OEM Tools 24370 Service manual

UNPACKING
After unpacking unit, inspect
carefully for any damage that
may have occurred during transit.
Check for loose, missing, or
damaged parts. If any damage
is observed, a shipping damage
claim must be filed with carrier. Do
not use the OEM Portable Power
Source if broken, bent, cracked or
damaged parts (including labels)
are noted. Any Portable Power
Source that appears damaged in
any way, operates abnormally or is
missing parts should be removed
from service immediately. If you
suspect that the Portable Power
Source was subjected to shock
load (a load that was dropped
suddenly, unexpectedly, etc.)
immediately discontinue use until
it has been checked by a factory
authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions
could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
The following safety information is provided as guidelines to help you operate your Portable Power Source under
the safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety
or safe handling instructions are not known or not followed. The following safety instructions are to provide the
user with the information necessary for safe use and operation. Please read and retain these instructions for the
continued safe use of your service system. Failure to follow instructions listed below may result in serious injury.
In addition, make certain that anyone that uses the equipment understands and follows these safety instructions
as well.
Operating Instructions and Parts Manual 24370
03/16
2016 ©OEMTOOLS
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
WARNING

2
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
Thank you very much for choosing an OEMTOOLS
Product!
For future reference, please complete the owner’s
record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is
important that you read the entire manual to become
familiar with this product before you begin using it.
This machine is designed for certain applications only.
OEMTOOLS cannot be responsible for issues aris-
ing from modification. We strongly recommend this
machine is not modified and/or used for any ap-
plication other than that for which it was designed.
If you have any questions relative to a particular
application, DO NOT use the machine until you have
first contacted OEMTOOLS to determine if it can or
should be performed on the product.
For technical questions please call 1-866-458-2472.
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn
the tool’s applications and limitations, as well as,
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept
away from the work area. Never let a child handle
a tool without strict adult supervision.
4. Do not operate this tool if under the influence
of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should
be worn at all times when operating this tool.
Use ANSI approved safety glasses. Everyday
eyeglasses are NOT safety glasses. Dust mask,
non-skid safety shoes, hard hat or hearing
protection should be used in appropriate
conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-
ties, rings, bracelets or other jewelry may present a
potential hazard when operating this tool. Keep all
apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance
at all times when operating this tool.
8. Check for damage. Check your tool regularly. If
part of the tool is damaged it should be carefully
inspected to make sure that it can perform its
intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified
technician. Consult your dealer for advice.
9. Keep away from flammables. Do not attempt
to operate this tool near flammable materials
or combustibles. Failure to comply may cause
serious injury or death.
10. Store idle tools out of the reach of children and
untrained persons. Tools may be dangerous in the
hands of untrained users.
• Maintain tools with care.
• Keep tools dry and clean.
• Do not use a damaged tool. Tag damaged tools “Do
not use” until repaired.
• If damaged, have the tool serviced before using. Many
accidents are caused by poorly maintained tools.
• Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one tool may become hazardous when
used on another tool.
• Tool service must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified personnel could result in a risk of injury.
• When servicing a tool, use only identical replacement
parts. Use of unauthorized parts or failure to follow
maintenance instructions may create a risk of injury.
• Maintain a safe working environment. Keep the work
area well lit. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris. Do not use this
product in a damp or wet location.
• Maintain labels and nameplates on this product.
These carry important information. If unreadable or
missing, contact OEM for a replacement.
• Before use, read and understand all warnings, safety
precautions, and instructions as outlined in the
vehicle manufacturer’s service manual. It is beyond
the scope of this manual to properly describe the
correct procedure and test data for each vehicle.
• Always perform vehicle service in a properly ventilated
area. Never run an engine without proper ventilation
for its exhaust. Stop work and take necessary steps
03/16
2016 ©OEMTOOLS

3
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
to improve ventilation in the work area if you develop
momentary eye, nose, or throat irritation as this
indicates inadequate ventilation.
• Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. When working
near moving engine parts, wear snug fit clothing and
keep hands and fingers away from moving parts.
Keep hoses and tools clear of moving parts. Always
stay clear of moving engine parts. Hoses and tools
can be thrown through the air if not kept clear of
moving engine parts. The unexpected movement of
a vehicle can injure or kill. When working on vehicles
always set the parking brake or block the wheels.
• Avoid accidental fire and/or explosion. Do not smoke
near engine fuel and battery components.
• We believe the information contained herein to be
reliable. However, general technical information is
given by us without charge and the user shall employ
such information at his own discretion and risk. We
assume no responsibility for results or damages
incurred from the use of such information in whole
or in part. Always refer to specific instructions and
technical information supplied by manufacturer of
vehicle or any other item you intend to connect the
OEMTOOLS Portable Power Source to.
• The manufacturer declines any and all responsibility
for damage to vehicles or components if said damage
is the result of unskillful handling by the operator or of
failure to observe the basic safety rules set forth in the
instruction manual.
Read Rules for Safe Operation and Instructions Carefully
PERSONAL PRECAUTIONS AND
SAFETY
• Working in vicinity of a lead-acid battery is dangerous.
Batteries generate explosive gases during normal
battery operation. For this reason, it is of utmost
importance that each time before using your Portable
Power Source, you read this manual and follow the
instructions exactly.
WARNING: Wear complete eye protection and clothing
protection, when working with lead-acid batteries.
1. Use only attachments recommended or sold
by manufacturer. Use of non-recommended
attachments may result in fire, electric shock, or
injury.
2. Do not disassemble Portable Power Source. Take
it to a qualified professional when service or repair
is required. Incorrect reassembly may result in
electric shock or fire.
3. To reduce risk of electric shock, unplug charger
from outlet before attempting any maintenance or
cleaning.
4. Make sure someone is within range of your voice
or close enough to come to your aid when you
work with or near a lead-acid battery.
5. Have plenty of fresh water and soap nearby for
use if battery acid contacts skin, clothing, or eyes.
If battery acid contacts skin or clothing, wash
immediately with soap and water.
6. Avoid touching your eyes while working with a
battery. Acid particles (corrosion) may get into your
eyes! If acid enters your eye, immediately flood
eye with running cold water for at least 10 minutes.
Get medical attention immediately.
7. Remove all personal metal items such as rings,
bracelets, necklaces, and watches when working
with a lead-acid battery. A lead-acid battery can
produce a short-circuit current high enough to
weld a ring (or the like) to metal, causing a severe
burn.
8. Take care not to drop a metal tool or other metal
onto the battery. Metal may cause sparking or
short circuit the battery or another electrical
devise. Sparking may cause an explosion.
9. NEVER smoke or allow a spark or flame in
the vicinity of the battery or engine. Batteries
generate explosive gases!
GENERAL BATTERY SAFETY
• When connecting to a battery in the vehicle, take
care to determine which post is grounded. To reduce
risk of a spark near battery, follow these steps when
battery is installed in vehicle.
WARNING: A spark near a battery may cause battery
explosion.
1. Stay clear of fan blades, belts, pulleys, and other
parts that can cause injury.
2. Check polarity of battery posts. Battery case will
be marked by each post: POSITIVE (POS, P, +)
and NEGATIVE (NEG, N, -). NOTE: The positive
battery post usually has a larger diameter than the
negative post.
3. Determine which post of battery is ground
(connected) to chassis.
NOTE: The negative post is normally grounded.
03/16
2016 ©OEMTOOLS
WARNING

4
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
IMPORTANT SAFETY INSTRUCTIONS
The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are
factors which cannot be built into this product, but
must be supplied by the operator.
DISPOSAL
At the end of the useful life of the OEMTOOLS Portable
Power Source, dispose of the components according
to all state, federal, and local regulations.
PURPOSE
The OEMTOOLS Portable Power Source 24370 is a
power source that is pocket sized but powerful enough
to start a car, light duty truck, motorcycles, boat or ATV
many times and can also charge cell phones, tablets
and cameras.
1. Always make sure the blue plug of the jumper
cable is fully engaged in the jump start socket
before jump starting the vehicle. This can limit the
available power and may cause damage or melting
of the blue plug.
2. Always make sure jumper clamps are well
connected, check if the vehicle’s battery
connections are rusted or dirty and if necessary,
clean before jumping start the vehicle.
3. DO NOT attempt to jump start more than 3
times. Otherwise, it can damage the OEMTOOLS
Portable Power Source. If your vehicle will not
start, check for other problems
4. DO NOT connect the two clamps. Otherwise, it
may be dangerous!
5. DO NOT disassemble the OEMTOOLS Portable
Power Source. Otherwise, it may be dangerous!
• Charge only using the charger provided with the
OEMTOOLS Portable Power Source
• Under extreme conditions, battery leakage may occur.
Carefully wipe the liquid off using a cloth and avoid
skin contact when you notice liquid on the batteries.
In case of skin or eye contact, rinse immediately with
clean water and seek medical attention.
• Do not attempt to jump start Diesel Engines
03/16
2016 ©OEMTOOLS
Size 160*75*28mm
Weight 420g
Battery Capacity 44.4Wh
Output 5V=2A; 12V=10A;
Input 14V=1A
Full Charging
Time 3 Hours
Starting Current 200A
Peak Current 400A
Operating
Temperature -5°F ~ 140°F
PRODUCT SPECIFICATIONS
WARNING
OEMTOOLS Portable Power Source. Only a repair technician
may repair this unit.

5
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
03/16
2016 ©OEMTOOLS
Press the switch to
check the charge level
of the OEMTOOLS
Portable Power
Source
The indicator lights
will flash one by one
during charging.
Different number of
solid indicators show charge level of the OEMTOOLS
Portable Power Source. All indicators light up when
the charging is paused or completed.
OPERATING INSTRUCTIONS
The OEMTOOLS Portable Power Source Charging
Instructions:
1. Plug the home adaptor into the universal socket.
2. Connect 12V 1A input port of the OEMTOOLS
Portable Power Source to the other end of home
adapter
OR
3. Plug the car adaptor into the socket of cigarette
lighter.
4. Connect 12V 1A input port of the OEMTOOLS
Portable Power Source to the other end of car
adaptor.
JUMP START 12V GASOLINE VEHICLE
INSTRUCTIONS:
1. Make sure that the number of indicators is not less
than 3 bars
2. Connect POSITIVE (RED) clip from Portable Power
Source to POSITIVE (POS, P, +) ungrounded post
of battery. Connect NEGATIVE (BLACK) clip to
vehicle chassis or engine block away from battery.
Connect to a heavy gauge unpainted metal part of
the frame or engine block.
3. WARNING: Do not connect clip to carburetor,
fuel lines, or sheet metal body parts.
4. Attach clips to battery post and twist or rock
back and forth several times to make a good
connection. This helps to keep clips from slipping
off terminals and helps to reduce risk of sparking.
5. Plug the cord of jumper cable into the jump start
socket.
6. Start the vehicle.
7. When the vehicle is started, remove jumper
cable from the OEM Portable Power Source and
disconnect red and black clamps to the vehicle
battery terminals.
8. Leave the vehicle’s engine running.
CHARGING CELL PHONE OR TABLET
INSTRUCTION:
1. Plug the pigtail cable B into the USB 5V 2A output
port.
2. Select appropriate connector and connect it to
your mobile phones or tablet.
3. Press the switch button to charge.
FOR POWER SUPPLY TO 12V VEHICLE
ACCESSORIES OR 12V ELECTRONICS
1. Plug the optional pigtail cable to 12V 10A output
port.
2. Connect the optional pigtail cable and 12V vehicle
accessories or 12V electronics.
3. Press the switch button to power supply.
LED FLASH LIGHT
1. Press the switch 3 seconds to start the LED flash
light
Indicator Storage Level
Unlit 0%
5 Flashing 10%
1 Solid 20%
2 Solid 40%
3 Solid 60%
4 Slolid 80%
5 Solid 100%
INDICATOR

6
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
MAINTENANCE
Very little maintenance is required for the OEMTOOLS
Portable Power Source. Follow common sense in
wiping the charger clean and store in a clean, dry area.
1. After use, wipe all battery corrosion and other dirt
or oil from clip, cord, and the OEMTOOLS Portable
Power Source case. Use a dry cloth.
2. Coil charger cords to prevent damage.
3. Replace any cracked or frayed cords.
4. Store the OEMTOOLS Portable Power Source in a
clean, dry area.
Figure Description Quantity
APortable Power
Source Battery Unit 1
B5V-2A USB Port with
Pigtail Adapters 1
C Wall Charger 1
D Auto Charger 1
E Jumper Cables 1
F Durable Storage Case
(Not Shown)
1
(B)
5V-2A USB Port with
Pigtail Adapters
(A)
Portable Power
Source Battery Unit
(C)
Wall Charger
(D)
Auto Charger
(E)
Jumper Cables
Composition and amount of toxic and harmful substances in "The Tiny"
Portable Power Source
Pb Hg Cd Cr(Vi) PBB PBDE
000000
0: Indicate all homogeneous materials' hazardous substances content are
below the MCV limit specified in the Standard 2002/95/EC(RoHs).
TOXIC AND HARMFUL SUBTANCES:
Composion and amount of toxic and harmful substances in the
Mul-Use Portable Power Source with Jumper Cables
Finding
Cause
Remedies
TheOEMPortable
PowerSourceisstill
notfullchargedwhile
it's5indicatorlights
aresolid.
Chargermayauto
stopat60%if
batteryisverylow
topreventdamage
Unplugtheadaptorand
plugitinagain.
Noresponsewhen
pressingtheswitch
button.
LowVoltage
protectionofthe
OEMPortablePower
Source.
Plugtheadaptorintothe
12V1Ainputto
recharge.
TheOEMPortable
PowerSourceisahot
whenchargingfor
Notebook.
Thechargingcurrent
isahigh(3.5A)
Removethebatteryof
yourNotebookanduse
theOEMPortablePower
Sourcetosupplypower
directly,orsimply
disconnectand
reconnectonceithas
cooledtothetouch.

TROUBLE SHOOTING:
Low Voltage
protecon of the
OEMTOOLS Portable
Power Source
03/16
2016 ©OEMTOOLS

7
Operating Instructions and Parts Manual 24370
MULTI-USE PORTABLE POWER
SOURCE WITH JUMPER CABLES
OEMTOOLS™ 90 DAYS LIMITED WARRANTY
From 90 days from the original purchase of this product, OEMTOOLS will warranty this item. If you find any
defect in material or workmanship, through normal usage, return it to the place of purchase or to OEMTOOLS
for repair or replacement at our discretion. In order to obtain this service send your tool and proof of purchase,
transportation pre-paid, to OEMTOOLS Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118. We will not
be responsible for lost or damaged goods during transportation, please insure your package. If our inspection
verifies the defect, we will either repair or replace the product at our election, or we may elect to refund the
purchase price if we cannot readily and quickly provide you with a replacement. We will return repaired products
at our expense, but if we determine there is no defect, or that the defect resulted from causes not within the
scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS does not provide warranty for products labeled other than OEM or OEMTOOLS. OEMTOOLS will
not provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not limited to,
abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not
cover bits, blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or
replace blades, bits, files, and batteries as necessary. OEMTOOLS reserves the right to makes any changes in
construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold.
OEMTOOLS makes every effort to assure that its products meet high quality and durability standards, and
warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS
WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
03/16
2016 ©OEMTOOLS
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www[email protected]
