Olympia Web.Radio 300 User manual

RInternet Radio Mini Hi−Fi
System
OPERATING MANUAL
05.03.2008 en/en
Web.Radio 300

Contents
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS iPage
Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Safety Precautions 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exemption From Liability 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intended Use 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Information on Disposal 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Features 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Information on References to Software and Hardware3
Operating Systems and Multimedia Programmes 3. .
Glossary 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Package Contents 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Positioning the Equipment 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting the Equipment 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inserting Batteries in the Remote Control 7. . . . . . . . . . . . . . . . . . . . . . . .
Conditions / Connecting to Internet 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Providers 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connection Options 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LAN connections 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WLAN connections 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal Notes 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Elements and Indicators 10. . . . . . . . . . . . . .
On the Unit 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On the Remote Control 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Icons 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Steps 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigation in the Menu 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring the Equipment 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Internet access via LAN 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Internet access via WLAN 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exiting the network wizard 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Information 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input via the remote control 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
While playing recordings 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main Menu 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Operation 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ripping from CD 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Requesting CD information from gracenote 21. . . . . . . . . . . . . . . . . . .
Internet Radio 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting entries in the Favorite list 22. . . . . . . . . . . . . . . . . . . . . . . . . . .
USB Flash Drive 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SD/MMC Memory Card 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FM Radio 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic radio station scanning 25. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual radio station scanning 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPNP 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
File Manager 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AUX 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
iiPage
Setup 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Date & Time 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sleep mode 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Language 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Information 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firmware upgrade 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Resetting all settings 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Settings 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect LAN 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use Proxy 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect WLAN 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use Proxy 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Access Via a UPnP Server 35. . . . . . . . . . . . . . . . . . . . . . .
Configuring the PC Using Windows 35. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Localising and Playing Files 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guarantee 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Modifications 37. . . . . . . . . . . . . . . . . . . . . . . . .
Conformity of the telephone with the applicable EU direc-
tives is confirmed by the CE symbol.
The corresponding Declaration of Conformity is enclosed
in the packaging as a supplementary sheet.

Introduction
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 1Page
Introduction
Important Safety Precautions
Please observe the following to ensure the equipment can be operated
reliably:
SPlease read this operating instruction manual thoroughly and
observe the information contained when using the equipment.
SIf the radio is moved from a cold to a warm area, wait for 2 to 3
hours before switching the it on. This enables any condensation
which may have developed inside the equipment to evaporate.
SDo not use the equipment if it is damaged in any way.
SPlace the radio on a non-slip base and lay the connection cables
so that they cannot be the source of an accident.
SEnsure access to the power connection is not obstructed by
furniture or such.
SDo not cover the air vents and ensure a minimum clearance of
5 cm on all sides of the equipment.
SOnly connect approved accessories.
SDo not expose the equipment to extreme temperatures or humid
conditions and protect it from vibrations, direct sunlight and dusty
conditions.
SOnly clean the equipment with a soft, moist cloth. Never use any
solutions, aggressive solvents or cleaning agents.
SNever open the equipment. Opening the equipment exposes the
person to the risk of an electric shock. The terms of guarantee are
also annulled.
SRepairs to defect equipment may only be carried out by service
centres authorised by the sales outlet.
Exemption From Liability
We cannot guarantee that the information which relates to the technical
properties of the product or to the product itself contained in this document
is correct. The product and its accessories described in this document are
subject to constant improvement and further development. For this reason,
we reserve the right to modify components, accessories, technical
specifications and related documentation of the product described herein at
any time without notice.
Intended Use
This equipment has been designed to be connected to an internet network
and play programmes from the radio stations streamed. It can also be used
to access folders on the PC connected within the network after taking the
corresponding approvals into account. It can be used to play recordings on
CDs. The system can be used to play and record tracks on appropriate
USB flash drives and SD/MMC memory cards. The radio can also be used
to receive and play programmes broadcast on the FM band. Any other use
is considered unintended use. Unauthorised modifications or reconstruction
not described in this manual are not permitted.

Introduction
OPERATING
INSTRUCTIONS
www.olympia.ag
2Page
Information on Disposal
The implementation of European law in national laws and directives obliges
you to dispose of consumable goods appropriately. This serves to protect
both persons and the environment.
The adjacent symbol indicates that electrical and electronic
apparatus as well as batteries no longer required must be
disposed of separate from domestic waste.
Old or unwanted devices must be disposed of at collection
points provided by public waste authorities.
Batteries and power packs must be disposed of at shops
which sell batteries or collection points which provide the
corresponding containers.
Packaging materials must be disposed of according to local
regulations.

Features
OPERATING
INSTRUCTIONS 3Page
www.olympia-vertrieb.de
Features
Congratulations on having purchased this high quality equipment which is
provided with the following features:
SReception of Internet radio stations worldwide
SSupports online streaming
SSupports MP3 and Windows Media
SPlays recordings stored on CDs
SPlays recordings stored on SD/MMC memory cards
SPlays recordings stored on USB flash drives
SReception of FM radio broadcasts
SRecording data on SD/MMC memory cards and USB flash
drives
SAUX input
SIR remote control
SHigh sound quality
SClock and alarm function, sleep timer
SFile sharing via Windows Media Connect function
SWEP and WPA coding
SPower supply: 230 V 50 Hz
SStandards: IEEE 802.11b and IEEE 802.11g
SSummer time function
S11 display languages
Information on References to Software and
Hardware
The software and hardware referred to in this manual are registered
trademarks and, as such, are subject to the provisions of law.
Operating Systems and Multimedia Programmes
The equipment can be used with various operating systems and multimedia
programmes.
Please refer to the corresponding descriptions for the necessary
information concerning system and programme configurations as well as
the procedures for authorising the sharing of file access.
Further information is available on the manufacturer’s web site.

Features
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
4Page
Glossary
Wireless AP Wireless AP refers to a Wireless LAN Access Point.
This is normally integrated in the router.
DHCP Dynamic Host Configuration Protocol (DHCP) enables
the dynamic assignment of an IP address in a network
with the aid of a corresponding server or router.
IP Address An IP address is a number which enables computers
and other devices to be accessed within an IP
network. It has four groups of numbers separated by a
dot, e.g: 192.168.178.100
MAC Address The MAC address is the hardware address of each
individual network device and serves for the unique
identification of every device within a network.
WEP Wired Equivalent Privacy is the previous standard
encryption algorithm for WLAN and is still used today
in many WLAN networks.
WPA Wi−Fi Protected Access is an encryption system used
for Wireless LAN. It provides a high degree of security
from external access and is preferable to the WEP
encryption system.
SSID SSID (Service Set Identifier) or ESSID (Extended
Service Set Identifier) relates to the identification
(name) of a radio network based on IEEE 802.11.
Gateway Gateway relates to the basic IP address of the router
via which the network computer establishes an internet
connection.
UPnP Universal Plug and Play. This relates to a standard
implemented by manufacturers to enable interoperation
of their devices with others introduced by Microsoft. In
this way, audio equipment such as the WebRadio can
communicate with the PC via an IP network.
Random This relates to the playback of recordings from a list of
audio files in an uncontrolled sequence.
Repeat Repeat playback of a recording in an audio file.
USB The Universal Serial Bus (USB) is a serial bus system
to connect a computer with external devices.
SD Card An SD Memory Card (Secure Digital Memory Card) is
a digital storage medium which works according to the
principle of the flash memory.
MMC Card A Multimedia Card (MMC) is a digital storage medium.
Rip To rip, in computer jargon, is to copy music or video
recordings from a data source onto a computer hard
disk or another medium.

Installation
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 5Page
Installation
Package Contents
SMini hi−fi system
S2 loudspeakers
SPower adapter
SConnection cable for the power adapter
SWLAN−USB adapter
SFM antenna
SRemote control
S2 batteries, type AAA
SOperating manual
Please check the contents of the package carefully. If anything is missing
or shows signs of transport damage, do NOT put the equipment into
service! In such a case, contact your sales outlet, with the purchase receipt
to hand, or the OLYMPIA Service Center directly.
Note: Keep the equipment packaging so that it can be used to prevent
equipment damage in the event of future transport.
Positioning the Equipment
Position the equipment in an easily accessible location. Ensure that it is set
down on a stable, level, non−slip surface. In addition, ensure that the
equipment is positioned where all the necessary cables can be laid in such
a way that nobody can trip over them. Do not cover the air vents and ensure
a minimum clearance of 5 cm on all sides of the equipment.
Do not expose the equipment to direct sunlight. Protect the
equipment from getting wet. It must not be set up in rooms
subject to condensation, corrosive vapours or high
concentrations of dust. The ambient temperature must be
between 0 _C and 60 _C.

Installation
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
6Page
Connecting the Equipment
Check that the voltage specifications on the equipment matches
that of the local power supply.
SConnect the jack plugs from the loudspeakers in the sockets
labelled SPEAKER R and L.
SIf necessary, connect the plug from the FM antenna in the socket
labelled ANTENNA.
SPlug the WLAN−USB adapter in the socket labelled USB and/or a
network cable in the socket labelled LAN.
SConnect the power adapter plug to the socket labelled DC 12V.
SPlug the power adapter plug in the power supply.
SPlug the power adapter in the power socket.
SSet the POWER switch to ON.
SThe equipment is now ready to be configured.
DC 12V SPEAKER
RL
AUX IN
ANTENNA
USB LAN
POWER
OFF ON

Installation
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 7Page
Inserting Batteries in the Remote Control
Open the battery compartment. Insert the batteries, type AAA, in the battery
compartment, paying attention to correct polarity. Replace the battery
compartment cover.
AAA NiMH
AAA NiMH
The equipment does not work if the batteries are inserted
incorrectly. The equipment could also be damaged as a result.
Conditions / Connecting to Internet
The following conditions must be fulfilled in order to use the equipment:
SThere must be an internet access available with a high
transmission speed.
SThe equipment must have an internet connection (preferably via a
router).
Note: If your WLAN network has been configured for WEP (Wired
Equivalent Privacy) or WPA (WLAN Protected Access) encryption, you must
know your WEP or WPA code.
SIf your WLAN network has been configured so that only authorised
device are accepted, you must notify the router of your equipment’s
MAC address. The way in which to find the equipment’s MAC
address is described in Section Access Via a UPnP Server.
SRefer to the operating manual supplied with the router for
information on how the transfer the equipment’s MAC address to
the router.
Note: The range of the WLAN network is influenced by environmental
conditions and certain building material (number/thickness of walls, solid
doors, windows). Refer to the operating manual supplied with the router for
information on how improve the range of your WLAN network.
Note: To increase the range of your network without any extensive effort, we
recommend using Olympia HomePlug components. Information on this is
available on our web site.
SEnsure that the WLAN network and connection to the Internet
function properly. Refer to the operating manual supplied with the
respective component.
SThe equipment is now ready to operate.
Providers
SSHOUTCast is preset as the provider for Internet radio stations.
Information on radio stations and providers is available on the web
site, www.shoutcast.com.
Sgracenote is the preset provider for the automatic request of CD
information. Details on requesting CD information and information
on the provider is available on the following web site,
www.gracenote.com.

Installation
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
8Page
Connection Options
The equipment can be connected to the internet or PCs in various ways.
LAN connections
Connection to a network linked to internet
ADSL or
cable modem Broadband router
Network cable
Network cable
Mini hi−fi system
PC (media server)
or direct connection to a stand−alone PC
Cross−over
network cable
Mini hi−fi system
PC (media server)
WLAN connections
Connection to a network linked to internet
ADSL or
cable modem
WLAN broadband router
Network cable
Mini hi−fi system
PC (media server)
PC (media server)
WLAN (WiFi) dongle
WLAN (WiFi) dongle
or direct connection to a stand−alone PC
Mini hi−fi system
WLAN (WiFi) dongle
PC (media server)
WLAN (WiFi) dongle

Personal Notes
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 9Page
Personal Notes

Operating Elements and Indicators
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
10Page
Operating Elements and Indicators
1
2
3
4
7
8
5
6
9
10
11
12
13
14
15
16
17
18
19
20
21

Operating Elements and Indicators
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 11Page
On the Unit
1 Button [SETUP], display settings
2a Button , select previous track/
(hold down) fast rewind
2b Button , select next track/
(hold down) fast forward
3 Button / , select options
4 Button [OK], confirm selection
5 Button , open/close CD tray
6 Button [MUTE], mute speakers
7 Button [Mem.], function explained in respective operation
sections
8 Button [Sleep], set timer (5, 10, 15, 20, 30 minutes)
9 Socket USB port
10 Socket SD card slot
11 Socket Headphone socket
12 Button [AL1] / [AL2], Alarm time 1/2, on/off
13 Tray For CD
14 Button [Menu], main menu
15 Button [REC.], record what is currently playing as MP3
16 Button / , set volume
17 Sensor Infrared receiver for remote control
18 Button , standby
19 Button , stop playback /
return to previous menu
20 Display
21 Button , play/pause

Operating Elements and Indicators
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
12Page
1
2
34
7
8
56
9
10
11
12 13
14 15
16
1718
19
20 21
22 23
24
25
26
27
28
29 30
31 32
33
34

Operating Elements and Indicators
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 13Page
On the Remote Control
1 Button , standby mode
2 Button [MENU], main menu
3 Button [SD/MMC], play from SD/MMC
4 Button [USB], play from USB flash memory
5 Button [AUX], play from AUX device
6 Button [FileMgr], copy and delete data on SD/MMC/USB
memory
7 Button , stop playback /
return to previous menu
8 Button , play/pause
9 Button [OK], confirm selection
10 Button [PRE SCAN], scan for FM radio stations
11 Button [ST.MO], stereo/mono toggle button for FM radio
12 Button [MUTE], mute speakers
13 Button [TIMER], set alarm
14 Button [VOL Y], increase volume
15 Button [SLEEP], set timer (5, 10, 15, 20, 30 minutes)
16 Button [VOL B], decrease volume
17 Button [REPEAT], play recording again, play all recordings
again, play recordings in random sequence
18 Button [RANDOM], play recordings in random sequence
19 Button [A-B], continuous playback of marked passage
20 Button [CLOCK], display time
21 Button [B.L.], back−lighting,
set/deactivate intensity
22 Button [SETUP], display settings
23 Button [INFO], display:
RDS information in FM mode or lyrics information
MP3/WMA mode
24 Button [P−EQ], set tone: Normal, Classic, Jazz, Pop, Rock
25 Button [X−BASS], extra bass boost on/off
26 Button , navigation in menus/stations,
move forward/back in track list
27 Button [REC.], record track currently playing as MP3
28 Button [MEM.], function explained in respective operation
sections
29 Button [UPNP], access to data on PC via UPNP
30 Button [FM], play FM radio
31 Button [I.RADIO], play internet radio
32 Button [CD], play CD
33 Button ..., digits keypad
34 Button , open/close CD tray

Operating Elements and Indicators
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
14Page
Display Icons
Play from CD
Internet radio
USB
SD/MMC
FM radio
UPnP
File manager
AUX
Settings
Time synchronisation
DHCP error
No access point or wrong code

Operating Elements and Indicators
www.olympia-vertrieb.de
OPERATING
INSTRUCTIONS 15Page
WLAN signal strength under 20%
WLAN signal strength between 20 and 59%
WLAN signal strength between 60 and 80%
WLAN signal strength over 80%
CD detected
CD is being loaded
Request CD information from Gracenote
Play from CD
USB flash drive detected
SD/MMC memory card detected
Summer time selected
Sleep mode activated
WLAN setup menu
WLAN encrypted

First Steps
OPERATING
INSTRUCTIONS
www.olympia-vertrieb.de
16Page
First Steps
Navigation in the Menu
The display in the unit provides menus in graphical and text form. Move to
the selection options by using the / or / buttons. To
confirm a selection, press the [OK] button.
Configuring the Equipment
1. Set the POWER switch to ON.
2. The company logo appears in the display.
3. The unit then searches for any network
components available.
4. If necessary, make a selection manually.
Select the menu option required and
confirm the selection.
SInternet access via LAN
SInternet access via WLAN
SExit the network wizard
Internet access via LAN
1. If the network is not yet connected, a
corresponding message is displayed.
Connect the equipment with the network
via the LAN socket.
2. The network settings are checked. A
network access is established.
3. The equipment data is synchronised with
the network.
4. The equipment switches to Standby mode.
Note: If a connection to the network cannot
be established, an error message is
displayed. Refer to Section Network Settings
and/or Troubleshooting.
  
  
  
  
  
!!"#$ %&
'(( '((
) *+,*-"
. /0 '
