OMNIDOTS SWARM User manual

Rev02 - Quick Start Guide - ©2019 Omnidots
INSTRUCTIONS PRIOR TO FIRST USE
Product innovaons over the air
The first me you power up your SWARM, the SWARM will look for the latest product
innovaons to download. Within a few minutes the SWARM is up-to-date and ready
to use. Update status and downloading progress can be viewed on your Honeycomb
overview page. How to create a Honeycomb account is explained below under the
secon “Set up your SWARM vibraon monitor”.
Requirements
Honeycomb subscripon. Honeycomb account. WiFi or LTE/ 4G access.
Acceptance of the terms of the license agreement, when creang a new account on:
hps://honeycomb.omnidots.com
Power requirements: 5V 1A.
Important noces
Omnidots’ hardware product is warranted against defects in materials and workman-
ship for a period of two (2) years from the date of original purchase, and only when
used in accordance with Omnidots’ user manuals and instrucons. IP65 Enclosure
IP rated as dustproof and protected against water projected from a nozzle.
When disconnected from the power cable, make sure to keep the connector sealed
using the dust cap. This will insure the SWARM remains waterght and dustproof.
Only use the power cable provided by Omnidots, using another power cable can
affect the IP65 protecon and cause water or dust damage. Using other power cables
will void the warranty. The provided SWARM power adapter is not intended for
outdoor use. For outdoor use, we recommend using the Omnidots baery pack.
The SWARM, including its SIM cover, should never be opened. Only an Omnidots’
cerfied facility can do so.
QUICK START GUIDE
Parts list
SWARM vibraon
monitor
Power cable
Power adapter
Screw with plug
(for mounng the SWARM)
Instrucons prior to
first use

1. 2. 3. 4. 5. 6. 7. 8.
SET UP YOUR SWARM VIBRATION MONITOR
THE POSITION OF THE X, Y AND Z AXIS WITH RESPECT TO THE SWARM
QUICK START GUIDE
Connect the
provided power
cable to the
SWARM
Make sure to ghten
the connector
coupling ring properly,
unl you feel a slight
click. This will insure
a waterght and
dustproof connecon.
SWARM standing view
SWARM axes when mounted
vercally, for example to a wall.
SWARM landscape view
SWARM axes when mounted
horizontally, for example to
a ground mounng plate.
SWARM hanging view
45 degrees
SWARM axes when mounted facing
downwards at an angle of 45 degrees,
for example to a sloping ceiling.
SWARM landscape view
45 degrees
SWARM axes when mounted facing
upwards at an angle of 45 degrees,
for example to a sloping wall.
SWARM hanging view
SWARM axes when mounted
facing downwards, for
example to a ceiling.
Mount the
SWARM
firmly to the wall,
ceiling or ground,
using only one
screw. Mounng
can be done at
any angle.
Leveling is
not necessary
as the SWARM
aligns its axes by
itself, automacally.
Power the
SWARM
using Omnidots’
baery pack. The
Swarm can also
be powered using
a solar panel, or
mains power.
Once the
Swarm’s LED
is breathing
green
your SWARM is
ready to measure
the vibraons of the
object it is
mounted on!
Create an
account / login
hps://honeycomb.
omnidots.com
Monitor and
check
the measured
data on the
Honeycomb
plaorm.
Create a
measuring
point for your
SWARM
Choose the sengs
you require for your
measuring point.
Please check Omnidots’ website for more informaon and online tutorials: hps://www.omnidots.com/en/faq
