ON-LAP 1303 Instruction sheet

Manual of 1303
Read Me Before Usage!

Chapter 1 Content Description —1
Section 1 On-Lap Monitor and Accessories —1
Section 2 Notices of On-Lap Monitor —3
Section 3 Safety Precautions —4
Section 4 Safety Instructions —4
Section 5 Product Maintenance —4
Section 6 LCD Pixel Statement —4
Section 7 Disposal of Electronic Equipment —5
Chapter 2 Installation Instructions —5
Section 1 Cover Stand and VESA 100 Kit Assembly —5
Section 2 Connect the Video Cable and USB Touch and
Power Cable —7
Chapter 3 Power On and Off the On-Lap Monitor —8
Section 1 Power On and Off the On-Lap Monitor —8
Section 2 Monitor Display Setting —8
Section 3 Windows 10/ 8.1/ 7 Touchscreen Setting —9
Section 4 Windows 8.1/ 10 Touch Gesture Description —10
Chapter 4 Hot Keys and OSD Instructions —10
Section 1 Hot Keys & LED lights Description —10
Section 2 OSD Description —11
Section 3 Low Power Protection Warning —13
Chapter 5 Specification —13
Section 1 Plug and Play —13
Section 2 Pin Assignment —13
Section 3 Specification —15
Section 4 Troubleshooting —16
Table of Contents
English

２． .
１．
．
．
目 次

Chapter 1 Content Description
Section 1 On-Lap Monitor and Accessories
1. Parts Description
1
Fig.: On-Lap 1303 Front & Back
Fig.: 1303 buttons and LED light Description
Fig.: On-Lap 1303H & 1303A Input & Output ports

Fig.: Parts Description of Protective Cover
2
Fig.: On-Lap 1303I Input & Output ports

2. Package & Accessories
Section 2 Notice of On-Lap Monitor
1. When plugging out the cables, do make sure the aspect of plug is hori-
zontally—do not shake the port or plug forcefully. Any damage caused
by wrong plug inserting is not included in warranty coverage.
2. The power input specification for On-Lap monitor is 5V 2A DC current。
Input power over than 5V will cause breakdowns on monitor and this
damage is not included in warranty coverage. It is suggested to connect
both plugs of USB power cable to computer’s USB ports or manufactur-
er’s 5V-2A adapter.
3. Unstable power input will interfere with touch signal, resulting inaccurate
or failed touch function. If some high power consumption equipment
share the power in the same electricity network, it may cause acute elec-
tricity fluctuation. It is suggested to use the USB port on laptop or manu-
facturer’s 5V-2A charger.
4. Do not put touch monitor near to light blub, electric cord, or anything
with great electromagnetic wave which may disturb projective capacitive
touch monitor and cause touchscreen function abnormal.
3
Accessories 1303I 1303H 1303A
USB-A to micro-USB power and touch signal
cable (1.2m) Yes(2 pcs) Yes(1 pcs) Yes (1 pcs)
HDMI-A to Micro-HDMI Video Cable (1.2m) Yes Yes Yes
On-Lap proprietary mini-Displayport cable Optional Optional Optional
On-Lap proprietary VGA cable (1.2m) Optional Optional Optional
Adapter(5V,Max.2A) 1 pcs Yes Yes No
Cover1 pcs Yes Yes Yes
Manual 1 pcs Yes Yes Yes
HDMI-A to micro-HDMI Video Cable (2.1m) Optional Optional Optional
Mini-HDMI to micro-HDMI Video Cable
(2.1m) Optional Optional Optional
On-Lap proprietary DisplayPort Cable (2.1m) Optional Optional Optional
USB-A to micro-USB power and touch signal
cable (2.1m) Optional Optional Optional
1303 VESA 100 kit Optional Optional Optional
Stand 4 Optional Optional Optional

5. Please do not use sharp objects o touch the screen. Gently use the finger
to touch or swipe on the screen. While touching the screen, please keep
finger clean and dry. Do not press the screen forcefully.
6. Notice for Monitor Clean
Disconnect power input before cleaning. Please use soft cloth to clean
touch screen monitor. If something is hard to wipe off, please wet the
cloth and wipe again. Please do not use chlorine, alcohol, ammonia, deter-
gent or other corroding solvents. These solvents may cause damage to the
touch screen monitor or leave unremovable residue.
7. Notice for Monitor Operation
Avoid to expose the monitor directly under sunlight for long, which may
result in damage. When monitor displays different images, image bright-
ness may become slightly uneven.
Section 3 Safety Precautions
1. The Product may be severely damaged from overturning or falling. Please
do not place on a shaky or unstable table, cupboard or trolley. Do not use
the On-Lap Monitor on a moving vehicle.
2. Do not place the items on a vibrating surface, vibration may cause dam-
age to the internal components.
3. The product is not waterproof. Do not use the Product at or near a place
with water.
4. Do not insert any object into the Product’s slots or gaps.
5. Loudness warning! Avoid volume levels that may be harmful to your
hearing. Please check the volume setting before you use the Audio Jack.
6. Please notice the plug in the box is applicable to its AC adapter only.
Section 4 Safety Instructions
Please read this Manual carefully and observe the operation instructions and
precautionary notes. Do retain this document for future reference.
Section 5 Product Maintenance
Do not attempt to repair the Product yourself. Should any of the following
conditions occur, please contact our maintenance personnel for service:
1) Unable to operate the Product after following the instructions in the
Manual.
2) The Product falls and the outer casing is damaged.
3) Power cable or video cables is damaged.
4) Liquid infiltrated into the Product.
Any normal wear and misuse, including but not limited to product failure due to normal
usage, is not covered under warranty. Accident, damage, software or hardware changes,
force majeure, or become in contact with liquid that result in product malfunction is not
covered under warranty.
Section 6 LCD Pixel Statement
The On-Lap Monitor uses a high quality LCD panel. Nevertheless, there might
be instances where defective pixels may occur; however, this will not affect the
normal functioning of the Product.
4

Section 7 Disposal of Electronic Equipment
The electronic equipment and batteries should not be disposed of
with household waste but should be left at an appropriate collection
point for recycling.
Chapter 2 Installation Instructions
Section 1 Cover Stand and VESA 100 Kit Assembly
1 Install Cover Stand
1-1 Take Monitor out: Hold both sides of the cover’s rim by thumbs and then
push the monitor from back by the fingers. When putting the monitor
back to the Cover Stand, first put the bottom of Monitor in and then push
the top part of monitor into the cover.
1-2 Take the magnetic buckle off first. There are 4 slots for the magnetic buck-
le on the back of Cover Stand. Put Magnetic Buckle in one of the slots
and the Cover Stand is set.
Fig ：Take Monitor out from Cover Stand
5
Caution: In order to avoid dropping or breaking the monitor, please keep
the back of monitor outward the cover Stand when not in usage.
Fig ：Put Monitor in Cover Stand
Fig ：Put Magnetic Buckle in slot
to set the Cover Stand

2 VESA 100 Kit Installation (Optional)
First Screw the VESA100 Kit in VESA100 arm or camera cradle head/ tripod.
Place the Monitor into VESA 100 Kit, as shown in Fig, and secure the Monitor
by screwing in.
3 Install Stand 4 (optional)
Step 1 Assemble Stand 4
Select the desired angle placement
to assemble Stand 4. During as-
sembly, check if X plate is properly
inserted onto slot.
Step 2 Place On-Lap monitor onto Stand 4.
Stand 4 is positioned at the bottom center of
monitor.
6
Fig ：Screw the VESA100 kit in VESA
arm. Put the Monitor in and secure it
by screws.
Fig ：Screw the VESA100 kit in camera
cradle head. Put the Monitor in and
secure it by screws.
Fig ：Install Stand 4
Fig ：Place 1303 in Stand 4

Section 2 Connect the Video Cable and USB Touch Power Cable
1. Connection method for On-Lap 1303H & 1303A
Connect USB Power cable first
and then connect Video ca-
ble. USB power Cable can be
connected to USB port of
laptop or 5V 2A USB charger.
Voice is transmitted by micro-
HDMI or DisplayPort ports.
VGA does not support voice
transmission.
PS: if one USB port of laptop
does not supply enough
power. Please insert another
USB plug to laptop, which
supply double power.
2. Connection method for On Lap 1303I
○
1Connect USB Touch Output
and Power Cable’s Micro USB
(B type) connector to On-Lap
1303I’s Micro USB port.
Connect the other end, USB
connector to USB port of lap-
top. With this connection,
laptop will provide power and
touch signal to On-Lap 1303I.
If one USB port on laptop is
unable to provide enough
power, please connect the two
USB connectors to two USB
ports on laptop, this can pro-
vide double power.
○
2Or connect the second USB power cable to the 5V 2A charger.
After then connect Video cable. Only when micro-HDMI or DisplayPort is
connected will the Monitor have sound. VGA does not support voice transmis-
sion.
Caution: Micro USB port can transmit both touch signal and power , but
Power port can only transmit power. If Micro USB port is not con-
nect to USB port of laptop, touch function can not be enabled.
7

Chapter 3 Power On and Off the On-Lap Monitor
Section 1 Power On and Off the On-Lap
1. From Off state to On state: Press Power Button to activate On/Off.
2. First time use: When Micro USB to USB touch signal and power connect
to USB port on computer or 5V DC Charger, On-Lap will automatically
start and detect video signal to automatically display video. (Connection
method shall refer to Chapter 2 Section 2)
Section 2 Monitor Display Setting
1. Set Extended Display Mode-Windows 10 System
Press and choose “Settings”> select”System”>select“Display”.
Then choose”Extend these displays” at Multiple displays.
Refer to 3.Set Extended Display Mode-Windows 7 System for resolution.
2. Set Extended Display Mode-Windows 8.1 System
Select directly from right side of screen [Devices] ->select [Project]->select
[2nd Monitor] -> select [Extend Mode]
For screen resolution setting please refer to the followings.
8

9
3. Set Extended Display Mode-Windows 7 System
●Click on icon
●Click on Control Panel >Appearance and Personalization
●Click on Display > Connect to an external display.
Normally Display ①is the laptop’s monitor, Display ② is the external mon-
itor. Click on Detect if you are unsure.
●At Display, select “2.HDMI” (digital video) or “2. display device:
VGA” (analog video) for Display
●Select Resoluton“1920x1080”
for 1303H& 1303I. Select Reso-
lution “1366x768” for 1303A.
●Select "Landscape" or "Portrait"
for Orientation.
●Select "Extend these displays" for
Multiple display, and drag Dis-
play 2 to the right side of Display
1. For Duplicated mode, select
"Duplicate these displays".
●Select OK and exit after saving
the settings.
Section 3 Windows 10/8.1/7 Touchscreen Setting
(Notice: Only 1303I supports Touch Function)
If you find the cursor acts wrongly, please calibrate the monitors at Windows
system. Please connect 1303I to laptop first, if not, the calibration can’t be
begun.
In Windows10, search”calibration” at ‘Settings’,select ‘Calibrate the
screen for pen or touch input’
In Windows8.1/7, Select ‘Tablet PC Setting’of Control Panel to calibrate
touch input.
As Fig., please select “Setting (S)”, when Windows message appears on the
screen of On-Lap 1303I, follow the direction to touch the screen and the
setting is complete.

Section 4 Windows 8.1/ 10 Touch Gesture Description
Common Touch Gesture Introduction:
1. Use finger to swipe in from edge:
○
1Swipe in from the right edge of
the screen (Arrow 1) : Open the five
charms –Search, Share, Start, De-
vices, and Settings
○
2Swipe in from the left edge of
the screen (Arrow 2) : Switch be-
tween apps
○
3Swipe in from the left edge of
the screen then out toward the left
edge of the screen (Arrow 3): Display all apps
○
4○ 5Swipe in from the top edge (Arrow 4) or bottom edge (Arrow 5):
Display commands of app, like Add New, Reminder, etc.
○
6With touch, drag the app from the top edge of screen (Arrow 6) to the
bottom of the screen: Close app
2. Select item: Tap on the item to open. This function is similar to clicking on
mouse.
3. Press and hold the item for a few seconds then release: Display item
information. This function is similar to right-clicking on mouse.
4. Zoom in and out: Touch the item with two fingers then move fingers
toward each other (pinch) or away from each other (stretch).
5. Slide finger on the screen, horizontally or vertically, to move through
content. This function is similar to scrolling with a mouse.
Chapter 4 Hot Keys and OSD Instructions
Section 1 Hot Keys and LED Light Description
*Notice: If need to adjust “Increase/up” or “Decrease/down” continuously , press
the button and hold. Do not press two buttons at the same time, due it may cause no
response or fault response.
LED Lights Description ：
It shows green light when turn on On-Lap Monitor and shows red light when
stand by.
10
Notice of operation system compliance
On-Lap 1303I supports Windows10/8.1/7 . You can plug & touch on Win-
dows 10/8.1/7 without any driver installation
For Windows 8/8.1 before 2015/10/15, which contains different touch oder,
may not recognize 1303I. Please upgrade your Windows, or email Gechic for
1303I firmware change.
For Linux and Android developer, please active”HID multitouch panels”
while establishing kernel, and the external touch monitor can be supported.
Or email Gechic for Linux driver for setting in Linux/Android system.

Hot Keys Description
Power: Press the Power Button can power on/off the Monitor.
Exit/Auto Adjustment: In the OSD panel, press the Exit Button to exit and
back to the previous page. When there is no OSD menu, press this
Button will activate automatic adjustment function (only pertains to analog
VGA signal)
Menu/Select: Press the Menu Button to launch OSD panel.
Increase Volume/UP: Press this Button to increase the volume of speakers.
If the OSD menu is launched, press this button will move up or move left the
list. Press and hold for automatic continuous increase.
Decrease Volume/Down: Press this Button to decrease the volume of
speakers. If the OSD menu is launched, press this button will move down or
move right the list. Press and hold for automatic continuous decrease.
Section 2 OSD Description
1. Basic Button Operation
Press button to launch the OSD panel. Press or to view the
functions. To adjust a certain function, press to launch it. If the select-
ed function consists of sub-menu, press or again to view the sub-
menu. When the desired function is highlighted, press to launch it.
Press or to change the setting. To exit, press to exit. Repeat the
preceding steps to adjust other setting.
2. Display Settings
As shown in Fig., after Display Settings is launched, can adjust Brightness,
Contrast, and Sharpness.
11

3. Color Setting
As show in Fig., after Color Settings is launched,
can adjust Color Temp and Color Effect to adjust
screen color setting.
Hue setting can make the image color lean to-
ward green or purple
Saturation setting can make saturation more
vivid or more black and white.
At Color Temperature, select “User”, can adjust
RGB color setting, please refer to Fig. Select
“Cool” can increase the blue saturation of the
image. Select “Warm”can increase the red
saturation of the image. At Color Effect, select
“Standard”, “Game”, “Movie”, “Photo” or
“Vivid”
Select “Standard” can adjust the Hue and Satu-
ration of Red/Blue/Green/Cyan/Yellow/Magenta
4. Aspect Ratio
Please refer to Fig. Suggested setting is 16:9.
When HDMI image is 4:3 format, can select 4:3, make image not enlarge to
16:9 and change shape. Using VGA image input
won’t have this function
Notice: When use 4:3 setting, the left and right
sides of On-Lap 1303 will show black frame. Be-
cause its not full screen image display, thus image
location and press signal location will not be the
same, will not be able to press the correct loca-
tion
Overscan: Only when input HDMI Video signal
(ex. 1080P/720P) , can use such function. Use this
function can adjust the image scan area.
5. Manual Image Adjust
Auto Adjust: Only when input VGA signal can use
such function. Will automatically adjust VGA
setting
H.Position: Moves the display area left and right .
V.Position: Moves the display area up and down
Clock: Adjust the pixel clock for user's preference
Phase: Adjust the pixel phase for user's prefer-
ence
12

Section 3 Low Power Protection Warning
If the volume setting is too high, the power requirement may be greater than
the power provided by computer or external 5V DC Charger. At this time, the
Low Power Protection Warning will appear. Please reduce the volume immedi-
ately. Connect the two USB connectors of Micro USB Touch and Power Cable to
the two USB ports on computer. If the vol-
ume is not reduced in time, the Monitor will
decrease the volume and brightness auto-
matically.
Fig.: Low voltage warning shown at upper
right corner on screen.
Chapter 5 Specification
Section 1 Plug and Play
The On-Lap Monitor conforms to VESA DDC standard and supports VESA
DDC2. DDC2B is a bi-directional data channel based on I2C protocol. The host
can request EDID information over the DDC2B channel. The On-Lap Monitor is
able to inform the host system of its identity, and depending on the level of
DDC used, communicate additional information about its display capabilities.
Section 2 Pin Assignment
1. HDMI Connector Pinout
Fig.: HDMI-A Connector
(Connect to HDMI port)
13
6. Audio: Adjust volume or select mute
7. OSD Menu
OSD Timer: Adjust OSD Time
OSD H. POS: Moves OSD left and right
OSD V. POS: Moves OSD up and down
OSD Transparency: Makes OSD transparent
Language: Select OSD language
Reset: Restore to factory setting
8. Input Source: Select VGA signal source, HDMI signal, DisplayPort signal
or Auto Detect
9. Information: Display factory version

2. mini-DisplayPort Connector Pinout
3. VGA Connector Pinout
4. USB Connector Pinout
14
Pin Name Pin Name Pin Name
1 GND 8 GND 15 ML_Lane2(p)
2 Hot Plug Detect 9 ML_Lane1(p) 16 AUX_CH(p)
3 ML_Lane0(p) 10 ML_Lane3(p) 17 ML_Lane2(n)
4 CONFIG1 11 ML_Lane1(n) 18 AUX_CH(n)
5 ML_Lane0(n) 12 ML_Lane3(n) 19 GND
6 CONFIG2 13 GND 20 DP PWR
7 GND 14 GND
Pin ：mini-DisplayPort Connector
(Connect mini-DisplayPort)
Pin No. Name Pin No. Name Pin No. Name
1RED 6RGND 11 NC
2GREEN 7GGND 12 SDA
3BLUE 8BGND 13 HSYNC
4NC 9+5V 14 VSYNC
5GND 10 SGND 15 SCL
Fig.: VGA connector
(connect to PC’s
VGA port)
Pin No. Name
1Vcc (+5V)
2D+
3D-
4Ground Fig .: USB Connector
Pin Name Pin Name
1TMDS Data2+ 11 TMDS Clock Shield
2TMDS Data2 Shield 12 TMDS Clock –
3TMDS Data2 –13 CEC
4TMDS Data1+ 14 Reserved
5TMDS Data1 Shield 15 SCL (I²C Serial Clock for DDC)
6TMDS Data1 –16 SDA (I²C Serial Data Line for DDC)
7TMDS Data0+ 17 DDC/CEC Ground
8TMDS Data0 Shield 18 +5 V Power
9TMDS Data0 –19 Hot Plug Detect
10 TMDS Clock+

Section 3 Specification
15
Model On-Lap1303I On-Lap1303H On-Lap1303A
Panel 13.3" TFT IPS(16:9
Wide) LED Backlight
13.3" TFT IPS(16:9
Wide)LED Backlight
13.3" TFT TN(16:9
Wide)LED Backlight
Resolution/
Color depth
1920x1080/
16.7M colors
1920x1080/
16.7M colors
1366x768/
262K colors
Viewing Angle
(Typical) 178° (H)/178° (V) 178° (H)/178° (V) 45° /20° /45° /45° (Up/Down/Left/Right)
Contrast Ratio
(Typical) 700:1 700:1 500:1
Response Time
(Typical) 14(ms) 14(ms) 8(ms)
Touch
Technology
Projected capacitive
touch screen;
10-point multi-
touch; Input by
fingers。
Support Win-
dows10/8.1,Win7
No touch screen
Screen coating Touch screen hard-
ness≧7H No touch screen
Resolution
Specification
1920*1080(60Hz/50Hz),1600*900(60Hz),1440*900
(60Hz),1366*768(60Hz),
1280*1024(60Hz),1280*960(60Hz),1280*800
(60Hz/50Hz),1280*768(60Hz/50Hz),
1280*720(60Hz/50Hz),1024*768(60Hz),
HDMI Video
Display
Capabilities
1080P(60Hz/50Hz);1080i(30Hz/25Hz);
720P(60Hz/50Hz); (HDCP Compliant)
Speakers 2x 1.0W(Max.) (Rated Impedance 4 Ω at 2KHz)
Rating Voltage/
Current 5V 2A 5V 2A 5V 1.4A
Dimension
(Typical)
348mm*225mm*10.
8mm(Monitor)
354mm*231mm*19.
5mm(Cover)
348mm*225mm*10.
5mm(Monitor)
354mm*231mm*19.
5mm(Cover)
348mm*225mm*10.5
mm(Monitor)
354mm*231mm*19.5
mm(Cover)
Weight(Typical) 900g (Monitor)
320g(Cover)
599g (Monitor)
320g(Cover)
599g (Monitor)
320g(Cover)
Safety
R53848
RoHS

Section 4 Trouble Shooting
1. Image or Audio output troubles
2. The unavailability of “ Duplicate these displays” or “ Extend these
displays” in Display setting may be limited by the graphics chip of the
laptop or have the graphic chip features limited due to the power saving
mode of the laptop or have the graphic chip driver updated. Please con-
sult your laptop manufacturer or graphic chip manufacturer.
16
Problem Solution
No response when finger
touches on the monitor
1.Check if USB Touch Power Cable plug is con-
nected to computer’s USB port. The USB plug
of USB Touch Power Cable cannot transmit touch
signal. (Refer to Chapter 2> Section 2)
2. Check if the computer installs Window 10 or Win-
dows 7.
While touching On-Lap
1303I, the cursor works on
the main display, not 1303I.
Please set up from ”Tablet PC Setting” (Windows
10/ 7) to calibrate the touch monitor. (Refer to Chap-
ter 3> Section 3)
Touch function malfunc-
tions sometime. Function
recovers after restarting
USB signal transmission might be broken off because
USB port may not provide sufficient power. Please
connect both USB-A plugs into USB ports of laptop/
5V-2A adapter.
No image or OSD displays
“ No Signal” warning
1.Check if Power On/Off Indicator shows green light.
If not, it means no power connection. Please refer
to user manual instruction to connect power.
2.Check if VGA/HDMI Video Cable is connected
between On-Lap’s connector port and comput-
er’s connector port.
3.Check if Micro HDMI Video Cable connector is
accidently connected to the VGA port/ DisplayPort
port on On-Lap.
4.Please adjust “Brightness” and “Contrast” in
OSD setting.
Image flicks or blinks and
recover later
Please avoid pulling video cable. Please connect both
Y-type USB-A plugs into USB ports to make sure the
power supply is sufficient.
Image disappears ,too big,
too small, or can’t be
aligned center.
The problem normally happens via VGA input. Please
adjust phase, clock, V.Position, H..Position by OSD
setting.
Monitor has image but no
sound
1.Press “Up”button to increase audio level.
2.Use of VGA input will not have audio signal.
3.Check Sound Setting of the computer. Choose
output to HDMI device.
4.1303 only supports audio out by phone jack. The
phone jack doesn’t support audio in function.

第一章 内容物の解説
その１．モニタ本体と付属品
1. 各部の説明
図：On-Lap 1303 部位説明
図：On-Lap 1303H/J &1303A 入力ポート接続説明
図:On-Lap 1303 ボタンと LED ランプ説明
17
