Omega ECHO-4 How to use

Model: ECHO-4
LCD 2-way Upgrade Kit
November 21, 2012
Operation & Installation Guide

Table Of Contents
Installing & Programming The ECHO System.......................................3
Controller Overview...............................................................................4
The 2-Way Controller ........................................................................4
System Operations............................................................................4
LCD Screen Icons .............................................................................5
In-Range Indicator.............................................................................5
Screen Illumination............................................................................5
Multi-Car Operation ...............................................................................6
Selecting CAR #1 or CAR #2 ............................................................6
Controller Options..................................................................................6
Parking Timer & Remote Start Timer.................................................6
Selecting Melody & Vibrate Modes....................................................6
Setting The Clock ..............................................................................7
Changing Remote Start Melodies .....................................................7
Button Lock .......................................................................................7

3
The ECHO-4 communicates with a window-mounted base unit which is plugged
directly into the host system’s module. The window-mount antenna should be
mounted directly to the interior glass by utilizing the attached adhesive pad (clean
the glass before adhering) for the best performance. The receiver/transmitter
also contains alternative Status Lights and a Valet Switch. these may be used, or
the original items may be retained.
NOTE: You must install the controller batteries before use.
Step 1
Locate &
Remove the
security system’s
antenna port.
Step 3 Program the Echo controller and the
original 1-way transmitters into the system
(see the system’s operation guide for instructions).
Echo Base
Transmitter/
Receiver Unit
Step 2 Plug in and route the Echo
transmitter/receiver unit wiring harness.
NOTE: Some systems’ existing harness
can be used.
Host Omega Security
System Control
Module
LED and
Valet Switch
plugs.
V
(congurations vary)
Installing & Programming The ECHO System
( ( (ECHO

4
Controller Overview
THE 2-WAY CONTROLLER
Controller part number: 154-03
1) LCD Display: Displays all controller functions
as well as the status of your system.
2) Control Buttons: Lock, Unlock, Trunk Re-
lease, Remote Start / 3rd Channel
3) Programming Button: This con gures the
controller’s features.
1
Transmitter battery replacement:
Remove the door from the back case, and replace
the two CR2032 batteries. Then replace the door
securely.
2
3
2
Your system operations are dependant on the design of the system being used with the ECHO kit.
Please refer to the system’s operation guide for details on each function. The controller buttons will
perform the same operations as your original transmitter’s buttons
SYSTEM OPERATIONS

5
Controller Overview (cont’d)
LCD SCREEN ICONS
Battery Level Melody/Vibrate
Hood
Trigger
Alarm Status
Remote Start
Shutdown Indicator
Clock
Door Trigger
In Range
Indicator
All primary commands sent to the system have a conrmation response that is sent to the control-
ler to indicate that the command was successful. If the command is successful, the icon will not
display the “X” in the middle of the icon. If no response is received within a few seconds, the “X” will
be displayed indicating that you may be out of range of your system.
IN-RANGE INDICATOR
Valet Mode Indicator
Anti-Carjack
Mode Activated
Sensor Trigger
Lock/Unlock Status
The LCD screen can be illuminated in dark environments by momentarily pressing the “P” button.
The screen will illuminate for 5 seconds with each press.
SCREEN ILLUMINATION

6
When controlling 2 systems, the controller will receive all status updates on the currently selected
vehicle and will receive only trigger alerts for the 2nd vehicle. Use these steps to change vehicles:
SELECTING CAR #1 OR CAR #2
Vehicle #1: Press the “P” and “LOCK” buttons for 1 second to select Car #1. The controller will beep/
vibrate once and the clock will change to “CAR 1”.
Vehicle #2: Press the “P” and “UNLOCK” buttons for 1 second to select Car #2. The controller
will beep/vibrate twice and the clock will change to “CAR 2”.
Multi-Car Operation
The controller has 2 convenient timer functions. The PARKING TIMER tells you how long you’ve
been parked in case you are at a parking meter or other parking areas with time restrictions. The
REMOTE START TIMER tells you how long your engine has been running in remote start mode.
PARKING TIMER: Press LOCK twice within 5 seconds. When the controller receives both LOCK
conrmations, it will start the timer indication by the clock changing to “00:00 P”.
REMOTE START TIMER: This turns on every time you remote start. indicated by the clock changing
to “00:00RS”.
Note: Pressing the “P” during either timer mode will switch between the timer and clock.
PARKING TIMER & REMOTE START TIMER
SELECTING MELODY & VIBRATE MODES
Whenever 2-way alerts are received from the system, the controller can alert you with a melody,
vibration, or both. By default, the controller is set for melody only. Press the “P” and “TRUNK“
buttons simultaneously for 1 second to change the setting. The melody & vibrate icons
on the status screen will turn on & off indicating your selection.
Controller Options

7
1) Press the “P” button for 5 seconds to access the controller features. The controller will beep twice.
2) Press and release the “P“ button once to select the clock (hour digits will ash).
3) Press the “TRUNK“ button to scroll up or the “ “ button to scroll down.
4) Press the “P” button to switch to the minute digits.
5) Press the “TRUNK“ button to scroll up or the “ “ button to scroll down.
6) Wait 10 seconds or press the “P” button to exit programming. The controller will beep once.
SETTING THE CLOCK
The controller has 5 different melodies to choose from for remote start ON and 5 melodies for
remote start OFF conrmation.
1) Press the “P” button for 5 seconds to access the controller features. The controller will beep twice.
2) Press and release the “P“ button 3 times to select the melody settings. The clock will change to “01
STRT” indicating “start melody #1” for the remote start ON melody.
3) Press the “TRUNK“ button or the “ “ button to scroll through the melodies.
4) Press the “P” button to switch to the remote start OFF melody selection.
5) Press the TRUNK button or the “ “ button to scroll through the melodies.
6) Wait 10 seconds or press the “P” button to exit programming. The controller will beep once.
CHANGING REMOTE START MELODIES
Controller Options (cont’d)
You can lock the buttons on the controller to prevent accidental button presses. To lock the buttons,
press “P” and “ “ simultaneously for 1 second. Repeat this to unlock the buttons.
BUTTON LOCK
*
*
*
*
*

This device complies with FCC Rules part 15. Operation is subject to the following
two conditions, (1) This device may not cause harmful interference and, (2) This
device must accept any interference that may be received, including interference
that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modi cations to this equipment. Such modi cations could void the
user’s authority to operate the equipment.
