Omega M-2 User manual

Contents
Thank you for choosing our product. Please read this operating
instructionsbook thoroughly beforeoperatingthemassage chair,and
afterthecarefulreading, pleasekeeptheinstructionswhere youcan
pick iteasily.
Preparations Before Using ....as........................ 5
Names & Function of Remote Control Button... ... .--6

Cautions on Safety
Don't let the baby or child use or play on it.
If the wire is broken or it doesn't work, please stop using it.
Turn off the electricity and pull out the plug at once. Please
consult the dealer or go to the maintenance place first.
If you feel uncomfortable or feel bad at the strong stimulus
when you're using, or feel the machine abnormal, please
cut off the electricity and stop using it.
Don't use it when the surface is broken.Pleaseconsult the
dealer or go to the maintenance place first.
If you have following problems, please consult your doctors
before using:
Accepting treatment at present or feel bad, vertebra abnormal,
vertebra crooked, having acute disease, hyperplasia,
intervertebral disc protruding, pregnant, having menstruation,
having high fever and so on.
Don't put the hand into the working part of the Chair.
Before you adjust the angle, make sure there is nothing or
nobody behind the machine, and there is enoughroom
behind it.
Don't use it when bare - backedor wet over.
Don't use it in the bathroom where there is a lot of moisture.
Besides, don't let the remote control drop into the water.
Please keep away from direct sunlight or heating appliances
like heat stove.
Don't use diluents, volatile oil or bleaching powder will
cause cloth change color or damaged.

Functions & Specialties
Inside the back part, there is an exclusive walking massage mechanism with
the coverage of the whole back; the mechanism can massage automatically in
the
4 mobile scopes from neck to waist; thru the button control, itcan also stop
at any suitable spot. This mechanism has a strong function; the operation thru
the controller can realize the following modes:
1 .The kneading and pinchingmassage
This exclusive mechanism can imitate the specializedmassagist to pull, press,
knead and pinch the painful and numb muscles on the back with gentle excitation
to the muscles to restore their elasticityand strengthenthe blood circulation on the
massaged spot, and let the body to relax in a limited time.
2.Swaying-massage
Not only does relaxingswaying - massageadjust the position of spinal column and
shake each vertebra and ligament, but also rectifies spinal column, stimulates
sympathetic nerve, activatesthe cells and promotesblood
- cycle.
3.The fingerpressingmassage
Inside the mechanism there is a finger pressing wheel that imitates the hand
finger pressingand carrieson the pressing
- relaxingmotions repeatedlyon the
importantpoints on human back with suitable force. The 3 adjustablefinger widths
help excite the back effectivelyto allow for smoother blood flow, fully activated human
potentialsand fortifiedhuman immunity.
4.The vibratingmassage
The vibratingmassage machine at the cushioncan produce durative massage
vibrationwave which forms an efficientexcitationto the leg, promote the blood
circulationin the capillaryvessels and relieve the tirednessquickly.
5.Thigh-massage
Eight massage - heads are equipped at the thigh part of the cushionto give soft but
powerfulmassage, which helps promptly mitigate ache in the thigh.
6.Calf-massage
Kneading - massage: The equipment can do kneading - massage on the calf from
ascend to bottom or from bottom to ascend to release the fatigue in the calf. Flexible
massage
- headsof the kneading - massage system are scatteredin the side of the calf.
Well
- distributed strength of kneading makes it more comfortable.

Functions & Specialties
7.Negative ion healthy oxygen - bar
This equipment is designed to be your negative ion healthy oxygen
- bar. It can
bring you natural enjoyments as you have experienced in forests, at seashores
and cataracts.The negativeion can raise the density of oxygen in the air, so it is
helpful to solve the problems such as fatiguebecause of lack of oxygen in sealed
rooms, brain hypoxia and anoxic skin
- aging . It makes you energeticevery minute.
8.Angle-adjusting function
Two restriction
- freepneumatic angle - adjustinginstrumentsare specially designed.
Working
- angle of the backrest and the foot - shelfcan adjust freely accordingto what
your preference. Any massage posturecan be satisfied. You can be sitting or even
lying to enjoy the massage.
9. Electronictimer
The inserted electronic timer can time automatically after startingup. It can turn
off after working a fixed time. This functioncan avoid the waste of energy and
excessive stimulationbecause of forgettingto turn off.
10. Automatic program include kinds of massage skills, massage time can be adjusted.
Specifications
Rated voltage: 100V-120V A C Q 220V-240V A C
Ratedfrequency: 50160HZ
Power consumption: 130W
Working time: 15minutes
Weight: 48 kg
Volume: high1000
X width700 X depth900mm
Safety devices: overheat proof devices, electronic timer
IEC 60335-2-3211993
% Note: Specificationsare subject tochange without notice.

Names and Functions of Parts
Back Cushion
Offer you a soft and comfortable situation.
If you want a stronger stimulus, turn it back
Back
"t
Movable massage
system inside
Remote Control Box
Back Adjusting Pole
Use atmospheric pressure adjustment
Feet
- lying Shelve Angle
Adjusting Pole
, ion function
X Note: Specificationsaresubject to change without notice.

Preparations Before Using
I .Open the pack of the massage - chair and carry the chassisout with 4 people(Don' t
lift the handrailsroughly). Please keep the Instructionsand Guaranteesafe.
2.Turn over the backrest cautiously. Fasten the orientationsheath at the lower end of
the backrest and the pneumatic spring at the lower part of the chair with provided
bolts and block
- forelocks.
3.Find the power cords under the chair. Connect
the plugs of the same color tight.
4.Leave certain room around the massage - chair
to avoid colliding other substances when adjusting
the angle and turning the chair.
5.Finishing assemblage, insert the power plug into
the socket and turn on the power switch at the
lower part on the right side of backrest, then you
switcl?
can use the telecontrolpanel to select massage
functionsand enjoy relaxing,healthy and
comfortable massage.
Fuse

Proper Ways of Using
I Start the massage - chair
Press the button
f? on the telecontrol panel ofthe massage - chair, and it will
be ready to work.
I1 Set the time of massage
After starting the massage
- chair. press the time - selecting button
time setting. Three alternatives are available; they are 5
- minute.10 - minute
and 15
- minute. From the display you can see the set working time.
111 Automatic massage program
When automatic massage is preferred, press the button
, and the
massage
- chair will be ready to massage automatically. Under this condition,
the massage equipment will knead the back and the leg automatically
according to the computer program complemented inside.
1. Select kneading st le
Press the button & and the massage - chair begins to knead the back.
Usually the implicit route of the massage
- chair is
select different kneading scopes using the button
, or you can also
move the massage equipment to locate the knea
button and
m.
2. Select swavina stvle
<-.
Press the button and the massage - chair begins to sway the back.
Usually the impli of the massage
- chair is
select different swaying scopes using the button
move t age
' ent to locate the swa
button and
3. Select finger - pressing style
Press the button
, and the massage - chair begins to massage the
back with finger
- pressing. Usually the implicit route of the massage - chair
is the whole body. Different finger
- pressing scopes can be selected through
the button
4. Select the speed of massage
When the massage
- chair is at rate of kneading or swinging can be
adjusted by pressing the button
. Three alternative rates are available.
From the display, you can see different rates selection from L1to
L3. And
different massage rate can be selected as needed.

Proper Ways of Using
5. Choosing massage areas
Press , you can choose one of the three massage areas.
When it is chosen,the indicator light relative to it will be on.
It will give massage up It will give massage up and It will give massage up and
and down from your neck down fromyour neck part to down fromyour lower back
to your waist. the upper back. to your waist part.
Press ( or , the massage device of backrestwill move up or
down. On release of the button, the mechanism stops for spot massage.The
pressing massagecan' t spotmassage.
V Thigh - massage
Pressthe button
, the instrumentsat the cushion will takerelaxing
massage on the thigh. Press thisbuttonagain to turn off this function.
VI Calf - massage
The equipment imitatesthe hand to knead and extrude on the calf. And this
stimulatesthe leg blood circulation,relaxes the leg musclesand releasesache
and anaesthesia.
l Press the button and the massage - chair beginsto massage the calf.
Press this buttonagain to stop massaging.
Press the button to adjust the kneadingstyle. Three modes are available.
From the display, you can see differentmode selected, from
L1 to L3. And different
modes can be selectedas needed.
W Adjust back angle
If you want to make the chair back down, lean against the back andpull the back
adjustingpole, when found apropersite, loosen adjustingof back willbe lock.
When want the chair back up, leave the back and pull the back adjustingpole.
% It will not effect with the massage functionwhen adjust the chair angle.

Proper Ways ofUsing
W1 Adjust foot - shelves
Pullthe foot - shelvesangle adjustingpulling - poleunder the left handrailupward
and lift feet slightly, then the foot
- shelveswill lift automatically.
When you need lower the foot - shelves,put your legs on the foot - shelves slightly
andpull the foot
- shelves angleadjustingpulling - poleon the left, then the foot-
shelves will lower slowly.
When you need adjustthe length of the foot - shelves,please pull theadjusting
pole on the right upward, move the foot
- shelf forwardor backwardto convenient
position, then release the adjustingpole. And the foot
- shelveswill be lockedthere.
IX Finishoperation
After operation, please turn off the power switch of the massage
- chair , take the
plug off the socket andput the telecontrolpanelinthe hoarding
- boxunder the
right handrailof the massage chair.
Ways ofstorage
a
c -
Please keep it where itis dry and there's less dust.
0 Damp and dust will shorten the machine's lifeandmay become the
causesof moldy or dirty marks.
Please keepaway from direct sunlightor heating applianceslike heat
stove.
Q The surface may change color or lose high quality.
Make sure the power is turnedoff, and pullout the plugfrom the outlet
when it is dept. Besidesdon't use wet hands to pullor insert the plug.
Q To avoidelectricshock.
Don't use diluents,volatile oil or bleachingpowder.
Q willcause cloth change color or damaged.
Use lukewarm water or thinnersoapsuds (neuter detergent)drop into
the soft clothand then dry it to wipe.
9
