Omega HPP-600 User manual

HPP-600
Pneumatic Hand Pump
INSTRUCTION
SHEET
M4673/0508
Shop online at: omega.com e-mail: [email protected]
For latest product manuals: omegamanual.info
Volume Control
The HPP-600 pump is equipped with two knobs for fine adjustment of the system
pressure. The vent knob can be used to slowly reduce the system pressure. The
vent knob should be closed prior to pressurizing the system by turning the knob
away from the pump housing. The Vernier knob can be used to increase or
decrease the system at a more controlled rate. For fast relieve of the pressure,
move the pressure/vacuum pin to the opposite direction.
Pressure/Vacuum Selector
The pump can be used to generate pressure or vacuum depending on the position
of the pin located in the pressure/vacuum switch. Press the pin on the side of the
pump housing according to labels for the desired operation.

For High Pressure Operation
Prior to pressurizing, back out the Vernier knob until the ring on the Vernier shaft
is showing. Pump to pressurize. Turn the Vernier knob towards the pump
housing and the pressure should easily be able to reach 600 psi.
NOTE:
The pump uses a Schrader valve instead of a needle valve. Thus, full open or
closed is several turns from the end of the travel. Over-tightening does not
increase the seal.
Fittings
The pump is equipped with 1/8" and 1/4" BSP ports. In order to use NPT fittings, a
NPT to BSP Parallel Thread Adapter is required. These adapters, which are
included with the pump, have a bonded washer attached to the male end of the
adapter.
MAINTENANCE
No routine maintenance is required. A periodic check of system calibration is
recommended. The Pump is not field serviceable and should be returned to
Omega Engineering if repair is needed (field repair should not be attempted and
may void warranty). Be sure to include a brief description of the problem plus
any relevant application notes. Contact customer service to receive a return
goods authorization number before shipping.
