ON Semiconductor AP0100CSSL00SPGAH-GEVB User manual

©Semiconductor Components Industries, LLC, 2015
September, 2015 − Rev. 0 1Publication Order Number:
EVBUM2316/D
AP0100CSSL00SPGAH-GEVB
AP0100CS Evaluation Board
User's Manual
Evaluation Board Overview
The evaluation boards are designed to demonstrate the features of
ON Semiconductor’s image sensors products. This headboard is
intended to plug directly into the Demo 2X system. Test points and
jumpers on the board provide access to the clock, I/Os, and other
miscellaneous signals.
Features
•Clock Input
♦Default – 27 MHz Crystal Oscillator
♦Optional Demo 2X Controlled MClk
•Two Wire Serial Interface
•Parallel Interface
•HiSPi (High Speed Serial Pixel) Interface
•ROHS Compliant
Block Diagram
Figure 2. Block Diagram of AP0100CSSL00SPGAH−GEVB
www.onsemi.com
EVAL BOARD USER’S MANUAL
Figure 1. AP0100CS Evaluation Board

AP0100CSSL00SPGAH−GEVB
www.onsemi.com
2
Top View
Figure 3. Top View of the Board with Default Jumpers
Headboard Connector J8
Headboard Connector J7
GPIO_DATA16 P37, P40, P41, P42
STANDBY P6
VDD P26
RESET Switch SW7
GPIO1_LED P17
Video Filter Sel P56, P57, P58
OSC/XTAL Sel P22, P23
MCLK_IN P16
SEN_RST_OUT P51
1OE/2OE P54
ON_LED P11
TRST_BAR P3
SPI Mem. Sel P7
SPI_SDI_BAR P5
SPI_SCLK/CS_N P44
SEN_DATA P31
SEN_CLK P30
EEPROM Sel P47, P48, P59
Bottom View
Figure 4. Bottom View of the Board
Baseboard Connector J5
Baseboard Connector J6
+VCC P14
+SVDDIO P10
+2V8_VDDPHY P20
+HVDDIO P12 +AVDD P9
+3V3_VDDADAC P21
HiSPi Connector J2HiSPi Connector J1

AP0100CSSL00SPGAH−GEVB
www.onsemi.com
3
Jumper Pin Locations
The jumpers on headboards start with Pin 1 on the
leftmost side of the pin. Grouped jumpers increase in pin
size with each jumper added.
Figure 5. Pin Locations for a Single Jumper. Pin 1 is Located at the Leftmost Side
and Increases as it Moves to the Right
Pins 1−4Pin 1
Figure 6. Pin Locations and Assignments of Grouped Jumpers.
Pin 1 is Located at the Top-Left Corner and Increases in a Zigzag Fashion Shown in the Picture
Pins 1 and 2Pin 1
Pins 3 and 4
Pins 5 and 6
Pins 7 and 8
Pins 9 and 10
Jumper/Header Functions & Default Positions
Table 1. JUMPERS AND HEADERS
Jumper/Header No. Jumper/Header Name Pins Description
P3 TRST_BAR Open OTPM Programming Voltage Not Supplied
2−3 (Default) Set to Normal Mode
P4 SADDR Open Set to Test Mode
Open Analog Test 1 Header
P5 SPI_SDI_BAR 1−2 (Default) GND; AP0100 in Host Mode
Open SPI_SDI_SEL; AP0100 in Flash Mode
P6 STANDBY 2−3 (Default) Active Mode
1−2 Standby Mode
Open I2C IO Expander Control
P7 SPI Memory Selection 2−3 (Default) EEPROM Disable/Flash Enable
1−2 Flash Disable/EEPROM Enable
P8 GPIO_5 Open (Default) Serial IO expander Control
1−2 Set to Normal
2−3 Set to Vertical Flip
P9 +AVDD Closed (Default) Connects to On-Board Regulator +1V8, Internal
Regulator Use
Open Disconnects from On-Board Regulator +1V8, External
Regulator Use
P10 +SVDDIO 3−5 Select Demo 3 Baseboard Clock
2−4 Select Slave Clock (for Slave Sensor in Multi-Camera
Mode)

AP0100CSSL00SPGAH−GEVB
www.onsemi.com
4
Table 1. JUMPERS AND HEADERS (continued)
Jumper/Header No. DescriptionPinsJumper/Header Name
P11 ON_LED 1−2 (Default) Connects to On-Board to Indicate Power On
P12 +HVDDIO 1−2 (Default) Connects to On-Board +HVDDIO Power Supply
2−3 External Power Supply Connection
P14 +VCC 1−2 (Default) Connects to On-Board +VCC Power Supply
2−3 External Power Supply Connection
P15 +5V0 1−2 (Default) USB +5V0_BUS Power Supply Connection
2−3 Connects to On-Board +5V0_EXT Power Supply
P16 MCLK_IN 1−2 (Default) Connects to On-Board Oscillator
2−3 Connects to XMCLK (i.e. Clock Signal from Demo 2
Baseboard)
P17 GPIO1_LED Open (Default) Off Frame LED
Closed On Frame LED
P19 +AVDD Closed (Default) Connects to On-Board Regulator +1V8, Internal
Regulator Use
Open Disconnects from On-Board Regulator +1V8, External
Regulator Use
P20 +2V8_VDDPHY 1−2 (Default) Connects to On-Board +2V8_VDDPHY Power Supply
2−3 External Power Supply Connection
P21 +3V3_VDDADAC 1−2 (Default) Connects to On-Board +3V3_VDDADAC Power Supply
2−3 External Power Supply Connection
P22, P23 Oscillator/Xtal
Selection P22 1−2,
P23 Open (Default) Selects Oscillator as AP0100 Input Clock
P22 2−3,
P23 Closed Selects Crystal as AP0100 Input Clock
P24 EXT_REG 1−2 (Default) Internal Regulator
2−3 External Regulator
P26 VDD 1−2 (Default) Internal Regulator +1V2_VDD
2−3 External On-Board Regulator U2 Set +1V2
P28 UART Transceiver Open (Default) Turn off UART Transceiver
Closed Turn on UART Transceiver
P30 SEN_CLK Open (Default) Beagle Serial No Access to Demo 2X & Sensor
1−2 Beagle Serial Access to Demo 2X & Sensor
P31 SEN_DATA Open (Default) Beagle Serial No Access to Demo 2X & Sensor
1−2 Beagle Serial Access to Demo 2X & Sensor
P32 ENLDO 1−2 (Default) Enable Internal Regulator
2−3 Disable Internal Regulator
P33 GPIO1_LED 1−2 Set to GPI
2−3 Set to GPO
P34 GPIO_4 Open (Default) Serial IO Expander Control
1−2 Set to Normal
2−3 Set to Horizontal Mirror
P35 GPIO_3 Open (Default) Serial IO Expander Control
1−2 Set to NTSC
2−3 Set to PAL
P36 GPIO_2 Open (Default) Serial IO Expander Control
1−2 Set to No Pedestal
2−3 Set to Pedestal
P37 GPIO_DATA16 1−2 (Default) Auto-Configuration Access
Open JTAG/UART Access

AP0100CSSL00SPGAH−GEVB
www.onsemi.com
5
Table 1. JUMPERS AND HEADERS (continued)
Jumper/Header No. DescriptionPinsJumper/Header Name
P38, P39 IO Expander U38
Setting P39 Open,
P38 Closed (Default) EEPROM Address Set to 0x48
P39 Open,
P38 Open EEPROM Address Set to 0x4C
P39 Closed,
P38 Open EEPROM Address Set to 0x44
P39 Closed,
P38 Closed EEPROM Address Set to 0x40
P40 GPIO_DATA17 1−2 (Default) Auto-Configuration Access
Open JTAG/UART Access
P41 GPIO_DATA18 1−2 (Default) Auto-Configuration Access
Open JTAG/UART Access
P42 GPIO_DATA19 1−2 (Default) Auto-Configuration Access
Open JTAG/UART Access
P43 SP1_SDO/SDI 1−2 (Default) Beagle SPI No Access to Sensor SPI
Open Beagle SPI Access to Sensor SPI
P44
P44 SP1_SCLK/CS_N 1−2 (Default) Beagle SPI No Access to Sensor SPI
Open Beagle SPI Access to Sensor SPI
P45 SPI_SDI Open (Default) Data or GND; AP0100 in Flash/Host Mode
1−2 High Z; AP0100 in Auto-Config Mode
P47, P48, P59 Serial I2C EEPROM
Address P47 Closed,
P48 Open,
P59 Open
EEPROM Address Set to 0xAA (Default)
P47 Closed,
P48 Open,
P59 Open
EEPROM Address Set to 0xA2
P47 Open,
P48 Closed,
P59 Open
EEPROM Address Set to 0xA6
P47 Open,
P48 Open,
P59 Open
EEPROM Address Set to 0xAE
P49 SEN_SCLK 2−3 (Default) AP0100 Serial Control
1−2 Demo 2X Serial Control
P50 SEN_SDATA 2−3 (Default) AP0100 Serial Control
1−2 Demo 2X Serial Control
P51 SEN_RST_OUT 2−3 (Default) AP0100 Reset
1−2 Demo 2X Reset
P52 BEAGLE_SCL 1−2 (Default) Demo 2X Accessed
2−3 Sensor Accessed
P53 BEAGLE_SDA 1−2 (Default) Demo 2X Accessed
2−3 Sensor Accessed
P54 1OE/2OE 1−2 (Default) Enable Level Transistor U9
2−3 Disable Level Transistor U9
P56, P57, P58 Video Filter Selection 1−2 (Default) Active Low Pass Filter
2−3 Discrete Low Pass Filter
SW7 RESET N/A When Pushed, 240 ms Reset Signal will be Sent to
AP0100 Chip

AP0100CSSL00SPGAH−GEVB
www.onsemi.com
6
Interfacing to ON Semiconductor Demo 2X Baseboard
The ON Semiconductor 2X baseboard has a similar
26-pin connector and 13-pin connector which mate with J5 and J6 of the headboard. The four mounting holes secure the baseboard and the headboard with spacers and screws.
