Omnitron Systems FlexPoint 10/100 User manual

FlexPoint
FlexPointTM
FlexPoint 10/100
10/100 Copper to Fast Ethernet Fiber Media Converter
The FlexPoint 10/100 is a modular 10BASE-T or 100BASE-TX
copper to 100BASE-FX ber media converter that provides
reliable and cost-effective network connectivity and ber
extension.
The FlexPoint 10/100 features a 10/100 auto-sensing RJ-45
port that adjusts to the highest level of performance supported
by the attached device. An override switch provides manual
control over the 10/100 operation of the RJ-45 port and the
Half/Full-Duplex operation of both the ber and RJ-45 ports.
When configured for auto-negotiation, the RJ-45 port
automatically detects and sets MDI/MDI-X crossover. When
congured for manual operation, the FlexPoint 10/100 features
a manual switch to provide the MDI/MDI-X crossover.
The ber port supports xed-ber connectors (SC, ST or LC)
and Small Form Pluggable (SFP) transceivers, enabling easy
adaptability to different ber types, distances and wavelengths.
The FlexPoint 10/100 supports multimode, single-mode, single-
mode single-ber, in standard and CWDM wavelengths.
Manual switch settings and LED indicators with on-the-label
descriptions enable easy conguration to legacy devices or
specic network requirements. The LEDs report the availability
of power, port activity and link status, speed and duplex modes.
FlexPoint modules can be mounted utilizing optional wall-
mounting hardware or with DIN-rail mounting brackets. They
can also be rack-mounted in a 5-Module shelf or in a high-
density 14-Module, power-redundant Powered Chassis.
FlexPoint modules installed in the 5-Module shelf or used
as standalone devices can be powered by an external AC to
DC power adapter, 2-pin DC terminal connector or through
the 5VDC chassis connector. Standalone modules can
also be powered by attaching an external DC power supply
(18-60VDC). When used in the 14-Module power-redundant
Powered Chassis with any combination of AC and DC power
supplies, the installed modules are powered via the 5VDC
chassis connector.
The wide variety of FlexPoint mounting and power options
provide exible upgrade paths as network requirements change
and grow.
FlexPoint unmanaged media converters are easy to use
and provide dependable ber connectivity in Enterprise and
Government networks around the world.
■The FlexPoint 10/100 is a 10BASE-T or 100BASE-TX
copper to 100BASE-FX ber media converter
■ The RJ-45 port supports auto or manual negotiation
■ Extends network distances up to 120km
■ Supports 100BASE-FX xed-ber (SC, ST or LC) and
100BASE-FX SFP transceivers
■ Labeled status LEDs and switches for quick and easy
installation
■ Auto MDI/MDI-X crossover
■ Available in AC and DC models
■ Wall-mount or rack-mount on a 5-Module shelf or in
a 14-Module power-redundant FlexPoint Powered
Chassis
■ Completely software independent with no installation of
drivers required
■ Commercial (0 to +50°C), wide (-40° to +60°C) and
extended (-40°C to +75°C) temperature ranges
■ Peace-of-mind reliability backed by a lifetime warranty
and free 24/7 technical support
KEY FEATURES
SFPs not included

In this enterprise campus application example, FlexPoint
10/100 media converters are installed in a 14-Module
Redundant Power chassis for high-density ber distribution
from UTP switch equipment at the Network Core. A UTP
workgroup switch (A) is connected via ber with a standalone
FlexPoint 10/100 media converter. Another FlexPoint 10/100
converts the ber to copper in a ber-to-desktop application
(B). An Ethernet switch (C) is connected directly via ber
to the FlexPoint module at the Network Core. In all cases,
multimode or single-mode ber can be used, and ber links
can be extended up to 120km using single-mode ber.
SPECIFICATIONS
Description FlexPoint 10/100
10/100BASE-T Copper to 100BASE-FX Fiber Media Converter
Standard
Compliances IEEE 802.3
Regulatory
Compliances UL, CE, FCC Class A, RoHS2 (6/6), WEEE, REACH
Frame Size Up to 1536 bytes
Port Types
Copper:
Fiber:
10/100BASE-T (RJ-45)
100BASE-FX (ST, SC, LC, SFP)
100BASE-BX (SC, SFP) Single-ber
Cable Types
Copper:
Fiber:
EIA/TIA 568A/B, Cat 5 UTP and higher
Multimode: 50/125µm, 62.5/125µm
Single-mode: 9/125µm
AC Power
Requirements
AC Adapter (-1): 100 - 120VAC/60Hz
0.06A @ 120VAC (typical)
AC Adapter (-2): 100 - 240VAC/50 - 60Hz
0.06A @ 120VAC (typical)
DC Power
Requirements Voltage Range:
Nominal Voltage:
Nominal Power:
Maximum Power:
Terminal or Barrel
Connector
5.0 to 32VDC
9VDC
0.5A @ 9VDC
1A @ 9VDC
Molex Connector
4.75 to 5.25VDC
5VDC
0.8A @ 5VDC
1A @ 5VDC
Dimensions W: 3.0" x D: 4.0" x H: 1.0"
L: 76.2 mm x B: 101.6 mm x H: 25.4 mm
Weight Without AC Adapter: 6 oz. (170.1 grams)
Temperature
Commercial:
Wide:
Extended:
Storage:
0 to 50°C
-40 to 60°C
-40 to 75°C
-40 to 80°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m
MTBF (hrs)
Without AC Adapter (-0, -9):
With AC Adapter (-1):
With AC Adapter (-2):
1,100,000
250,000
100,000
Warranty Lifetime warranty with 24/7/365 free Technical Support
Page 2FlexPoint 10/100
APPLICATION EXAMPLE

800-675-8410 • 949-250-6510 • www.omnitron-systems.com • [email protected] • 38 Tesla, Irvine, CA 92618
© 2016 Omnitron Systems Technology, Inc. All rights reserved. FlexPoint is a Trademark of Omnitron Systems Technology, Inc.
Trademarks are owned by their respective companies. Specications are subject to change without notice.
091-04340-004H 5/16
ORDERING INFORMATION
Fiber
Type Distance
Connector Type Tx
Lambda
(nm)
Rx
Lambda
(nm)
Min. Tx
Power
(dBm)
Max. Tx
Power
(dBm)
Min. Rx
Power
(dBm)
Max. Rx
Power
(dBm)
Min.
Attenuation
(dB)
Link
Budget
(dB)
ST SC LC SFP
- - - - - 4359-0 - - - - - - - -
MM/DF 5km 4342-x 4340-x 4355-1x -1310 1310 -24 -14 -31 -14 -7
SM/DF 30km 4343-x 4341-x 4355-2x -1310 1310 -15 -8 -31 -8 -16
SM/DF 60km 4345-x 4344-x 4355-3x -1310 1310 -5 0-31 -3 3 26
SM/DF 120km -4349-x 4355-4x -1550 1550 -5 0-31 -3 3 26
SM/SF120km -4357-1x - - 1310 1550 -15 -5 -30 -3 -15
SM/SF120km -4357-2x - - 1550 1310 -15 -5 -30 -3 -15
AC Adapter Kits (-x): -0 = No AC adapter included, -1 = 110-120 VAC/60 Hz (US plug), -2 = 100-240 VAC/50-60 Hz (IEC plug, no power cord),
-9 = 2 pin terminal (non-isolated) connector.
For wide temperature (-40 to 60°C), add a “W” to the end of the model number.
Contact Omnitron for other ber options, extended temperature (-40 to 75° C) models and RoHS (5/6) compliant models.
1 When using single-ber (SF) media converter models, the Tx wavelength on one end has to match the Rx wavelength on the other.
Order the appropriate SFPs separately. Visit the Omnitron Optical Transceivers web page.
Page 3
FlexPoint 10/100
Accessories
Model Number Description
8250-0 DIN-Rail Mounting Bracket
4380 Wall-Mount Bracket
