One Control TriLoop User manual

TriLoopUsersManual'

1
2
3
456789
10
11
12 13
1.FootswitchR
2.INPUTjack
3.DCjack (negativecenterDC 9V)
4.BJFbufferon/offindicator
5.SENDjackofLoop1
6.RETURNjack of Loop1
7.MODEindicator
8.SENDjackofLoop2
9.RETURNjack of Loop2
10.OUTPUTjack
11.FootswitchL
12.Loop2indicator
13.Loop1indicator
PREVIEW

MODEInitialization
Power off
Triloopcanbeinitializedasdifferentpurposelooper/switcher/footswitch
mode: BlackLoop(Cascadetwoloops/Footswitch)
mode: WhiteLoop (flashloop / ABbox/Splitter/Selector)
mode: Momentaryfootswitch(N.CorN.O)
mode: SpecialMomentaryfootswitch
Power off
Hold L”Hold L”
Poweron
Press R”
Release L”
Press R”
Press R”
Press R”
Hold R”for2s
Initializationcomplete

MODE ACTION L(press) R(press)
Engage/bypassloop2
Toggleloop1/loop2
MomentaryswitchviaSEND2
Favorite LatchviaOUTjack
Engage/bypassloop1
Masterbypass
MomentaryswitchviaSEND1
TaptempoviaSEND1 (TRScable)
RED
BLUE
GREEN
MODE ACTION L(Holdfor4s) R(Holdfor 4s)
NIL
turnon/offBJFbuffer for loop2
SEND2setstobeN.OorN.C
NIL
Turnon/offBJF buffer
Turnon/offBJF bufferforloop1
SEND1setstobeN.OorN.C
NIL
RED
BLUE
GREEN
PRESSBehaviorTable
HOLDBehavior Table
Dimensions................................................................118(L)x64(W)X50(H)mm
Weight........................................................................250g
Power Supply.............................................................DC9V(NegativeCenter)
CurrentDrain..............................................................max. 100mA
Max.Input Vp-p......................................................... 3V
Parameters

FX1
FX1
FX2
INPUT
RETURN
AMP
SEND FS
Cascadetwoloops
SignalPath:Guitar->BJFBuffer(if on)->loop1->loop2->AMP
A
A/A+B
B
SignalPath: A(loop2off)
A+B(loop2on)
Donot connect cablehere
Guitar->BJFBuffer(ifon)->FX1(if on)->
Tutorials

INPUT
footswitch2
AMP
footswitch1
monocable
monocable
INPUT
AMP
footswitch (TIP/RING/SLEEVE)
Stereocable
Donot connect cablehere
Ampswitching(twomonofootswitchjacks)
Ampswitching(1stereofootswitchjack)
TIPRINGSLEEVE
TIP RING SLEEVE
Stereocable
Tutorials

FX1
FX2
INPUT
RETURN
AMP
SEND FS
loop1/loop2toggle
Eachloopcouldturnon/offBJFbufferseparately
if masterbypassed
OUT2
Splitter(Loop2on)
OUT1
SignalPath:Guitar->BJFBuffer(if on)-> OUT1
OUT2
Donot connect cablehere
SignalPath: Guitar->
BJFbuffer(ifloop1bufferon)-> FX 1(ifmasterbypassoff)->AMP
FX 2(ifmasterbypassoff)->AMP
loop1on
loop2on
BJFbuffer(ifloop2bufferon)->
if masterbypassed
Tutorials

B2
ABBox
B1
SignalPath:
Donot connect cablehere A
Guitar-> BJF buffer(if loop1bufferon)-> A
B1+B2
loop1on
loop2on
BJF buffer(if loop2bufferon)->
Selector
SignalPath:
Guitar1 masterbypass
INPUT
RETURN
AMP
SEND FS
GUITAR1
GUITAR2
GUITAR3
Guitar2
Guitar3
loop1on
loop2on
AMP
Tutorials

DigitalMulti-effectprocessor
Amplifierwithdigitalmodules
INPUT
AMP
Tutorials

Tutorials GREEN
TRS
TAPTEMPO
Favorite
Mono
