Oliver 2218 Operation instructions

2218S20000-CV
Walker, Michigan, U.S.A. 49534-7564
USER’S OPERATING AND INSTRUCTION MANUAL
MODEL 2218
ROTARY ACCUMULATOR

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20001 0-1
INDEX
Section Description Document No. Page No.
SAFETY INSTRUCTIONS --------------------------------------2218S20002 --------------------------- 1-1
DESCRIPTION/SPECIFICATIONS ---------------------------2218S20013----------------------------2-1
Description -------------------------------------------------------------------------------------------------- 2-1
Specifications----------------------------------------------------------------------------------------------- 2-1
INSTALLATION INSTRUCTIONS ---------------------------- 2218S20014 --------------------------- 3-1
Accumulator Installation ----------------------------------------------------------------------------------3-1
OPERATING INSTRUCTIONS --------------------------------2218S20015 --------------------------- 4-1
TROUBLESHOOTING -------------------------------------------2218S20006 --------------------------- 5-1
The Accumulator Will Not Start (Motor is Not Humming) ----------------------------------------5-1
The Accumulator Will Not Start (Motor is Humming) ---------------------------------------------5-1
MAINTENANCE --------------------------------------------------- 2218S20007 --------------------------- 6-1
Removing and Replacing the Rotary Table -------------------------------------------------------- 6-1
Cleaning ---------------------------------------------------------------------------------------------------- 6-1
PARTS ASSEMBLY-------- ------------------------------------- 2218S20022 --------------------------- 7-1
Drawing -------------------------------------------------------------------------------------------------7-1
Parts List ----------------------------------------------------------------------------------------------- 7-2
WIRING DIAGRAM 1-60-115 --------------------------------- 2218S20023 -------------------------- 8-1
WARRANTY ------------------------------------------------------- GEN 040225
WARRANTY PROCEDURE------------------------------------ GEN 040226
RETURNED PARTS POLICY --------------------------------- GEN 040227
REV. 2-17-23

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20002 1-1
SAFETY INSTRUCTIONS
WARNING
MACHINE OPERATORS AND MAINTENANCE PERSONNEL MUST OBSERVE THE
FOLLOWING SAFETY PRECAUTIONS. IMPROPER INSTALLATION,
MAINTENANCE, OR OPERATION OF THIS EQUIPMENT COULD CAUSE SERIOUS
INJURY OR DEATH.
1. Read this manual before attempting to operate your machine. Never allow an
untrained person to operate or service this machine.
2. Connect the machine to a properly grounded electrical supply that matches the
requirements shown on the electrical specification plate and follow all specifications
of local electrical codes.
3. Disconnect and lock-out the machine from the power supply before cleaning or
servicing.
4. Check and secure all covers and guards before starting the machine.
5. Observe all caution and warning labels affixed to the machine.
6. Use only proper replacement parts.
7. Do not wear loose fitting clothing or loose hair when working near this machine.
Shirt tails should be tucked in.
8. Wear proper protective personal safety equipment.
9. Keep hands away from the moving parts of this machine while it is in operation.
10. In addition to these general safety instructions, please follow the more specific safety
instructions in the rest of this operating instruction manual.
WARNING
DO NOT USE FOR OTHER THAN ORIGINALLY INTENDED PURPOSE.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20013 2-1
DESCRIPTION/SPECIFICATIONS
Description
The Oliver Model 2218 Rotary Accumulator is a sturdy compact machine that is easy to
operate and will provide years of operation requiring little maintenance. This machine is
intended to act as a buffer in a packaging line by temporarily receiving and holding
packages exiting a conveyor.
The Model 2218 Rotary Accumulator is made with a stainless and durable painted steel
base and a removeable smooth plastic tabletop for easy cleaning and maintenance.
Specifications
Space Requirements:
2218 (All Dimensions are Approximate)

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20013 2-2
Product Capacities:
Table is designed to support up to 25 lbs. of packages at a time.
Standard Electrical:
1 phase, 60 hz, 115VAC, 1 Amp
Standard Table Size:
36 in. diameter
Shipping Weight:
175 lbs. (approximate)
Net Weight:
98 lbs. (approximate)

Oliver Packaging & Equipment Company
236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20014 3-1
INSTALLATION INSTRUCTIONS
Accumulator Installation:
CAUTION
THE ACCUMLATOR IS HEAVY, USE PROPER TECHNIQUE WHEN LIFTING.
KEEP BACK STRAIGHT, KNEES BENT, AND LIFT WITH LEGS.
USE GLOVES TO PROTECT HANDS.
Select a location for your accumulator having a compatible electrical service available
with the machine as indicated on the electrical data plate attached to the machine.
Remove the outer packaging. Using at least two people, lift the accumulator base from
the packaging and set the machine onto the floor.
After the base has been moved to the desired use location (with the tabletop
unassembled to get through any narrow doorways or to carry over stairs), install the
tabletop by lining up the square tube on the bottom of the tabletop with the square drive
hub on the base and carefully lower into position. The underside of the tabletop should
contact the supporting rollers if properly installed.
Move the table to receive packaged items by rolling the machine to the desired sealer or
conveyor outfeed location and lock the casters.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20015 4-1
OPERATING INSTRUCTIONS
CAUTION
THE ACCUMULATOR TABLETOP ROTATES — MAKE SURE PERSONNEL AND
EQUIPMENT ARE CLEAR.
DO NOT ALLOW THE TABLETOP TO RUB ON STATIONARY OBJECTS TO
PREVENT WEAR AND DAMAGE.
To operate the accumulator, turn the selector switch on the base to the ON “I” position.
Table speed can be varied by use of the speed control knob located below the selector
switch.
Balance the rate at which the table turns and is loaded and unloaded to avoid overfilling
the tabletop.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20006 5-1
TROUBLE SHOOTING
WARNING
ALWAYS DISCONNECT THE ACCUMULATOR FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY TYPE OF MAINTENANCE TASK.
The Accumulator Will Not Start (Motor Is Not Humming)
 The machine is not plugged in.
 There is no power at the outlet. (Check by plugging in a small working appliance,
such as a lamp. Check to see if a circuit breaker has tripped. If the circuit breaker
has not tripped and the circuit is still not working have a qualified electrician check
the circuit.)
 The ON/OFF switch is in the off “0” position. Turn the selector switch to the on “I”
position.
 The speed may be set too low. Turn the speed control clockwise to increase table
speed.
 The problem is somewhere else in the electrical system of the machine. (Have a
qualified electrician find and repair the problem.)
The Accumulator Will Not Start (Motor Is Humming)
CAUTION
DO NOT ALLOW THE MOTOR TO HUM WITHOUT STARTING.
OVERHEATING CAN PERMANENTLY DAMAGE THE MOTOR.
 The drive system is binding. (Have a qualified service agent check for defective
bearings or other restrictions to free movement.)
 There is mechanical interference between other parts of the accumulator. (Have a
qualified service agent evaluate the machine for adjustment or replacement of
defective parts.)
 The motor has failed. (Have it checked by a qualified electrician.)

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20007 6-1
MAINTENANCE
WARNING
ALWAYS UNPLUG THE ACCUMULATOR BEFORE PERFORMING
ANY TYPE OF MAINTENANCE TASK.
Removing and Replacing the Rotary Tabletop
To remove the rotary tabletop, pull straight up and off the base unit. To replace the
rotary tabletop, line up the square tube on the bottom of the tabletop with the square
drive hub on the base and carefully lower into position. The underside of the tabletop
should contact the supporting rollers if properly installed.
Cleaning
Use a cloth dampened with a mild detergent solution to clean the exterior surfaces daily
or as necessary. Do immerse or wash down the equipment. The tabletop may be
hand washed when separated from the base, but do not soak or immerse.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20022 7-1
ACCUMULATOR ASSEMBLY
FOR SERVICE PARTS CALL OLIVER PACKAGING & EQUIPMENT @ 800-253-3893

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20022 7-2
FOR SERVICE PARTS CALL OLIVER PACKAGING & EQUIPMENT @ 800-253-3893

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
ROTARY ACCUMULATOR
2218S20023 8-1
ACCUMULATOR WIRING DIAGRAM
FOR SERVICE PARTS CALL OLIVER PACKAGING & EQUIPMENT @ 800-253-3893

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
GEN 040225 
WARRANTY
PARTS
Oliver Packaging & Equipment Company warrants that if any part of the equipment (other than a part
not manufactured by Oliver Packaging & Equipment ) proves to be defective (as defined below) within
one year after shipment, and if Buyer returns the defective part to Oliver Packaging & Equipment
within one year, Freight Prepaid to Oliver Packaging & Equipment plant in Walker, MI, then Oliver
Packaging & Equipment , shall, at Oliver Packaging & Equipment option, either repair or replace the
defective part, at Oliver Packaging & Equipment expense.
LABOR
Oliver further warrants that equipment properly installed in accordance with our special instructions,
which proves to be defective in material or workmanship under normal use within one (1) year from
installation or one (1) years and three (3) months from actual shipment date, whichever date comes
first, will be repaired by Oliver Packaging & Equipment or an Oliver Packaging & Equipment
Authorized Service Dealer, in accordance with Oliver Packaging & Equipment published Service
Schedule.
For purposes of this warranty, a defective part or defective equipment is a part or equipment which is
found by Oliver Packaging & Equipment to have been defective in materials workmanship, if the
defect materially impairs the value of the equipment to Buyer. Oliver Packaging & Equipment has no
obligation as to parts or components not manufactured by Oliver Packaging & Equipment, but Oliver
Packaging & Equipment assigns to Buyer any warranties made to Oliver Packaging & Equipment by
the manufacturer thereof.
This warranty does not apply to:
1. Damage caused by shipping or accident.
2. Damage resulting from improper installation or alteration.
3. Equipment misused, abused, altered, not maintained on a regular basis, operated carelessly, or
used in abnormal conditions.
4. Equipment used in conjunction with products of other manufacturers unless such use is approved
by Oliver Packaging & Equipment Company in writing.
5. Periodic maintenance of equipment, including but not limited to lubrication, replacement of wear
items, and other adjustments required due to installation, set up, or normal wear.
6. Losses or damage resulting from malfunction.
The foregoing warranty is in lieu of all other warranties expressed or implied AND OLIVER
PACKAGING & EQUIPMENT COMPANY MAKES NO WARRANTY OF MERCHANTABILITY OR
FITNESS FOR PURPOSE REGARDING THE EQUIPMENT COVERED BY THIS WARRANTY.
Oliver Packaging & Equipment Company neither assumes nor authorizes any person to assume for it
any other obligations or liability in connection with said equipment. OLIVER PACKAGING &
EQUIPMENT COMPANY SHALL NOT BE LIABLE FOR LOSS OF TIME, INCONVENIENCE,
COMMERCIAL LOSS, INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
GEN 040226
WARRANTY PROCEDURE
1. If a problem should occur, either the dealer or the end user must contact the Parts and
Service Department and explain the problem.
2. The Parts and Service Manager will determine if the warranty will apply to this particular
problem.
3. If the Parts and Service Manager approves, a Work Authorization Number will be
generated, and the appropriate service agency will perform the service.
4. The service dealer will then complete an invoice and send it to the Parts and Service
Department at Oliver Packaging & Equipment Company.
5. The Parts and Service Manager of Oliver Packaging and Equipment Company will
review the invoice and returned parts, if applicable, and approve for payment.

Oliver Packaging & Equipment Company
3236 Wilson Drive NW, Walker, MI 49534
[phone]
GEN 040227
RETURNED PARTS POLICY
This policy applies to all parts returned to the factory whether for warranted credit,
replacement, repair or re-stocking.
Oliver Packaging and Equipment Company requires that the customer obtain a Return
Material Authorization (RMA) number before returning any part. This number should appear
on the shipping label and inside the shipping carton as well. All parts are to be returned
prepaid. Following this procedure will insure prompt handling of all returned parts.
To obtain an RMA number contact the Repair Parts Deptartment toll free at [phone].
Parts returned for re-stocking are subject to a RE-STOCKING CHARGE.
Thank you for your cooperation,
Repair Parts Manager
Oliver Packaging and Equipment Company
