Onix OC83s User manual

OC83s
OWNER MANUAL'S
CD PLAYER
CD P LAYER O C83 s
ON / STA NDBY

1
Notices for Use
CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN.
We thank you for purchasing this ONIX CD Player. Please read all the safety and operating instructions before using the
product. Retain the manual for future reference and adhere to all warnings in the manual or on the CD Player.
The lightning flash with an arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of un-insulated dangerous voltage within the product s
enclosure which may be of sufficient magnitude to constitute a risk of electric shock.
'
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Fig.1 Fig.2
1. Do not open this device yourself to repair or modify it.
Opening this device or
attempting to carry out any modification without approval may affect the performance or quality of this device.
2. For good ventilation, a minimum of 10cm clearance shall be maintained at the back and two sides and 20cm at the top of
the unit.
Allow no water dripping or splashing into the unit. Place no object containing liquid on the unit, e.g. Vase.
4. Do not cover any ventilation hole with newspaper, cloth, curtain, etc. in case of ventilation blocking.
5. Allow no exposed flame source on the unit, e.g. burning candle.
The unit shall be connected to AC power output socket with grounding protection.
If power plug and appliance coupler are used as disconnecting device, the disconnecting device shall be easily operable.
8. Any batteries requiring disposal must be handled in accordance with local regulations.
9. This device is intended for safe use in an area with elevation under 2000m. (Fig.1)
10. This device is intended for safe use under non-tropical climate conditions. (Fig.2)
You should never attempt to service the product beyond that
described in this manual. All other servicing should be referred to qualified service personnel.
3.
6.
7.

USE ON LY WITH A 250V FU SE
~2 2 0 V /5 0 H z
IR I N
IR O UT
CLASS 1 LA SER PRODUC T
APPAR EIL LASER DE CL ASSE 1
PRODU CTO LASER CL ASE 1
MO DEL : OC8 3s
PO WER C ONS UMP TIO N: 15 W
CD P LAYER
SE RIA L N O.:
UP GRA DE
PO RT
ON IX EN GL AND E LE CTRONIC S LTD
DI GITA L INPUT DI GITA L OUTPUT
AN ALO G OUTPU T
FUS E 100V - 12 0V: T2AL
220 V - 240V: T1 AL
AC I N
PO WER
ON
OF F
XL R RC A RC A XL R
US B OPT ICA L CO AXI AL CO AXI AL AE S / EBU AE S / EBU
LR
iP od
CD P LAYE R OC83s
ON / S TANDBY
2
Names of Parts
1 2 34567
8910 11 12 13 14 15 16
2
13 4
1. Display window
2. Standby contact switch (the whole metal bar)
3. Standby indicator light
4. Remote control receiving window
1. iPod Digital signal input interface
2. USB Digital signal input interface
3. Optical fiber digital signal input interface
4. Balancing digital signal input interface
5. Coaxial digital signal input interface
6. Coaxial digital signal output interface
7. Balancing digital signal output interface
8. XLR right sound channel audio output interface
9. RCA right sound channel audio output interface
10. RCA left sound channel audio output interface
11. XLR left sound channel audio output interface
12. Software upgrade interface
13. Remote control signal input interface
14. Remote control signal output interface
15. AC input socket (fuse attached)
16. Power switch button

3
Install Battery
1. Open the battery cover.
3. Close the battery cover.
2. Insert 2 AAA batteries and check the positive and negative polarity of the
batteries is correct.
XRC 3B
MUTE DIMMER
TUNING MEM
PRESET FREQ
BAND ENTER
MENU
OK
FAVORITE RETURN
INPUT VOLUME
PROG
CD/AMP NWP AUX
A-BCD INPUT
Remote Control Diagram
Notes on playing the disc:
After placing the disc into the disc area, you should press it into the disc positioner, and close the disc door, and press the
PLAY button. Then the disc will start to play.
Area for disc
Previous song button
Input selection button
Next song button
Play/pause button
Stop button
Disc
Disc positioner
Fast forward/backward selection button
Previous song/next song selection button
Numbers selection button
Input selection button
Brightness adjusting button
Random play button
Replay button
Play/pause button
Stop button
A-B clip replay button
Programming play button
Notes:
The unmarked button are not functional buttons
of the device, therefore pressing those button is
invalid operation.
Standby switch button
(press and hold)
Device mode shift button
(placing at CD/AMP position)

4
Operation Instructions
Preparations
Selection of the sound source
1. Make sure the power line and the signal line of the device are connected properly. Move the power switch on the back-
panel to“ON”position. The indication light of the“ON/STANDBY”on the panel will turn red. At this time, touch the
metal bar (more than 1 second) or press and hold the〈CD/AMP〉button on the remote control, the indication light will
turn to green, and the device will start to work.
2. When the device needs to be powered off, touch the metal bar on the panel (more than 1 second) or press and hold on the
〈CD/AMP〉button, the indication light will turn red. At this time, the device is in a standby mode. Move the power
switch on the back panel to“off”position and the device is powered off.
3. If the device will not be used for a long time, please unplug the AC power line connected to the device.
Press the INPUT button on the device or the CD INPUT button on the remote control, the display screen will show
the following selection items on a loop.
〈 〉 〈 〉
Read IPOD USB OPTI AES COAX
Disc play/Pause
1. Move the disc cover backward and open it, put the disc onto the disc area and press it into the disc positioner, and draw the
disc cover forward and close it.
2. When the device starts to work, the total number of songs and playing time will be displayed on the display screen.
3. Press the button of the device or on the remote control, the disc will start to play.〈 〉
4. When the disc is playing, press the button of the device or on the remote control, the disc will stop to play, and
“Pause”will be displayed on the screen. Press the button once again, the device will restart to play.
〈 〉
Stop
1. When the disc is playing, press the〈 〉button, the disc will stop playing.
2. When the disc is playing, if you want to change a disc, please press the〈 〉button and stop the playing, and open the
disc cover.
Previous song/Next song
1. When the disc is playing, press the〈 〉of the device or on the remote control, the disc will stop and start to play the
previous song.
2. When the disc is playing, press the〈 〉of the device or on the remote control, the disc will stop and start to play the
next song.
Replay
1. If you want to replay the content on the disc, press the button on the remote control once, then there will be a T
before the play time, and it will be displayed with the current playing song alternately. If you want to replay all the content
on the disc, press the〈 〉button on the remote control, then there will be an“A”before the play time, and it will be
displayed with the current playing song alternately. If you want to cancel the replay function, press the〈 〉button once
again, the display area will go back to the normal display.
〈 〉“ ”
2. When the device is stopped, operation of the button is invalid.

5
A-B clip replay
1. If you want to replay some content on the disc, press the A-B button on the remote control at the beginning of the
content, then there will be an“A-”before the play time, and it will be displayed with the current playing song
alternately. When it plays to the ending of the content you like, press the〈A-B〉button on the remote control, then there
will be an“AB”before the play time, and it will be displayed with the current playing song alternately. After the
operation, the disc will replay the content from“A”to“B”. If you want to cancel the replay function, press the〈A-
B〉button once again.
〈 〉
2. When the device is stopped, operation of the button is invalid.
Fast forward/backward
1. When it is playing normally, press and hold the button on the remote control, it is fast backward search. When no
button is pressed or held, it is normal playing condition.
〈 〉
2. When it is playing normally, press and hold the button on the remote control, it is fast forward search. When no
button is pressed or held, it is normal playing condition.
〈 〉
Selection of the songs
1. If you want to select songs from number 1 to 9, just press the buttons on the remote control. If you want to select a song
numbered 10 or more, you should press the number from the left to right. For example, if you want to select a song
numbered 12, you should press 1, then press 2.
2. If you press the button on the device or the remote control, you can select the previous one of the current song; and
if you press the〈 〉button on the device or the remote control, you can select the next one of the current song.
〈 〉
Random play
1. When the disc stops playing or is playing, press the button, then there will be a R before the play time, and it
will be displayed with the current playing song alternately, which means the random play function is started. The random
playing function is randomly playing the content of the disc until all the content is played.
〈 〉“ ”
2. If you want to cancel the function when the random playing function is effective, pressing the button or
button will be OK.
〈 〉 〈 〉
Programming play
1. When the disc in a stop condition, press the PROG button on the remote control, P00-00 will be displayed on the
display screen.
〈 〉 “ ”
2. Press the numbers of the songs you want to program separately. If you press the wrong number, just press the PROG
button again to cancel it, then you can program the songs you love.
〈 〉
3. When the programming is finished, press the of the device or on the remote control, the disc will play according
to the programming, and there will be an“M”before the playing time. It will be displayed with the currently playing
song title alternately.
〈 〉
4. If you want to cancel the playing function, press twice the button.〈 〉
Display brightness adjusting
1. Combining the brightness of play environment, press the DIMMER button on the remote control to adjust the
brightness of the displayed words.
〈 〉
2. Press DIMMER button on the remote control, the display brightness intensity circulate among bright, dim, off ,
and each time the users press, the brightness will be changed to the next mode.
〈 〉 “ ”
3. When the device is started, the display screen is automatically put into a bright status.“ ”

6
iPod input
iPod input function has a corresponding iPod interface on the back-panel of the device, which is a USB type interface.
You can use the dedicated data line of the iPod. The interface can provide 5V/1.5A power supply.
“ ”
1. Connect the iPod/iPhone/iPad to the iPod interface on the back-panel of the device.“ ”
2. Turn on the power supply, and press the INPUT button of the device or the CD INPUT button on the remote
control, and select the corresponding iPod input signal.
〈 〉 〈 〉
USB setting
1. Connect the USB cable line between the computer and the back-panel of the device.
2. Turn on the power supply of the device, and press the INPUT button of the device or the CD INPUT button on the
remote control, and select the corresponding USB input signal.
〈 〉 〈 〉
3. Install the attached USB drive optical disc to the computer.“ ”
4. Set the Sound item of the computer, and tick the speaker 2-XMOS USB Audio as the default equipment.“ ” “ ”
Troubleshooting
Fault Possible causes Treatment
No power Poor connection in socket or no utility. Check power source and connect socket tightly.
Unable to play Disc seriously cut or dirty.
Disc upside down.
Clean the disc or replace with good disc.
Insert the disc with the labeled or printed side on top.
No sound Audio cable not connected. Connect audio cable properly.
No remote control Remote battery misplaced or depleted. Reinstall battery or replace with new battery.
Note: If the machine still does not work after above listed procedures, please contact local distributor or service center.
Return the machine to service center if necessary.

7
Technical Specification
Balanced analog output level 4.8V
Unbalanced analog output level 2.4V
Frequency response 6Hz-20KHz (-0.5dB)
THD <0.0013%
SNR >113dB
Dynamic range >110dB
USB receiver specification USB2.0, 32bit/384KHz
DSD signal specification DSD 1bit/ 2.8MHz, DSD 1bit/5.6MHz
Power consumption 15W
Standby power consumption <1W
Dimension (W×D×H) 480×393×159mm
Net weight About 18.5kg
Accessories
User manual
Power source line
USB line
Remote control
Disc positioner
USB drive disc

8
1. 不可自行开启本机进行维修或改造！本产品不设有用户自行检修的零件，本机的维修须请具备专业资
格的人员进行。开启机器及随意改造内部电路会令检修人员难以维修本机，而且会对机器造成性能或
质量的影响。
3. 设备不应遭受水滴或水溅，机器上不应放置诸如花瓶一类的装满液体的物品。
7. 用电源插头和器具耦合器作为断开装置，断开装置应当保持能方便地操作。
6. 设备应当连接到带保护接地连接的电网电源输出插座上。
5. 设备上不要放置裸露的火焰源，如点燃的蜡烛。
4. 通风孔不要覆盖诸如报纸、桌布和窗帘等物品而防碍通风。
8. 必须遵照电池废弃的相关地方条例来废弃旧电池。
2. 为了充分通风，设备背面和两侧应最少保留10cm，顶部应最少保留20cm的空间。
敬爱的用户：
欢迎购买 CD系列唱盘，让我们借此机会向您表示诚挚的谢意。我们向您建议：在动手操作之前，
请仔细阅读此使用说明书，并注意存放好以备随时参考。
使用注意事项
注意：为防电击，请勿打开机盖。
等边三角形中有箭头闪电符号的图形表示警告使用者在产品内有高
压电，会导致人为的触电。
等边三角形中有叹号的图形表示警告使用者该设备有重要的操作和
维护指示。
9. 仅适用于海拔2000m以下地区安全使用，标志见图1。
10. 仅适用于非热带气候条件下安全使用，标志见图2。 图1 图2

USE ON LY WITH A 250V FU SE
~2 2 0 V /5 0 H z
IR I N
IR O UT
CLASS 1 LA SER PRODUC T
APPAR EIL LASER DE CL ASSE 1
PRODU CTO LASER CL ASE 1
MO DEL : OC8 3s
PO WER C ONS UMP TIO N: 15 W
CD P LAYER
SE RIA L N O.:
UP GRA DE
PO RT
ON IX EN GL AND E LE CTRONIC S LTD
DI GITA L INPUT DI GITA L OUTPUT
AN ALO G OUTPU T
FUS E 100V - 12 0V: T2AL
220 V - 240V: T1 AL
AC I N
PO WER
ON
OF F
XL R RC A RC A XL R
US B OPT ICA L CO AXI AL CO AXI AL AE S / EBU AE S / EBU
LR
iP od
CD P LAYE R OC83s
ON / S TANDBY
1 2 34567
8910 11 12 13 14 15 16
1. iPod数字信号输入接口
2. USB数字信号输入接口
3. 光纤数字信号输入接口
4. 平衡数字信号输入接口
5. 同轴数字信号输入接口
6. 同轴数字信号输出接口
7. 平衡数字信号输出接口
8. XLR右声道音频输出接口
9. RCA右声道音频输出接口
10. RCA左声道音频输出接口
11. XLR左声道音频输出接口
12. 软件升级接口
13. 遥控信号输入接口
14. 遥控信号输出接口
15. 交流电源输入插座 (带保险管)
16. 电源开关键
9
部件名称
1. 显示窗口
2. 待机触摸开关(整条金属)
2
13 4
3. 遥待机指示灯
4. 遥控接收窗口

数字直选键
快退/快进选择键
上一曲/下一曲选择键
停止键
播放/暂停键
重复播放键
A-B片段重复播放键
随机播放键
显示亮度调节键
注: 遥控器未标示按键非本机功
能，操作无效属正常现象。
编程播放键
输入选择键
1. 打开电池盖。
2. 装入两节七号电池，确认电池正负极安装正确。
3. 盖上电池盖。
电池安装
遥控器示意图
XRC 3B
MUTE DIMMER
TUNING MEM
PRESET FREQ
BAND ENTER
MENU
OK
FAVORITE RETURN
INPUT VOLUME
PROG
CD/AMP NWP AUX
A-BCD INPUT
放碟区
上一曲选择键
输入选择键
下一曲选择键
播放/暂停键
停止键
播放注意：
放入碟片后必须放
上碟压并关上碟盖
后按播放键即可播
放碟片曲目内容。
碟片
碟压
机型切换键
置于CD/AMP状态
待机开关键(长按)
10

碟片播放/暂停
1. 先把碟盖向后推动打开，把碟片放在放碟区上并放上碟压，再将碟盖向前拉动关闭。
2. 碟机启动后显示屏显示碟片的总曲目和总时间。
3. 按下机器或遥控器上的〈 〉键即可播放碟片上的所有内容。
上一曲/下一曲
1. 在正常播放时，按一下机器或遥控器上的〈 〉键即可跳向上一曲进行播放。
2. 在正常播放时，按一下机器或遥控器上的〈 〉键即可跳向下一曲进行播放。
选择音源
按下机器上的〈INPUT〉或遥控器上的〈CD INPUT〉键，显示屏上显示循环如下：
Read IPOD USB OPTI AES COAX
11
操作说明
3. 若长时间不使用本机，请将与机器连接的交流电源线插头拔下。
准备工作
1. 首先连接好机器的电源及信号线，再将后板上的电源开关置于“ON”位置，面板上的“ON/STANDBY”
指示灯点亮为红色，此时可触摸面板上金属条的任何位置(1秒以上)或长按遥控器上的〈CD/AMP〉键，
指示灯变为绿色，机器进入正常工作状态。
2. 要关闭本机电源时，触摸面板上金属条的任何位置(1秒以上)或长按遥控器上的〈CD/AMP〉键，指示
灯变为红色，此时机器处于待机状态，再将后板上的电源开关置于“OFF”位置即可关闭本机电源。
4. 在播放状态下按机器或遥控器上的〈 〉键，可对当前碟片进行暂停播放，显示屏上显示“Pause”
字符，再按一次该键时则恢复正常播放状态。
停止
1. 在播放状态下，按下机器或遥控器上的〈 〉键，可停止当前碟片的播放。
2. 在播放状态下，当想更换碟片时，请先按下机器或遥控器上的〈 〉键，停止当前碟片的播放，再打开
碟盖。
重复播放
1. 若想连续播放当前碟片上的曲目内容，按下遥控器上的〈 〉键一次，显示区在播放时间前显示“ T ”
字符，并与当前播放曲目字符交替显示。若想连续重复播放整张碟片上的曲目内容，则再按一次遥控器
上的〈 〉键，显示区在播放时间前显示“ A ”字符，并与当前播放曲目字符交替显示。若想取消重
复播放功能，则再按一次遥控器上的〈 〉键，显示区恢复正常显示。
2. 在停止状态下操作此键无效。

A-B片段重复播放
2. 在停止状态下操作此键无效。
1. 在你喜欢碟片内容的起点按下遥控器上的〈A-B〉键，显示区在播放时间前显示“ A- ”字符，并与当
前播放曲目字符交替显示。当播放至你喜欢内容的结束点时，再按一次遥控器上的〈A-B〉键，显示区
在播放时间前显示“ AB ”字符，并与当前播放曲目字符交替显示。此时机器将从开始点“ A ”至结束
点“ B ”进行重复播放，直到再次按下遥控器上的〈A-B〉键，片段播放功能才会取消。
12
1. 在停止状态下，按下遥控器上的〈PROG〉键，显示区显示“ P00-00 ”字符。
3. 编程完成后，按下机器或遥控器上的〈 〉键，开始按已编好的曲目进行播放，显示区在播放时间前
显示“ M ”字符和当前播放曲目字符交替显示。
4. 如想取消编程播放功能，按两次〈 〉键即可。
2. 分别按下需编程播放曲目的号码，如果错误按下不需要的号码可再按一次〈PROG〉键取消编程，再按
一次该键重新编入喜欢的曲目。
编程播放
1. 在停止或播放状态下，按下遥控器上的〈 〉键，显示区在播放时间前显示“ R ”字符和当前播放曲
目字符交替显示，表示已在开始执行随机播放功能。随机播放功能是随碟机自动播放碟片曲目内容直至
全部播放完毕。
2. 在执行随机播放过程中如想取消该功能，按一次〈 〉键或〈 〉键即可。
随机播放
快退/快进
1. 在正常播放时，按住遥控器上的〈 〉键即可快速向后搜索，放开该键时恢复正常播放状态。
2. 在正常播放时，按住遥控器上的〈 〉键即可快速向前搜索，放开该键时恢复正常播放状态。
选 曲
1. 选第1至第9首曲目，可以直接按遥控器上的1至9数字键。选10首或以上曲目先按十位数对应的数字键，
再按个位数字对应数字键。如：选12首曲目，先按数字键1，再按数字键2即可。
2. 按下机器或遥控器上的〈 〉键可以选择当前曲目的前一首，按下机器或遥控器上的〈 〉键可以选
择当前曲目的下一首。
1. 结合播放环境的光线强度，可按下遥控器上的〈DIMMER〉键进行显示区显示字符的亮度调节。
2. 每按下一次遥控器上的〈DIMMER〉键，显示区亮度将从“亮”、“暗”、“关”中循环变换。
3. 开机时显示区自动置于“ 亮 ”状态。
显示亮度调节

此功能对应的是机器后板上的“iPod”接口，它是一个USB类型的接口，可以用iPod自带的数据线连接，
此接口提供5V/1.5A的供电能力。
1. 将iPod/iPhone/iPad接入机器后板上的“iPod”接口。
2. 打开机器电源并按下机器上的〈INPUT〉或遥控器上的〈CD INPUT〉键，选择到对应的iPod输入信号。
iPod输入
13
常见故障及排除
USB设置
1. 将USB电缆从电脑连接到机器后板上。
2. 打开机器电源并按下机器上的〈INPUT〉或遥控
器上的〈CD INPUT〉键，选择到对应的USB输
入信号。
3. 将随机附带的“USB驱动光盘”安装到电脑上。
4. 将电脑的“声音”选项进行设置，并把“扬声器
2-XMOS USB Audio”勾选为默认设备，如右图：
电源插座接触不良或无电。
正确连接音频电缆。
检查电源的来路，插紧插座。
可能的原因 处理办法
音频电缆没接好。
清洁碟片或换用良好的碟片。
将碟片有字或图案的一面朝上。
碟片严重划伤或污浊。
碟片放反。
故障现象
电源无法接通
无声音
不能播放
遥控器的电池装反或耗尽。 重新安装电池或更换新电池。
注: 如按以上方法还无法正常工作，请与当地经销商或维修点联络，必要时将机器送维修点检查。
无遥控

随机附件
技术规格
平衡模拟输出电平 4.8V
频率响应 6Hz-20KHz (-0.5dB)
谐波失真 <0.0013%
信噪比 >113dB
动态范围 >110dB
消耗功率 15W
待机功率 <1W
体积（宽×深×高） 480×393×159mm
净 重 约 18.5kg
用户手册
电源线
遥控器
碟 压
USB驱动光盘
USB接收器规格 USB2.0, 32bit/384KHz
DSD信号规格 DSD 1bit/2.8MHz, DSD 1bit/5.6MHz
14
非平衡模拟输出电平 2.4V
USB线

由于产品不断改进，各项规格及设计随时更改，恕不另行通知。
Due to continuous improvement, every specification and design is
subject to change at any time without further notice.
www.onix-audio.co.uk
ONIX ELECTRONICS LTDENGLAND
