Omega National NPT8730K User manual

Important Notes
•Always read instructions completely and carefully before beginning assembly.
•Remove and check contents for concealed damage and or missing parts.
•Keep the original carton and packing material, which are required for all returns.
Step 1: Using the paper template provided align it with the face frame
of the corner cabinet and drill 2 holes 1/16” in diameter at the
marked locations. The template will set the Easy Access Cor-
ner Pantry 1/4” back from the inside of the face frame. Each
cabinet varies so check the fit of the unit inside the cabinet
before drilling any holes.
4ea.: #8 X 1” Flat Head Wood Screw Aluminum Bearing
Plastic Detent
Easy Access
Corner Pantry 4ea.: 1/4-20 Flat Head
Machine Screw
Meets BHMA Class 1 Specifications
Patents Pending
Form OME-093, 03/2014
©Omega National Products
Cabinet Bottom (Not Included)
Drawer

Step 2: Locate the Bearing with the bottom up, Make sure the plas-
tic catch is engaged. Attach to the shelf with 2 - #8 x 1” Flat
Head Wood Screws, through the outer race of the bearing.
Make sure the screws go into the 2 holes drilled in Step 1.
Step 3: Remove the drawer from the Easy Access Corner Pantry by
pulling it out and up while depressing the 2 latches on the
underside of the drawer.
Step 4: Temporarily install the Easy Access Corner Pantry by attaching
it to the inner race of the bearing with at least 2 - 1/4 - 20 X 1
flat head machine screws. Spin it and make sure it clears the
inside of the cabinet and stops in the correct position. Make
any necessary adjustments to the bearing location if it does
not.
Step 5: Remove the Easy Access Corner Pantry and attach the bear-
ing with 2 more #8 x 1” Flat Head Wood Screws
Step 6: Install the Easy Access Corner Pantry by attaching it to the
inner race of the bearing with 4 ea. 1/4 - 20 X 1 flat head ma-
chine screws. Spin it and make sure it clears the inside of the
cabinet and stops in the correct position
Step 7: Set the drawer on top of the slide rails and push in to the back
until you hear the catches engage.
