DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
OleumTech® H Series Sensors
Differential Pressure Transmitters
Model Number: HDPTxxxx
User Guide
Document ID: 80-7119-001_C

Page 2
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
Table of Contents
1. PRODUCT INTRODUCTION ................................................................................. 3
2. PRODUCT DIMENSIONS / MOUNTING / INSTALLATION .................................. 15
3. HARDWARE OVERVIEW.................................................................................... 18
4. SAFETY, CERTIFICATIONS, COMPLIANCE.......................................................... 19
5. POWER ............................................................................................................. 23
6. WIRING DIAGRAMS .......................................................................................... 24
7. MODBUS RTU COMMUNICATIONS PROTOCOL ............................................... 27
8. LOCAL LCD DISPLAY INTERFACE - RS485 .......................................................... 29
9. LOCAL LCD DISPLAY INTERFACE – 1-5 V ........................................................... 33
10. LOCAL LCD DISPLAY INTERFACE – 4-20 mA/HART ....................................... 38
11. HART DEVICE CONNECTION......................................................................... 46
12. TROUBLESHOOTING..................................................................................... 47
13. MAINTENANCE............................................................................................. 49
14. LIMITED WARRANTY .................................................................................... 50
15. REVISION HISTORY....................................................................................... 51

Page 3
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
1. PRODUCT INTRODUCTION
1. Description
The OleumTech H Series Differential Pressure Transmitter is a high-
performance instrument utilizing the world's most advanced
monocrystalline silicon* pressure sensor and patented encapsulation
technology. The Differential Pressure “DP” Transmitter is designed for use
in rigorous industrial applications with robust resistance to chemical
exposures, mechanical loads, and EMI. The DP Transmitter is easy to
install and operate. It can be ordered with a variety of options to fit your
specific need.
The OleumTech H Series Differential Pressure Transmitter is a natural
choice for a wide variety of oil, gas, water, wastewater, and other mission-
critical applications that require high level of accuracy and reliability.
Adjustable span**:High accuracy and stability
Output Signal: 1-5 V, 4-20 mA, 4-20 mA/HART, RS485 (Modbus)
Process Temperature: Silicone Oil Filling: -40 to 120 °C (-40 to 248 °F)
Local Display Interface: Simple menu system along with built-in
configuration buttons allow you to configure the device in minutes.
Configure in hazardous areas without removing the transmitter cover using
externally isolated magnetic menu operation keys.
2. Main Parameters
*
*The span adjustability does not apply to the RS485 model since the reading output
is digital.
3. Approvals
Pressure Type
Differential Pressure
Measuring Range -435 to 1500 PSI (-12040 to 41520 inH2O)
Please refer to the ordering information
Output Signal
1-5 V, 4-20 mA, 4-20 mA + HART,
RS485 (Modbus)
Reference Accuracy
± 0.075 % URL
Adjustable Span TD ratio of up to 100:1 (accuracy not
affected at TD ratio of 10:1 and below)**

Page 4
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
4. Technical Specifications
a. Measuring Range and Limit
*All models support PV reversal (high side / low side) except for the 1500 PSI
model.
b. Standard Specifications and Reference Conditions
Test standard: IEC 60770; zero based-calibration span, linear output,
silicone oil filling, 316L stainless steel isolation diaphragm.
c. Performance Specifications
The overall performance including but not limited to reference
accuracy, environmental temperature affects and other
comprehensive error.
Accuracy: ± 0.075 % URL (± 0.05 % URL optional model)
Stability: ± 0.2 % URL/5 years
d. Reference Accuracy
Standard and reference conditions, including linearity (BFSL),
hysteresis and repeatability.
Calibration temperature: 20 °C ± 5 °C (68 °F ± 9 °F)
Linear output accuracy:
TD = Turndown Ratio
when URV ≥ LRV, TD = URL / URV
when URV ≤ LRV, TD = URL / LRV
URL = Upper Range Limit
URV = Upper Range Value
LRV = Lower Range Value
TD ≤ 10:1, ± 0.075% URL
With a turndown ratio equal to or less than 10:1, the accuracy is
0.075% of URL.
10:1 < TD ≤100:1, ± 0.0075% x TD URL
With a turndown ratio greater than 10:1 but equal to or less than
100:1, the accuracy is 0.0075% times the turndown of the URL.
The square root output accuracy is 1.5 times the linear output
accuracy.
Part
Number Nominal Value Smallest Cal. Span
Lower Range
Limit (LRL)
Upper Range
Limit (URL)
Static Pressure
Limit
Low Pressure Side
Overload Limit
High Pressure Side
Overload Limit
PSI
inH2O
PSI
inH2O
PSI
inH2O
PSI
inH2O
PSI
inH2O
PSI
inH2O
PSI
inH2O
HDPT0005 5 138 0.05 1.4 -5 -138 5 138 5800 160543 2320 64217 3625 100340
HDPT0030 30 830 0.3 8.3 -30 -830 30 830 5800 160543 2320 64217 3625 100340
HDPT0150 150 4152 1.5 41.5 -150 -4152 150 4152 5800 160543 2320 64217 3625 100340
HDPT0400 400 11072 4 110.7 -400 -11072 400 11072 5800 160543 2320 64217 3625 100340
HDPT1500* 1500 41520 15 415.2 -435 -12041 1500 41520 5800 160543 2320 64217 3625 100340

Page 5
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
e. Power Supply Effect
When power supply voltage is within the operating rating, zero and
span changes have less than ± 0.005 % of URL/V.
f. Mounting Position Effect
Installation error of less than 0.058 PSI (400 Pa) can be corrected by
PV = 0 reset.
g. Vibration Effects
Per IEC 61298-3 tests, < 0.1% URL
h. Ambient Temperature Effects
Within the range of -20 to 80 °C (-4 to 185 °F):
± (0.1 + 0.1 TD) % URL Accuracy °C
i. Static Pressure Effects
Effect on zero: ± 0.15 TD % URL / 1450 PSI (10 MPa)
Effect on full scale: ± 0.2 % URL / 1450 PSI (10 MPa)
j. Insulation Resistance
≥20 MΩ @, 100 Vdc
k. Damping Time
Total damping time constant: equal to the sum of damping time of
amplifier and sensor capsule
Damping time of amplifier: 0-100 S adjustable
Diaphragm capsule (isolated diaphragm and silicone oil filling)
damping time: ≤ 0.2 S
Startup after power off: ≤ 6 S
Normal services after data recovery: ≤ 31 S
l. Output Signal
Two wire 4-20 mA output with digital communications, linear or
square root output programmable, HART protocol is superimposed on
the 4-20mA signal.
m. Surge Protection
The transmitter has been tested to withstand a transient surge up to
2000 V (common mode) or 1000 V (normal mode) without damage
(Per IEC Std. 61000-4-5).
n. Weight
Net: 8.5 lbs. (3.9 kg) / Gross: 9.5 lbs. (4.3 kg)

Page 6
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
o. 4-20 mA Power Supply Voltage vs Loop Resistance
p. HART Multi-drop Minimum Power Supply Voltage
V min = 15.5 Vdc + 0.004 x N devices x (250 + Rloop)
Example: four devices with round loop resistance 20 ohm
V min = 15.5 + 0.004 x 4 x 270 = 14.82 Vdc
q. Power Supply and Load Requirements
r. Environmental Conditions
Items
Operational condition
Working
temperature
-40 to 85
℃(-40 to 185
°
F)
, integrated
LCD display: -20 to 70
℃(-4 to 158
°
F)
Storage
temperature
-40 to 110 ℃(-40 to 230 °F), integrated
LCD display: -40 to 85 ℃(-40 to 185 °F)
Media
temperature
Silicone oil filling: -40 to 120 ℃(-40 to
248 °F)
Working humidity
5-100 % RH @40
℃
Protection class
IP66
Hazardous
location
ExiaIICT4 or ExdIICT6
R
(Ω) External load resistance
R=U-10.5
0.021
600
Digital
communication
range
HART
0
10 . 5 16 . 5 23 . 8
55 Power supply

Page 7
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
s. EMC Environment
NO.
Test Items
Basic Standards
Test Conditions
Performance Level
1
Radiated interference
CISPR22
30 MHz - 1000 MHz
OK
2
Conducted interference (DC power port)
CISPR22
0.15 MHz - 30 MHz
OK
3
Electrostatic discharge immunity test (ESD)
I E C 61000 - 4 - 2
4 kV (Contact), 8 kV (Air)
B(Note2)
4
Immunity to radio frequency EM-fields
I E C 61000 - 4 - 3
1 0V / m ( 80 M H z to 1 G H z )
A(Note1)
5
Power frequency magnetic field Immunity test
I E C 61000 - 4 - 8
30A/m
A(Note1)
6
Electrical fast transient / Burst Immunity Test
I E C 61000 - 4 - 4
2 k V ( 5 / 50 n s , 1 00 k H z )
B(Note2)
7
Surge immunity requirements
I E C 61000 - 4 - 5
1 kV (Line to line) 2 kV (Line to
ground)
(1 . 2 u s / 50 u s )
B(Note2)
8
Immunity to conducted disturbances induced by
radio frequency fields
I E C 61000 - 4 - 6
3 V (150 kHz to 80 MHz)
A(Note1)
(Note 1) Performance level A: The performance within the limits of normal technical specifications.
(Note 2) Performance level B: Temporary reduction or loss of functionality or performance, it can restore itself.
The actual
operating conditions, storage and data will not be changed.

Page 8
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
5. Menu Functions
a. Output Type
Output Signal
1-5 V
4-20 mA
4-20 mA + HART
RS485 (Modbus)
b. LCD Display Unit
Display
mode
Details
PV
Process variable shows on main screen,
percentage and progress bar shows on main
screen
mA*
Current shows on main screen, percentage and
progress bar shows on main screen
%*
Percentage shows on main screen, percentage
and progress bar shows on main screen
Voltage
Voltage shows on main screen. Applicable only to
the DC model.
*Not applicable on the RS485 model.
c. Measuring Menu
Mark
State
URV
Upper range value, 20 mA
LRV
Lower range value, 4 mA
d. Damping Time
Units
Setting Range
S
0-100 Seconds
e. Unit
f. Analog Output Type***
***Applies only to 4-20 mA + HART models.
Unit
Definition
kPa
Kilopascal
MPa
Megapascals
BAR
BAR
PSI
Pounds per square inch
mmHg
Millimeter of mercury @ 0 ℃
mmH2O
Millimeter of water @ 4 ℃
mH2O
Meter of water @ 4 ℃
INH2O
Inches of water @ 4 ℃
FTH2O
Feet of water @ 4 ℃
INHg
Inches of mercury @ 0 ℃
mHg
Meter mercury column @ 0 ℃
TORR
Torr
mBAR
Millibar
g/cm2
Gram per square centimeter
kg/cm2
Kilogram per square centimeter
Pa
Pascal
ATM
Standard atmospheric pressure
OSI
Ounce per square inch
mm
Millimeter (Note1)
m
Meter (Note1)
Note1: Length unit need mark medium density
Parameters
Output Type
mA LINER
Linearity (default)
mA √
Square Root

Page 9
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
g. Alarm Signal
Parameters
Alarm Signal
ALARM NO
None
ALARM H
20.8 mA
ALARM L
3.8 mA
h. Fixed Output
Parameters
Fixed Output Value
FIX/C NO
None
3.8000
3.8000 mA
4.0000
4.0000 mA
8.0000
8.0000 mA
12.000
12.000 mA
16.000
16.000 mA
20.000
20.000 mA
20.800
20.800 mA
i. Quick Menu
Parameter
Instruction
PV = 0
Set current output to zero value,
used to correct the error caused
by static pressure and
installation.
Zero adjustment
4 mA re-range with pressure
Span adjustment
20 mA re-range with pressure
Restore factory setting Restore backup data when error

Page 10
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
6. Product Selection Guide
a. Ordering Information

Page 11
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
b. Sensor Selection Table
Code
Nominal
Value
Description
HDPT0005
5 PSI (138 inH2O)
Range -5 to 5 PSI (-138 to 138 inH2O),
smallest calibratable span 0.05 PSI
HDPT0030
30 PSI (830 inH2O)
Range -30 to 30 PSI (-830 to 830 inH2O),
smallest calibratable span 0.3 PSI
HDPT0150
150 PSI (4152 inH2O)
Range -150 to 150 PSI (-4152 to 4152
inH2O),
HDPT0400
400 PSI (11072 inH2O)
Range -400 to 400 PSI (-11072 to 11072
inH2O), smallest calibratable span 4 PSI
HDPT1500
1500 PSI (41520 inH2O)
Range -435 to 1500 PSI (-12041 to 41520
inH2O), smallest calibratable span 15 PSI
c. Diaphragm
d. Sensor Filling Fluid and Sensor Seal
e. Housing Type
Aluminum-alloy terminal, 2 cable entry 1/2” NPT (F), 1 plug included
Code
Items
Description
H
Diaphragm
material
Hastelloy C
S
316L SS
Code
Items
Description
D
Fluid filling
Inert Oil Filling: -45 to 160 °C
(-49 to 320 °F)
S
Silicone Oil Filling: -45 to 205 °C
(-49 to 401 °F)
P
Sensor seal
FKM -20 to 200 °C
(-4 to 392 °F)

Page 12
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
f. Output Type
g. Display Option
Code
Items
Description
D
Output
signal
1-5 V
F
4-20 mA two-wire
H
4-20 mA + HART two-wire
R
RS485 MODBUS
Code
Items
Description
A
Display
Without display
C
With LCD display (Backlit LCD type)

Page 13
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
h. Flange Options (Process Connection), 1/4”-18 NPT(F) 316 SS
i. Wet Parts
H1
Drain valve on rear end
of flange
H2
Drain valve on upper end
of flange
H3
Drain valve on down end
of flange

Page 14
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
j. Optional Mounting Kit
Wall or 2” Pipe Mounting Kit, includes bracket and hardware
(Part # SX1000-MK10)
Dimensions:
4.1” (W) x 4.6” (H) x 3.9” (D) / 10.4 cm(W) x 11.6 cm (H) x 9.8 cm (D)
Provided DP Transmitter mounting bolt size: M10
Provided wall mounting bolt size: M8
Provided U-Bolt: Heavy duty exhaust clamp with 2.5” U-Bolt

Page 15
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
2. PRODUCT DIMENSIONS / MOUNTING / INSTALLATION
a. Drawings and Dimensions of HDPTxxxx (inches / mm).

Page 16
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
b. Wall or 2” Pipe Mounting Kit (inches / mm).
Part number: SX1000-MK10
c. Housing Rotation
To improve field wiring access or provide better viewing of the LCD
display, the housing and sensor can be slightly rotated from each
other.
1. Use a 3 mm hex wrench to loosen the set screw to rotate the
housing.
2. Do not rotate the housing by more than 90° max (1/4 turn
only)to the left or right from its original position.
3. Over-rotating can damage the transmitter. A loose housing to
sensor connection may cause water ingress issues.
4. Must tighten the set screw after making the adjustment.

Page 17
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
d. Straight Threaded Connection
Picture 1: The length of pressure transmitter thread should be longer
than the depth of the thread to ensure an effective seal with the head
gasket.
Picture 2: The length of pressure transmitter thread should be shorter
than the depth of the thread to ensure an effective seal with the root
gasket.
e. Cable Protection Conduit
When using Explosion-proof pressure transmitters in hazardous
locations, a metal Explosion-proof conduit should be used to connect
the cable into the threading box, and lead to a non-hazardous
location.
WARNING: Do not open when an explosive atmosphere is present.
WARNING: A seal shall be installed withing 50 mm of the enclosure.
f. Zero Point Calibration
•Perform the calibration after completing the installation because the
mounting position will affect the zero setting.
•The transmitter must be isolated from the process.
•No pressure or medium on the measuring diaphragm, the system is
under atmospheric conditions.
•Power connection please refer to Local LCD Display Interface sections.
•Please set PV=0 after three weeks of installation to ensure the best
accuracy
•Set PV=0 at least once a year.

Page 18
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
3. HARDWARE OVERVIEW
1. Enclosure
All housing entries MUST be tightly SEALED using thread seal tape or
sealant. Failure to seal all port entries may allow moisture to enter the
transmitter housing, cause damage to internal components, and void
warranty.
All housing covers MUST be tightly fastened to protect against external
environmental elements.
Check the housing cover O-ring(s) every time the access cover is removed.
- Apply lubricant if the O-ring is dry.
- Replace the O-ring when it is damaged, discolored, or showing
signs of wear.
- The O-ring should be seated firmly on the bottom of threads
without stretching to fit or without bulging.

Page 19
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
4. SAFETY, CERTIFICATIONS, COMPLIANCE
1. Safety
CAUTION: Ensure installation of the transmitter meets applicable state and
National Electrical Code requirements. The installation of the transmitter
should only be performed by a qualified installer or a factory
representative.
WARNING: The pressure transmitter is powered by an external power
supply. The power supply circuit must comply with energy-limiting circuit
by relevant standards and pay attention to the high voltage circuits that
may exist.
WARNING: Do not exceed the maximum static pressure rating of the
sensor.
WARNING: Using the pressure transmitter in hazardous areas, installation,
use and maintenance must also comply with the operation manual and
relevant requirements of national standards.
WARNING: Disassemble the pressure transmitter only at normal
atmospheric pressure.
WARNING: EXPLOSION HAZARD – THIS DEVICE SHALL BE REMOVED
FROM THE AREA KNOWN TO BE HAZARDOUS IF MAINTENANCE IS
REQUIRED.
WARNING: To prevent static discharge, wipe with damp cloth only.
WARNING: Although the transmitter is very durable, do not install it on
high vibration applications or where transmitter is subject to severe
mechanical shock.
WARNING: If the equipment is used in a manner not specified by
OleumTech, the protection provided by the equipment may be impaired.
WARNING: Safety of any system incorporating the transmitter is the
responsibility of the assembler of the system.
WARNING: Do not open when an explosive atmosphere is present.
WARNING: A seal shall be installed withing 50 mm of the enclosure.

Page 20
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
Sécurité
MISE EN GARDE: Veiller à l'installation de la passerelle répond Etat et des
exigences nationales de code de l'électricité. L'installation de la transmitter
ne doit être effectuée par un installateur qualifié ou un représentant de
l'usine.
AVERTISSEMENT: le transmetteur de pression est alimenté par une
alimentation externe, le circuit d'alimentation doit être conforme au circuit
de limitation d'énergie selon les normes applicables et faire attention aux
circuits haute tension qui peuvent exister.
AVERTISSEMENT: Ne dépassez pas la pression nominale maximale du
capteur.
AVERTISSEMENT: L'utilisation du transmetteur de pression dans des zones
dangereuses, l'installation, l'utilisation et la maintenance doivent
également être conformes au manuel d'utilisation et aux exigences
pertinentes des normes nationales.
AVERTISSEMENT: ne démontez le transmetteur de pression qu'à la
pression atmosphérique normale.
AVERTISSEMENT: RISQUE D'EXPLOSION - CET APPAREIL DOIT ÊTRE RETIRÉ
DE LA ZONE CONNUE POUR ÊTRE DANGEREUSE SI L'ENTRETIEN EST
NÉCESSAIRE.
AVERTISSEMENT: pour éviter les décharges d'électricité statique, essuyez
uniquement avec un chiffon humide.
AVERTISSEMENT: bien que le transmetteur soit très durable, ne l'installez
pas sur des applications à fortes vibrations ou là où le transmetteur est
soumis à de graves chocs mécaniques.
AVERTISSEMENT: si l'équipement est utilisé d'une manière non spécifiée
par OleumTech, la protection fournie par l'équipement peut être altérée.
AVERTISSEMENT: La sécurité de tout système intégrant l'émetteur est de
la responsabilité de l'assembleur du système.
AVERTISSEMENT: ne pas ouvrir en présence d'une atmosphère explosive.
AVERTISSEMENT: Un joint doit être installé à 50 mm du boîtier.
