DMP Electronics RoBoard RM-G146 User manual

RoBoard Module RM-G146
Manual V1.01
The Heart of Robotics
Jan 2011
DMP Electronics Inc

Copyright
The information in this manual is subject to change without notice for continuous
improvement in the product. All rights are reserved. The manufacturer assumes
no responsibility for any inaccuracies that may be contained in this document.
And makes no commitment to update or to keep current the information
contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted, in
whole or in part, in any form or by any means without the prior written
permission of the DMP Electronics Inc.
¤Copyright 2010 DMP Electronics Inc.
Manual No. RM-G146-01 Ver.1.01 Jan, 2011
Trademarks Acknowledgment
Other brand names or product names appearing in this document are
the properties and registered trademarks of their respective owners. All
names mentioned herewith are served for identification purpose only.

T a b l e O f C o n t e n t s
C h a p t e r 1............................................................................................4
Introduction........................................................................4
1.1 Packing List..........................................................4
1.2 Product Description..............................................5
1.4 I2C Address ..........................................................7
1.5 Board Dimension .................................................8
C h a p t e r 2.............................................................................................9
Installation..........................................................................9
2.1 Board Outline.......................................................9
2.2 Connectors & Pin 1 Location.............................10
2.3 Connectors & Jumpers Summary ......................11
2.4 Pin Assignments.................................................12
J1: I2C connector (Top)..............................12
J2: I2C connector (Bottom) ........................12
C h a p t e r 3........................................................................................13
Development Note ...........................................................13
Sample and development code.................................13

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
4
C h a p t e r 1
Introduction
1.1 Packing List
Product Name Package
RM-G146
RoBoard Module RM-G146
Cable-RM-1
1x6 pin Cable x 1

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
5
1.2 Product Description
The RoBoard Module RM-G146 is fully integrated 9-Axis module, combines
3-axis magneto-resistive sensor and 3-axis accelerometer with the LSM303DLH,
and 3-axis angular rate sensor (Gyroscope) with the MPU-3050, simply and all
done through I2C interface, the dimension of it is wee as 20 x 20 mm.
The MPU-3050 is comprised of an embedded 3-axis digital gyroscope. offers a
programmable full-scale range from ±250 to ±2000 degrees per second which
ensures precision tracking of both fast and slow motions.
The LSM303DLH is a system-in-package featuring a 3D digital linear
acceleration sensor and a 3D digital magnetic sensor. It has a linear
acceleration full-scale of ±2 g / ±4 g / ±8 g and a magnetic field full-scale of ±1.3
/ ±1.9 / ±2.5 / ±4.0 / ±4.7 / ±5,6 / ±8.1 gauss, both fully selectable by the user.

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
6
1.3 Specifications
RM-G146 9-Axis sensor module
Gyroscope
MPU-3050
Magnetometer
LSM303DLH
Accelerometer
LSM303DLH
Interface
I2C
Default Address
Gyroscope : 0xD0
Magnetometer : 0x3C
Accelerometer : 0x30
Connectors
1.25mm 6-pin wafer for I2C x 2
Power Input
DC-in 5V
Dimension
20mm X 20mm
Weight
2.5g

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
7
1.4 I2C Address
¾Magnetometer : 0x3C
¾Gyroscope : 0xD0
¾Accelerometer : 0x30

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
8
1.5 Board Dimension

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
9
C
Ch a p t e r 2
Installation
2.1 Board Outline
Top Side
Bottom Side

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
10
2.2 Connectors & Pin 1 Location
Connectors
Top Side
Bottom Side
Pin 1 Location
Top Side
Bottom Side

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
11
2.3 Connectors & Jumpers Summary
Summary Table
Description
Type of Connections
Pin
J1
I2C connector (Top)
Wafer, 2.54mm,6x1
6-pin
J2
I2C connector (Bottom)
Wafer, 2.54mm,6x1
6-pin

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
12
2.4 Pin Assignments
J1: I2C connector (Top)
Pin #
Signal Name
1
Vcc (Red)
2
GND (Black)
3
SCL(Blue)
4
SDA(Green)
5
X (White)
6
X (Orange )
J2: I2C connector (Bottom)
Pin #
Signal Name
1
Vcc (Red)
2
GND (Black)
3
SCL(Blue)
4
SDA(Green)
5
X (White)
6
X (Orange )

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
13
C
Ch a p t e r 3
Development Note
Sample and development code
The RM-G146 provides sample and development code.
Please download from official website: http://www.roboard.com

RoBoard Module RM-G146 TheHeartofRobotics
www.RoBoard.com
14
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order at
any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modifications, accident or disaster.
Vendor assumes no liability for any damages, lost profits, lost savings or any
other incidental or consequential damage resulting from the use, misuse of,
originality to use this product. Vendor will not be liable for any claim made by
any other related party. Return authorization must be obtained from the vendor
before returned merchandise will be accepted. Authorization can be obtained by
calling or faxing the vendor and requesting a Return Merchandise Authorization
(RMA) number. Returned goods should always be accompanied by a clear
problem description.
