MAINTENANCE / ON-SITE - MANUAL
Electro Surgical Generator
ESG-400
7.022.211 / ISSUE 5

ESG-400
INTRODUCTION
Introduction
The intended use depends on the approval of the country. Refer to the instructions for use of the electrosurgical
unit.
Maintenance instructions
This maintenance manual contains essential information on using and maintaining this electrosurgical
generator safely and effectively. Instructions for the operation of this electrosurgical generator and related
danger, warnings and cautions concerning electrosurgery are beyond the scope of this maintenance manual.
Before using and maintaining, thoroughly review this manual and the instructions for use or maintenance
manuals of all equipment which will be used during maintenance. Use the equipment as instructed. Keep this
manual in a safe, accessible location. If you have any questions or comments about any information in this
maintenance manual, contact Olympus.
Signal words
The following signal words are used throughout this maintenance manual:
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
d
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury. It may also be used to alert against unsafe practices
or potential equipment damage.
NOTE Indicates additional helpful information.
User qualifications
The user must have received appropriate training in using this electrosurgical generator. The following
instructions are for use by qualified personnel only. Use of this maintenance manual by other individuals is
prohibited. The training will be provided by authorized representatives of Olympus during installation and
commissioning.
NOTE
The user must have received appropriate training in using, servicing,
adjustment, updating and upgrading this electrosurgical generator.
Federal Law of the USArestricts this device to use by, or on the order of, a physician.
7.022.211 / ISSUE 5 2 / 110 Introduction

ESG-400
Precautions
High frequency leakage current or spark discharge may cause user burns.
Follow the dangers, warnings and cautions given below when handling and servicing this electrosurgical unit.
This information is to be supplemented by the dangers, warnings and cautions given in each chapter.
User
-related error prevention
WARNING Improper use
The safety and effectiveness of electrosurgical interventions depend not only o
n the design of
the equipment used, but also to a major extent on factors which are under the control of the
user. It is therefore extremely important to read, understand and follow the instructions supplied
with the electrosurgical generator and the accessories in order to ensure safety and
effectiveness.
Always use the electrosurgical generator as outlined in this
maintenance manual. Improper use
will not only impede functions and prevent optimum performance, but may cause equipment
damage and
/ or compl
ications. Before each use, always inspect the equipment as outlined in
this
maintenance manual.
WARNING Annual safety checks / Inspection
The electrosurgical generator and the footswitch must undergo a safety check in yearly intervals
in accordance with
the national statutory regulations (refer to chapter 7 “Inspection”).
Environmental
conditions
CAUTION Interference of the unit with other equipment
Be sure that this electrosurgical unit is not used adjacent to or stacked with other equipment
(other than the components of this electrosurgical unit or system) to avoid electromagnetic
interference.
Before use, thoroughly confirm the compatibility of all equipment.
To ensure electrical safety, the electrosurgical unit should not be used in conjunction w
ith:
•Electrical equipment whose safety against leakage current is not guaranteed.
•Electrosurgical equipment whose safety in combined use is not guaranteed.
The electrosurgical generator complies with the electromagnetic compatibility (EMC) standard.
Never
theless, when the electrosurgical generator is active it may disturb neighboring electronic
equipment. If an auxiliary computer system is in use together with the electrosurgical generator
and endoscopic imaging techniques, the image on the monitor might f
reeze or blackout. Follow
the instructions in “Electromagnetic Compatibility (EMC) information” in the Appendix of the
instruction for use regarding electromagnetic ambient conditions.
Never loop the cords (active cord, bipolar cord, neutral electrode cor
d) or bundle cords together
with cords belonging to other medical equipment. The high frequency signals or spark discharge
noise generated by the unit may interfere with the operation of other medical equipment.
Do not use the electrosurgical unit in a location exposed to strong electromagnetic radiation
(microwave or short
-
wave medical treatment equipment, Magnetic Resonance Imaging, radio or
mobile phone equipment). Electrosurgical unit malfunction can occur.
CAUTION Unsuitable temperature and humidity
The electrosurgical
generator
should only be used under the conditions as described in chapter
1
-3 (Limitations). Use under other conditions may impede normal performance and / or result in
equipment damage.
7.022.211 / ISSUE 5 3 / 110 Introduction

ESG-400
Accessories
WARNING Mechanical stress
Do
not apply excessive bending, straining, or squeezing force to any cords. It may cause
malfunction.
CAUTION Non-compatible accessories and accessory damage
The electrosurgical generator shall only be used with compatible accessories. When connecting
accessories (cords, electrodes, HF instruments) avoid output settings where the maximum
output voltage of the electrosurgical generator may exceed the rated accessory voltage (refer to
“Mode characteristics”, “Output characteristics” in the Appendix of the ins
truction for use, and the
instruction manual of the accessory). For a list of compatible neutral electrodes, refer to
“Specifications” in the Appendix of the instruction for use.
Before use, the electrosurgical unit and accessories must be examined for damage. All
communication cables and its plugs must be free of scratches and cracks. Cables and
accessories with damaged insulation or connections must not be used.
Electric shock
WARNING Grounding failure
To prevent the risk of electric shock, the housing of the electrosurgical unit must be grounded.
Always connect the power cord plug to a properly grounded wall outlet. Do not use a
3
-pin / 2-pin adapter, as it can impair safe operation of the unit.
WARNING User shock
To prevent user shock, malfunction
and damage of the electrosurgical unit, keep liquids away
from all electrical equipment.
When taking measurements or troubleshooting of the electrosurgical unit, take appropriate
precautions, such as using isolated tools and equipment, using the “one han
d rule,” etc.
CAUTION Injury during servicing
When the housing is opened, there is a danger of electric shock. The unit must only be serviced
by
authorized technicians.
Burns
WARNING User
The maximum output voltage characteristics of the electrosurgi
cal generator are shown in the
diagrams in “Output characteristics” in the Appendix of the instruction for use. When setting the
power level, first set it to a low level and increase it gradually. If the output is initially set to a high
level, the electro
de’s insulation may be damaged and cause user and /
or patient burns.
However, certain modes may present an unacceptable risk at low output power settings. For
example, with the PulseCut fast mode or PulseCut slow mode, the risk of an excessive thermal
effect rises if the output power setting is too low. Therefore, it is recommended that you perform
basic testing before using the electrosurgical generator. If the instruction manual of the HF
instrument to be used stipulate a rated voltage, the output should
be set so that it does not
exceed that voltage.
High frequency, high voltage signals that can cause severe burns are present in the
monopolar
/ bipolar sockets described in this maintenance manual. Take appropriate precautions
when testing and troublesho
oting this area of the electrosurgical unit.
7.022.211 / ISSUE 5 4 / 110 Introduction

ESG-400
Fire
/ Explosion
DANGER Ignitable anaesthetics / fire supporting gases
The risk of flammable gases or other materials being ignited exists with any contact of electrical
energy. Precautionary measures must be taken to keep flammable materials and substances
away from an active electrosurgical unit (do not use flammable
anesthetics, nitrous oxide or
oxygen). Otherwise, explosion or fire may result and cause serious injuries. This electrosurgical
uni
t is not explosion-proof. Do not use the unit within an explosion zone.
WARNING Ignitable cleaning- and disinfection agents
Flammable agents used for cleaning and disinfection must be allowed to evaporate before the
electrosurgical unit is used and servi
ced.
Non
-flammable agents should be used for cleaning and disinfection wherever possible.
WARNING Risk of fire
Disconnect the power plug before changing the fuses!
Replace fuses as marked. The fuses
must only be replaced by
authorized technicians.
Haz
ards and complications
WARNING Contamination
The electrosurgical unit may be contaminated with infections materials; therefore, all surfaces of
the unit’s housing should be cleaned before servicing according to chapter
1-8 (Cleaning).
WARNING Output performance
Should any abnormal output be suspected during operation, immediately terminate the use of
the equipment by releasing the footswitch. If the footswitch does not react, switch off the
electrosurgical unit. Otherwise, malfunction of the equipment m
ay cause an unintended increase
in output.
WARNING Service persons
Take additional precautions for service technicians, when using the unit’s service operation
mode (see chapter 15, Service operation mode).
CAUTION Unit defect
To prevent electrosurgic
al unit damage, never short-
circuit electrodes (accessories, neutral
electrodes).
In the event of a defect or malfunction in the unit, an undesirably high output power may be
emitted.
DANGER Unit defect
Never use the electrosurgical unit if an abnormality is suspected.
Repair and Maintenance
CAUTION Repair
Repairs must only be carried out by Olympus or a firm authorized by Olympus.
CAUTION Maintenance
Preventive maintenance (inspection / periodic safety check) must only be carried out by a
qualifie
d person / technician.
7.022.211 / ISSUE 5 5 / 110 Introduction

ESG-400
Copyright
©2011 Olympus Winter & Ibe GmbH. All rights reserved.
Unauthorized reproduction or distribution in part or in whole is prohibited.
Trademarks
OLYMPUS is a registered trademark of the Olympus Corporation.
The company names, product names, and proprietary technical terms in this document are the trademarks or
registered trademarks of their respective owners.
7.022.211 / ISSUE 5 6 / 110 Introduction

ESG-400
CONTENT
INTRODUCTION................................................................................................................2
CONTENT..........................................................................................................................7
CHAPTER 1: PRODUCT SPECIFICATIONS ....................................................................9
1 OUTLINE ......................................................................................................................10
1-1 Intended Use....................................................................................................................................10
1-2 Compatibility.....................................................................................................................................10
1-3 Expected service life........................................................................................................................ 10
2 FEATURES...................................................................................................................11
2-1 Application Modes............................................................................................................................ 11
2-2 Accessories......................................................................................................................................12
3 LIMITATIONS................................................................................................................13
4 SPECIFICATIONS ........................................................................................................14
4-1 ELECTROSURGICAL GENERATOR ESG-400 (REF: WB91051W) ..............................................14
4-2 Power cords (4.5 m angled plug)..................................................................................................... 15
4-3 Footswitch (REF: WB50402W, double pedal) .................................................................................16
4-4 Footswitch (REF: WB50403W, single pedal, optional).................................................................... 16
4-5 Neutral electrode cable “P-cord” (REF: MAJ-814, optional)............................................................ 16
4-6 Communication cable 0.25 m (REF: MAJ-1871, optional) ..............................................................17
4-7 Communication cable 10 m (REF: MAJ-1872, optional) ................................................................. 17
4-8 Adapter for UHI-2/3 (REF: MAJ-1873, optional)..............................................................................17
5 NAME AND FUNCTION OF EACH PART....................................................................18
5-1 Symbols and descriptions................................................................................................................ 18
5-1-1 Safety related symbols............................................................................................................18
5-1-2 Front panel .............................................................................................................................. 19
5-1-3 Touch screen...........................................................................................................................19
5-1-4 Rear panel...............................................................................................................................21
5-2 Front panel.......................................................................................................................................22
5-3 Rear panel........................................................................................................................................24
5-4 Bottom panel.................................................................................................................................... 25
5-5 All screen .........................................................................................................................................25
5-6 Set screen........................................................................................................................................26
5-7 Mode screen .................................................................................................................................... 27
5-8 Footswitch with two pedals .............................................................................................................. 28
5-9 Footswitch with one pedal (optional)................................................................................................28
5-10 Neutral electrode cable “P-cord” (optional)...................................................................................... 29
6 CONNECTOR...............................................................................................................30
6-1 Docking Connector .......................................................................................................................... 30
6-2 Monopolar Standard 1......................................................................................................................30
6-3 Monoploar Standard 2 (Erbe)........................................................................................................... 30
6-4 Bipolar Standard 3............................................................................................................................ 30
6-5 Monopolar Neutral Electrode...........................................................................................................31
6-6 Foot switch 1 (SIP/SOP).................................................................................................................. 31
6-7 Foot switch 2 (SIP/SOP).................................................................................................................. 32
7 SYSTEM DIAGRAM .....................................................................................................33
8 CLEANING, STORAGE AND DISPOSAL ....................................................................34
8-1 Cleaning...........................................................................................................................................34
8-2 Storage............................................................................................................................................. 35
8-3 Disposal of the unit .......................................................................................................................... 35
CHAPTER 2: BLOCK DESCRIPTION.............................................................................37
1 BLOCK DESCRIPTIONS..............................................................................................38
1-1 Motherboard..................................................................................................................................... 39
1-2 HVPS Board..................................................................................................................................... 41
1-3 Generator board............................................................................................................................... 41
1-4 Relay Board ..................................................................................................................................... 41
1-5 Front Panel....................................................................................................................................... 42
CHAPTER 3: REPAIR SYSTEM......................................................................................43
7.022.211 / ISSUE 5 7 / 110 Content

ESG-400
1 ESG-400 MAIN UNIT....................................................................................................44
2 BOARD COMPATIBILITY.............................................................................................44
3 OPTIONAL ACCESSORIES.........................................................................................44
3-1 WB50402W (Footswitch with two pedals) ....................................................................................... 44
3-2 WB50403W (Footswitch with one pedal)......................................................................................... 44
3-3 MAJ-814 (Neutral electrode cable “P-cord”)....................................................................................44
4 PRECAUTIONS ON FUNCTION AND OPERATION SETTINGS.................................44
4-1 General Precautions ........................................................................................................................ 44
CHAPTER 4: TROUBLESHOOTING ..............................................................................45
1 GENERAL.....................................................................................................................46
2 NEUTRAL ELECTRODE OPERATION........................................................................47
3 ERROR SCREEN, CODES AND MEASURES.............................................................48
3-1 What to do when no error code is displayed....................................................................................50
3-2 What to do when an error code is displayed.................................................................................... 54
CHAPTER 5: INSPECTION.............................................................................................73
1 JIGS, TOOLS, AND MEASURING EQUIPMENT FOR INSPECTION..........................74
2 INSPECTION PROCEDURES......................................................................................75
2-1 Visual inspection of the electrosurgical generator and accessories................................................ 76
2-2 Verifying the contact quality monitor function .................................................................................. 80
2-3 Checking the DC resistance (according to IEC 60601-2-2)............................................................. 82
2-4 Checking the earth resistance (according to IEC 60601-1 and IEC 62353)....................................82
2-5 Checking the earth leakage current (according to IEC 60601-1) ....................................................82
2-6 Checking the patient leakage current (according to IEC 60601-1)..................................................83
2-7 Checking the current and power consumption and output waveform..............................................84
2-8 Checking the high frequency leakage current (according to IEC 60601-2-2)..................................86
2-8-1 Measurement of the monopolar high frequency leakage current under loaded condition...... 86
2-8-2 Measurement of the monopolar high frequency leakage current under unloaded condition..88
2-8-3 Measurement of the bipolar high frequency leakage current under loaded condition............90
2-8-4 Measurement of the bipolar high frequency leakage current under unloaded condition........92
2-9 Checking the output power..............................................................................................................94
2-10 Checking for certain features and error messages..........................................................................94
2-11 Final test...........................................................................................................................................95
2-11-1 Self test.................................................................................................................................... 95
2-11-2 Display and sound check ........................................................................................................95
2-11-3 Functionality of push buttons .................................................................................................. 95
2-11-4 Communication test................................................................................................................. 95
2-11-5 Restore of output power settings ............................................................................................96
2-12 Inspection label (For applicable markets)........................................................................................96
3 INSPECTION CARD.....................................................................................................97
CHAPTER 6: DEVICE MENU........................................................................................103
1 SAFETY TEST............................................................................................................104
2 SOFTWARE VERSION...............................................................................................105
CHAPTER 7: REVISION HISTORY...............................................................................107
3 REVISION HISTORY ..................................................................................................108
7.022.211 / ISSUE 5 8 / 110 Content

ESG-400
CHAPTER 1: PRODUCT SPECIFICATIONS
1 OUTLINE ......................................................................................................................10
1-1 Intended Use....................................................................................................................................10
1-2 Compatibility.....................................................................................................................................10
1-3 Expected service life........................................................................................................................ 10
2 FEATURES...................................................................................................................11
2-1 Application Modes............................................................................................................................ 11
2-2 Accessories......................................................................................................................................12
3 LIMITATIONS................................................................................................................13
4 SPECIFICATIONS ........................................................................................................14
4-1 ELECTROSURGICAL GENERATOR ESG-400 (REF: WB91051W) ..............................................14
4-2 Power cords (4.5 m angled plug)..................................................................................................... 15
4-3 Footswitch (REF: WB50402W, double pedal) .................................................................................16
4-4 Footswitch (REF: WB50403W, single pedal, optional).................................................................... 16
4-5 Neutral electrode cable “P-cord” (REF: MAJ-814, optional)............................................................ 16
4-6 Communication cable 0.25 m (REF: MAJ-1871, optional) ..............................................................17
4-7 Communication cable 10 m (REF: MAJ-1872, optional) ................................................................. 17
4-8 Adapter for UHI-2/3 (REF: MAJ-1873, optional)..............................................................................17
5 NAME AND FUNCTION OF EACH PART....................................................................18
5-1 Symbols and descriptions................................................................................................................ 18
5-1-1 Safety related symbols............................................................................................................ 18
5-1-2 Front panel .............................................................................................................................. 19
5-1-3 Touch screen........................................................................................................................... 19
5-1-4 Rear panel...............................................................................................................................21
5-2 Front panel.......................................................................................................................................22
5-3 Rear panel........................................................................................................................................24
5-4 Bottom panel.................................................................................................................................... 25
5-5 All screen .........................................................................................................................................25
5-6 Set screen........................................................................................................................................26
5-7 Mode screen .................................................................................................................................... 27
5-8 Footswitch with two pedals .............................................................................................................. 28
5-9 Footswitch with one pedal (optional)................................................................................................28
5-10 Neutral electrode cable “P-cord” (optional)...................................................................................... 29
6 CONNECTOR...............................................................................................................30
6-1 Docking Connector .......................................................................................................................... 30
6-2 Monopolar Standard 1......................................................................................................................30
6-3 Monoploar Standard 2 (Erbe)........................................................................................................... 30
6-4 Bipolar Standard 3............................................................................................................................ 30
6-5 Monopolar Neutral Electrode...........................................................................................................31
6-6 Foot switch 1 (SIP/SOP).................................................................................................................. 31
6-7 Foot switch 2 (SIP/SOP).................................................................................................................. 32
7 SYSTEM DIAGRAM .....................................................................................................33
8 CLEANING, STORAGE AND DISPOSAL ....................................................................34
8-1 Cleaning...........................................................................................................................................34
8-2 Storage............................................................................................................................................. 35
8-3 Disposal of the unit .......................................................................................................................... 35
7.022.211 / ISSUE 5 9 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
1 Outline
1-1 Intended Use
The intended use depends on the approval of the country. Refer to the instructions for use of the electrosurgical
generator.
1-2 Compatibility
This product can be used in combination with the products listed in compatibility table.
1-3 Expected service life
The expected service life is 10 years.
7.022.211 / ISSUE 5 10 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
2 Features
The ESG-400 is a reusable, non-sterile electrosurgical generator with different mono- and bipolar cutting and
coagulation modes. The maximum output power is 320 W.
On the front side it features a touch screen display that displays the connection status of accessories and
peripherals connected to the electrosurgical generator. It is also used to show and modify the output settings
(e.g. mode, output power, effect) as well as to control other functions (e.g. save settings).
In addition the ESG-400 has a bipolar socket, two monopolar sockets, a neutral electrode socket, and a
universal socket to connect applicators with instrument recognition. The power switch turns the generator on
and off.
Two contact quality indicators (one for split and one for non-split electrodes) are green illuminated if neutral
electrodes are correctly connected. Three additional push buttons allow recalling a previously saved setting
(Select Procedure), to assign the footswitches to specific output sockets (Footswitch), and to control several
other functions (Menu), e.g. select language, touch tone control, output volume, or brightness.
On the rear panel the volume control, a ventilation hole, the equipotential bonding point, the AC power socket,
and two footswitch sockets can be found. Furthermore, for the connection of peripheral equipment 26-pin plugs
respectively 14-pin plugs can be connected to the LINK-IN or to the LINK-OUT socket.
On the bottom panel, a docking socket is featured. It can be used to connect the ESG-400 directly to the
USG-400 and upcoming devices. The ESG-400 is compatible with the new USG-400 ultrasonic generator to
enable the use of combined (US + HF) instruments.
2-1 Application Modes
Monopolar Cut:
•PureCut (Cutting of varying tissue structures; 3 Effects)
•BlendCut (Cutting of varying tissue structures; 3 Effects)
•PulseCut slow (Intermittent cutting; 3 Effects)
•PulseCut fast (Intermittent cutting; 3 Effects)
Monopolar Coagulation:
•SoftCoag (Coagulation of tissue with little sticking and carbonization; 3 Effects)
•ForcedCoag (Fast and effective coagulation; 3 Effects)
•SprayCoag (Contact-free surface coagulation with little penetration depth; 3 Effects)
•PowerCoag (Fast and effective coagulation with increased dissection capabilities; 3 Effects)
7.022.211 / ISSUE 5 11 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
Bipolar Cut:
•BipolarCut (All bipolar cutting procedures of tissue structures; 3 Effects)
•SalineCut (Cutting in conductive fluid; 3 Effects; only available via UNIVERSAL socket)
•PK PureCut (Cutting of varying tissue structures; 3 Effects; only available via UNIVERSAL socket)
•PK SoftCut (Cutting of varying tissue structures; 3 Effects; only available via UNIVERSAL socket)
•PK LoopCut (Cutting of varying tissue structures, especially fibroid tissue; 3 Effects; only available via
UNIVERSAL socket)
•PK MorceCut (Cutting of varying tissue structures, especially fibroid tissue; 3 Effects; only available
via UNIVERSAL socket)
Bipolar Coagulation:
•BiSoftCoag (Coagulation with little sticking and carbonization; 3 Effects)
•AutoCoag (Coagulation with little sticking and carbonization; 3 Effects)
•SalineCoag (Coagulation in conductive fluid; 3 Effects; only available via UNIVERSAL socket )
•HardCoag (Controlled tissue coagulation; 3 Effects)
•RFCoag (Controlled deep tissue coagulation; with and without RCAP)
•FineCoag (Coagulation of tissue with little sticking and carbonization; 1 Effect)
•PK Coag (Coagulation of tissue with little sticking and carbonization; 3 Effects)
•PK SoftCoag (Coagulation of tissue with little sticking and carbonization; 3 Effects)
•PK AutoCoag (Controlled tissue coagulation; 1 Effect)
The modes have preset power levels that may be customized by the user in a defined range.
2-2 Accessories
Footswitch Double Pedal (WB50402W): It has a blue pedal that is used to activate the selected coagulation
mode and a yellow pedal that is used to activate the selected cutting mode.
Footswitch Single Pedal (optional; WB50403W): It has a blue pedal that is used to activate the selected
coagulation mode
P-Cord (optional; MAJ-814): The P-cord is used to connect a patient plate to the ESG-400.
7.022.211 / ISSUE 5 12 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
3 Limitations
(1) Use this product under the supervision of a doctor at a medical facility.
(2) Do not use this product in combination with the products other than those designated by Olympus.
(3) This product shoul be used, transported or stored in the following environment.
Operation
environment
Temperature
+ 10…+ 40°C
Relative humidity
30…85%, non-condensing
Atmospheric pressure
70…106 kPa
Transportation and
storage
environment
Temperature
- 25…+ 60°C
Relative humidity
10…85%, non-condensing
Atmospheric pressure
50…106 kPa
7.022.211 / ISSUE 5 13 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
4 Specifications
4-1 ELECTROSURGICAL GENERATOR ESG-400 (REF: WB91051W)
Power supply Voltage range 100…120 V~ / 220…240 V~
Frequency
50 / 60 Hz
Maximum input power 1500 VA
Power fuse 10 A (only FST-
series from
Schurter)
Power connection line IEC 60320-1 / C13
Maximum length: 4.5 m
Terminal for potential
equalization Yes
Size, weight and
packaging Width x Depth x Height 370 × 465 × 156 mm
Volume
25752 cm³
Weight of generator
12.5 kg
Weight of packaging 2.3 kg
Type of packaging
Cardboard and expanded
polypropylene material
Classification
Protection class according
to IEC 60601-1 CF, Class I
Classification according to
MDD 93/42/EEC IIb
Output High frequency functions Monopolar / Bipolar
High frequency 430 kHz ±20%
Maximum high frequency
power 320 W
All modes 25% duty cycle
(e.g. 10 s activated /
30 s
deactivated)
RFCoag (with or without
RCAP) 100% duty cycle
7.022.211 / ISSUE 5 14 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
Sockets MONOPOLAR 1 3-pin (∅4 mm),
Valleylab standard;
coaxial (∅8 mm),
Bovie standard
MONOPOLAR 2 3-pin (∅4 mm),
Valleylab standard;
coaxial (∅5 / 9 mm),
Erbe standard
BIPOLAR 2-pin (∅4 mm,
pin spacing 28.8 mm),
Valleylab standard;
coaxial
(∅inner 8 mm, ∅outer 4 mm),
Erbe standard
UNIVERSAL 7-pin, Olympus standard
Neutral electrode Single or split, 10 mm plug
Contact quality
monitor (CQM)
Allowable resistance range
for split type neutral
electrodes
10...155 Ω ±15 Ω
Allowable resistance range
for non-
split type neutral
electrodes
< 10 Ω ±5 Ω
4-2 Power cords (4.5 m angled plug)
Power cords WA95621A Many European countries
Type E/F
WA95622A
USA, Canada and other
countries
Type B
WA95623A United
Kingdom and other
countries
Type G
7.022.211 / ISSUE 5 15 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
4-3 Footswitch (REF: WB50402W, double pedal)
Classification
Protection class according
to IEC 60529 IPX8 (except the plug section)
Size, weight and
packaging Width x Depth x Height 350 × 185 × 65 mm
Weight of footswitch 1.9 kg
Length of cord 4 m
Weight of packaging 0.5 kg
Type of packaging
Cardboard material
4-4 Footswitch (REF: WB50403W, single pedal, optional)
Classification
Protection class according
to IEC 60529 IPX8 (except the plug section)
Size, weight and
packaging
Width x Depth x Height
175 × 185 × 50 mm
Weight of footswitch 1.6 kg
Length of cord 4 m
Weight of packaging 0.5 kg
Type of packaging Cardboard material
4-5 Neutral electrode cable “P-cord” (REF: MAJ-814, optional)
Size Weight 0.14 kg
Length of cord 3.1 m
7.022.211 / ISSUE 5 16 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
4-6 Communication cable 0.25 m (REF: MAJ-1871, optional)
Size Weight 0.05 kg
Length of cord 0.25 m
4-7 Communication cable 10 m (REF: MAJ-1872, optional)
Size Weight 0.5 kg
Length of cord 10 m
4-8 Adapter for UHI-2/3 (REF: MAJ-1873, optional)
Size Width x Depth x Height 100 × 77 × 42 mm
Weight 0.35 kg
Compatible cables MAJ-1871, MAJ-1872
7.022.211 / ISSUE 5 17 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
5 Name and Function of each part
5-1 Symbols and descriptions
5-1-1 Safety related symbols
Date of
manufacture
CE marking
Non-ionizing electromagnetic radiation
Output insulated from earth
(connection for neutral electrode)
Caution, read
instructions
Refer to
instructions
Defibrillation proof type CF applied
part (cardiac application)
Waste electrical and electronic
equipment
cTUVus marking
Manufacturer
Potential equalization terminal
Fuse rating
Type plate
7.022.211 / ISSUE 5 18 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
5-1-2 Front panel
Power on / off
Neutral electrode – non-split type
Neutral electrode – split type
Select procedure
Footswitch
Menu
BIPOLAR socket
MONOPOLAR 1 socket
UNIVERSAL socket
MONOPOLAR 2 socket
5-1-3 Touch screen
Double footswitch
Single footswitch
Autostart
Plus
Minus
Return
OK
Cancel
7.022.211 / ISSUE 5 19 / 110 Chapter 1: PRODUCT SPECIFICATIONs

ESG-400
Save procedure
Delete procedure
Languages
Touch tone on
Touch tone off
Software version
Safety test
Service
Volume
Brightness
Select procedure (in title line)
Menu (in title line)
Toggle
Previous
Next
Numeric
Alphabetic
Uppercase / lowercase
Backspace
Caution
Communication indicator
7.022.211 / ISSUE 5 20 / 110 Chapter 1: PRODUCT SPECIFICATIONs
