are illustrated as a convenient
reference for location and position in the assembly sequence.

7
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
NOTES:

8
Operating Instructions and Parts Manual 24666
11/18
2018 OEMTOOLS™
1/2" DRIVE IMPACT WRENCH
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS™One Year Warranty
For up to one year from the date of purchase of this OEMTOOLS™product, if you find any defect in material or
workmanship (through normal usage), return it to the place of purchase or to OEMTOOLS™for repair or replacement at
our discretion. In order to obtain this service, send the product and proof of purchase (transportation pre-paid) to:
OEMTOOLS™Q.A. Dept, 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our
inspection verifies the defect, we will either repair or replace the product, or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you
must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS™reserves the right to make any changes in construction or design at
any time without any obligation in incorporating such changes to tools or equipment previously sold. OEMTOOLS™
makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original
purchaser that this product is free from defects in materials and workmanship for the period of one year from the
date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear or to
lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Don’t forget to register your new OEMTOOLS™ product at www.oem-tools.com.
