Omnitronix Data-Link DL30 Owner's manual

DL30
Pollable Remote Access Unit
Installation and Operation Guidelines
Manual Rev. 1.00

2005 Omnitronix, Inc. 2
Omnitronix, Inc.
1200 North 96th St.
Seattle, WA 98103
U.S.A.
Tel: [phone]
Fax: [phone]
[e-mail]
www.omnitronix.com
© 2005 Omnitronix, Incorporated. All rights reserved.
The content of this manual is provided for informational use only, and is subject to change without
notice. Examples, data, and names used in this manual are examples and fictitious unless
otherwise noted. No part of this document may be reproduced or electronically transmitted
without permission from Omnitronix, Incorporated.
Omnitronix, Data-Link, DL30, and AlarmManager are trademarks of Omnitronix, Incorporated.

2005 Omnitronix, Inc. 3
Table of Contents
Page
Quickstart Guide………………………………………………………………………………………..…4
Hardware Checklist
Data Checklist
Connecting
What is a DL30…………………………………………………………………………………………….6
Basics
Parts Identification
Front Panel LEDS
Back Panel
Dip Switches
Features……………………………………………………………………………………...……………10
Data Collection and Storage
Polling
Remote Access (Pass-through)
Data Alarm Monitoring
Alarm Notification
OmniAlarms
Status Screen……………………………………………………………………………………….……13
Setup Menu..………………………………………………………………………………………….…..14
Option Types
General Settings
Network Settings
Serial Settings
Alarm Settings
Command Reference………………………………………………………………………………..….19
User Interface Commands
Data Release Commands
Setup Commands
System Commands
Appendices………………………………………………………………………………………….……21
Internal Modem Guidelines
Canadian Dept of Communications
Warranty Information…………………………………………………………………………………...24

2005 Omnitronix, Inc. 4
Quickstart Guide
Hardware Checklist
●Omnitronix Data-Link DL30
●Computer with male DB9 RS-232 serial port and terminal emulation software
●DB9 serial cable (included)
●Power adaptor (included)
●Ethernet network access (optional)
●POTS (analog) phone line (optional)
Data Checklist
If your DL30 comes with optional Ethernet port you will need:
●Static IP address to assign to the DL30
●Subnet mask
●Default router (gateway) IP address
Connecting
Cables and power
1. Connect one end of the DB9 cable to Output port of the DL30 and the other
end into a serial comm port of the computer with terminal emulation software.
2. Connect the power supply cord into the DL30 and the transformer into an
appropriate power receptacle.
3. If installed with Ethernet port, connect a network Ethernet cable into this port.
4. If installed with an internal modem, connect a POTS (analog) phone line into the
RJ-11 modem jack.
Power up sequence
On power up the DL30 the internal buzzer beeps three times. When the Reset button is
pressed and released the DL30 beeps twice. The Power LED remains on steady and the
25% LED flashes on and off about once per second when boot up is complete.

2005 Omnitronix, Inc. 5
Accessing the command line
1. On the computer open the terminal emulation program to whatever comm port is
connected to the DL30 at baud rate and parity setting of 19200, 8N1.
2. Press <enter> three times. The “Data-Link” banner will appear.
3. Type STATUS <enter> (or the “?”).
Note: Commands entered into the DL30 are not case sensitive.
You should be presented with the Status screen, which looks similar to the following:
Data-Link DL30 1.00 STD Unit Serial # 1030331E
ID : Data-Link I/O1 Baud Rate : 19200
Date : TUE 08/01/05 I/O1 Parity, etc. : 8N1
Time : 12:08:15 I/O2 Baud Rate : 19200
Memory : 256K I/O2 Parity, etc. : 8N1
% Full : 0% File Records : 0
Modem : NO File Bytes : 0
Network : YES Handshake : NONE
IP Add : 192.168.100.19 File Wrap : OFF
MAC Add : 00:10:A3:30:33:1D Alarm Filter : ON
COMPLETE
You are now successfully connected to the DL30 command processor.

2005 Omnitronix, Inc. 6
What is a DL30
Basics
The DL30 is a hardware device that provides three basic functions to facilitate management and
monitoring of attached serial port devices. These functions are:
●Data collection, storage and forwarding
●Remote access of attached serial devices
●Monitoring of serial data alarm conditions
The DL30 has a diverse selection of communication methods available for different applications.
The following methods can be used to either access the command processor or provide a pass-
through connection to devices connected to the Input port:
●RS-232 serial
●Modem (if optional modem installed)
●Telnet (if optional Ethernet installed)
●FTP (if optional Ethernet installed)
Data may be retrieved from or through the DL30 by any of the following methods depending on
the hardware configuration:
●Serial or modem connection to command processor (using Line or Zmodem) or pass-
through
●Telnet to command processor or pass-through
●Inline Mode (data in Input port, out the Output port)
●FTP push (automatic delivery to FTP server)
●FTP get (manual retrieval from FTP server)
Alarms generated or detected within the DL30 can be delivered as “OmniAlarms” via the modem
as described later in this manual.
Parts Identification
The base DL30 comes with the following standard onboard components:
●DB9 Male RS-232 serial port (Input)
●DB9 Female RS-232 serial port (Output)
●AC power adaptor
●Reset button
In addition to the above components, the base DL30 is shipped with the following accessories:
●This product manual/CD
●DB9 female to DB9 male straight-thru serial cable
●Female to female DB9 gender changer
●12VAC power supply
The following components are optional and may be installed on your DL30:
●RJ-45 Ethernet port
●Internal 33K modem

2005 Omnitronix, Inc. 7
Front Panel LEDS
●Power
The Power LED will remain on steady when power is applied to the unit
●Percent Full
The DL30 has four LEDs to indicate file full status. A blinking Percent Full LED indicates
the file database has less than the amount indicated by that LED, but more than the
previous. A solid lit LED indicates the file database percentage is at or over the value for
that LED.
●Link
The Link LED flashes whenever data is transmitted on the Ethernet port.
●In
The In LED flashes whenever data is received on the Input port.
●Out
The Out LED flashes whenever data is received on the Output port.

2005 Omnitronix, Inc. 8
Back Panel
The Input port is configured to automatically detect DTE/DCE and baud rate.
Default settings for the serial ports are 19200 baud, 8-bit word length, No parity, and one stop bit
(19200 8N1). Use either the internal Setup menu or the external dip switches to adjust the
settings of either serial port.
●Ethernet
The Ethernet 10BaseT connector (if installed) is an RJ-45. Connect a network cable from
an Ethernet hub or switch to this port.
●Internal Modem
The 33K internal modem connector (if installed) is an RJ-11. Connect a POTS
(analog) phone line to this port.
The modem installed in the DL30 is FCC certified. For further information refer
to the Internal Modem Guidelines or the serial number label on the bottom of the
DL30.
●Reset button
The Reset button, when pressed for approximately 2 seconds, will reboot the DL30. All
buffered data and internal configurations will be preserved.

2005 Omnitronix, Inc. 9
Dip Switches
One bank of twelve dip switches is located on the bottom of the DL30:
Dip switch orientation
INPUT PORT OUTPUTPORT
Baud rate SW1 SW2 SW3 Baud rate SW6 SW7 SW8
9600 OFF OFF OFF 9600 OFF OFF OFF
300 OFF OFF ON 300 OFF OFF ON
600 OFF ON OFF 600 OFF ON OFF
1200 OFF ON ON 1200 OFF ON ON
2400 ON OFF OFF 2400 ON OFF OFF
4800 ON OFF ON 4800 ON OFF ON
9600 ON ON OFF 9600 ON ON OFF
19200 ON ON ON 19200 ON ON ON
Word, Parity, Stop SW4 SW5 Word, Parity, Stop SW9 SW10
8 bits, None, 1 OFF OFF 8 bits, None, 1 OFF OFF
7 bits, None, 1 OFF ON 7 bits, None, 1 OFF ON
7 bits, Odd, 1 ON OFF 7 bits, Odd, 1 ON OFF
7 bits, Even, 1 ON ON 7 bits, Even, 1 ON ON
PASSWORD REQUIRED SW11
Password – Yes ON
Password – No OFF
OUTPUT PORT MODE SW12
Inline Mode ON
Command Mode OFF

2005 Omnitronix, Inc. 10
Features
Data Collection and Storage
The DL30 stores data received from an RS-232 serial device. The data received on the Input
port is stored in File 1.
Polling
There are four methods available to poll the data from File 1:
●Line mode via the Output port, modem, or telnet
Line mode releases data just as it was entered with no printable character
manipulation. Line mode is not recommended as a polling method because there is no
error checking.
●Zmodem via the Output port, modem, or telnet
Data can be polled using a terminal emulator or other software that supports the
Zmodem protocol. Zmodem transfers data in blocks and uses error checking to ensure
accuracy.
●Inline mode via the Output port
The Output port can be changed from a command port to Inline port (set dip switch
SW12 ON). Inline mode links the Output port to the Input port so that data received on
the Input port is immediately released out the Output port to a PC running polling
software. In the event the communication link with the PC fails, the DL30 will then
begin buffering call records. When the link becomes available again, buffered data will
be released based on the handshaking mode configured in the Serial Port setup menu.
●FTP - either FTP push or FTP get
In a DL30 equipped with an Ethernet port, the data buffered in File 1 can be
polled via FTP in one of two ways:
1) FTP push – the DL30 can be configured in the Network Settings menu to
“push” the data in File 1 to an FTP server at specific intervals. Once the remote
host has received the data, it is automatically deleted from the DL30.
2) FTP get – the DL30 has a built-in FTP server that allows inbound connections
for the purpose of retrieving data. The user can make an FTP connection to the
DL30 and issue the “get File1” command to poll the data.
Remote access (pass-through)
The DL30 provides a user with transparent access to devices connected to either serial port via
pass-through connections. Remote access can be used to configure, maintain, or manipulate
devices that would normally have no remote access. A pass-through connection can be made
via a serial connection to the Output port, modem or telnet.
•Via serial connection to Output port or modem
From the command line enter the command “Bypass1” to connect to the Input
port, and “Bypass 2” (modem connection only) to connect to the Output port.
“Bypass” by itself will connect to the Output port by default.
•Via Telnet
Telnet to the DL30 IP address followed by port number 2101 or 2102 for either
the Input port or the Output port.
(example: telnet 192.168.100.19 2101 will connect to the Input port)
Data Alarm Monitoring
The DL30 can be configured to monitor data coming in the Input port for user-defined Data Alarm
Strings and then report the alarm via the modem using OmniAlarms (see Alarm notification
below) or via the Ethernet port using SNMP traps (not implemented yet).

2005 Omnitronix, Inc. 11
Alarm Notification
Incoming data that matches the Data Alarm Strings can trigger two types of actions; an
OmniAlarm delivered via the modem, or an SNMP trap delivered via the network (not
implemented yet). The modem number to be called, or the IP address of the SNMP Manager to
which the trap is sent, are configured in the Alarms Settings menu.
OmniAlarms
OmniAlarms are a receipt-verified alert system delivered via modem.
When an OmniAlarm is initiated, the box dials the callout number specified by the action. Once
connected, it sends a header and waits for a specific response. If the DL30 receives a specific
response to the header, it delivers alarms in CRC mode; otherwise, alarms are delivered in non-
CRC mode. In CRC mode, each OmniAlarm is transmitted with some extra control characters
and a CRC, and the remote host is required to acknowledge each alarm in a certain format.
After all OmniAlarms have been delivered, the box waits for 20 seconds for any type of keystroke.
If a keystroke is detected, the box will present a login menu.
OmniAlarm Protocol
Initial header
Upon dialing into the receiver, the DL30 will send a message similar to the following:
Data-Link DL30
Server Room B
Omnitronix Alarm Notice ver. 1.00
(CR/LF)(ENQ)
•The first line of the output is the DL30 answer string.
•The second line is the DL30 unit ID.
•The third line indicates the version of OmniAlarm.
•The final line is the (ENQ) control code.
Non-CRC Mode
After sending the initial header, the DL30 pauses for 10 seconds to wait for an ACK from the
receiver. Non-CRC mode requires the Require OmniAlarm ACKs is setting to be turned off. If
the DL30 sees no response or the receiver replies with:
(ACK)00(ACK)
then non-CRC mode is assumed and the sender will transmit the alarms. The control characters
(SOH), (SOT), and (ETX) are not transmitted in non-CRC mode.
CRC Mode
CRC mode exists to ensure that event notifications are delivered intact. OmniAlarms delivered in
CRC mode have extra control characters and a 16-bit CRC included in each alarm to allow for
error detection by the receiver. Additionally, CRC mode causes the DL30 to store and later retry
each alarm until a proper acknowledgement is received from the receiver.
If Require OmniAlarm ACKs is enabled, the DL30 will require a positive CRC mode response or it
will disconnect and retry the call. To enable CRC, the receiver must respond with the following
after the header is received:
(ACK)01(ACK)

2005 Omnitronix, Inc. 12
Once CRC mode is enabled, each alarm must be acknowledged by a message in the following
format:
(ACK)XX(ACK)
XX represents the alarm ID to acknowledge. The ID can be found in the first line of each record
sent by the DL30.
Alarm Transmission
After successfully initiating a session, alarms are delivered in the following format:
(SOH)ID=XX(SOT)
Date=06/01/04
Time=10:30:02
TargetPort=
TargetName=
AlarmType=Data Alarm
AlarmName=Test Alarm
Threshold=0
Severity=Critical
Text1=text record line
Text2=text record line
(ETX)XX
(CR/LF)
(CR/LF)
•The alarm ID indicates the index number of each alarm delivered during a call. This
number restarts at 1 for each new call.
•The severity line represents the Class value defined for this alarm.
•Up to twelve lines of Textnmay be sent.
•XX represents the 16-bit CRC if CRC mode is enabled. If not, this line will contain two
spaces.
If additional alarms are queued to be sent in the same transmission, the above output is
repeated, incrementing the ID with each alarm. When non-CRC alarm transmission is selected,
alarms are sent with a 5 second delay between each. When all alarms and been transmitted,
then DL30 sends the following:
(EOT)
(CR/LF)
(CR/LF)
At this point, the DL30 waits 20 seconds for the receiver to send any input, and then hangs up. If
any commands are received, a command prompt is established and the connection will remain
active.

2005 Omnitronix, Inc. 13
Status Screen
The DL30 Status Screen is the unit’s one-stop informational source. Most of the information that
a user would need to know about the unit is available on this display. The Status Screen is
dynamically created according to the configuration of each particular unit, and can be displayed
be entering the command STATUS (command not case sensitive) or “?”.
Data-Link DL30 1.00 STD Unit Serial # 1030331E
ID : Data-Link I/O1 Baud Rate : 19200
Date : TUE 08/01/05 I/O1 Parity, etc. : 8N1
Time : 12:05:58 I/O2 Baud Rate : 19200
Memory : 256K I/O2 Parity, etc. : 8N1
% Full : 0% File Records : 0
Modem : NO File Bytes : 0
Network : YES Handshake : NONE
IP Add : 192.168.100.19 File Wrap : OFF
MAC Add : 00:10:A3:30:33:1D Alarm Filter : ON
ID is the identifier assigned to the DL30 by the user.
Date and Time displays the current date and time, also configurable by the user.
Memory indicates the amount of data-ready memory installed in the DL30.
% Full indicates the percent of the memory installed that is currently occupied by serial port data
or alarm records.
Modem and Network indicate whether or not that component is installed in the DL30 via either
YES or NO.
If a network interface is installed, the IP Add and MAC Add display the appropriate values. The
user configures the IP Add. The MAC Add cannot be changed, but is displayed for informational
purposes.
Unit Serial # is the unique factory assigned serial number for this DL30.
The I/O1 Baud Rate and I/O1 Parity, etc settings are the baud, word length, parity, and stop bit
settings for the Input Port.
The I/O2 Baud Rate and I/O2 Parity, etc settings are the baud, word length, parity, and stop bit
settings for the Output Port.
File Records indicates the number of carriage return, linefeed, or ETX (end of text) delimited
records stored in memory.
File Bytes indicates the number of bytes the above records are occupying.
Handshake indicates the current method of handshaking for the Input port.
File Wrap indicates whether file wrapping is enabled or not. When enabled, a unit that is 100%
full will overwrite the oldest buffered records with new ones.
Alarm Filter indicates if a Data Alarm is active on the Input port.

2005 Omnitronix, Inc. 14
Setup Menu
The Setup Menu contains all of the configuration options available on the DL30. Enter the
command Setup to display the Main Setup Menu:
Data-Link DL30 - Main Setup Menu
A) General Settings
B) Network Settings
C) Serial Settings
D) Alarm Settings
Each subsequent section in this chapter will go over one of the above sub-menus, outlining each
option within.
Option Types
There are two different types of inputs employed within the Setup menu.
1) The most common is the string type entry:
A) Unit ID [Data-Link]
When selected, this setting will provide a prompt requesting a new value. At this point,
press <ENTER> to abort the option entry or press <SPACE> and <ENTER> to delete the
current value and leave it blank. Some numerical or required settings will not allow an
administrator to leave an option blank, so be aware when attempting to delete a setting's
value.
2) The second most common option type is the toggle type option:
E) Wrap Around [ON]
When selected, this option will not prompt for a new value. It will simply cycle to the next
available option in its list. This switch type is only used for options with two or three
choices. In the example above the settings are “ON” and “OFF”
General Settings
These settings control general functionality global settings.
Data-Link DL30 - General Settings
A) Unit ID [1030331E]
B) Answer String [Data-Link]
C) Password [password]
D) Escape Key [27]
E) Wrap Around [ON]
F) Current Date [TUE 08/01/05]
G) Current Time [01:53:56]
H) Adjust for Daylight Savings [ON]
Unit ID
The identification string that is included with alarm messages and at the top of the main Status
screen. This string should be unique for clarity when responding to alarm notifications and
connecting to the device.
Answer String
Sets the string presented when a user connects to the unit via Telnet or modem.
Password
Sets the password used when a user connects the unit via Telnet or modem. The default
password is “password”.

2005 Omnitronix, Inc. 15
Escape Key
The key used to break out of pass-through and other transparent modes. This setting can be any
ASCII character from 1 –127. Default is 27, which is the “Esc” key on your keyboard.
Wrap Around
This option allows the unit to continue collecting data in the event the buffer becomes full. Each
record received by the unit will cause the oldest record to be deleted, effectively wrapping the
port's database.
Current Date/Time
The current date and time.
Note: The date and time settings are maintained by means of an internal battery backup when
power is removed from the DL30.
Adjust for Daylight Savings
An on/off toggle that allows automatic daylight savings time updating.
•A brief explanation of daylight savings time
On the first Sunday in April, clocks are set ahead one hour at 2:00 a.m. local standard
time, which becomes 3:00 a.m. local daylight time. On the last Sunday in October, clocks
are set back one hour at 2:00 a.m. local daylight time, which becomes 1:00 a.m. local
standard time.
Network Settings
These settings are for all of the options pertaining to network communication.
Data-Link DL30 - Network Settings
A) IP Address [192.168.100.19]
B) Subnet Mask [255.255.255.0]
C) Router Address [192.168.100.1]
D) Telnet Duplex [ON]
E) Inactivity Timeout [0]
F) FTP Get AutoDelete [OFF]
G) FTP Push Enable [OFF]
H) FTP Server Address [10.10.5.20]
I) Username [user]
J) Password [password]
K) Directory [\]
L) Minutes Between Push Attempts [1440]
IP Address
Should be provided by the network administrator.
Subnet Mask
Should be provided by the network administrator.
Router Address
Should be provided by the network administrator.
Telnet Duplex
This controls the echo settings for Telnet. Full duplex causes the unit to echo all characters sent
to the remote device. Half duplex turns off character echo.

2005 Omnitronix, Inc. 16
Inactivity Timeout
The number of minutes the DL30 will wait before terminating an idle connection. "0" disables this
feature.
FTP Get AutoDelete
Toggles automatically deleting records fetched from the DL30 FTP server.
FTP Push Enable
An on/off toggle for FTP push.
FTP Server Address
The IP address of the FTP server to push to.
Username/Password
The username and password settings for accessing the remote FTP server.
Note: The FTP Get login is 'user' (not modifiable), and the password is same as option
'J' in the Network Settings menu.
Directory
The path used to upload the file(s). Leaving this option blank uploads the files into the root login
directory.
Minutes Between Push Attempts
1 to 9999 minutes.
Note: This manual refers to FTP get and push frequently. "FTP get" is defined as any user or
process accessing the DL30 via FTP in order to fetch records or data. "FTP push" is where the
DL30 initiates an outbound FTP session where it deposits stored data in a predefined location.
Serial Settings
These settings are for all of the options pertaining to serial communication:
Data-Link DL30 - Serial Settings
A) Serial Port 1 Settings
B) Serial Port 2 Settings
Serial Port 1 is the Input port and Serial Port 2 is the Output port.
Serial Port 1 (Input port):
Data-Link DL30 - Serial 1
A) Baud Rate [19200]
B) Data Format [8N1]
C) Handshaking [None]
Baud Rate, Data Format
These are the basic communication settings for this port. This must match the baud rate of the
serial port on the PBX.
Handshaking
Available options are XON/XOFF, DTR, both, and none.

2005 Omnitronix, Inc. 17
Serial Port 2 (Output port):
Data-Link DL30 - Serial 2
A) Baud Rate [19200]
B) Data Format [8N1]
C) Handshaking [None]
D) Duplex [ON]
E) Port Mode [COMMAND]
F) Inline Mode Handshaking [XON/XOFF]
Baud Rate, Data Format
These are the basic communication settings for this port. This must match the baud rate of the
PC if connected.
Handshaking
Available options are XON/XOFF, DTR, both, and none.
Duplex
Controls the echo settings for the command processor. Full duplex causes the DL30 to echo all
characters sent to it.
Port Mode
Controls the action of the output port. In command mode it can be used for pass-through access
or to configure the unit. In Inline mode the unit will output any records stored in it. (Port mode
can also be configured via dips switch SW12.)
Inline Mode Handshaking
Determines what methods can be used to control the release of records in Inline mode: Xon/Xoff
to start and stop record release, or DTR, which is Hardware Handshaking.
Alarm Settings
These settings are for monitoring incoming serial data for alarm conditions:
Data-Link DL30 - Alarm Actions
A) Data Alarm Enable [ON]
B) SNMP Manager []
C) Modem Callout [233]
D) Data Alarm Strings
Data Alarm Enable
Toggles the alarm monitor on and off.
SNMP Manager
Sets the IP address of the SNMP Manager that receives the traps. (Not implemented yet.)
Modem Callout
Sets the phone number for delivery of alarms.
•Data Alarm Strings sub-menu
The DL30 will examine each record to see if the string specified in the following menu is
in the record received. If it is, the unit will take the actions specified above. Selecting a
letter allows the user to enter the search string for alarms.

2005 Omnitronix, Inc. 18
This is the menu where up to twenty individual alarm strings can be entered:
Data-Link DL30 - Data Alarm Strings
A)
B)
C)
D)
E)
F)
G)
H)
I)
J)
K)
L)
M)
N)
O)
P)
Q)
R)
S)
T)
Enter your Selection:

2005 Omnitronix, Inc. 19
Command Reference
Note: Commands are not case sensitive
User Interface Commands
Command Summary Syntax Description
BYE Disconnect from
unit
BYE Disconnect a processor session.
PING Ping IP address PING target_address Performs a standard network ping
function on the specified IP address.
RESTART Restart unit RESTART Reset the system, same as pressing
the physical reset button.
STATUS or ? Display status
screen
STATUS or ? Display the status screen
Data Release Commands
Command Summary Syntax Description
CLEAR Clear
released
data
CLEAR Delete released records in the active file.
COUNT Count
records in
file
COUNT Display the number of records in the partition.
FREE Check free
space
FREE Display the amount of remaining memory in the
record database.
RL Release
data
RL Release records or data in the active file.
SZ Release via
Zmodem
SZ file_name Release the specified data file via Zmodem. The
file can be FILE1.
Setup Commands
Command Summary Syntax Description
SETUP Enter setup
menu
SETUP Opens the setup menu.

2005 Omnitronix, Inc. 20
System Commands
Command Summary Syntax Description
BYPASS Access serial
ports
BYPASS [port_number] Provide pass-through terminal access
between the user and the input port.
COLDSTART Cold boot unit COLDSTART Resets the same settings as the
DEFAULT command and then reboots
the unit.
DEFAULT Restore
factory
defaults
DEFAULT Resets all settings to factory default
values, except does not change the
following settings:
•IP address
•Subnet mask
•Router address
•Serial port baud rate and data format
•Data alarm fields
•Data alarm settings
•Does not affect record data
FTEST Test flash
memory
FTEST Destructive test of CRDB flash memory.
All record data is lost, and any active
polling sessions will fail. Records are
NOT recoverable.
PUSHTEST Test FTP pushPUSHTEST Attempt to connect to the FTP server
specified in FTP push settings.
WRAP Toggle wrap
mode
WRAP Toggles the storage file wrapping mode
for the current database file.
ZAP Clear unit ZAP Clear all data and restore all settings to
factory default values.
ZERO Dump records ZERO Clear all data in the database.
