2
En
For customers in North and South America
Trademarks
• IBM is a registered trademark of International Business Machines Corporation.
• Microsoft and Windows are registered trademarks of Microsoft Corporation.
• Macintosh is a trademark of Apple Computer Inc.
• ImageLink/Easyshare are trademarks of the Eastman Kodak Company.
• xD-Picture Card™ is a trademark.
• All other company and product names are registered trademarks and/or
trademarks of their respective owners.
• The standards for camera file systems referred to in this manual are the “Design
Rule for Camera File System/DCF” standards stipulated by the Japan
Electronics and Information Technology Industries Association (JEITA).
• Thank you for purchasing an Olympus digital camera. Before you start to use your
new camera, please read these instructions carefully to enjoy optimum performance
and a longer service life.
• This manual explains shooting and playback basics. For details on functions, read the
advanced manual. Keep this manual in a safe place for future reference.
• We recommend that you take test shots to get accustomed to your camera before
taking important photographs.
• The screen and camera illustrations shown in this manual were produced during the
development stages and may differ from the actual product.
For customers in USA
Declaration of Conformity
Model Number : D-555 ZOOM
Trade Name : OLYMPUS
Responsible Party :
Address : Two Corporate Center Drive, P.O. Box 9058, Melville, NY
11747-9058 U.S.A.
Telephone Number : 1-631-844-5000
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
For customers in Canada
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
d4255_basic_e_00_bookfile_7.book Page 2 Wednesday, June 8, 2005 1:33 PM

3
En
Manual Contents
Safety Precautions....................................................... 4
UNPACKING THE BOX CONTENTS................... 11
LOADING THE BATTERIES.............................13
INSERTING THE MEMORY CARD .....................16
TURNING THE CAMERA ON ...........................19
TAKING A PICTURE......................................21
REVIEWING A PICTURE ................................23
TURNING THE CAMERA OFF ..........................24
Enjoy the camera more.............................................. 25
Things you can do with this camera ............................. 25
Things you can do with the IMAGELINK PRINTER ..... 26
Installing OLYMPUS Master Software.......................... 27
Specifications ............................................................. 28
d4255_basic_e_00_bookfile_7.book Page 3 Wednesday, June 8, 2005 1:33 PM

4
En
Safety Precautions
Read All Instructions — Before you use the product, read all operating
instructions.
Save These Instructions — Save all safety and operating instructions for future
reference.
Heed Warnings — Read carefully and follow all warning labels on the product and
those described in the instructions.
Follow Instructions — Follow all instructions provided with this product.
Cleaning — Always unplug this product from the wall outlet before cleaning. Use
only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner,
or any type of organic solvent to clean this product.
Attachments — For your safety, and to avoid damaging the product, use only
accessories recommended by Olympus.
Water and Moisture — Never use this product around water (near a bathtub,
kitchen sink, laundry tub, wet basement, swimming pool or in the rain). For
precautions on products with weatherproof designs, read the weatherproofing
sections of their manuals.
General Precautions
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL.
Lightning flash with an arrowhead, enclosed in a triangle, alerts you to the presence of uninsulated voltage
points inside the product which could cause a serious electrical shock.
An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instructions in
the documentation provided with the product.
WARNING!
TO AVOID THE RISK OF FIRE OR ELECTRICAL SHOCK, NEVER EXPOSE THIS PRODUCT TO WATER OR
OPERATE IN A HIGH HUMIDITY ENVIRONMENT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
d4255_basic_e_00_bookfile_7.book Page 4 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
5
En
Location — To avoid damage to the product and prevent personal injury, never
place this product on an unstable stand, tripod, bracket, table or cart. Mount
only on a stable tripod, stand, or bracket. Follow the instructions that describe
how to safely mount the product, and use only the mounting devices
recommended by the manufacturer.
Power Sources — Connect this product only to the power source described on
the product label. If you are not sure about the type of power supply in your
home, consult your local power company. Refer to your operating instructions
for information on using the product with a battery.
Grounding, Polarization — If this product can be used with a specified AC
adapter, the adapter may be equipped with a polarized alternating current line
plug (a plug with one blade wider than the other). This safety feature allows the
plug to fit into the power outlet only one way. If you cannot insert the plug into
the wall outlet, pull it out, reverse it, and then reinsert it. If the plug still fails to
fit, contact an electrician and have the receptacle replaced.
Protecting the Power Cord — The power supply cord should be placed so it will
not be walked on. Never put a heavy object on the power cord or wrap it around
the leg of a table or chair. Keep the area around the power cord connection
points, at the power outlet, and at the product connection, free of all AC adapter
or accessory power cords.
Lightning — If a lightning storm occurs while using a specified AC adapter,
remove it from the wall outlet immediately. To avoid damage from unexpected
power surges, always unplug the AC adapter from the power outlet and
disconnect it from the camera when the camera is not in use.
Overloading — Never overload wall outlets, extension cords, power strips, or
other power connection points with too many plugs.
Foreign Objects, Liquid Spillage — To avoid personal injury caused by fire or
electrical shock from contact with internal high voltage points, never insert a
metal object into the product. Avoid using the product where there is a danger
of spillage.
Heat — Never use or store this product near any heat source such as a radiator,
heat register, stove, or any type of equipment or appliance that generates heat,
including stereo amplifiers.
Servicing — Refer all servicing to qualified personnel. Attempting to remove the
covers or disassemble the product, could expose you to dangerous high
voltage points.
d4255_basic_e_00_bookfile_7.book Page 5 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
6
En
Damage Requiring Service — If you notice any of the conditions described below
while using a specified AC adapter, unplug it from the wall outlet and refer
servicing to qualified service personnel:
a) Liquid has been spilled onto the product or some other object has fallen into
the product.
b) The product has been exposed to water.
c) The product does not operate normally despite following operating
instructions. Adjust only the controls described in the operating instructions
as improper adjustment of other controls could damage the product and
require extensive repair work by a qualified technician.
d) The product has been dropped or damaged in any way.
e) The product exhibits a distinct change in performance.
Replacement Parts — When replacement parts are required, make sure that the
service center uses only parts with the same characteristics as the originals, as
recommended by the manufacturer. Unauthorized substitution of parts could
result in fire, electrical shock, or create other hazards.
Safety Check — Upon completion of servicing or repairs, ask the service
technician to perform safety checks to determine that the product is in good
working order.
WARNING
(Do not use the camera near flammable or explosive gases.
• To avoid causing a fire or explosion, never use the camera near flammable
or explosive gases.
(Do not use the flash on people (infants, small children, etc.) at
close range.
• Use caution when taking flash pictures at close range. When you fire the
flash, you must be at least 1 m (3 ft.) away from the faces of your subjects,
especially when taking pictures of infants and small children. Firing the flash
too close to the subject’s eyes could cause a momentary loss of vision.
DANGER
If the product is used without observing the information given under this
symbol, serious injury or death may result.
WARNING
If the product is used without observing the information given under this
symbol, injury or death may result.
CAUTION
If the product is used without observing the information given under this
symbol, minor personal injury, damage to the equipment, or the loss of
valuable data may result.
Handling the Camera
d4255_basic_e_00_bookfile_7.book Page 6 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
7
En
(Keep young children and infants away from the camera.
• Always use and store the camera out of the reach of young children and
infants to prevent the following dangerous situations which could cause
serious injury:
• Becoming entangled in the camera strap, causing strangulation.
• Accidentally swallowing the battery, cards or other small parts.
• Accidentally firing the flash into their own eyes or those of another child.
• Accidentally being injured by the moving parts of the camera.
(Do not look at the sun or strong lights with the camera.
• To avoid damaging your eyes, never aim the camera directly into the sun,
or any other extremely bright light source.
(Do not touch charging batteries (included in some areas) or the
battery charger until charging is finished and the batteries have
cooled.
• The batteries and battery charger become hot while charging. A specified
AC adapter also becomes hot during long use. At these times, they may
cause minor burns.
(Do not use or store the camera in dusty or humid places.
• Using or storing the camera in dusty or humid places may result in a fire or
electric shock.
(Do not cover the flash with a hand while firing.
• Do not cover the flash with a hand while firing or touch it after it has just been
fired. It may be hot and cause minor burns. Avoid using the flash for
extended periods.
(Do not take apart or modify the camera.
• Never attempt to disassemble the camera. The internal circuits contain high
voltage points which could cause serious burns or electrical shock.
(Do not let water or foreign objects inside the camera.
• If the camera is accidentally dropped in water, or if liquid is spilled into the
camera, stop using it, allow it to dry, and then remove the batteries. Contact
the nearest authorized Olympus service center.
CAUTION
(Stop using the camera immediately if you notice any unusual
odors, noise, or smoke around it.
• If you notice any unusual odors, noise, or smoke around the camera during
operation, switch it off immediately – and disconnect a specified AC adapter
(if attached). Allow the camera to sit idle for a few minutes to cool. Take the
camera outdoors, away from flammable objects, and carefully remove the
batteries. Never remove the batteries with bare hands, which may cause a
fire or burn your hands. Contact the nearest Olympus service center
immediately.
d4255_basic_e_00_bookfile_7.book Page 7 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
8
En
(Do not use the camera with wet hands.
• To avoid dangerous electrical shock, never hold or operate the camera with
wet hands.
(Do not leave the camera in places where it may be subject to
extremely high temperatures.
• Doing so may cause parts to deteriorate and, in some circumstances, cause
the camera to catch fire. Do not use the charger or AC adapter if it is covered
(such as a blanket). This could cause overheating, resulting in fire.
(Handle the camera with care to avoid getting a low-temperature
burn.
• When the camera contains metal parts, overheating can result in a low-
temperature burn. Pay attention to the following:
• When used for a long period, the camera will get hot. If you hold on to the
camera in this state, a low-temperature burn may be caused.
• In places subject to extremely cold temperatures, the temperature of the
camera’s body may be lower than the environmental temperature. If
possible, wear gloves when handling the camera in cold temperatures.
(Be careful with the strap.
• Be careful with the strap when you carry the camera. It could easily catch
on stray objects – and cause serious damage.
(Use only the AC adapter specified by Olympus.
• Never use any AC adapter except one specified by Olympus. Using a
different AC adapter may damage the camera or power source, or result in
accidents or fire. Ensure the adapter used is designed for your region or
country. For more information, contact the nearest Olympus service center
or the store of purchase. Olympus makes no representations or warranties
regarding any damages caused by AC adapters not recommended by
Olympus.
(Do not damage the power-supply cord.
• Never pull or modify the power-supply cord of the AC adapter or
accessories. Make sure only the plug is securely held during insertion and
removal from the outlet. Stop using the camera immediately, and contact the
nearest Olympus service center or the store of purchase if:
• The power-supply cord becomes hot, or it gives off smoke or unusual
odors.
• The power-supply cord is cut or damaged, or the plug has a faulty
contact.
d4255_basic_e_00_bookfile_7.book Page 8 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
9
En
DANGER
• When using NiMH batteries (included in some areas), use only the Olympus
brand NiMH batteries and fitting charger.
• Never heat or incinerate batteries.
• Take precautions when carrying or storing batteries to prevent them from
coming into contact with any metal objects such as jewelry, pins, fasteners, etc.
• Never store batteries where they will be exposed to direct sunlight, or subjected
to high temperatures in a hot vehicle, near a heat source, etc.
• To prevent causing battery leaks or damaging their terminals, carefully follow all
instructions regarding the use of batteries. Never attempt to disassemble a
battery or modify it in any way, by soldering, etc.
• Never attempt to connect a battery directly to a power outlet, or to a cigarette
lighter in a vehicle.
• If battery fluid gets into your eyes, flush your eyes immediately with clear, cold
running water and seek medical attention immediately.
• Always store batteries out of the reach of small children. If a child accidentally
swallows a battery, seek medical attention immediately.
WARNING
• Keep batteries dry at all times. Never allow them to come into contact with fresh
or salt water.
• To prevent batteries from leaking, overheating, or causing a fire or explosion,
use only batteries recommended for use with this product.
• Never mix batteries (old and new batteries, charged and uncharged batteries,
batteries of different manufacture or capacity, etc.).
• Never attempt to charge alkaline, lithium or CR-V3 lithium battery packs.
• Insert the battery carefully as described in the operating instructions. Never load
the battery with its +/- terminals reversed. Never force the battery into the battery
compartment.
• Do not use batteries if their body is not covered by the insulating sheet or if the
sheet is torn, as this may cause fluid leaks, fire, or injury. Do not use these
batteries even if they were purchased in this condition.
Battery handling precautions
Follow these important guidelines to prevent batteries from leaking,
overheating, burning, exploding, or causing electrical shocks or burns.
d4255_basic_e_00_bookfile_7.book Page 9 Wednesday, June 8, 2005 1:33 PM

Safety Precautions
10
En • If NiMH batteries (included in some areas) are not charged within the specified
time, stop charging them and do not use them.
• Do not use a battery if it is cracked or broken.
• If a battery leaks, becomes discolored or deformed, or becomes abnormal in
any other way during operation, stop using the camera and consult your dealer
or an authorized Olympus service center. Continued use may result in fire or
electric shock.
• If a battery leaks fluid onto your clothing or skin, remove the clothing and flush
the affected area with clean, running cold water immediately. If the fluid burns
your skin, seek medical attention immediately.
• Never attempt to modify the battery compartment on the camera, never insert
anything (other than the recommended battery) into the battery compartment.
• Never subject batteries to strong shocks or continuous vibration.
CAUTION
• Before loading, always inspect the battery carefully for leaks, discoloration,
warping, or any other abnormality.
• The batteries may become hot during prolonged use. To avoid minor burns, do
not remove it immediately after using the camera.
• The following AA (R6) batteries cannot be used.
Batteries whose
bodies are only
partially or not at all
covered by an
insulating sheet.
Batteries whose
terminals are flat and
not completely covered
by an insulating sheet.
(Such batteries cannot
be used even if the
-
terminals are partially
covered.)
Batteries whose -
terminals are raised,
but not covered by an
insulating sheet.
d4255_basic_e_00_bookfile_7.book Page 10 Wednesday, June 8, 2005 1:33 PM

11
En
UNPACKING THE BOX CONTENTS
If you find any contents missing or damaged, contact the place of
purchase.
Note
Be sure to carefully read the instruction manual for the printer in addition to
this one.
Digital Camera Strap Card Camera Insert
AA (R6) Alkaline
Batteries (two)
USB Cable OLYMPUS Master
CD-ROM
Printer Paper Tray AC Adapter Power Cord
Ink ribbon cartridge
for 4 × 6 printing
4 × 6 Paper
Camera
Warranty Card
Basic Manual
(this manual)
Advanced Manual
(CD-ROM)
Registration Card
Printer Warranty Card
Instruction Manual
d4255_basic_e_00_bookfile_7.book Page 11 Wednesday, June 8, 2005 1:33 PM

UNPACKING THE BOX CONTENTS
12
En
1Attach the strap as shown.
Note
Be careful with the strap when you carry the camera, as it can easily catch on
stray objects, causing injury or damage.
Attach the strap correctly as shown above. Olympus is not responsible for any
damages resulting from the strap coming loose due to incorrect attachment.
Attaching the strap
Pull the strap tight so that it does not come loose.
Strap eyelet
Â
d4255_basic_e_00_bookfile_7.book Page 12 Wednesday, June 8, 2005 1:33 PM

13
En
LOADING THE BATTERIES
1Make sure the camera is turned off.
2Open the battery compartment cover.
3Insert the batteries.
The POWER switch is located at OFF.
Slide
Lift
o
n
Battery compartment
cover
The battery insertion direction is indicated in the battery compartment
and on the bottom of the camera.
d4255_basic_e_00_bookfile_7.book Page 13 Wednesday, June 8, 2005 1:33 PM

LOADING THE BATTERIES
14
En
4Close the battery compartment cover.
In addition to the batteries provided with the camera, the following types of
battery can be used. Choose the power source best suited to the situation.
(AA (R6) alkaline batteries
When you need batteries in a hurry, you can use AA (R6) alkaline batteries, which are
easy to obtain anywhere. However, the number of pictures that you can take may vary
considerably depending on the battery manufacturer, shooting conditions, etc.
This camera uses two AA (R6) alkaline batteries.
(NiMH batteries (rechargeable batteries)
Olympus NiMH batteries are rechargeable and economical. However, repeatedly charging
the batteries before using up their capacity will shorten the life of the batteries per charge.
The batteries are not fully charged at the time of purchase. Charge the batteries with the
battery charger specified by Olympus before use. For details, refer to the instruction
manual for your charger.
This camera uses two NiMH batteries.
(Lithium battery pack (CR-V3)
The Olympus CR-V3 lithium battery pack has a long service life
allowing you to use the camera longer than with alkaline
batteries. However, it cannot be recharged. Do not remove the
label on the battery pack.
This camera uses one lithium battery pack.
Close
n
Press down on the center of the cover when sliding.
Slide
o
The battery
Manganese (zinc-carbon) batteries cannot be used.
Important
d4255_basic_e_00_bookfile_7.book Page 14 Wednesday, June 8, 2005 1:33 PM

LOADING THE BATTERIES
15
En
Note
Power consumption by the camera varies depending on which functions are
used.
Power is consumed continuously during the conditions described below
causing batteries to become exhausted quickly.
The monitor is turned on.
The monitor is on in playback mode for an extended period of time.
The zoom is used repeatedly.
The shutter button is pressed halfway repeatedly in shooting mode,
activating the auto focus.
The camera is connected to a computer or printer.
Battery life varies depending on the type of battery, manufacturer, shooting
conditions, etc.
Using exhausted batteries or alkaline batteries may cause the camera to turn
off without displaying the battery level warning.
d4255_basic_e_00_bookfile_7.book Page 15 Wednesday, June 8, 2005 1:33 PM

16
En
INSERTING THE MEMORY CARD
1Make sure the camera is off.
2Open the card cover.
The POWER switch is located at OFF.
Card cover
Card cover
d4255_basic_e_00_bookfile_7.book Page 16 Wednesday, June 8, 2005 1:33 PM

INSERTING THE MEMORY CARD
17
En
3Insert the card.
Note
The card may not record properly if it is not inserted all the way in.
Releasing your finger quickly after pushing the card all the way in may
cause it to eject forcefully out of the slot.
4Close the card cover.
Â
Notch
Contact area
Make sure that the card is
oriented correctly and
insert while keeping it
straight, otherwise the
contact area on the card
may be damaged or the
card may get stuck.
Grasp and remove.
To remove the card
Push the card all the way in and
release slowly.
d4255_basic_e_00_bookfile_7.book Page 17 Wednesday, June 8, 2005 1:33 PM

INSERTING THE MEMORY CARD
18
En
This camera uses an xD-Picture Card (16MB – 1GB).
Note
This camera may not recognize a non-OLYMPUS card or a card that was
formatted on another device (such as a computer, etc.). Before use, be sure
to format the card on this camera.
Do not press on the card with hard or pointed items such as ballpoint pens.
Never open the battery compartment cover or the card cover, or remove the
card or the battery while the camera is turned on. Doing so could destroy the
data stored on the card. Once destroyed, data cannot be restored.
Do not place a sticker or label on the card as this could prevent the card from
being ejected.
The card
Index area
You can use this space to write the contents of the card.
Contact area
The part where the data transferred from the camera
enters the card.
d4255_basic_e_00_bookfile_7.book Page 18 Wednesday, June 8, 2005 1:33 PM

19
En
TURNING THE CAMERA ON
1Slide the POWER switch to K, pressing and
holding the lock button.
Note
To save battery power, the camera automatically enters sleep mode and stops
operating after about 3 minutes of non-operation. The camera activates again
as soon as you lightly press the shutter button or zoom lever.
4 hours after the camera enters sleep mode, the camera turns off
automatically. Turn the camera on to use.
The camera turns on when the
POWER switch is set to shooting
mode.
The lens extends and the monitor
turns on.
Battery check indicator
POWER switch
Shooting mode
Lock button
d4255_basic_e_00_bookfile_7.book Page 19 Wednesday, June 8, 2005 1:33 PM

TURNING THE CAMERA ON
20
En
Languages available on the camera
Available languages may vary according to
where you purchased the camera. The
instructions given in this manual and the
Advanced Manual apply to the camera
screens in English. See "Changing the
display language" in Chapter 6 of the
Advanced Manual.
Setting the date and time
It is recommend that you set the date and
time on the camera the first time you use it.
See "Setting the date and time" in Chapter
6 of the Advanced Manual. The camera can
be operated without making this setting.
The battery check indicator changes according to how much power is
remaining.
When you first turn on the camera
Battery check indicator
ef
Lit (green)
(Disappears after a
while.)
Ready to shoot.
No power is left. Replace with
new batteries or recharge the
batteries.
Blinking (red)
Only a little power is
remaining. Have some new
batteries ready or recharge
the batteries.
[BATTERY EMPTY]
is displayed.
d4255_basic_e_00_bookfile_7.book Page 20 Wednesday, June 8, 2005 1:33 PM
