OLIMEX OLinuXino-MAXI User manual

OLinuXino-MAXI
single-board Linux computer
USER’S MANUAL
Initial release, May 2012
Designed by OLIMEX Ltd, 2012
All boards produced by Olimex LTD are ROHS compliant

OLIMEX© 01 OLinuXino User's Manual
Disclaimer:
© 01 Olimex Ltd. Olimex®, logo and combinations thereof, are registered trademarks of Olimex Ltd.
Other terms and product names may be trademarks of others.
The information in this document is rovided in connection with Olimex roducts. No license, ex ress
or im lied or otherwise, to any intellectual ro erty right is granted by this document or in connection
with the sale of Olimex roducts.
The Hardware project is released under the Creative Commons Attribution-Share Alike 3.0 United States
License. You may reproduce it for both your own personal use, and for commertial use. You will have to
provide a link to the original creator of the project http://www.olimex.com on any documentation or website.
You may also modify the files, but you must then release them as well under the same terms. Credit can be
attributed through a link to the creator website: http://www.olimex.com
The software is released under GPL.
It is possible that the pictures in this manual differ from the latest revision of the board.
The product described in this document is subject to continuous development and improvements. All
particulars of the product and its use contained in this document are given by OLIMEX in good faith.
However all warranties implied or expressed including but not limited to implied warranties of
merchantability or fitness for purpose are excluded. This document is intended only to assist the reader in the
use of the product. OLIMEX Ltd. shall not be liable for any loss or damage arising from the use of any
information in this document or any error or omission in such information or any incorrect use of the
product.
This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation
purposes only and is not considered by OLIMEX to be a finished end-product fit for general consumer use.
Persons handling the product must have electronics training and observe good engineering practice
standards. As such, the goods being provided are not intended to be complete in terms of required design-,
marketing-, and/or manufacturing-related protective considerations, including product safety and
environmental measures typically found in end products that incorporate such semiconductor components or
circuit boards.
Olimex currently deals with a variety of customers for products, and therefore our arrangement with the user
is not exclusive. Olimex assumes no liability for applications assistance, customer product design, software
performance, or infringement of patents or services described herein.
THERE IS NO WARRANTY FOR THE DESIGN MATERIALS AND THE
COMPONENTS USED TO CREATE OLINUXINO. THEY ARE CONSIDERED
SUITABLE ONLY FOR OLINUXINO.
Page of 44

OLIMEX© 01 OLinuXino User's Manual
Table of Contents
HAPTER 1.................................................................................................................5
OVERVIEW.................................................................................................................5
1. Introduction to the cha ter.......................................................................................................5
1.1 Features.....................................................................................................................................5
1.2 The OLinuXino family............................................................................................................6
1.2 Target market and ur ose of the board..............................................................................6
1.3 Organization.............................................................................................................................6
HAPTER 2 ................................................................................................................8
SETTING UP THE OLINUXINO BOARD..............................................................8
2. Introduction to the cha ter.......................................................................................................8
2.1 Electrostatic warning...............................................................................................................8
2.3 Requirements...........................................................................................................................8
2.4 Powering the board..................................................................................................................9
2.5 Prebuilt software......................................................................................................................9
HAPTER 3...............................................................................................................11
OLINUXINO BOARD DES RIPTION..................................................................11
3. Introduction to the cha ter.....................................................................................................11
3.1 Layout (to view)...................................................................................................................11
HAPTER 4...............................................................................................................12
THE iMX233 MI RO ONTROLLER..................................................................12
4. Introduction to the cha ter.....................................................................................................12
4.1 The microcontroller...............................................................................................................12
HAPTER 5 ..............................................................................................................16
ONTROL IR UITY AND HARDWARE MODULES.....................................16
5. Introduction to the cha ter.....................................................................................................16
5.1 Reset........................................................................................................................................16
5.2 Clocks......................................................................................................................................16
5.3 Power su ly circuit..............................................................................................................17
HAPTER 6...............................................................................................................19
ONNE TORS AND PINOUT...............................................................................19
6. Introduction to the cha ter.....................................................................................................19
6.1 Debugging interfaces.............................................................................................................19
6.1.1 UART debug........................................................................................................................20
6.1.2 SJTAG debug......................................................................................................................20
6.1.3 Classic JTAG debug...........................................................................................................21
Page 3 of 44

OLIMEX© 01 OLinuXino User's Manual
6.2 SD/MMC slot..........................................................................................................................23
6.3 UEXT module.........................................................................................................................24
6.4 GPIO (General Pur ose In ut/Out ut) 40 in connector .................................................25
6.5 USB HOSTs............................................................................................................................28
6.6 LAN connector.......................................................................................................................29
6.7 PWR Jack...............................................................................................................................30
6.8 Head hones and line-in connector.......................................................................................30
6.9 Battery connector...................................................................................................................31
6.10 Com osite video connector.................................................................................................32
6.11 Boot mode ositions.............................................................................................................32
6.12 Jum er descri tion..............................................................................................................34
6.12.1 SCL_SW/SCL_HW and SDA_SW/SDA_HW................................................................34
6.12.2 5V_E...................................................................................................................................34
6.12.3 3.3V_E and 3.3VIO_E jum ers.......................................................................................34
6.12.4 Boot mode selecting jum ers...........................................................................................35
6.13 Additional hardware com onents......................................................................................35
HAPTER 7...............................................................................................................36
BLO K DIAGRAM AND MEMORY....................................................................36
7. Introduction to the cha ter.....................................................................................................36
7.1 Memory addresses.................................................................................................................36
7.2 Processor block diagram.......................................................................................................37
7.3 Physical memory ma ...........................................................................................................38
HAPTER 8...............................................................................................................39
S HEMATI S...........................................................................................................39
8. Introduction to the cha ter.....................................................................................................39
8.1 Eagle schematic......................................................................................................................39
8.2 Physical dimensions...............................................................................................................41
HAPTER 9...............................................................................................................42
REVISION HISTORY AND SUPPORT.................................................................42
9. Introduction to the cha ter.....................................................................................................42
9.1 Document revision.................................................................................................................42
9.2 Useful web links and urchase codes...................................................................................43
9.3 Product su ort.....................................................................................................................44
Page 4 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 1
OVERVIEW
1. Introduction to the chapter
Thank you for choosing the OLinuXino single board computer from Olimex! This document
provides a user’s guide for the Olimex OLinuXino board. As an overview, this chapter gives the
scope of this document and lists the board’s features. The differences between the members of the
OLinuXino family are mentioned. The document’s organization is then detailed.
The OLinuXino development board enables code development of applications running on the
microcontroller i.MX 33, manufactured by FreeScale Semiconductor.
1.1 Features
•iMX 33 ARM9 6J processor at 454Mhz
•64 MB RAM
•SD-card connector for booting the Linux image
•TV PAL/NTSC video output
• USB High Speed Hosts
•Ethernet 100 Mbit
•Stereo Audio Input
•Stereo Headphones Audio Output
•Two Buttons
•UEXT connector for connection of different peripherial modules
•40 pin GPIO for connection to external hardware
•Board is in the proper shape and dimensions to fit inside Pactec JM4 plastic box
http://www.pactecenclosures.com/pdfs/drw_JM-4 .pdf
•PCB dimensions: 3.70'' x .15'' W x H (94.0mm x 54.6mm)
•Nominal dimensions: 3.70'' x .65'' W x H (94.0mm x 67.3mm)
Page 5 of 44

OLIMEX© 01 OLinuXino User's Manual
1.2 The OLinuXino family
Table of comparison
OLinuXino-MICRO OLinuXino-MINI OLinuXino-MAXI
Processor iMX233 @ 4 4Mhz iMX233 @ 4 4Mhz iMX233 @ 4 4Mhz
Ram [MB] 64 64 64
# USB hosts 1 3 2
100 Mbit Ethernet No No/WIFI option* Yes
GPIO connector 60pins 40pins 40pins
# Buttons 3 2 2
Reset button Yes Yes Yes
DC power supply V V-16V V-16V
Dimensions 3.40'' x 1.70'' 3.70'' x 2.6 '' 3.70'' x 2.6 ''
Breadboarding Yes No No
The mini has a connector for WIFI modem connect. For more info visit the OLinuXino-MINI web
page.
1.2 Target market and purpose of the board
OLinuXino is a ready to use, easy to setup board suitable for embedded programming enthusiasts,
Linux hobbyists, gadget fans and also professionals (since its low cost makes it very good solution
for application orientated embedded systems). The main usage of the board is software embedded
development without the urge of understanding perfectly the hardware.
The strong points of the board are the processor speed, the mobility of the board and the low price.
1.3 Organization
Each section in this document covers a separate topic, organized as follow:
–Chapter 1 is an overview of the board usage and features
–Chapter provides a guide for quickly setting up the board
–Chapter 3 contains the general board diagram and layout
–Chapter 4 describes the component that is the heart of the board: the iMX 33
Page 6 of 44

OLIMEX© 01 OLinuXino User's Manual
microcontroller
–Chapter 5 is an explanation of the control circuitry associated with the microcontroller to
reset. Also shows the clocks on the board
–Chapter 6 covers the connector pinout, peripherals and jumper description
–Chapter 7 shows the memory map
–Chapter 8 provides the schematics
–Chapter 9 contains the revision history, useful links and support information
Page 7 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 2
SETTING UP THE OLINUXINO BOARD
2. Introduction to the chapter
This section helps you set up the OLinuXino development board for the first time.
Please consider first the electrostatic warning to avoid damaging the board, then discover the
hardware and software required to operate the board.
The procedure to power up the board is given, and a description of the default board behavior is
detailed.
2.1 Electrostatic warning
OLinuXino is shipped in a protective anti-static package. The board must not be exposed to high
electrostatic potentials. A grounding strap or similar protective device should be worn when
handling the board. Avoid touching the component pins or any other metallic element.
2.3 Requirements
In order to set up the OLinuXino optimally, the following items are required:
- 6V to 16V source of power with 1A maximum amperage.
- SWD interface programmer
- USB keyboard
- Monitor with composite interface or Personal Computer + USB-SERIAL-CABLE
- SD card with Linux image
Note that the board arrives without SD card or Linux image. You can purchase a card with Linux
separately. It is recommended that the user has basic Linux experience.
Some of the suggested items can be purchased by Olimex, for instance:
iMX233-OLinuXino-SD - SD card with the Linux image
USB-SERIAL-CABLE - USB serial console cable
SY0612E - power supply adapter 1 V/0.5A for iMX 33-OLinuXino-Maxi
Page 8 of 44

OLIMEX© 01 OLinuXino User's Manual
2.4 Powering the board
The board is powered either via the PWR jack or via a battery. It should be supplied from a 6V to
16V source with maximum current of 1A from the power jack.
If measuring the current consumption it should be around 0.06A before initializing all the
peripherals. The consumption raises to 0.1 A without LAN and USB hosts initialized and Linux
running. The consumption goes up 0.15A with the Linux running when LAN and both USB hosts
initialized.
If you have a standard USB flash drive attached to a USB host, Linux and LAN running the typical
consumption is around 0. 0A.
When powered by the typical 3.7V battery the LAN and USB-hosts are disabled. The consumption
when Linux is running is around 0.75A.
When you ower the board by battery you have to ress the PWR_BUT to start the board.
If you start Linux and it is already running no matter which owering method you use
(PWR_JACK or BAT) ressing the PWR_BUT will lead the Linux to ower save mode.
For the European customers we sell a power supply adapter 1 V/0.5A - SY0612E.
2.5 Prebuilt software
Note that the boards arrive without Linux or SD card. The Linux image can be urchased
se arately on a SD card or you can built and write it yourself.
When we program the boards we change the default position of the following HW_OCOTP_ROM0
fuses of the processor:
SD_MBR_BOOT(3) - Blown
SD_POWER_GATE_GPIO( 1: 0) – 10-PWM3
For burning the fuse position we use the BitBurner software.
The Linux image is created and downloaded from https://github.com/Freescale/fsl-community-bsp-
platform. There is explanation how to make the image from the latest sources on the github. Further
Page 9 of 44

OLIMEX© 01 OLinuXino User's Manual
instructions on how the Linux image can be created will be added to this guide at a later time.
To ensure you have the latest Linux version supported with all the updates visit
https://github.com/OLIMEX/OLINUXINO and https://github.com/Freescale/fsl-community-bsp-
platform.
Page 10 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 3
OLINUXINO BOARD DES RIPTION
3. Introduction to the chapter
Here you get acquainted with the main parts of the board. Note the names used on the board differ
from the names used to describe them. For the actual names check the OLinuXino board itself.
3.1 Layout (top view)
Page 11 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 4
THE iMX233 MI RO ONTROLLER
4. Introduction to the chapter
In this chapter is located the information about the heart of OLinuXino – its microcontroller. The
information is a modified version of the datasheet provided by its manufacturers.
4.1 The microcontroller
ARM9 6 CPU Running at 454 MHz
Integrated ARM9 6EJ-S CP
16-Kbyte data cache and 16-Kbyte instruction cache
— One-wire JTAG interface
— Resistor-less boot mode selection using integrated OTP values
3 Kbytes of Integrated Low-Power On-Chip RAM
64 Kbytes of Integrated Mask-Programmable On-Chip ROM
1 Kbit of On-Chip One-Time-Programmable (OCOTP) ROM
Universal Serial Bus (USB) High-Speed (Up to 480 Mb/s), Full-Speed (Up to 1 Mb/s)
— Full-speed/high-speed USB device and host functions
— Fully integrated full-speed/high-speed Physical Layer Protocol (PHY)
— Mass storage host-capable (uncertified by USB-IF)
Power Management Unit
— Single inductor DC-DC switched converter with multi-channel output supporting Li-Ion
batteries.
— Features multi-channel outputs for VDDIO (3.3 V), VDDD (1. V), VDDA (1.8 V),
VDDM ( .5V) and regulated 4. V source.
— Direct power from 5-V source (USB, wall power, or other source), with programmable
current limits for load and battery charge circuits.
— Silicon speed and temperature sensors enable adaptive power management over
temperature and silicon process.
Audio Codec
— Stereo headphone DAC with 99 dB SNR
— Stereo ADC with 85 dB SNR
— Stereo headphone amplifier with short-circuit protection and direct drive to eliminate
bulky capacitors
Page 1 of 44

OLIMEX© 01 OLinuXino User's Manual
— Amplifiers are designed for click/pop free operation.
— Two stereo line inputs
— Microphone input
— SPDIF digital out
16-Channel Low-Resolution ADC
— 6 independent channels and 10 dedicated channels
— Resistive touchscreen controller
— Temperature sensor controller
— Absolute accuracy of 1.3%
— Up to 0.5% with bandgap calibration
Security Features
— Read-only unique ID for digital rights management algorithms
— Secure boot using 1 8-bit AES hardware decryption
— SHA-1 hashing hardware
— Customer-programmed (OTP) 1 8 bit AES key is never visible to software.
External Memory Interface (EMI)
— Provides memory-mapped (load/store) access to external memories
— Supports the following types DRAM:
– 1.8V Mobile DDR
– Standard .5V DDR1
Wide Assortment of External Media Interfaces
— Up to four NAND flash memories with hardware management of device interleaving
— High-speed MMC, secure digital (SD)
— Hardware Reed-Solomon Error Correction Code (ECC) engine offers industry-leading
protection and performance for NANDs.
— Hardware BCH ECC engine allowing for up to 0-bit correction and programmable
redundant area.
Dual Peripheral Bus Bridges with 18 DMA Channels
— Multiple peripheral clock domains save power while optimizing performance.
— Direct Memory Access (DMA) with sophisticated linked DMA command architecture
saves power and off-loads the CPU.
Highly Flexible Display Controller
— Up to 4-bit RGB (DOTCK) modes
— Up to 4-bit system-mode including VSYNC and WSYNC modes.
— Up to VGA (640x480) resolution at 60Hz LCD panel support
— 8-bit data ITU-R BT.656 D1 digital video stream output mode (PAL/NTSC), with onthe-
fly RGB to YCbCr color-space-conversion.
— Flexible input formats
Page 13 of 44

OLIMEX© 01 OLinuXino User's Manual
Pixel Processing Pipeline (PXP)
— Provides full path from color-space conversion, scaling, alpha-blending to rotation
without intermediate memory access
— Bi-linear scaling algorithm with cropping and letterboxing
— Alpha-blend, BITBLT, color-keying
— Memory efficient block-based rotation engine
— Supports up to eight overlays
Integrated TV-Out Support
— Integrated PAL/NTSC TV-encoder fully pipelined to display controller’s D1 resolution
output stream
— Integrated low-power 10-bit Video DAC (VDAC) for composite analog video output.
Data Co-Processor (DCP)
— AES 1 8-bit encryption/decryption
— SHA-1 hashing
— High-speed memory copy
Three Universal Asynchronous Receiver-Transmitters (UARTs)
— Two high-speed application UARTs operating up to 3. 5 Mb/s with hardware flow
control and dual DMA.
— Debug UART operates at up to 115Kb/s using programmed I/O.
I C Master/Slave
— DMA control of an entire EEPROM or other device read/write transaction without CPU
intervention
Dual Synchronous Serial Ports (for SPI, MMC, SDIO, Triflash)
— Up to 5 MHz external SSP clock for all modes, including SPI
— 1-bit, 4-bit and 8-bit MMC/SD/SDIO modes
— Compliant with SDIO Rev. .0
— SPI with single, dual and quad modes.
Four-Channel 16-Bit Timer with Rotary Decoder
Five-Channel Pulse Width Modulator (PWM)
Real-Time Clock
— Alarm clock can turn the system on.
— Uses the existing 4-MHz XTAL for low cost or optional low power crystal (3 .768 kHz
or 3 .0 kHz), customer-selectable via OTP.
SPDIF Transmitter
Dual Serial Audio Interface (SAIF), Three Stereo Pairs
— Full-duplex stereo transmit and stereo receive operations
— Cell phone baseband processor connection and external ADCs and DACs
— Bluetooth hands-free connection
Page 14 of 44

OLIMEX© 01 OLinuXino User's Manual
— Analog I/O for peripheral bus breakouts
— I2S, left-justified, right-justified, and non-standard formats
Customer-Programmable One-Time-Programmable (OTP) ROM via Integrated eFuse Block
— Resistor-less boot mode selection
— 1 8-bit boot mode crypto key
— Boot mode specification of NAND characteristics for device that the customer is
soldering to the board. This means no more costly delays waiting for new device support in t
he boot ROM.
— Fully software-programmable and accessible
Flexible I/O Pins
— All digital pins have drive-strength controls
— Most non-EMI digital pins have general-purpose input/output (GPIO) mode.
For comprehensive information on the microcontroller visit the Freescale’s web page for a
datasheet.
At the moment of writing the microcontroller datasheet can be found at the following link:
http://www.freescale.com/files/dsp/doc/ref_manual/IMX 3RM.pdf
Page 15 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 5
ONTROL IR UITY AND HARDWARE MODULES
5. Introduction to the chapter
Here you can find information about reset circuit and quartz crystals locations, the power supply
circuit is discussed.
5.1 Reset
OLinuXino's reset circuit includes R9 (47KΩ), R10 (47 Ω), T1, T , Q1 and a RESET button. The
RESET is specific for the fact that it is accomplished when the quarz is disconnected using 3.3V
and the transistors T1 and T .
5.2 locks
4 MHz quartz crystal Q1 is connected to pins 1 1 and 1 of the iMX 33 processor.
5 MHz quartz crystal Q is found at pins 60 and 61 of the Ethernet controller – LAN951 -JZX.
Page 16 of 44

OLIMEX© 01 OLinuXino User's Manual
5.3 Power supply circuit
The power supply circuit of OLinuXino-MAXI allows flexible input supply from 6V to 16V direct
current. This means a wide range of power supplies, adapters, converters are applicable. The
maximum amperage recommended is 1A by default (0. 50mA if 3.3VIO_E is closed – read below).
If measuring the current consumption it should be around 0.06A before initializing all the
peripherals. The consumption raises to 0.1 A without LAN and USB hosts initialized and Linux
running. The consumption goes up 0.15A with the Linux running when LAN and both USB hosts
initialized.
If you have a standard USB flash drive attached to a USB host, Linux and LAN running the typical
consumption is around 0. 0A.
When powered by the typical 3.7V battery the LAN and USB-hosts are disabled. The consumption
when Linux is running is around 0.75A.
The board can be powered either from the power jack or from the LIPO_BAT connector. Note that
since standard batteries can't provide the voltage needed for the board it is advisable to use the
power from the power jack. When you use the LIPO_BAT connector and a battery the chip
handling the Ethernet and the USB hosts is disabled. Also the power button has alternative function
when the board is powered by a battery – check 6.13.
If you have successfully powered the board the RED PWR LED will turn on. Note that it is possible
to have the PWR LED on even if there isn't enough power for the board altogether with all the
peripherals currently connected.
Page 17 of 44

OLIMEX© 01 OLinuXino User's Manual
The jumper 5V_E (5V Enable) which is closed by default enables powering the board via the power
supply circuit. The 3.3V_E (3.3V Enable) jumper when closed enables the 3.3V power line.
Note the 3.3VIO_E jumper which by default is closed – it disables the U6 DC-DC converter and
enables a built-in the iMX 33 DC-DC. The problem is that the built-in DC-DC has a limit of
50mA of amperage the chip heats a bit so we decided to put external DC-DC for better stability.
When working with 3.3VIO_E closed pay attention to the amperage used.
Page 18 of 44

OLIMEX© 01 OLinuXino User's Manual
HAPTER 6
ONNE TORS AND PINOUT
6. Introduction to the chapter
In this chapter are presented the connectors that can be found on the board all together with their
pinout and notes about them. Jumpers functions are described. Notes and info on specific
peripherals are presented. Notes regarding the interfaces are given.
6.1 Debugging interfaces
If you don't have a separate monitor or display around, and you don't wish to swap cables constantly
with your personal computer using the debug interfaces provide better option for you OLinuXino
experience.
There are three debugging options available on the OLinuXino. It is prefarable to use one of the
first two - UART or SJTAG but in case you want to use the classic 6-wire parallel JTAG there is an
option explained below.
Page 19 of 44

OLIMEX© 01 OLinuXino User's Manual
6.1.1 UART debug
The first one is a debug UART interface – U_DEBUG. You will need a cable adapter and a level
shifter to be able to debug via USB (creating virtual COM port) on your personal computer. For
instance, you can use our product MOD-USB-RS 3 as a level shifter and a simple wire connection
between the OLinuXino and MOD-USB-RS 3 's UEXT connector for a setup allowing you to
communicate with the device via a terminal program. Alternatively you can use serial to USB cable
for instance our product: USB-SERIAL-CABLE for debugging via the UART.
U_DEBUG
Pin # Signal Name Processor Pin #
1PWM0/DUART_RXD 12
2PWM1/DUART_TXD 126
3GND 30, 3 , 98, 10 , 112, 118
4DEBUG 84
You can also check the pin names at the bottom of the board under the U_DEBUG header.
6.1.2 SJTAG debug
The second interface is the Serial JTAG (SJTAG) one-wire interface. It works with various external
JTAG debugger dongles through a Freescale-defined FPGA/CPLD. SJTAG supports the Green
Hills Slingshot and ETM probe debugger dongles, as well as those made by ARM, Abatron, and
Lauterbach.
Note that the SJTAG interface comes without plastic header mounted.
The HW_DIGCTL_CTRL_USE_SERIAL_JTAG bit in the digital control block selects whether the
one-wire serial JTAG interface or the alternative six-wire parallel JTAG interface is used. There are
other options in the digital control block which might interest you and our advice is to check the
iMX 33's datasheet released by Freescale.
Page 0 of 44
