Offex GX-OF-5115 User manual

Lot Number:
Date Purchased:
Version: Jan./19
NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Japson Ladder Desk
Item # GX-OF-5115

Metal Frame (x 4)ADesktop (x 1)BLower Shelf (x 1)C
Upper Shelf (x 1)
DPartition Panel (x 2)E
Desktop Support (x 2)
G
Cross Metal Wire (x 1)
F
Read through instructions from beginning to end before starting to assemble the
Identify all parts and hardware.
PARTS CONTENTS

TABLE OF CONTENTS
Table of Contents ....................................................................................................................... 2
Part Contents .......................................................................................................................... 2
Hardware Contents .................................................................................................................... 3
Assembly Instructions ............................................................................................................... 4
Maximum Loads ....................................................................................................................... 8
Page 2

Adjustable Foot
Qty: 4
3
M6.3 x 40 mm Allen Head Screw
Qty: 12
Screws shown below are actual size.
M6 x 30 mm
Allen Head Mechanical Bolt
Qty: 8
Plastic Stopper
Qty: 4
12
4
M6 x 27 mm
Allen Head Mechanical Bolt
Qty: 4
5
Nut
Qty: 4
6
Cam Lock
Qty: 2
7
Allen Wrench
Qty: 1
10
Wrench
Qty: 1
11
Cam Bolt
Qty: 2
8
Cam Lock Cover
Qty: 2
9
12

HARDWARE CONTENTS
1 set of Anti-tip Devices
M4 x 40 mm
Flat Head Long Screw
Qty: 1
M4 x 13 mm
Flat Head Short Screw
Qty: 1 Metal Bracket
Qty: 1
Wall Anchor
Qty: 1
1. Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
2. When laying out furniture parts, place them on a clean, dry and soft surface to prevent
scratching.
3. Do not push furniture, especially on carpeted floor, have someone help you lift the item and
place it in its new location, remove any shelves before moving.
4. Do not place toys, food, etc. on the top of furniture items, a child may try to reach an item
of interest by climbing on furniture, causing accidents, damage or personal injury as a result
of the unit tipping over, door(s) closing on extremities or fall damage.
5. Make sure all bolts/screws are tightly fastened before the unit is used, check bolts/screws
periodically and tighten them if necessary.
SAFETY INFORMATION
Page 3

Actual Size
4x 4
10
Actual Size
4x 4
10
11
x 4
2
2
x 4
Step 2:
Hardware
Used:
Step 1:
Hardware
Used:
ASSEMBLY INSTRUCTIONS
10
4
Tighten Loosen
4
10
Tighten
Loosen
A x 2
B
B
A
A
G
Please keep these holes the
same flat on the metal frame.
Page 4

Actual Size
3
3
x 4
7
7
x 2
8x 2
9x 2
10
Actual Size
123
The arrow must
point toward the
edge of the board
2
Step 3:
Hardware
Used:
ASSEMBLY INSTRUCTIONS
Tighten Loosen
C
D
D
D
E
E
E
E
8
8
Arrow
3
10
9
9
Page 5

Actual Size Actual Size
3x 8
10
5x 4
66
x 4
10
11
11
Step 5:
Hardware
Used:
Step 4:
Hardware
Used:
ASSEMBLY INSTRUCTIONS
10
Tighten
Loosen
5
A
F
3
10
Tighten
Loosen
C
B
A
A
D
Page 6

12 Anti-tip
Devices
Long Screw
Short Screw
Short Screw
Long Screw
Metal Bracket
Metal
Bracket
Metal
Bracket
Wall Anchor
Step 6:
Hardware
Used:
ASSEMBLY INSTRUCTIONS
Actual Size
Actual Size
STUD
Warning
Children can be severely injured by tipping
furniture.
It is imperative that the tipping restraint
hardware be installed to prevent the unit
from tipping over, potentially causing injury
or even fatality.
1. Use the short screw install the metal
bracket on the reverse side of the lower
shelf (C), find the stud position and put the
unit against the stud. Use a pencil to mark
the holes by the metal bracket. Be careful
to avoid any studs, wires or anything else
behind the wall.
2. Use the electric drill with 3/16” (5 mm)
drill bit to drill holes to the wall.
3. Tap the wall anchor to the holes flush to
the wall.
4. Use the long screw cross the metal
bracket tighten into the wall anchor.
Assembly of the anti-tip device
STUD
STUD
12 3
4
Wall Anchor
C
B
Page 7

This unit has been designed to support the maximum loads as indicated below. Exceeding
those load limits may cause sagging, instability or even product collapse, which may cause
serious injury.
MAXIMUM LOADS - CARGA MAXIMA - CHARGES MAXIMALES
80 lbs. / 36.29 kg
20 lbs. / 9.07 kg
5 lbs.
2.27 kg
5 lbs.
2.27 kg
5 lbs.
2.27 kg
