Omron CQM1H - 08-2005 User manual

Cat.No. W238--E1--8
Dedicated I/O Units
CQM1H/CQM1-series
OPERATION MANUAL
SYSMAC

CQM1H/CQM1Series
Dedicated I/O Units
Operation Manual
Revised August 2000

!
!
!
v
Notice:
OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can result in injury to people or dam-
age to property.
DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, or property damage.
OMRON Product References
All OMRON products are capitalized in this manual. The word “Unit”is also capitalized when it refers
to an OMRON product, regardless of whether or not it appears in the proper name of the product.
The abbreviation “Ch,”which appears in some displays and on some OMRON products, often means
“word”and is abbreviated “Wd”in documentation in this sense.
The abbreviation “PC”means Programmable Controller and is not used as an abbreviation for any-
thing else.
Visual Aids
The following headings appear in the left column of the manual to help you locate different types of
information.
Note Indicates information of particular interest for efficient and convenient operation
of the product.
1, 2, 3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.
OMRON, 1993
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permis-
sion of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is
constantly striving to improve its high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no
responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the informa-
tion contained in this publication.

TABLE OF CONTENTS
vii
PRECAUTIONS xv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Intended Audience xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 General Precautions xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Safety Precautions xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Operating Environment Precautions xvii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Application Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART I 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B7A Interface Unit 1. . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 3. . . . . . . . . . . . . . . . .
1-1 Features 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Connecting Devices 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Word Allocation 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-5 Bit Allocation 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Settings 9. . . . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Switch Settings 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Connections 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Connections to B7A Link Terminals 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Wiring 20.................................................................
Appendices
A Specifications 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART II 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
G730 Interface Unit 25. . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 27. . . . . . . . . . . . . . . . .
1-1 Features 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Connecting Devices 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Settings 33. . . . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Switch Settings 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Connections 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Transmission Cables 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 External Output Connection Cables 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 4
Operation 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Word Allocation 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-2 Handling Power On 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-3 Transmission Delay Time 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
viii
Appendices
B Specifications 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C Troubleshooting 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART III 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I/O Link Unit 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 61. . . . . . . . . . . . . . . . .
1-1 Features 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Connecting Devices 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Word Allocation 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Settings 65. . . . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Switch Settings 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Connections 69. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 SYSMAC BUS Cable Connections 70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendices
D Specifications 71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART IV 73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Analog Input Unit and Analog Power Supply Units 73
SECTION 1
Features and System Configuration 75. . . . . . . . . . . . . . . . .
1-1 Features 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Connecting Devices 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 System Construction 78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Functions 79. . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Functions 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Operation 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Settings 86. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Bit Number Allocation 88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Programming and Adjustment 89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendices
E Specifications 95. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F Troubleshooting 99. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
ix
PART V 101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Analog Output Unit and Analog Power Supply Units101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 103. . . . . . . . . . . . . . . . .
1-1 Features of Analog Output Unit 104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Functions 107. . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 108. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Functions 109. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Operation 111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Settings 112. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Bit Number Allocation 114. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Programming and Adjustment 115. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendices
G Specifications 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
H Troubleshooting 121. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART VI 123. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sensor Unit 123. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 125. . . . . . . . . . . . . . . . .
1-1 Features 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Connecting Devices 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 System Construction 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Nomenclature and Functions 129. . . . . . . . . . . . . . . . . . . . . .
2-1 Nomenclature 130. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Switch Settings 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Connections 137. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Wiring Precaution 138. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Mounting and Dismounting the Sensor Module 140. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Connection of CQM1-TU001 Remote Console 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-4 Connection of a Variety of Sensors 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 4
Sensor Module Operation 145. . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Operation without CQM1-TU001 Remote Console 146. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 5
Remote Console Operation 153. . . . . . . . . . . . . . . . . . . . . . . .
5-1 Mode Setting 154. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-2 Sensitivity Adjustment 154. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
x
Appendices
I Specifications 157. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART VII 167. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Linear Sensor Interface Units 167. . . . . . . . . . . . . . . . .
SECTION 1
Features and System Configuration 169. . . . . . . . . . . . . . . . .
1-1 Features 170. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 System Configuration 170. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Functions 173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-1 Scaling 174. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Timing Hold 175. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-3 Scaled Conversion Data/Comparison Result 178. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-4 Teaching 178. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-5 Forced Zero (Zero-shift) 179. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-6 Voltage Monitor Output 180. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Nomenclature and Functions 181. . . . . . . . . . . . . . . . . . . . . .
3-1 Nomenclature 182. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Terminals 183. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 4
Connections 185. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Mounting and Wiring 186. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 5
Basic Operation 187. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-1 Operating Method 188. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-2 Programming Console Operation 189. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-3 Operation Mode 190. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-4 Scaling 192. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-5 Comparison 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-6 Monitoring 196. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 6
Applied Operation 199. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-1 Scaling Value Teaching 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-2 Set Value Teaching 201. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-3 Forced-zero Shift 202. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-4 BCD Value Read 203. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-5 Monitor Output 203. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 7
Commands 205. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7-1 Command Usage 206. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7-2 List of Commands 208. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7-3 Commands and Responses 208. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
xi
Appendices
J Specifications 219. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
K Block Diagram 221. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
L Data Processing Timing 223. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M Troubleshooting 227. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART VIII 229. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Control Units 229. . . . . . . . . . . . . . . . . . .
SECTION 1
Temperature Control Unit Model Numbers 231. . . . . . . . . .
SECTION 2
CQM1-TC20j/TC30jTemperature Control Units 233. . .
2-1 Features and Word Allocations 234. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Specifications 235. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-3 Nomenclature 238. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-4 Terminology and Function Descriptions 242. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-5 Wiring 243.................................................................
2-6 Application 245. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-7 IOTC(––) 251. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-8 Troubleshooting 259. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-9 Command Tables 260. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
CQM1-TC00j/TC10jTemperature Control Units 261. . .
3-1 Features and Word Allocations 262. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Specifications 263. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Nomenclature 264. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-4 Wiring 266.................................................................
3-5 Application Examples 267. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-6 AT (Expansion Mode) 272. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-7 Troubleshooting 277. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Revision History 279. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

xiii
About this Manual:
This manual describes the installation and operation of the CQM1H/CQM1-series Dedicated I/O Units
and includes the parts and sections described below. The CQM1H/CQM1-series Dedicated I/O Units
consist of the Units listed below.
Please read this manual carefully and be sure you understand the information provided before attempting
to install and operate the CQM1H/CQM1-series Dedicated I/O Units.
Part I: B7A Interface Units
Section 1 describes the general features, system configuration, and word allocation of the B7A Interface
Units.
Section 2 provides the nomenclature and switch settings for the B7A Interface Units.
Section 3 describes the connections between the B7A Interface Units and B7A Link Terminals.
The Appendix provides the specifications for the Units.
Part II: G730 Interface Units
Section 1 describes the general features, system configuration, and word allocation of the G730 Inter-
face Units.
Section 2 provides the nomenclature and switch settings for the G730 Interface Units.
Section 3 describes the connections between the G730 Interface Units and G730 Remote Terminals.
Section 4 provides the operational procedures for the G730 Interface Unit.
The Appendices provide the specifications, dimensions, and troubleshooting procedure for the Units.
Part III: I/O Link Unit
Section 1 describes the general features, system configuration, and word allocation of the CQM1-LK501
I/O Link Unit.
Section 2 provides the nomenclature and switch settings for the CQM1-LK501 I/O Link Unit.
Section 3 describes the SYSMAC BUS cable connections for the CQM1-LK501 I/O Link Unit.
The Appendix provides the specifications for the Unit.
Part IV: Analog Input Unit and Analog Power Supply Units
Section 1 provides the features and system configuration relating to the Analog Input Unit and Analog
Power Supply Units.
Section 2 provides the nomenclature and functions of the Analog Input Unit and Analog Power Supply
Units.
Section 3 provides the operational procedures for the Analog Input Unit and Analog Power Supply Units.
TheAppendices provide the specifications, internal configuration, dimensions, and troubleshooting pro-
cedure for the Units.
Part V: Analog Output Unit and Analog Power Supply Units
Section 1 provides the features and system configuration relating to the Analog Output Unit and Analog
Power Supply Units.
Section 2 provides the nomenclature and functions of the Analog Output Unit.
Section 3 provides the operational procedures for the Analog Output Unit.
The Appendices provide the specifications and troubleshooting procedures for the Units.
WARNING Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
!

xiv
Part VI: Sensor Unit
Section 1 provides the features and system configuration relating to the Sensor Unit and dedicated sen-
sor modules.
Section 2 provides the nomenclature and switch settings for the CQM1-SEN01, CQM1-TU001, E3X-
MA11, E3C-MA11, and E2C-MA11.
Section 3 describes the connections between the CQM1-SEN01 and E3X-MA11, E3C-MA11, E2C-
MA11, and CQM1-TU001.
Section 4 provides information on the operation of the CQM1-SEN01.
Section 5 provides information on the operation of the CQM1-TU001 Remote Console.
The Appendix provides the specifications for the Units.
Part VII: Linear Sensor Interface Units
Section 1 provides the features and system configuration relating to the Linear Sensor Interface Unit.
Section 2 provides an explanation of the scaling, timing hold, measured value, teaching, forced-zero
shift, and monitor output functions.
Section 3 provides the nomenclature, and terminal and indicator functions of the Linear Sensor Interface
Unit.
Section 4 describes the connections of the Linear Sensor Interface Unit.
Section 5 describes the basic operation of the Linear Sensor Interface Unit using the Programming Con-
sole.
Section 6 describes the applied operation of the Linear Sensor Interface Unit using the Programming
Console.
Section 7 provides details on the commands and responses of the Linear Sensor Interface Unit.
TheAppendices provide the specifications, block diagram, data processing timing, and troubleshooting
for the Units.
Part VIII: Temperature Control Units
Section 1 lists the Temperature Control Unit model numbers and the basic specifications for each Unit.
Section 2 describes the features and operation of the CQM1-TC20j/TC30j Temperature Control Units.
Section 3 describes the features and operation of the CQM1-TC00j/TC10j Temperature Control Units.
The Appendix provides the specifications for the Unit.

xv
PRECAUTIONS
This section provides general precautions for using the Programmable Controller (PC) and related devices.
The information contained in this section is important for the safe and reliable application of the Programmable Con-
troller. You must read this section and understand the information contained before attempting to set up or operate a
PC system.
1 Intended Audience xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 General Precautions xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Safety Precautions xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Operating Environment Precautions xvii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Application Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!
!
!
!
3Application Precautions
xvi
1 Intended Audience
This manual is intended for the following personnel, who must also have knowl-
edge of electrical systems (an electrical engineer or the equivalent).
•Personnel in charge of installing FA systems.
•Personnel in charge of designing FA systems.
•Personnel in charge of managing FA systems and facilities.
2 General Precautions
The user must operate the product according to the performance specifications
described in the operation manuals.
Before using the product under conditions which are not described in the manual
or applying the product to nuclear control systems, railroad systems, aviation
systems, vehicles, combustion systems, medical equipment, amusement ma-
chines, safety equipment, and other systems, machines, and equipment that
may have a serious influence on lives and property if used improperly, consult
your OMRON representative.
Make sure that the ratings and performance characteristics of the product are
sufficient for the systems, machines, and equipment, and be sure to provide the
systems, machines, and equipment with double safety mechanisms.
This manual provides information for programming and operating the Unit. Be
sure to read this manual before attempting to use the Unit and keep this manual
close at hand for reference during operation.
WARNING It is extremely important that a PC and all PC Units be used for the specified
purpose and under the specified conditions, especially in applications that can
directly or indirectly affect human life. You must consult with your OMRON
representative before applying a PC System to the above-mentioned
applications.
3 Safety Precautions
WARNING Do not attempt to take any Unit apart while the power is being supplied. Doing so
may result in electric shock.
WARNING Do not touch any of the terminals or terminal blocks while the power is being
supplied. Doing so may result in electric shock.
WARNING Provide safety measures in external circuits, i.e., not in the Programmable
Controller (CPU Unit and associated Units; referred to as “PC”), in order to
ensure safety in the system if an abnormality occurs due to malfunction of the PC
or another external factor affecting the PC operation. Not doing so may result in
serious accidents.
•Emergency stop circuits, interlock circuits, limit circuits, and similar safety
measures must be provided in external control circuits.
•The PC will turn OFF all outputs when its self-diagnosis function detects any
error or when a severe failure alarm (FALS) instruction is executed. As a coun-
termeasure for such errors, external safety measures must be provided to en-
sure safety in the system.
•The PC outputs may remain ON or OFF due to deposition or burning of the
output relays or destruction of the output transistors. As a countermeasure for

!
!
!
!
!
!
!
4Application Precautions
xvii
such problems, external safety measures must be provided to ensure safety in
the system.
•When the 24-VDC output (service power supply to the PC) is overloaded or
short-circuited, the voltage may drop and result in the outputs being turned
OFF. As a countermeasure for such problems, external safety measures must
be provided to ensure safety in the system.
Caution Execute online edit only after confirming that no adverse effects will be caused
by extending the cycle time. Otherwise, the input signals may not be readable.
Caution Confirm safety at the destination node before transferring a program to another
node or editing the I/O area. Doing either of these without confirming safety may
result in injury.
WARNING Do not attempt to disassemble, repair, or modify any Units. Any attempt to do so
may result in malfunction, fire, or electric shock.
Caution Provide appropriate safety measures, such as overheat prevention and alarm
systems, in separate circuits to ensure safety of the entire system even when the
Temperature Controller malfunctions.
4 Operating Environment Precautions
Caution Do not operate the control system in the following places:
•Locations subject to direct sunlight.
•Locations subject to temperatures or humidity outside the range specified in
the specifications.
•Locations subject to condensation as the result of severe changes in tempera-
ture.
•Locations subject to corrosive or flammable gases.
•Locations subject to dust (especially iron dust) or salts.
•Locations subject to exposure to water, oil, or chemicals.
•Locations subject to shock or vibration.
Caution Take appropriate and sufficient countermeasures when installing systems in the
following locations:
•Locations subject to static electricity or other forms of noise.
•Locations subject to strong electromagnetic fields.
•Locations subject to possible exposure to radioactivity.
•Locations close to power supplies.
Caution The operating environment of the PC System can have a large effect on the lon-
gevity and reliability of the system. Improper operating environments can lead to
malfunction, failure, and other unforeseeable problems with the PC System. Be
sure that the operating environment is within the specified conditions at installa-
tion and remains within the specified conditions during the life of the system.

!
!
5Application Precautions
xviii
5 Application Precautions
Observe the following precautions when using the PC System.
WARNING Always heed these precautions. Failure to abide by the following precautions
could lead to serious or possibly fatal injury.
•Always ground to 100 Ωor less when installing the Units. Improper grounding
may result in electric shock.
•Always turn OFF the power supply to the PC before attempting any of the fol-
lowing. Not turning OFF the power supply may result in malfunction or electric
shock.
•Assembling the Units.
•Setting DIP switches or rotary switches.
•Connecting or wiring the cables.
•Connecting or disconnecting the connectors.
Caution Failure to abide by the following precautions could lead to faulty operation of the
PC or the system, or could damage the PC or PC Units. Always heed these pre-
cautions.
•Fail-safe measures must be taken by the customer to ensure safety in the
event of incorrect, missing, or abnormal signals caused by broken signal lines,
momentary power interruptions, or other causes.
•Install external breakers and take other safety measures against short-circuit-
ing in external wiring. Insufficient safety measures against short-circuiting may
result in burning.
•Mount the Unit only after checking the terminal block completely.
•Be sure that all the mounting screws, terminal screws, and cable connector
screws are tightened to the torque specified in the relevant manuals. Incorrect
tightening torque may result in malfunction.
•Always use the power supply voltage specified in this operation manual. An
incorrect voltage may result in malfunction or burning.
•Take appropriate measures to ensure that the specified power with the rated
voltage and frequency is supplied. Be particularly careful in places where the
power supply is unstable. An incorrect power supply may result in malfunction.
•Leave the label attached to the Unit when wiring. Removing the label may re-
sult in malfunction.
•Remove the label after the completion of wiring to ensure proper heat dissipa-
tion. Leaving the label attached may result in malfunction.
•Use crimp terminals for wiring. Do not connect bare stranded wires directly to
terminals. Connection of bare stranded wires may result in burning.
•Do not apply voltages to the Input Units in excess of the rated input voltage.
Excess voltages may result in burning.
•Do not apply voltages or connect loads to the Output Units in excess of the
maximum switching capacity. Excess voltage or loads may result in burning.
•Be sure that the terminal blocks, Memory Units, expansion cables, and other
items with locking devices are properly locked into place. Improper locking
may result in malfunction.
•Disconnect the functional ground terminal when performing withstand voltage
tests. Not disconnecting the functional ground terminal may result in burning.
•Double-check all the wiring and switch settings before turning ON the power
supply. Incorrect wiring or switch settings may result in burning.

5Application Precautions
xix
•Check that the DIP switches and data memory (DM) are properly set before
starting operation.
•Check the user program for proper execution before actually running it on the
Unit. Not checking the program may result in an unexpected operation.
•Resume operation only after transferring to the new CPU Unit the contents of
the DM and HR Areas required for resuming operation. Not doing so may result
in an unexpected operation.
•Confirm that no adverse effect will occur in the system before attempting any of
the following. Not doing so may result in an unexpected operation.
•Changing the operating mode of the PC.
•Force-setting/force-resetting any bit in memory.
•Changing the present value of any word or any set value in memory.
•Do not pull on the cables or bend the cables beyond their natural limit. Doing
either of these may break the cables.
•Do not place objects on top of the cables. Doing so may break the cables.
•When replacing parts, be sure to confirm that the rating of a new part is correct.
Not doing so may result in malfunction or burning.
•Before touching the Unit, be sure to first touch a grounded metallic object in
order to discharge any static built-up. Not doing so may result in malfunction or
damage.
•Do not turn OFF the power supply to the Unit while data is being transferred.
•When transporting or storing the product, cover the PCBs with electrically con-
ductive materials to prevent LSIs and ICs from being damaged by static elec-
tricity, and also keep the product within the specified storage temperature
range.
•Install the Unit properly as specified in the operation manual. Improper installa-
tion of the Unit may result in malfunction.
•Provide a control circuit so that the power to the I/O circuits will turn ON after
the power to the PC turns ON. If the power to the I/O circuits turns ON before
the power to the PC turns ON, the system may malfunction temporarily.
•If the I/O Hold Bit (SR 25212) is turned ON, the outputs from the PC will not be
turned OFF and will maintain their previous status when the PC is switched
from RUN or MONITOR mode to PROGRAM mode. Make sure that the exter-
nal loads will not produce dangerous conditions when this occurs. (When op-
eration stops for a fatal error, including those produced with the FALS(07)
instruction, all outputs from Output Unit will be turned OFF and only the internal
output status will be maintained.)
•When assembling the Units or mounting the end cover, be sure to lock them
securely as shown in the following illustrations. If they are not properly locked,
desired functionality may not be achieved.
•Be sure to mount the end cover to the rightmost Unit.
•Be sure that the connectors, terminal blocks, connection cables, and other
items with locking devices are properly locked into place. Improper locking
may result in malfunction.
•Be sure to confirm the orientation and polarities when connecting terminal
blocks and connectors.
•Do not touch the back side of circuit boards or the components mounted to
them with your bare hands. There are sharp leads and other parts on the
boards that may cause injury if handled improperly.
•Provide sufficient clearances around the Unit and other devices to ensure
proper heat dissipation. Do not cover the ventilation openings of the Unit.
•Do not allow metallic objects or conductive wires to enter the Unit.

5Application Precautions
xx
•Set the operating settings of the Temperature Controller properly according to
the system to be controlled.
•Allow at least 30 minutes after turning ON the Temperature Controller as war-
mup time.
•Do not use thinner to clean the product. Use commercially available cleaning
alcohol.
