Olympus LC30 User manual

Installation Manual
OLYMPUS LC30
Microscope Digital Camera
English
Optical Microscope Accessory
To obtain optimum performance of this camera and to ensure the
safety, study this manual thoroughly before operating the camera
and keep it on hand during operation of the camera.
Keep this instruction manual in a safe place.

Any copyrights relating to this manual shall belong to Olympus Soft Imaging Solutions GmbH.
We at Olympus Soft Imaging Solutions GmbH have tried to make the information contained in
this manual as accurate and reliable as possible. Nevertheless, Olympus Soft Imaging
Solutions GmbH disclaims any warranty of any kind, whether expressed or implied, as to any
matter whatsoever relating to this manual, including without limitation the merchantability or
fitness for any particular purpose. Olympus Soft Imaging Solutions GmbH will from time to time
revise the software described in this manual and reserves the right to make such changes
without obligation to notify the purchaser. In no event shall Olympus Soft Imaging Solutions
GmbH be liable for any indirect, special, incidental, or consequential damages arising out of
purchase or use of this manual or the information contained herein.
No part of this document may be reproduced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the prior written permission of
Olympus Soft Imaging Solutions GmbH.
All brands are Trademark or registered Trademark of their respective owners.
The software that can be used in combination with the camera may contain 3rd party
components, including open source software. The license information and the source code of
open source software components can be retrieved separately. Please contact your local
customer support for information on how to get the data.
© Olympus Soft Imaging Solutions GmbH
All rights reserved
Printed in Germany
510_UMA_LC30_en_03__02March2020
Olympus Soft Imaging Solutions GmbH, Johann-Krane-Weg 39, D-48149 Münster,
Tel. [phone], Fax.: [phone]

Contents
1 The OLYMPUS LC30 color camera . . . . . . . . . . . . . . . . . . . 4
1.1 Scope of supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.4 Operating and storage conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Explanation of the symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Avoiding personal injuries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.3 Avoiding device damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3 System environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 General remarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3.2 Microscopes and camera adapters . . . . . . . . . . . . . . . . . . . . . . . . .12
3.3 PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.4 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Step 1: Insert USB 3.0 PCI express card . . . . . . . . . . . . . . . . . . . . .15
4.2 Step 2: Install the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
4.3 Step 3: Connect the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5 Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.1 Contacting Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
7 Notes on conformity and disposal . . . . . . . . . . . . . . . . . . 21

CMOS color camera OLYMPUS LC30
4
1 The OLYMPUS LC30 color camera
1.1 Scope of supply
The camera's scope of supply comprises:
Item name: CAM-LC30 (E9700777)
for America / Europe / Africa
Item name: CAM-LC30-CH (E9700798)
for Japan / Asia / Australia
Camera with protective cap Camera with protective cap
USB 2.0 cable USB 2.0 cable
Installation Manual Installation Manual
USB 3.0 PCI express card with driver on CD and
power supply cable
not included in the scope of supply
1 adapter cable for the USB 3.0 PCI express
card's power supply (SATA to IDE)
not included in the scope of supply
CMOS sensor
USB port type B
Camera
USB plug type A
USB plug type B
USB 3.0 PCI express card USB 2.0 cable Installation Manual
adapter cable

1 The OLYMPUS LC30 color camera
5
Other essential
components
To be able to use the camera, you'll also need the following components:
Computer with MS-Windows operating system
Light microscope with camera adapter or something similar, for example a
macro stand
Software to operate the camera (see chapter 3.4 on page 14).
1.2 Intended use
This camera is intended to be used for the acquisition of digital images, but not for
clinical diagnostic purposes.
1.3 Specifications
Properties of the
OLYMPUS LC30
The OLYMPUS LC30 is a CMOS color camera with a high frame rate. It was
specially developed for acquisitions using light microscopy. The LC30 is of a
compact design and can be connected to all common types of light microscope by
a C-mount. The ICC profile technology guarantees an optimal color mapping.
Binning modes The OLYMPUS LC30 has three binning modes. In binning mode, the camera's
CMOS sensor combines neighboring pixels into pixel blocks. This results in a higher
sensitivity and a shorter processing time, but also in a lower resolution.
Technical data OLYMPUS LC30
Chip type CMOS
Chip size Type 1/2 Inch
Effective area (width x height) 6.55 mm x 4.92 mm
Pixel size 3.2 µm x 3.2 µm
Maximum resolution 2048 x 1532 pixels
Bit depth 24 bit (8 bit per color channel)
Read-out speed 5 – 40 MHz
Interface USB 2.0
Camera mount Standard C-Mount
Binning Resolution Max. frame rate Exposure times
Maximum reso-
lution
2048 x 1532 pixels 10 frames per second 57 µs - 750 ms
Binning 2x 1024 x 768 pixels 28 frames per second 41 µs - 268 ms
Binning 3x 680 x 512 pixels 37 frames per second 46 µs - 200 ms
Binning 4x 508 x 384 pixels 49 frames per second 46 µs - 150 ms

CMOS color camera OLYMPUS LC30
6
1.4 Operating and storage conditions
Please operate and store your camera under the following conditions:
The maximum permissible range for the ambient temperature during camera
operation is +5°C to +40°C.
The maximum permissible relative humidity during camera operation is 80 %
(condensation free).
When the camera is stored or transported, the ambient temperature must be
kept between -20°C and +60°C.
Indoor use only.
Maximum altitude: 2000 m.

2 General safety instructions
7
2 General safety instructions
The camera has been developed and produced in conformity with recognized safety
regulations. However, it is not possible to entirely rule out possible hazards for the
user, damage to the camera or microscope, or impairments of the camera's
functionality. For this reason, always read and follow the general safety instructions
and warnings before and during the installation.
2.1 Explanation of the symbols used
Personal injuries
Device damage
General notes
The warning sign and the word WARNING indicate dangerous situations that can
lead to serious injuries or even death if ignored.
The warning sign and the word CAUTION indicate dangerous situations that can
lead to light injuries if ignored.
WARNING
CAUTION
The exclamation mark and the word ATTENTION indicate situations, where
irreparable damage to the product can occur if ignored.
ATTENTION
This symbol indicates useful advice, tips for the user and important information
about the product.

CMOS color camera OLYMPUS LC30
8
2.2 Avoiding personal injuries
Electric shock due to damaged cable!
When a cable is frayed or damaged, a person touching it risks the danger of an
electric shock.
Shut off the hardware and replace the cable immediately!
Poisoning due to toxic gases!
In the case of a fire, the material of the camera can give off toxic gases. When
these are inhaled, it can cause irritation of the respiratory passages and damage
to them.
Wear respiratory protection when fighting the fire!
Tripping hazard!
Cables laid across a room can be a dangerous tripping hazard. This can cause
injuries to people and damage to equipment.
Wherever possible, lay cables along the wall or behind furniture. Fix cables that run
across the room.
WARNING
WARNING
CAUTION

2 General safety instructions
9
2.3 Avoiding device damage
Never open the camera housing!
The camera's CMOS chip is extremely sensitive. Electrostatic discharge can
permanently damage the camera.
Therefore, never, under any circumstances, open the camera housing!
Avoid vibration shocks!
Mechanical shocks and strong vibrations can damage the camera.
Don't drop the camera during installation. Make sure it is securely mounted on the
microscope. When it's not in use, store it in a safe place!
Secure microscopes with additional components!
A top-heavy microscope can tip over or fall down and result in damage to both the
camera and the microscope.
If the microscope is top-heavy or otherwise unstable, fix it to the wall!
Don't touch the protective glass!
The protective glass over the CMOS chip is extremely sensitive and must not come
into contact with bare hands or any other objects, otherwise the acquisitions will be
impaired by fingerprints or scratches.
Remove dust from the protective glass carefully with compressed air. For the
removal of dust stuck due to static electricity, ionized air is recommended.
Observe the operating conditions!
Exposure to high temperatures or humidity can damage component parts of the
camera.
Always observe the operating and storage conditions (see chapter 1.4 on page 6).
Don't expose the camera to strong light!
Exposure to strong light can cause the camera to overheat, which may cause
damage to its component parts.
Do not expose the camera to strong light (such as sunlight) for long periods of time.
Only use the USB cable that is delivered with your camera
Operate the camera only with the USB cable that is part of the camera's scope of
supply. This ensures that the EMC basic standards are fulfilled.
ATTENTION
ATTENTION
ATTENTION
ATTENTION
ATTENTION
ATTENTION
ATTENTION

CMOS color camera OLYMPUS LC30
10
3 System environment
3.1 General remarks
To acquire images with best possible quality, the microscope has to be configured
correctly. The illumination for example must be set in a way to enable image
acquisitions with appropriate exposure times.
This camera installation manual does not contain explanations on how to setup the
microscope. Please refer to the microscope manual for this information. Additionally,
the online help of OLYMPUS Stream and cellSens contains detailed information on
image acquisition.
Using the OLYMPUS LC30 in special application contexts
Using the camera with non-Olympus microscopes
The OLYMPUS LC30 can be used in combination with many available micro-
scopes. However, its performance in combination with non-Olympus microscopes
has not been tested.
Application context Explanation Countermeasure
Using objectives with
low magnification
(< 10x)
Depending on the microscope configuration,
vignetting might occur in the image if objectives
with a magnification of less than 10x are used.
Switch on the shading
correction or use a camera
adapter with a higher
magnification.
Using objectives with
high magnification
(> 40x)
The maximum exposure time might not be suffi-
cient to acquire a correctly exposed image.
Increase illumination intensity
or use a camera adapter with
a lower magnification.
Darkfield and
fluorescence
microscopy
The OLYMPUS LC30 is not suitable for
darkfield or fluorescence microscopy due to its
limited exposure range.
No countermeasure
available.

3 System environment
11
Working with
subarrays
Acquiring only a part of the image (subarray)
does not increase the frame rate, because the
OLYMPUS LC30 does not support the so-called
hardware clipping.
No countermeasure
available.
Using different Live
and Snapshot
resolutions
If Live and Snapshot resolutions differ,
measurements performed on the Live image
may be slightly displaced on the Snapshot
image (max. 2 pixels).
Use identical resolutions for
Live and Snapshot when
performing measurements.
Observing low
contrast samples
Observing highly
reflecting samples
When observing a low contrast sample or alter-
natively a highly reflecting one, a so-called spot
flare may be noticeable, if the AS diaphragm is
almost completely closed.
Switch on the shading correc-
tion or decrease illumination
intensity and open the AS
diaphragm.
Observing high
contrast samples
High contrast samples may cause the auto
exposure to fail, resulting in an underexposed
image.
In the Camera Control of the
software, define an exposure
compensation. Alternatively,
switch to manual exposure
mode.
Acquiring images with
a long exposure time
When acquiring images with a long exposure
time (e.g. > 200 ms), an increasing amount of
hot pixels may become visible.
No countermeasure
available. This phenomenon
is common to all camera
sensors and not caused by a
failure of the equipment.
Accessing USB data
storage devices
When attaching, removing or accessing USB
data storage devices, for example an external
hard drive, while the image acquisition is in
progress, a temporary drop in frame rate might
be observed.
Only use or access USB
devices when no image
acquisition is in progress.

CMOS color camera OLYMPUS LC30
12
3.2 Microscopes and camera adapters
Suitable camera
adapters
The system table shows the camera adapters you can use to connect the
OLYMPUS LC30 to many available Olympus microscopes.
Please note that you can also use microscopes that are not listed there. Basically,
all of the camera adapters with the magnification factor 0.35 or larger are suitable.
U-CMAD3
U-TV1x-2
U-TV0.5xC-3 U-TV0.63xC
GX-TV0.5xC
GX-TV0.7xC
MVX-TV0.63xC
MVX-TV1xC
Upright
microscopes
BX61/ BX51/ BX41
CX41/ CX31/ MX61
CX23/ CX33/ CX43
MX61L/ MX51
BX43/ BX46/ BX53
BX63
Inverted
microscopes
IX81/ IX71/ IX51
IX83/ IX73/ IX53
CKX53
Stereo
microscope
SZX16/ SZX10
SZX7/ SZX12
SZ61TR
Inverted
metallography
microscope
GX71/ GX51
Fluorescence
microscope
MVX10
USB cable
Camera Software with camera driver
U-TV0.35xC-2
U-TV1xC
Camera adapter

3 System environment
13
3.3 PC
3.3.1 System requirements for the computer
For optimal use, the system requirements listed in the table must be fulfilled.
Depending on the software used to operate the camera, there may be additional or
more extensive system requirements. Therefore, also check the system require-
ments for the camera you want to use.
* Make sure that the software you want to operate the camera with supports one of
the operating systems listed here.
3.3.2 Operating the camera with a laptop
Generally speaking, it is possible to operate the camera with a laptop. If the power
supply is not sufficient to operate the camera when an integrated USB interface is
used, connect the camera to the laptop via an external USB hub with its own power
supply.
System requirements
Processor (CPU) Intel® Core 2 Quad or better, Intel® i5 or higher,
Intel® XEON, compatible AMD processors
Hard disk at least 30 GB free storage space
RAM 8GB
Screen resolution at least 1920 x 1200 pixels
Drive DVD-ROM drive
Interfaces USB 2.0
Operating systems* MS-Windows 10 (32 bit or 64 bit)
MS-Windows 8.1 (32 bit or 64 bit)
MS-Windows 7 (32 bit or 64 bit)
Computer power supply > 300 W

CMOS color camera OLYMPUS LC30
14
3.4 Software
You'll need the appropriate software to acquire images with the camera. The camera
is operated optimally with this paid software from Olympus:
cellSens (software for Life Science applications)
OLYMPUS Stream (software for industry applications)
You can also operate the camera with the free software DP2-TWAIN. TWAIN is a
standardized software interface between software programs and image acquisition
hardware, such as digital cameras or scanners.
You can download the DP2-TWAIN software from this Olympus website:
https://www.olympus-lifescience.com/en/support/downloads
When the Software Downloads website is displayed, click the Camera Software
Interface entry.
A subdirectory opens. Click the Details button, next to the DP2-TWAIN Ver8.2 entry.
A file is displayed that contains further information and the download link. Click this
link.
You have to log in or register before the download can begin.

4 Installation
15
4Installation
Follow the order below when installing the camera and software.
1) Insert USB 3.0 PCI express card This card can also be used for USB 2.0
cameras.
2) Install the software
3) Connect the camera
4.1 Step 1: Insert USB 3.0 PCI express card
The camera is connected to the computer via a USB 3.0 PCI express card. Even if
your computer already has a USB 3.0 PCI express card, we strongly recommend
inserting the supplied PCI express card. When you do so, it ensures the camera's
full functionality and avoids any traffic bottlenecks.
When inserting the PCI express card, please follow the instructions given by the
manufacturer. Also pay attention to the safety instructions given below:
After you have inserted the card, make sure to note the following point.
This step is only necessary when a USB PCI express card is included in the scope
of supply (Item name: CAM-LC30 (E9700777)).
Danger of electric shock from a plugged-in computer!
When installing hardware on a PC, there is a risk of electric shock.
Be sure to disconnect the power supply before you open the PC!
Injuries caused by sharp metal edges!
The metal edges of the computer and the PCI express card are sharp. You can
injure yourself on them.
Therefore, take care when you open the computer and install the PCI express
card. It's a good idea to wear thin gloves when you do so.
WARNING
WARNING
Use the supplied power supply cable
Use the power supply cable supplied with the USB 3.0 PCI express card.
ATTENTION

CMOS color camera OLYMPUS LC30
16
4.2 Step 2: Install the software
In the following, you'll find a short overview of how to install the paid software
OLYMPUS Stream. The installation of the cellSens software is almost the same.
Detailed information on software installation can be found in the installation manual
that is delivered with the software.
It is important that you select the camera you are using when installing the software.
The correct camera driver will then be automatically installed.
Do the following:
1) Close all running application programs, including the application programs that
run in the background, for example, antivirus software.
2) Browse to the directory that contains the software and double-click the
setup.exe file.
The installation wizard starts.
Follow the
instructions of the
installation wizard.
3) Follow the instructions of the installation wizard, provide the requested informa-
tion, then click the Next button to continue.
4) In the Image Source Selection dialog box, select the Olympus manufacturer.
Select the LC30 check box.
5) At the end of the installation, the files are copied to the PC. You can then
finalize the installation procedure.
Log on as an administrator
To be able to install software, you must log on to your computer as an adminis-
trator. If you don't have administrator rights, contact your company's authorized IT
specialist.

4 Installation
17
The software and the camera driver have now been installed on your PC.
4.3 Step 3: Connect the camera
You can connect the camera to the microscope and computer as soon as you've
installed the software. Do the following:
1) Remove the camera's protective cap.
2) Mount the camera onto the microscope's camera adapter.
3) Plug the end of the USB cable with the type B plug into the camera socket.
Make sure that you only use the USB cable that is delivered with your camera.
The proper functioning of the camera can only be guaranteed when this cable
is used.
4) Plug the end of the USB cable with the type A plug into a slot of the USB 3.0
PCI express card inserted with step 1.
Camera
adapter
OLYMPUS Monitor
PC
Microscope
LC30
Make sure that the plug is the right way round
The USB plugs are not symmetrical. Make sure that the plugs are the right way
round when you plug them into the ports.
ATTENTION

CMOS color camera OLYMPUS LC30
18
After connecting the camera to your PC, the camera driver is automatically
installed. As a rule, this installation only takes a few seconds. Please pay
attention to the icons displayed in the status bar.
5) Wait until the installation of the camera driver has been finished.
The camera has now been registered as a device and is ready for use. Now
the camera driver appears in the Device Manager.
6) Start the software that has already been installed.

5 Care and maintenance
19
5 Care and maintenance
When correctly handled, the camera has a long life span and is to a large extent
maintenance-free. The full functionality is assured when you observe the care
instructions.
Cleaning the protective glass
To clean the camera's protective glass, use a common blower bulb to blow dust
away and wipe it gently with cleaning paper (or clean gauze).
In the case of fingerprints or oil smudges on the protective glass, wipe it with clean
gauze moistened with pure alcohol.
Cleaning the housing
Parts other than the glass components should be cleaned by wiping with a clean
cloth. Do not use organic solvents to remove major stains. Use a soft cloth
moistened with a neutral detergent solution.
Danger of fire when using alcohol!
Alcohol is highly flammable and can cause fires.
Make absolutely sure that the alcohol doesn't come into contact with open flames
or electric components.
WARNING
Do not dismantle any parts!
The camera is made up of parts that are easily damaged and their disassembly
can quickly cause a malfunction or reduced performance.
Therefore, do not dismantle any parts of the camera.
ATTENTION

CMOS color camera OLYMPUS LC30
20
6 Troubleshooting
The following text describes typical errors that may occur when using the camera.
6.1 Contacting Customer Service
Please contact your local OLYMPUS support if you have any questions about the
product. The addresses can be found on the following websites:
Life Science Solutions
https://www.olympus-lifescience.com/en/contact-us/
Industrial Solutions
https://www.olympus-ims.com/en/contact-us/
Error Possible causes Solution
The camera can't be
found
The camera was not
selected during the installa-
tion of your software.
The camera driver has to be installed. To do so, start the
installation wizard for the software again.
Browse to the directory that contains the cellSens or
OLYMPUS Stream software and double click the
setup.exe file. The installation wizard starts.
In the next dialog boxes, select the options Install or
maintain imaging software > Maintain imaging software >
Provide licenses, update installation.
When the Image source selection dialog box is displayed,
select the Olympus manufacturer and select the check
box next to the camera you want to use for image acqui-
sition.
Follow the further instructions of the installation wizard
and finish the installation.
A faulty image appears A power saving mode in the
BIOS prevents image
acquisition.
If possible, ask your system administrator to switch off all
power saving modes in the BIOS of your PC.
Please note:
Changes in the BIOS (Basic Input Output System) can
have a negative effect on the way your computer
operates. Make sure that only qualified personnel make
changes to the settings in the BIOS.
When starting the live-
image, the “Camera time-
out “error message
appears.
The USB cable you are
using is too long.
Use the supplied USB cable.
Other processes that
require a lot of processing
power are running at the
same time.
Check which other processes are running and end those
that are not required.
