Oliveri 883U Installation instructions

9 9/16"
9/16"
5 1/8"
21 1/16"
32 7/8"
16 7/8"
3 9/16"
20"
1 3/8"
8 7/16"
"4/331
18"
4 1/4" 15 5/8" 10"
R 2 3/4"
R 3 5/8"
R 4 5/16"
R 38 1/8"
R 39"
R 8 5/16"
R 7 1/2"
R 5 3/16"
"2/19
13"
1 9/16"
Model No: 884U
800 Series
UNDERMOUNT SINK
Head Off ce and Manufactur ng
Tasman S nkware Ptty Ltd
51 Naweena Rd. Regency Park
South Austral a, 5010, AUSTRALIA
Tasman S nkware
North Amer ca
1230 Ra lroad St
Corona CA 92882
northamer ca@ol ver s nks.com
INCLUDED
ACCESSORIES
AC80 Bas n
Protector
Model No: 884U
SINK DIMENSIONS
MATERIAL
Sta nless Steel
304 Grade
18 Gauge
CONSTRUCTION
Ind v dual bowls
welded nto r m
SHIPPING WEIGHT
(Packed)
29.0 lb
INSTALLATION
METHOD
Des gned to be
undermounted n
a sol d surface top
CABINET
M n mum
36”
WARRANTY
All Ol ver s nks carry
Tasman s nkware’s
L fet me L m ted
Buyer Warranty
Prod ct Specifications
Undermount CAD files
(DXF & DWG format)
can be do nloaded from
our eb site
.oliverisinks.com
Project / Customer Name:
__________________________________________________________________________________________
Approval: ________________________________________________________________________
Date: ________________________________________________________________________________
AC09 Basket
Waste x 1
6" deep
