Omron DeviceNet Safety NE1A-HDY01 User manual

OPERATION MANUAL
Cat. No. Z921-E1-01
DeviceNet Safety
NE1A-HDY01
Mobile Console

DeviceNet Safety
NE1A-HDY01
Mobile Console Operation Manual
Produced April 2009

iv

v
Notice:
OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can result in injury to people or dam-
age to property.
!WARNING Indicates a potentially hazardous situation which, if not avoided, will result in minor or
moderate injury, or may result in serious injury or death. Additionally, there may be signifi-
cant property damage.
!Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, or property damage.
OMRON Product References
All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers to
an OMRON product, regardless of whether or not it appears in the proper name of the product.
The abbreviation “PLC” means Programmable Controller.
Visual Aids
The following headings appear in the left column of the manual to help you locate different types of
information.
IMPORTANT Indicates important information on what to do or not to do to prevent failure to
operation, malfunction, or undesirable effects on product performance.
Note Indicates information of particular interest for efficient and convenient opera-
tion of the product.
1,2,3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.
Indicates a general CAUTION or WARNING precaution for which there is no spec-
ified symbol.
Indicates the risk of explosion under specific conditions.
Indicates general prohibitions for which there is no specific symbol.
Indicates general mandatory actions for which there is no specific symbol.

vi
Trademarks and Copyrights
DeviceNet, DeviceNet Safety, EtherNet/IP, EtherNet/IP Safety, CIP, and CIP Safety are registered
trademarks of the ODVA.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
Other product names and company names in this manual are trademarks or registered trademarks of
their respective companies.
OMRON, 2009
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, o
r
by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission o
f
OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con-
stantly striving to improve its high-quality products, the information contained in this manual is subject to change without
notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility
for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in
this publication.

vii
TABLE OF CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
1 Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
2 General Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
3 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
4 Precautions for Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xx
5 Precautions for Correct Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi
6 Regulations and Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi
7 Checking the Contents of the Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii
8 Definition of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii
SECTION 1
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-1 Overview of Mobile Console. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-2 Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1-3 Control Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1-4 Stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1-5 External Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-6 Starting and Stopping the Mobile Console and Standby Mode. . . . . . . . . . . . . . . . . . . . . . . 13
1-7 Using the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1-8 Using the Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
1-9 Replacing the Clock Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
1-10 Attaching the Hand Strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SECTION 2
Screen Names and Console Settings. . . . . . . . . . . . . . . . . . . 25
2-1 Screen Names and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2-2 Console Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
SECTION 3
Online Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3-1 Basic Online Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3-2 Reading Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3-3 Replacing a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3-4 Uploading Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3-5 Downloading Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
3-6 Resetting a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
3-7 Changing the Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
3-8 Locking/Unlocking Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

viii
TABLE OF CONTENTS
SECTION 4
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4-1 Mobile Console Ratings and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4-2 Battery Pack Ratings and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4-3 Charger Ratings and Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
4-4 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

ix
About this Manual:
This manual describes the NE1A-HDY01 DeviceNet Safety Mobile Console (called simply the Mobile
Console in this manual). Please read this manual carefully and be sure you understand the information
provided before attempting to use the Mobile Console. Be sure to read the precautions provided in the
following section.
The Mobile Console features easy operation by tapping a touch screen with a stylus. It is a portable
maintenance terminal that can be used for maintaining NE0A/NE1A-series Controllers and DST1-
series Safety I/O Terminals.
The following manuals provide information on the DeviceNet and DeviceNet Safety.
DeviceNet Safety Mobile Console Operation Manual (this manual) (Z921)
This manual describes the specifications, functions, and operating procedures of the Mobile Console.
DeviceNet Safety NE0A Series Safety Network Controller Operation Manual (Z916)
This manual describes the specifications, functions, and operating procedures of the NE0A-series
Safety Network Controllers.
DeviceNet Safety NE1A Series Safety Network Controller Operation Manual (Z906)
This manual describes the specifications, functions, and operating procedures of the NE1A-series
Controllers.
DeviceNet Safety System Configuration Manual (Z905)
This manual explains how to configure the DeviceNet Safety system using the Network Configurator.
DeviceNet Safety I/O Terminal Operation Manual (Z904)
This manual describes the models, specifications, functions, and operating procedures of the DST1
Series.
EtherNet/IP-DeviceNet Router Operation Manual (Z912)
This manual describes the specifications, functions, and operating procedures of the EtherNet/IP-
DeviceNet Router.
DeviceNet Operation Manual (W267)
This manual describes the construction and connection of a DeviceNet network. It provides detailed
information on the installation and specifications of cables, connectors, and other peripheral equip-
ment used in the network, and on the supply of communications power. Obtain this manual and gain a
firm understanding of its contents before using a DeviceNet network.
CS/CJ Series DeviceNet Units Operation Manual (W380)
This manual describes basic setup and standard communications using CS/CJ-series DeviceNet
Units.
!WARNING Failure to read and understand the information provided in this manual may result in per-
sonal injury or death, damage to the product, or product failure. Please read each section
in its entirety and be sure you understand the information provided in the section and
related sections before attempting any of the procedures or operations given.

x

xi
Read and Understand this Manual
Please read and understand this manual before using the product. Please consult your OMRON
representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a
period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-
INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT
LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which
liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.

xii
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses
listed may be suitable for the products:
• Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or
uses not described in this manual.
• Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.
• Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND INSTALLED
FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any
consequence thereof.

xiii
Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be changed
without any notice. When in doubt, special model numbers may be assigned to fix or establish key
specifications for your application on your request. Please consult with your OMRON representative at any
time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and does
not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must
correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and
Limitations of Liability.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

xiv

xv
PRECAUTIONS
1 Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
2 General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
3 Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
4 Precautions for Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx
5 Precautions for Correct Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi
6 Regulations and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi
7 Checking the Contents of the Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii
8 Definition of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

xvi
Intended Audience 1
1 Intended Audience
This manual is intended for the following personnel, who must have knowl-
edge of electrical systems (an electrical engineer or the equivalent).
• Personnel in charge of introducing FA and safety systems into production
facilities
• Personnel in charge of designing FA and safety systems
• Personnel in charge of managing FA facilities
• Personnel who have the qualifications, authority, and obligation to provide
safety during each of the following product phases: mechanical design,
installation, operation, maintenance, and disposal
2 General Precautions
The user must operate the product according to the performance specifica-
tions described in the operation manuals.
Before using the product under conditions which are not described in the
manual or applying the product to nuclear control systems, railroad systems,
aviation systems, vehicles, combustion systems, medical equipment, amuse-
ment machines, safety equipment, and other systems, machines, and equip-
ment that may have a serious influence on lives and property if used
improperly, consult your OMRON representative.
Make sure that the ratings and performance characteristics of the product are
sufficient for the systems, machines, and equipment, and be sure to provide
the systems, machines, and equipment with double safety mechanisms.
This manual provides information for programming and operating the Unit. Be
sure to read this manual before attempting to use the Unit and keep this man-
ual close at hand for reference during operation.
!WARNING Heed the following items during system configuration to ensure that safety-
related components are configured in a manner that allows the system func-
tions to operate sufficiently.
• Risk Assessment
The proper use of safety devices described in this Manual as it relates to
installation conditions and mechanical performance and functions is a pre-
requisite for their use. When selecting or using a safety device, risk assess-
ment must be conducted with the aim of identifying potential danger factors
in equipment or facilities in which the safety device is to be applied, during
the development stage of the equipment or facilities. Suitable safety devic-
es must be selected under the guidance of a sufficient risk assessment
system. An insufficient risk assessment system may lead to the selection
of unsuitable safety devices.
• Typical related international standards: ISO 14121, Safety of Machin-
ery -- Principles of Risk Assessment
• Safety Measures
When using safety devices to build systems containing safety-related com-
ponents for equipment or facilities, the system must be designed with the
full understanding of and conformance to international standards, such as
those listed below, and/or standards in related industries.

xvii
General Precautions 2
• Typical related international standards: ISO 12100, Safety of Machin-
ery -- Basic Concepts and General Principles for Design
IEC 61508, Safety Standard for Safety Instrumented Systems (Func-
tional Safety of Electrical/Electronic/Programmable Electronic Safety-
related Systems)
• Role of Safety Device
The safety devices are provided with safety functions and mechanisms as
stipulated in relevant standards, but suitable designs must be used to allow
these functions and mechanisms to operate properly inside system con-
structions containing safety-related components. Build systems that en-
able these functions and mechanisms to perform properly, based on a full
understanding of their operation.
• Typical related international standards: ISO 14119, Safety of Machin-
ery -- Interlocking Devices Associated with Guards -- Principles of De-
sign and Selection
• Installation of Safety Device
The construction and installation of systems with safety-related compo-
nents for equipment or facilities must be performed by technicians who
have received suitable training.
• Typical related international standards: ISO 12100, Safety of Machin-
ery -- Basic Concepts and General Principles for Design
• Complying with Laws and Regulations
The safety devices conform to the relevant regulations and standards, but
make sure that they are used in compliance with local regulations and
standards for the equipment or facilities in which they are applied.
• Typical related international standards: IEC 60204, Safety of Machin-
ery -- Electrical Equipment of Machines
• Observing Precautions for Use
When putting the selected safety devices to actual use, heed the specifi-
cations and precautions in this Manual and those in the Operation Manuals
that comes with the products. Using the products in a manner that deviates
from these specifications and precautions will lead to unexpected failures
in equipment or devices, and to damages that result from such failures,
due to insufficient operating functions in safety-related components.
• Moving or Transferring Devices or Equipment
When moving or transferring devices or equipment, be sure to include this
Manual to ensure that the person to whom the device or equipment is be-
ing moved or transferred will be able to operate the system properly.
• Typical related international standards: ISO 12100, Safety of Machin-
ery -- Basic Concepts and General Principles for Design
IEC 61508, Safety Standard for Safety Instrumented Systems (Func-
tional Safety of Electrical/Electronic/Programmable Electronic Safety-
related Systems)

xviii
Safety Precautions 3
3 Safety Precautions
!WARNING
Serious personal injury or fire may occasionally occur due to leakage, rupture, combustion, or
heat generation. Use only the peripheral devices specified by OMRON.
• Battery Pack: RB-B2001A
• Charger: RB-C2001
• Power Cable: NE1A-BTCHG-JP
NE1A-BTCHG-EU (packed together)
Serious personal injury or fire may possibly occur due to rupture, combustion, or heat genera-
tion. Observe the following precautions on the built-in lithium-ion battery and lithium battery.
• Do not use, place, or store the Product at high temperatures or in a location exposed to sun-
light.
• Do not heat the Product or expose it to fire.
• Do not allow the Product to be deformed by pressure or subjected to strong shock.
• When replacing the Battery Pack or the clock battery, do not allow the connection terminals to
come into contact with metal parts.
• Do not disassemble or modify the Product.
Serious personal injury or fire may occasionally occur due to rupture, combustion, or heat gen-
eration. Do not attempt to charge the clock battery. It is a lithium primary battery.
Serious personal injury may occasionally occur due to electric shock, rupture, combustion, or
heat generation. Do not place the Product in water or operate it with wet hands.
Serious personal injury may possibly occur due to loss of safety functions. Observe the following
precautions.
• Do not use the NE1A-HDY01 Mobile Console directly or indirectly in applications for detecting
humans to ensure safety.
• Perform a user test before operating the system, and check to make sure that all the device
configuration data and operations are correct.
• After replacing a device, check to make sure that the replacement device is in the appropriate
configuration and is operating correctly
Serious personal injury or fire may possibly occur due to rupture, combustion, or heat genera-
tion. Observe the following precautions.
• When carrying or storing the Battery Pack or the clock battery, insulate them with a material
such as tape to prevent metal parts from coming into contact with the Battery Pack connection
terminals.
• If any abnormality, such as smoke or an unusual odor or noise, occurs during operation, imme-
diately turn OFF the power switch and stop using the Product.
Personal injury may occasionally occur. Stop using the Product immediately if the touch screen
is damaged.
• If leaked fluid comes into contact with skin or clothing, immediately flush it thoroughly with
clean water.
• If leaked fluid comes into contact with the eyes or mouth, do not rub it. Flush thoroughly with
clean water and then consult a physician.
Personal injury may occasionally occur. Stop using the Product immediately if leaked fluid or an
unusual odor from the Battery Pack or clock battery is detected.
• If there are flames nearby, move the Product away from the flames. Failure to do so may result
in leaked fluid catching fire, causing rupture or combustion.
• If leaked fluid comes into contact with skin or clothing, immediately rinse it thoroughly with
clean water.
• If leaked fluid comes into contact with the eyes or mouth, do not rub it. Flush thoroughly with
clean water and then consult a physician.

xix
Safety Precautions 3
■Warnings on RB-B2001A Battery Pack
■Warnings on RB-C2001 Charger
!WARNING
Serious personal injury or fire may occasionally occur due to rupture, combustion, or heat gen-
eration.
• Do not short-circuit the plus (+) and minus (−) terminals of the Battery Pack.
• Do not use, place, or store the Battery Pack in a location exposed to sunlight.
• Do not heat the Battery Pack or expose it to fire.
• Do not drop the Battery Pack or allow it to be subjected to severe shock.
Serious personal injury or fire may occasionally occur due to leakage, rupture, combustion, or
heat generation.
• Do not use a charger other than the one specified by OMRON for charging the Battery Pack.
• Do not disassemble or modify the Battery Pack.
• Do not use the Battery Pack with a device other than the NE1A-HDY01 Mobile Console.
• Do not place the Battery Pack in water or operate it with wet hands.
When carrying or storing the Battery Pack, insulate it with material, such as tape, to prevent
metal parts from coming into contact with the Battery Pack connection terminals. Failure to do
so may result in short-circuiting, occasionally causing serious personal injury or fire due to rup-
ture, combustion, or heat generation.
Personal injury may occasionally occur.
If leakage or an unusual odor from the Battery Pack is detected, stop using the Battery Pack
immediately.
• If there are flames nearby, move the Battery Pack away from the flames. Failure to do so may
result in leaked fluid catching fire, causing rupture or combustion.
• If leaked fluid comes into contact with skin or clothing, immediately rinse it thoroughly with
clean water.
• If leaked fluid comes into contact with the eyes or mouth, do not rub it. Flush thoroughly with
clean water and then consult a physician.
!WARNING
If the charge indicator is flashing red, or if charging does not finish even though the specified
time has been exceeded, stop charging and remove the power plug from the outlet. Failure to do
so may occasionally result in serious personal injury or fire due to leakage, rupture, combustion,
or heat generation.
Using other devices may occasionally result in serious personal injury or fire due to leakage,
rupture, combustion, or heat generation.
Do not use the Charger for charging any Battery Pack other than the one specified by OMRON.
Serious personal injury may occasionally occur due to electric shock, rupture, combustion, or
heat generation. Do not place the Product in water or operate it with wet hands.
Serious personal injury may occasionally occur due to combustion, heat generation, or electric
shock. Observe the following precautions.
• When not charging, remove the power supply plug from the outlet.
• Do not damage the Charger power cable, modify it, place heavy objects on it, or bend it past its
natural bending radius.

xx
Precautions for Safe Use 4
4 Precautions for Safe Use
• Before Operation
When opening the package, perform a visual check for any damage. Light-
ly shake the Product and listen for any unusual sounds.
• Storage and Operating Environments
Do not store or operate the Product in any of the following locations.
• Locations subject to direct sunlight
• Locations subject to temperatures or humidity outside the range spec-
ified in the specifications
• Locations subject to condensation as the result of severe changes in
temperature
• Locations subject to steam.
• Locations subject to corrosive or flammable gases
• Locations subject to dust (especially iron dust) or salts
• Locations subject to water, oil, or chemicals
• Locations subject to shock or vibration
Take appropriate and sufficient measures when installing systems in the
following locations. Inappropriate and insufficient measures may result in
malfunction.
• Locations subject to static electricity or other forms of noise
• Locations subject to strong electromagnetic fields
• Locations subject to possible exposure to radioactivity
• Locations close to power supplies
The Mobile Console is a Class A product. It may cause radio interference
in residential areas, in which case the user may be required to take ade-
quate measures to reduce interference.
• Power Supply
Do not connect the Charger to a power supply that exceeds the ratings.
• Periodic Inspections and Maintenance
Always turn OFF the power switch before installing or replacing the Battery
Pack or clock battery.
• Disposal
• When disposing of the Battery Pack or clock battery, insulate the plus
(+) and minus (−) terminals of the battery with tape.
• Follow all local government regulations as applicable when disposing
of the Mobile Console and used batteries.
• The Battery Pack is a lithium-ion secondary battery. It can be recycled.

xxi
Precautions for Correct Use 5
5 Precautions for Correct Use
Observe the following precautions in order to prevent Product failure, Product
malfunction, or adverse effects on the performance of the Product.
• Handling the Memory Card
Do not perform any of the following operations while the Memory Card is
being accessed. Doing so may cause data to be lost.
• Turning OFF the Mobile Console power switch
• Removing the Battery Pack
• Removing the Memory Card
• Handling the Touch Screen
• Use the enclosed stylus for touch screen operations. Using a sharp ob-
ject may scratch the touch screen surface so that the screen cannot be
used for inputs.
• Do not press hard on or rub the touch screen surface. Doing so may
not only cause damage but may break the glass.
• Cleaning
Use a clean, dry cloth for cleaning. If dirt cannot be removed using a dry
cloth, dampen the cloth with a neutral cleaning solution, wring the cloth out
tightly, and then wipe the dirty section.
Never use benzene or thinner, or other volatile solvents or chemical cloths,
to clean the Product. Doing so may discolor the surface or cause damage.
6 Regulations and Standards
The NE1A-HDY01 has been determined to conform to the EC EMC Directive
by conforming to the following standards.
Certifying organization Standards
TÜV Rheinland IEC 61131-2
IEC 61000-6-4
CISPR 16-1-2
CISPR 16-2-1
CISPR 16-2-3
