Onkyo A-9377 User manual

A-9377

SERVICE MANUAL

RC-748S

INTEGRATED AMPLIFIER

Black and Silver models

MODEL A-9377(B)/(S)

230 AC, 50Hz

B CPP

S CPP

Ref. No. 4140

062009

120/220-240V AC, 50/60Hz

B CWT

S CWT

SAFETY-RELATED COMPONENT

WARNING!!

COMPONENTS IDENTIFIED BY MARK ON THE

SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

REPLACE THESE COMPONENTS WITH ONKYO

PARTS WHOSE PART NUMBERS APPEAR AS SHOWN

IN THIS MANUAL.

MAKE LEAKAGE-CURRENT OR RESISTANCE

MEASUREMENTS TO DETERMINE THAT EXPOSED

PARTS ARE ACCEPTABLY INSULATED FROM THE

SUPPLY CIRCUIT BEFORE RETURNING THE

APPLIANCE TO THE CUSTOMER.

A-9377

EXPLODED VIEW

A-9377

Sxx

x 7 pcs.

A36

x 2 pcs.

A03

x 5 pcs.

Sxx

x 5 pcs.

Sxx

x 2 pcs.

Sxx

x 2 pcs.

Sxx

x 2 pcs.

A29

x 2 pcs.

Sxx

x 4 pcs.

Sxx

x 17 pcs.

Sxx

x 5 pcs.

Sxx

x 2 pcs.

E01

x 2 pcs.

Sxx

x 2 pcs.

A50

x 8 pcs.

Sxx

x 3 pcs.

Q737a

x 4 pcs.

Sxx

x 2 pcs.

Sxx

x 4 pcs.

Sxx

x 4 pcs.

Sxx

x 3 pcs.

A22

x 3 pcs.

E01

x 4 pcs.

A23

x 2 pcs.

A19

x 4 pcs.

Sxx

x 4 pcs.

A21

x 4 pcs.

Sxx

x 4 pcs.

A06

x 3 pcs.

A18

A05

A08

Sxx

A09

A34

A28

A27

P01a

A31

A32

A33

A35

A24

(T201)

F201

F202

A20

A10

A14

U02-4

U02-5

(NSP)

Q740

Q739

BD702

Q737

Q738

U02-3

U02-1

U01-1

U01-2

U02-2

A07

A13

A02

A01

A04

DF-Tape

A39

x 2 pcs.

F203<CWT>

A40

x 2 pcs.

A38

x 6 pcs.

A37

U01-3<CWT>

A41

x 2 pcs.

E02

<CWT>

Sxx

x 2 pcs.<CWT>

DF-Tape

<Note>

Sxx = NSP

For SPEAKERS

and REC SELECTOR

A-9377

BLOCK DIAGRAM

BCDEFGH

A-9377

SCHEMATIC DIAGRAM-1

MAIN

BCDEFGH

0.22/50

A-9377

SCHEMATIC DIAGRAM-2

POWER

BCD

GND

+7.6V(ST/BY)

P/D

ST RLY

A-9377

SCHEMATIC DIAGRAM-3

FRONT

BCDEFGH

0.22/5.5

A-9377

WIRING VIEW

BCDEFGH

CWT Version

A-9377

PACKING PROCEDURE

P04

P05

A-9377

TOP

FRONT

TOP

FRONT

TOP

P05

P02

<R>

P09

P06a-d

P06-d P07

P07

P01

P11

x 2 pcs

P12

P13

<CPP>

P16

<CPP>

P02

<L>

P14

<CPP>

P18

<CWT>

P10

P17

<CPP>

P15

<CWT>

Front side

marking

Right side

marking

Top side

marking

Front side

marking

Left side

marking

Top side

marking

1/4 PAGE

A-9377

EXPLODED VIEWS PARTS LIS

<Notes>

(B) : Black model

(S) : Silver model

<CPP> : European model

<CWT> : Asian model

REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS

EXPLODED Q737 TR 2SA1695-O PW TR TO3P 1 2202513

EXPLODED Q739 TR 2SA1695-O PW TR TO3P 1 2202513

EXPLODED Q738 TR 2SC4468-O PW TR TO3P 1 2202523

EXPLODED Q740 TR 2SC4468-O PW TR TO3P 1 2202523

EXPLODED Q737a ISO SHEET AC238 4 223024

EXPLODED BD702 D,RECTIFIER BRIDGE DIODE BRIDGE KBJ6-J 600V/6A STRAIGHT TYPE 1 K047600600010S

EXPLODED P01a POSISTOR PTC 120MM/2P(SMH250-02) WH1569#24 105'C 1 F320121021240S

EXPLODED A01 KNOB A-9377B (CPP) BLK-00055 AL+ABS A4/VOLUME(KD) 1 5087211998000SZ (B)

EXPLODED A01 KNOB A-9377S (CPP) SIV-00217 AL+ABS A4/VOLUME(KD) 1 5087211998010SZ (S)

EXPLODED A02 KNOB A-9377B (CPP) BLK-00055 AL+ABS A4/INPUT(KD) 1 5087211988000SZ (B)

EXPLODED A02 KNOB A-9377S (CPP) SIV-00217 AL+ABS A4/INPUT(KD) 1 5087211988010SZ (S)

EXPLODED A03 KNOB A-9377B (CPP) BLK-00234 ABS HF380 A4 / SPEAKER 5 5087211971000S (B)

EXPLODED A03 KNOB A-9377S (CPP) SIV-00251 ABS HF380 A4 / SPEAKER 5 5087211971100S (S)

EXPLODED A04 BADGE BADGE 1 28135244 (B)

EXPLODED A04 BADGE --- 1 28135298 (S)

EXPLODED A05 PANEL A-9377B (CPP) BLK-00055 AL-EXT A2 / FRONT 1 3067214458000S (B)

EXPLODED A05 PANEL A-9377S (CPP) SIV-00217 AL-EXT A2 / FRONT 1 3067214458010S (S)

EXPLODED A06 LENS A9377/CPP(ONKYO) ACRYL MILKY A4/SPEAKER 3 3710210833000S

EXPLODED A07 WINDOW A9377/CPP ACRYL SMOKE A4/REMOCON 1 5070212723000S (B)

EXPLODED A07 WINDOW A9377(S)CPP ACRYL MILKY A4/REMOCON 1 5070212723100S (S)

EXPLODED A08 FRAME A-9377B (ALL) BLK-00234 ABS BK A1 / FRONT 1 3217212051000S (B)

2/4 PAGE

EXPLODED A08 FRAME A-9377S (ALL) SIV-00251 ABS HF380 A1/FRONT 1 3217212051100S (S)

EXPLODED A09 BUTTON A-9377B (CPP) ABS UV COATING A4 / POWER 1 5097213841000S (B)

EXPLODED A09 BUTTON A-9377S (CPP) ABS SIV-00251증착+UV COATING/POWER 1 5097213841100S (S)

EXPLODED A10 BRACKET SR7200/U2B(MARANTZ) SECC 1.0t /POWER 1 4010210876000S

EXPLODED A13 LENS A9377/CPP(ONKYO) ACRYL MILKY A4/TONE 1 3710210823000S

EXPLODED A14 LENS A9377/CPP ACRYL MILKY A4/INPUT 1 3710210813000S

EXPLODED A18 CABINET A-9377B (ALL) BLK-00230 SECC t0.8 SPRAY A2/TOP 1 3007211426000S (B)

EXPLODED A18 CABINET A-9377S (ALL) SIV-00259 SECC t0.8 SPRAY A2/TOP 1 3007211426010S (S)

EXPLODED A19 LEG AS 4 27175425

EXPLODED A20 CHASSIS A9377/CPP(ONKYO) SECC 1.2t A1/MAIN 1 3200212866000S NSP

EXPLODED A21 FASTENER () BUTTON SUPPORT DABS-16R 4 4420040243010S

EXPLODED A22 SUPPORTER R871G(DOM) DONG-A DABS-10R(L) 10mm / PCB 3 4070210344000S

EXPLODED A23 CUSHION SX315KUCXCN(PIONEER) EVA BKΦ10XΦ5X8t/TRANS SCREW 2 4050211205000S

EXPLODED A24 POWER TRANS A-9377(CPP)/MAIN 230V/50HZ 96*56 1 8200960560200S <CPP>

EXPLODED A24 POWER TRANS A-9377(CWT)/MAIN 220V-240V/50HZ-60HZ 96*56 1 8200960560210S <CWT>

EXPLODED A27 HEAT SINK A9377/CPP AL 6063 EXT A3/MAIN 1 2120211458000S NSP

EXPLODED A28 BRACKET A9377/CPP SECC t1 A4/HEATSINK 1 4010214096000S

EXPLODED A29 BRACKET AVCS7000S(DENON) SECC 1.0t A4/PCB 2 4010212356000S

EXPLODED A31 CHASSIS A-9377 (CPP) SECC 0.8t Silk 1도A2 / BACK 1 3207212856000S <CPP>

EXPLODED A31 CHASSIS A-9377 (CWT) SECC 0.8t Silk 1도A2 / BACK 1 3207212856100S <CWT>

EXPLODED A32 SOCKET,POWER AC AC INLET VAC18S 1 G430000180010S

EXPLODED A33 TERMINAL S4011062KN 1 3790000090000S

EXPLODED A34 SUPPORTER UPAF07 ABS BK/PCB 1 4070001601010S

EXPLODED A35 CUSHION A9377 CR BK 난연 10t*24*19/PCB 1 4050212595000S

EXPLODED A36 CUSHION A9377 RUBBER 50*20*t2.5 A4/SIDE 2 4050212545000S

3/4 PAGE

EXPLODED A37 COVER A9377(B)(ONKYO) PC 770F BLACK t0.5 A3/SAFETY 1 4310214912100S (B)

EXPLODED A37 COVER A9377(S) PC G42 CLEAR t0.5 A3/SAFETY 1 4310214912000S (S)

EXPLODED A38 COVER AVR1908 SRE2(DENON) 94HB.BLACK POM A4/HOLDER 6 4310213701000S (B)

EXPLODED A38 COVER AVR1909SPE2(DENON) (DENON)SP POM A4/HOLDER 6 4310213701100S (S)

EXPLODED A39 COVER A9377 PC-770F BLACK t0.5 A4/SCREW 2 4310214932000S

EXPLODED A40 FELT A9377 10X30Xt0.25 부직포 A4/SIDE 2 2690210269000S

EXPLODED A41 SPRING VSAS1/JJXCN(PIONEER) SWP PI1.2 내경PI7.7 A4/KNOB 2 3720210276000S

EXPLODED A50 RIVET () SNAP RIVET DASR-355 8 1560040036010S

EXPLODED E01 WIRE TIE BSK-1 6 260208 ALL

EXPLODED E02 WIRE TIE BSK-1 1 260208 <CWT>

EXPLODED (U01) P.C.B TOTAL ASSY A9377/CPP(ONKYO) / MAIN* 1 7025HA0802020 <CPP>

EXPLODED (U01) P.C.B TOTAL ASSY A9377/CWT(ONKYO) / MAIN* 1 7025HA0802010 <CWT>

EXPLODED U01-1 P.C.B SUB ASSY A9377/CPP(ONKYO) / MAIN (1) 7028068111010

EXPLODED U01-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER (1) 7028068112020 <CPP>

EXPLODED U01-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER (1) 7028068112010 <CWT>

EXPLODED U01-3 P.C.B SUB ASSY A9377/CPP(ONKYO) / VOL_SEL (1) 7028068113010 <CWT>

EXPLODED (U02) P.C.B TOTAL ASSY A9377/CPP(ONKYO) / FRONT* 1 7025HA0802021 <CPP>

EXPLODED (U02) P.C.B TOTAL ASSY A9377/CWT(ONKYO) / FRONT* 1 7025HA0802011 <CWT>

EXPLODED U02-1 P.C.B SUB ASSY A9377/CPP(ONKYO) / FRONT (1) 7028068121010

EXPLODED U02-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / REMOTE (1) 7028068122010

EXPLODED U02-3 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER_S/W (1) 7028068123010

EXPLODED U02-4 P.C.B SUB ASSY A9377/CPP(ONKYO) / H_P (1) 7028068124010

EXPLODED U02-5 P.C.B SUB ASSY A9377/CPP(ONKYO) / VOLUME (1) 7028068125010

A-9377

PACKING PROCEDURE PARTS LIS

<Notes>

(B) : Black model

(S) : Silver model

<CPP> : European model

4/4 PAGE

<CWT> : Asian model

REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS

PACKING P01 BOX,GIFT A-9377 (CPP/CWP) DW2(BA FLUTE) 동보선(535*422*239) 1 6007211390000S

PACKING P02 CUSHION,SNOW A9377/CPPEPS 55배A2 1 6230212504000S

PACKING P04 PE,SHEET () 경고28개국어NITRON 750*1460/SET 1 6327040059000S

PACKING P05 TAPE (SEROHAN)NITTO NO.29 1 29110149

PACKING P06a LABEL ONKYO 130x50 SET+BOX / SERIAL 1 NSP (B) <CPP>

PACKING P06b LABEL ONKYO 130x50 SET+BOX / SERIAL 1 NSP (S) <CPP>

PACKING P06c LABEL ONKYO 130x50 SET+BOX / SERIAL 1 NSP (B) <CWT>

PACKING P06b LABEL ONKYO 130x50 SET+BOX / SERIAL 1 NSP (S) <CWT>

PACKING P07 PP TAPE NITTO No.3903(500mmx100m) 1 29110200

PACKING P07 or PP TAPE W50 SBT-70 (1) 29110205

PACKING P09 POLY BAG w250xd350 1 29100250A

PACKING P10 REMO CON RC-748S 1 24140748

PACKING P11 BATTERY R6/AA(UM-3) 2 3010194

PACKING P11 or BATTERY R6/AA(UM-3) (2) 3010054

PACKING P12 INSTRUCTION MANUAL A-9377 (CPP/CWP) ENG ONLY 1 5707000002550S

PACKING P13 INSTRUCTION MANUAL A-9377 (CPP) Fr/Sp/It 1 5707000002600S <CPP>

PACKING P14 INSTRUCTION MANUAL A-9377 (CPP) Ge/Neth/Swe 1 5707000002630S <CPP>

PACKING P15 INSTRUCTION MANUAL A-9377 (CWP) TIWAN ONLY 1 5707000002540S <CWT>

PACKING P16 INST SHEET WEEE 1 29355537A <CPP>

PACKING P17 CORD ASSY 16A/250V M3204/VAC17S H05VV-F2C*1.0MM 1.8M 1 L068250160020S

PACKING P18 CORD ASSY 7A/125V TW15CS2/VAC17S VCTF 2*0.75MM 1.83M 1 L068125070060S <CWT>

1 / 6 ページ

A-9377

EXPLODED VIEWS PARTS LIS

for CWT Version

REF. NO. PART NAME DESCRIPTION Require

Q'ty PART NO. (SN) - 1 PART NO. (SN) - 2 REMARKS

PCB CWT U01 P.C.B TOTAL ASSY A9377/CWT(ONKYO)/MAIN * 1 7025HA0802010

PCB CWT U01-1 P.C.B SUB ASSY A9377/CPP(ONKYO)/MAIN 1 7028068111010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/MAIN-AXIAL 1

PCB CWT * P.C.B A-9377(ONKYO) 330*247 1.6T FR1/MAIN 1

PCB CWT R821 R822 R,CARBON FILM 10-J,1/5W-52RE-AX 2 417341004T

PCB CWT R806 R807 R,CARBON FILM 100-J,1/5W-52RE-AX 2 417341014T

PCB CWT R716 R717 R752 R753 R791 R826

R830 R833 R836 R851 R857 R,CARBON FILM 1K-J,1/5W-52RE-AX 11 417341024T

PCB CWT R743 R744 R901 R,CARBON FILM 10K-J,1/5W-52RE-AX 3 417341034T

PCB CWT R747 R748 R789 R790 R815 R817 R,CARBON FILM 100K-J,1/5W-52RE-AX 6 417341044T

PCB CWT

R718 R719 R720 R721 R722 R723

R724 R725 R726 R727 R728 R729

R730 R731

R,CARBON FILM 1M-J,1/5W-52RE-AX 14 417341054T

PCB CWT R813 R814 R816 R818 R,CARBON FILM 120K-J,1/5W-52RE-AX 4 417341244T

PCB CWT R838 R841 R,CARBON FILM 1.5K-J,1/5W-52RE-AX 2 417341524T

PCB CWT R844 R847 R852 R858 R,CARBON FILM 18K-J,1/5W-52RE-AX 4 417341834T

PCB CWT R893 R894 R898 R899 R,CARBON FILM 22-J,1/5W-52RE-AX 4 417342204T

PCB CWT R701 R702 R709 R710 R805 R,CARBON FILM 2.2K-J,1/5W-52RE-AX 5 417342224T

PCB CWT R776 R777 R885 R887 R900 R,CARBON FILM 22K-J,1/5W-52RE-AX 5 417342234T

PCB CWT R736 R737 R758 R759 R802 R877 R,CARBON FILM 220K-J,1/5W-52RE-AX 6 417342244T

PCB CWT R803 R804 R823 R827 R,CARBON FILM 270-J,1/5W-52RE-AX 4 417342714T

PCB CWT R809 R811 R,CARBON FILM 27K-J,1/5W-52RE-AX 2 417342734T

PCB CWT

R703 R704 R705 R706 R707 R708

R711 R712 R713 R714 R825 R829

R832 R835 R880 R883

R,CARBON FILM 330-J,1/5W-52RE-AX 16 417343314T

PCB CWT R764 R765 R784 R788 R849 R855 R,CARBON FILM 3.3K-J,1/5W-52RE-AX 6 417343324T

PCB CWT R888 R889 R890 R,CARBON FILM 33K-J,1/5W-52RE-AX 3 417343334T

PCB CWT R853 R859 R,CARBON FILM 3.9K-J,1/5W-52RE-AX 2 417343924T

PCB CWT R740 R810 R812 R,CARBON FILM 470-J,1/5W-52RE-AX 3 417344714T

PCB CWT R768 R769 R792 R,CARBON FILM 4.7K-J,1/5W-52RE-AX 3 417344724T

PCB CWT R800 R801 R892 R897 R903 R,CARBON FILM 47K-J,1/5W-52RE-AX 5 417344734T

PCB CWT R741 R742 R,CARBON FILM 470K-J,1/5W-52RE-AX 2 417344744T

PCB CWT R745 R746 R,CARBON FILM 51K-J,1/5W-52RE-AX 2 417345134T

PCB CWT R749 R,CARBON FILM 56-J,1/5W-52RE-AX 1 417345604T

PCB CWT R824 R828 R854 R860 R,CARBON FILM 5.6K-J,1/5W-52RE-AX 4 417345624T

PCB CWT R732 R733 R,CARBON FILM 56K-J,1/5W-52RE-AX 2 417345634T

PCB CWT R884 R886 R,CARBON FILM 6.8K-J,1/5W-52RE-AX 2 417346824T

PCB CWT R861 R862 R864 R865 R,CARBON FILM 68K-J,1/5W-52RE-AX 4 417346834T

PCB CWT R738 R739 R,CARBON FILM 820-J,1/5W-52RE-AX 2 417348214T

PCB CWT R760 R761 R,CARBON FILM 82K-J,1/5W-52RE-AX 2 417348234T

PCB CWT R891 R896 R,METAL FILM 100PPM 8.2-J,1W-52RE-AX 2 C0608R2065520S !

PCB CWT R873 R874 R875 R876 R,FUSIBLE METAL PNFR 0.22-J,1/2W-52RE-AX 4 C101R22064520S !

PCB CWT L801 L802 L803 L804 L805 COIL,LINE FILTER BFS2550A0F1(52MM)5D320255000520S

PCB CWT D711 D712 D,SWITCHING 1SS133T-72-52MM 2 223163T

PCB CWT D707 D708 D709 D710 D,SWITCHING 1N4007 52REEL 1000V 1A 4 K000400700010S

PCB CWT D713 D,ZENER MTZJ5.1B-0.5W/5MA-52MM 1 224470512T

PCB CWT D701 D702 D,ZENER MTZJ7.5B-0.5W/5MA-52MM 2 224470752T

PCB CWT ZD708 D,ZENER MTZJ9.1B-0.5W/5MA-52MM 1 224470912T

NOTE : THE COMPONENTS IDENTIFIED BY THE MARK

!ARE CRITICAL FOR RISK OF FIRE AND

ELECTRIC SHOCK. REPLACE ONLY WITH PART

NUMBER SPECIFIED.

2 / 6 ページ

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/MAIN-MANUAL 1

PCB CWT * HEAT SINK P656(DOM) P656 AL6063 40MM/SUB 1 NSP

PCB CWT * HEAT SINK HEAT SINK REG TR(24X60) 1 NSP

PCB CWT CLAMP405 CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 1 4330000120000S

PCB CWT * SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH 2 B020030081B10S

PCB CWT R878 R879 R881 R882 R,CEMENT MPR RGC5-0.22-J/5W W14*H17 4 C144R22069000S

PCB CWT C809 C,ELECT GE 85C 2200UF-M/16V,12.5*20-BULK UVR1C222MHD (NICHICON) 1 394642227S

PCB CWT C813 C,ELECT GE 85C 2200UF-M/35V,16*25-BULK UVR1V222MHD (NICHICON) 1 394662227S

PCB CWT C814 C,ELECT GE 85C 3300UF-M/35V,16*35.5-BULK UVR1V332MHD (NICHICON) 1 394663327S

PCB CWT C824 C825 C,ELECT GE 85C 8200UF-M/63V,30*50-BULK LLS1J822MESNOC (NICHICON) 2 3504420 !

PCB CWT L702 L703 COIL,FILTER-INDUCTOR 0.5UH-BULK 2 D330R50000000S

PCB CWT JACK717 JACK,D3.5 EARPHONE JACK PJ-308-02 1 G40130802000YS

PCB CWT JACK100 TER,RCA 2PIN RCA-207AE-02 NI(WH,RD) 1 G601207AE020YS

PCB CWT JACK105 JACK106 TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU2G602405B0400YS

PCB CWT JACK104 TER,RCA 6PIN RCA-603B-05(WH,WH,WH,RD,RD,RD)YUQIU 1 G603603B05000S

PCB CWT * TER,BOARD SCREW 8P JB-801A-06(RD,BK,BK,RD-RD,BK,BK,RD) 1 G614801A0600YS

PCB CWT RL702 RL703 RELAY HL3-2A-12S 12V 5A 1회로 2접점 2G680120503020S

PCB CWT RL701 RELAY BC3-12 24V 2A 2회로 2접점(SMALL SIGNAL) 1G680240202030S

PCB CWT IC708 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD 1 222780054JRC

PCB CWT IC712 IC,LINEAR-REGULATOR KIA7812API,20W-TO220IS MOLD 1 222780124JRC

PCB CWT IC707 IC,LINEAR-REGULATOR KIA7815API,20W-TO200IS 1 222780155KEC 222780154JRC

PCB CWT IC706 IC,LINEAR-REGULATOR KIA7915PI,20W-TO220IS MOLD 1 222790155KEC 222790154JRC

PCB CWT Q733 Q735 SEMI,TR/GE PNP 2SA 2SA1930 20W/2-10R1A 2 2203000

PCB CWT Q734 Q736 SEMI,TR/GE NPN 2SC 2SC5171 20W/2-10R1A 2 2203010

PCB CWT BD701 D,RECTIFIER BRIDGE KBPC604 6A 1 K047604000020S !

PCB CWT CP703 CP715 CN.WAFER 2.0MM 20010WS-03A00 DIP3P STRAIGHT 2 L101200100310S

PCB CWT CP705 CN.WAFER 2.0MM 20010WS-05A00 DIP5P STRAIGHT 1 L101200100510S

PCB CWT CP704 CN.WAFER 2.0MM 20010WS-06A00 DIP6P STRAIGHT 1 L101200100610S

PCB CWT CP701 CN.WAFER 2.0MM 20010WS-10A00 DIP10P STRAIGHT 1 L101200101010S

PCB CWT P703 P704 CN.WAFER 2.0MM 53014-0310 3P 2 L101530140310S

PCB CWT CP709 CN.WAFER 2.5MM SMW250-2P/연호, ST 1L102020010020S

PCB CWT CP707 CN.WAFER 2.5MM 5267-05A 5P 1 L102526700500S

CWT CP708 CN.WAFER 7.92MM 35328-0360, 7.92MM HEADER,VER,3CKT 1 L108353280360S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/MAIN-RADIAL 1

PCB CWT R750 R751 R774 R775 R,METAL FILM 100PPM 10-J,1/4W-R.REEL 4 C060010063050S !

PCB CWT R904 R905 R,METAL FILM 100PPM 390-J,1W-R.REEL 2 C060039165050S !

PCB CWT R831 R834 R,METAL FILM 100PPM 56-J,1W-R.REEL 2 C060056065050S !

PCB CWT R837 R840 R,METAL FILM 100PPM 68-J,1W-R.REEL 2 C060068065060S !

PCB CWT R755 R756 R,METAL FILM 100PPM 680-J,1/4W-R.REEL 2 C060068163060S !

PCB CWT R754 R757 R839 R842 R843 R845

R846 R848 R868 R871 R,METAL FILM 100PPM 82-J,1W-R.REEL 10 C060082065050S !

PCB CWT R863 R866 R,METAL FILM 100PPM 2.2-J,1/4W-R.REEL 2 C0602R2063050S !

PCB CWT R895 R902 R,METAL FILM 100PPM 2.2-J,1W-R.REEL 2 C0602R2065050S !

PCB CWT R850 R856 VR,SEMI CARBON MOLD EVN-DJAA03B23/REEL 2 5210390T

PCB CWT C827 C829 C,CERAMIC T.C DISC SL2PF-C/50V-5RE 2 345020201T

PCB CWT

C705 C706 C707 C708 C711 C712

C713 C714 C765 C766 C799 C801

C832 C834

C,CERAMIC HIK DISC SL100PF-J/50V-5RE 14 345021014T

PCB CWT C717 C718 C,CERAMIC HIK DISC SL470PF-J/50V-5RE 2 345024714T

PCB CWT C857 C858 C859 C860 C862 C863 C,FILM POLYESTER ST-0.001UF-J/100V-5RE 6 D02010206C060S

PCB CWT C780 C793 C797 C,FILM POLYESTER MI-0.01UF-J/50V-5RE ECQV1H103JL3 (PANASONIC) 3 374721034T

PCB CWT C842 C843 C848 C849 C,FILM POLYESTER ST-0.1UF-J/100V-5RE 4 D02010406C060S

PCB CWT C723 C725 C731 C732 C,FILM POLYESTER ST-0.0015UF-J/100V-5RE4D02015206C060S

PCB CWT C719 C720 C721 C771 C772 C850 C,FILM POLYESTER MI-0.022UF-J/50V-5RE ECQV1H223JL3 (PANASONIC) 6 374722234T

PCB CWT C821 C823 C830 C831 C836 C846

C847 C,FILM POLYESTER MI-0.047UF-J/50V-5RE ECQV1H473JL3 (PANASONIC) 7 374724734T

PCB CWT C738 C751 C,FILM POLYESTER RED-0.47UF-K/63V-5RE 2 D020474078060S

PCB CWT C728 C730 C,FILM POLYESTER ST-0.0068UF-J/100V-5RE 2 D02068206C060S

PCB CWT C749 C750 C844 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SY (Pb Free) 3 D040010087150S

PCB CWT C733 C734 C783 C784 C788 C789

C804 C826 C828 C840 C841 C,ELECT GE 85C 10UF-M/50V,5*7-5RE SY (Pb Free) 11 D040100087080S

3 / 6 ページ

PCB CWT C845 C,ELECT GE 85C 100UF-M/25V,6.3*11-5RE.SY 1 D040101084060S

PCB CWT C735 C737 C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SY 2 D040220087060S

PCB CWT C727 C729 C,ELECT GE 85C 220UF-M/10V,6.3*11-5RE.SMS-SY (Pb Free) 2 D040221082090S

PCB CWT C747 C748 C763 C764 C817 C818 C,ELECT GE 85C 220UF-M/25V,8*11.5-5RE.SY 6 D040221084060S

PCB CWT C739 C744 C745 C746 C753 C754

C755 C756 C773 C774 C798 C800 C,ELECT GE 85C 47UF-M/25V 5*11-5RE.SY 12 D040470084070S

PCB CWT C724 C726 C794 C795 C,ELECT GE 85C 47UF-M/50V,6.3*11-5RE.SY (Pb Free) 4 D040470087070S

PCB CWT C785 C786 C,ELECT GE 85C 47UF-M/63V,6.3*11-5RE UVR1J470MDD (NICHICON) 2 394674707T

PCB CWT C741 C743 C,ELECT GE 85C 470UF-M/10V,6.3*11-5RE 2 D040471082060S

PCB CWT C782 C,ELECT GE 85C 0.22UF-M/50V,5*11-5RE.SY 1 D040R22087070S

PCB CWT Q745 SEMI,TR/GE PNP 2SA 2SA970-GR,0.3W/TO92-REEL 1 2211395T

PCB CWT Q702 SEMI,TR/GE PNP 2SA 2SA1015-Y 0.4W/TO-92 REEL 1 2211454T

PCB CWT Q721 Q722 Q723 Q724 Q726 Q728 SEMI,TR/GE PNP 2SA 2SA949-Y 0.8W/TO-92M REEL 6 2211354T

PCB CWT Q729 Q730 Q731 Q732 SEMI,TR/GE NPN 2SC 2SC1740SR,0.3W/TO92M-REEL 4 2213284T

PCB CWT Q703 SEMI,TR/GE NPN 2SC 2SC1815-Y 0.4W/TO-92 REEL 1 2211254T

PCB CWT Q725 Q727 Q742 Q743 SEMI,TR/GE NPN 2SC 2SC2229-Y 0.8W/TO-92M REEL 4 2211639T

PCB CWT Q716 Q718 Q719 Q720 Q741 Q744 SEMI,TR/GE NPN 2SC 2SC2240-BL 0.3W/TO-92 REEL 6 2211406T

PCB CWT Q715 Q717 SEMI,TR/GE NPN 2SC 2SC2240-GR,0.3W/TO92-REEL 2 2211405T

PCB CWT Q713 Q714 SEMI,TR/GE NPN 2SC 2SC2458-GR 0.2W/TO-92 REEL 2 2212115T

PCB CWT Q748 SEMI,TR/GE NPN 2SC KTC3198Y,0.6W/TO92-REEL 1 2215984T

PCB CWT R867 R869 R870 R872 R,FIXED,M.O. RSD-R1-1WJ-10 3*9 P=5MM SMALL R.REEL 4 N113135610020S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/MAIN-SMD 1

PCB CWT R808 R819 R820 R908 R,CHIP THICK 10K-J,1/16W-1608REEL 4 C20001036M160S

PCB CWT C853 C854 C,CERAMIC CHIP HIK X7R)0.01UF-K/50V-1608REEL TDK 2 D011103777162S

PCB CWT IC709 IC,ELECT VR R2S15211FP 8CH-VOL WITH 11 INPUT QFP80P 1 22242297R3

PCB CWT IC704 IC,LINEAR OP NJM2068M-SOP8P 1 22240051R2

PCB CWT IC701 IC,LINEAR OP NJM4565MD-SOP8P 1 22241383R2

PCB CWT Q709 SEMI,CHIP TR/PNP 2SA KRA101S R1,R2=4.7K 0.2W/SOT-23 REEL 1 J520010100010S

PCB CWT Q705 Q746 Q747 SEMI,CHIP TR/NPN 2SC KRC105S (NE) 0.2W/SOT-23 REEL 3 2217290R2

PCB CWT Q706 Q707 Q710 Q711 SEMI,CHIP TR/NPN 2SC KTC2875B(MB) 0.15W/LOW-ON-RES SOT23(RTK)-REEL 4 J5222875B0010S

PCB CWT D703 D704 D714 D715 D737 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) 5 223283R2

PCB CWT U01-2 P.C.B SUB ASSY A9377/CPP(ONKYO)/POWER 1 7028068112010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER-AXIAL 1

PCB CWT D201 D202 D203 D204 D,SWITCHING 1N4007 52REEL 1000V 1A 4 K000400700010S

PCB CWT J825 J827 J828 CN,WIRE 1P JUMPER (0.6/52MM) 3 L045084006040S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER-MANUAL 1

PCB CWT BKT1 BRACKET AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 1 4010210196100S

PCB CWT SUB201 POWER TRANS VSX819K-RFLXCN 110-127,220-240V/50-60HZ 28*15/STBY 1 8200280150610S !

PCB CWT RUG1 RING,TER WIRE 60MM/1P 7542-BS(4.2)=B1813TOP-02 BK1007#18 1 8410600010080S

PCB CWT C206 C,CERAMIC AC(SAFETY) SCF2E472M10FF7 0.0047UF 250VAC 7.5MM-REEL 1 D00847208H010S !

PCB CWT C204 C,ELECT GE 85C 2200UF-M/16V,12.5*20-BULK UVR1C222MHD (NICHICON) 1 394642227S

PCB CWT JACK401 SOCKET,POWER RECEPTA A304D0070P 2P(220V) 1 G435304D00700S !

PCB CWT RLY201 RELAY HL3-1A-6SH DC6V 1A 1회로 1접점(POWER) 1G680060102020S !

PCB CWT CN211 CN.WAFER 2.5MM 5267-04A 4P 1 L102526700400S

PCB CWT CP211 CN.WAFER 7.92MM YW396(05AV) 3P ST 1 L108039605010S !

PCB CWT CP206 CN.WAFER 7.92MM YW396(09AV) 5P ST 1 L108039609010S !

PCB CWT CP208 CN.WAFER 7.92MM PLUG JE202B1T2 ST2P 3-B2 1 L108202000220S !

PCB CWT CP207 CN.WAFER 7.92MM 35328-0263, 7.92MM HEADER,VER,2CKT,YEL 1 L108353280290S !

PCB CWT CP1 CN.WAFER 7.92MM 35328-0560, 7.92MM HEADER,VER,5CKT 1 L108353280560S

PCB CWT F201 F202 FUSE GLASS TUBE 20MM T2.5A /250V-SVBRTC(K) 218 2 252075GR !

PCB CWT F203 FUSE GLASS TUBE 20MM T4A /250V-SVBRTC(K) 218 1 252077GR !

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER-RADIAL 1

PCB CWT R206 R,METAL FILM 100PPM 82-J,1W-R.REEL 1 C060082065050S !

PCB CWT C203 C,ELECT GE 85C 1UF-M/50V,5*11-5RE UVR1H010MDD (NICHICON) 1 394680107T

PCB CWT C205 C,ELECT GE 85C 3.3UF-M/50V,5*11-5RE SY 1 D0403R3087050S

PCB CWT F201A2 F201B2 F202A1 F202B1

F203A2 F203B2 HOLDER,FUSE CLIP PI5.2-REEL 6 G645000050010S !

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER-SMD 1

PCB CWT R369 R,CHIP THICK 4.7K-J,1/16W-1608REEL 1 C20004726M160S

PCB CWT R370 R,CHIP THICK 47K-J,1/16W-1608REEL 1 C20004736M160S

PCB CWT Q316 SEMI,CHIP TR/NPN 2SC KTC3875S 0.15W SOT-23 REEL 1 2216175R2

PCB CWT D205 D206 D207 D,SWITCHING CHIP 1N4148W FAST SWITCHING SOD-323 3 K005041480020S

4 / 6 ページ

PCB CWT U01-3 P.C.B SUB ASSY A9377/CPP(ONKYO)/VOL_SEL 1 7028068113010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOL_SEL-AXIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOL_SEL-MANUAL 1

PCB CWT * P.C.B A-9377 97*97 1.6T FR1 ARRY(20)/VOLTAGE SELECTOR 1

PCB CWT S/W202 SW,SLIDE EV-32-91A-4U 10A/250V VOLTAGE SELECTOR SWITCH 1 G060329140000S !

PCB CWT CN222 CN,WIRE 120MM/5P CKM3962-09=CKM99050101-09 WH1617#22 CROSS 1 L000121050110S !

PCB CWT CN203 CN,WIRE 150MM/3P CKM3962-05=CKM99050101-05 WH1617#22 CROSS 1 L000151030180S !

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOL_SEL-RADIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOL_SEL-SMD 1

PCB CWT * P.C.B SUB ASSY A9377/CPP(ONKYO)/CLAMP_A 1

PCB CWT * P.C.B INS ASSY A9377/CPP(ONKYO)/CLAMP_A-MANUAL 1

PCB CWT CLAMP401 CLAMP402 CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 2 NSP

PCB CWT * P.C.B SUB ASSY A9377/CPP(ONKYO)/CLAMP_B 1

PCB CWT * P.C.B INS ASSY A9377/CPP(ONKYO)/CLAMP_B-MANUAL 1

PCB CWT CLAMP403 CLAMP404 CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 2 NSP

PCB CWT U02 P.C.B TOTAL ASSY A9377/CWT(ONKYO)/FRONT * 1 7025HA0802011

PCB CWT U02-1 P.C.B SUB ASSY A9377/CPP(ONKYO)/FRONT 1 7028068121010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/FRONT-AXIAL 1

PCB CWT * P.C.B A-9377(ONKYO) 330*247 1.6T FR1 ARRY(2)/FRONT 1

PCB CWT L301 COIL,FILTER-INDUCTOR 47UH-Q45/20M-R4.0-52RE LAL04TB 1 D330470104010S

PCB CWT D313 D,ZENER MTZJ5.1B-0.5W/5MA-52MM 1 224470512T

PCB CWT D308 D,ZENER MTZJ5.6B-0.5W/5MA-52MM 1 224470562T

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/FRONT-MANUAL 1

PCB CWT BASS VR,ROTARY 14MM RK14K124007A-100KC*2 CURVE 1 C454121400100S

PCB CWT BALANCE VR,ROTARY 14MM RK14K1240-250KMN CURVE 1 C454122300100S

PCB CWT TREBLE VR,ROTARY 14MM RK14K124004Z-50KC*2 CURVE 1 C454125300100S

PCB CWT SPK_SEL SW,ROTARY SRBV141201 POSITION=4 CLICK=3 SHAFT L=20MM 1 G120141201010S

PCB CWT REC_SEL SW,ROTARY SRBV170501 POSITION=7 CLICK=6 SHAFT L=20MM 1 G120170501010S

PCB CWT INPUTSEL SW,ENCODER SRRM1C7800 L=20MM CLICK=12 ENDLESS CUTTING SHAFT 1 25030424

PCB CWT IC303 IC,LINEAR-DRIVER IC TA7291S 1 22240239

PCB CWT D309 LED,ROUND WEJ314RD-741 3PI RED P=2.54 BULK 1 K500032001010S

PCB CWT D310 D311 LED302 LED303 LED304

LED305 LED306 LED307 LED,ROUND WEJ3Z4YOT-D02 3PI YELLOW ORANGE P=2.54 8 K500033000050S

PCB CWT LED301 LED,ROUND WEJ3Z4YOT-823-D02 3PI YELLOW ORANGE P=2.541K500033000060S

PCB CWT CN315 CN,WIRE 330MM/4P 5264-04=CKM2509HR-04 WH1007#22 연접 1L000331040020S

PCB CWT CN313 CN,WIRE 2MM 200MM/5P 20010HS-05=CKM2002HR-05 WH1007#26 연접 1L002201052630S

PCB CWT CN312 CN,WIRE 2MM 260MM/6P 20010HS-06=CKM2002HR-06 WH1007#26 연접 1L002261062630S

PCB CWT CN311 CN,WIRE 2MM 270MM/3P 20010HS-03=CKM2002HR-03 WH1007#26 연접 1L002271030010S

PCB CWT CN401 CN,WIRE 2MM 270MM/10P 20010HS-10=CKM2002HR-10 WH1007#26 연접 1L002271100020S

PCB CWT CN301 CN,WIRE 2MM 50MM/3P 20010HS-03=CKM2002HR-03 WH1007#261L002500030070S

PCB CWT CN314 CN,WIRE 2MM 60MM/5P 20010HS-05=CKM2002HR-05 WH1007#261L002600050040S

PCB CWT CP303 CN.WAFER 2.0MM 20010WR-08A00 DIP8P RIGHT ANGLE 1 L101200100820S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/FRONT-RADIAL 1

PCB CWT R422 R424 R,METAL FILM 100PPM 22-J,1/4W-R.REEL 2 C060022063050S

PCB CWT C302 C312 C313 C,FILM POLYESTER MI-0.01UF-J/50V-5RE ECQV1H103JL3 (PANASONIC) 3 374721034T

PCB CWT C411 C414 C,FILM POLYESTER MI-0.012UF-J/50V-5RE ECQV1H123JL3 (PANASONIC) 2 374721234T

PCB CWT C408 C409 C,FILM POLYESTER RED-0.22UF-J/63V-5RE (E12 SERIES) 2 D020224068120S

PCB CWT C407 C410 C,FILM POLYESTER MI-0.047UF-J/50V-5RE ECQV1H473JL3 (PANASONIC) 2 374724734T

PCB CWT C412 C413 C,FILM POLYESTER MI-0.082UF-J/50V-5RE ECQV1H823JL3 (PANASONIC) 2 374728234T

PCB CWT C306 C320 C,ELECT GE 85C 1UF-M/50V,5*11-5RE UVR1H010MDD (NICHICON) 2 394680107T

PCB CWT C303 C305 C,ELECT GE 85C 10UF-M/50V,5*11-5RE UVR1H100MDD (NICHICON) 2 394681007T

PCB CWT C618 C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL 1 D040101083090S

PCB CWT C301 C304 C314 C,ELECT GE 85C 100UF-M/16V,5*11-5RE UVR1C101MDD (NICHICON) 3 394641017T

PCB CWT C415 C416 C,ELECT GE 85C 220UF-M/25V,6*11(SHL TYPE) SY 2 D040221084600S

PCB CWT C307 C,ELECT GE 85C 330UF-M/6.3V,6.3*11-5RE UVR0J331MED (NICHICON) 1 394623317T

PCB CWT C401 C402 C403 C404 C405 C406 C,ELECT GE 85C 47UF-M/25V 5*11-5RE.SY 6 D040470084070S

PCB CWT C316 C,ELECT GE 85C 6.8UF-M/50V,5*11-5RE SHL SY 1 D0406R8087050S

PCB CWT C308 C,DOUBLE LAYER(70) 0.22F/5.5V-5RE FMOH224ZF -TP18 11.5*10.5 (REEL) 1 D090R22902400S

PCB CWT SW301 SW,TACT SKHV10910D01 KB581/LG 160G 1 G180040500010S

PCB CWT R301 R,FIXED,M.O. RSD-R1-1WJ-22 3*9 P=5MM SMALL R.REEL 1 N113135622020S !

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/FRONT-SMD 1

5 / 6 ページ

PCB CWT R313 R322 R,CHIP THICK 0-J,1/16W-1608REEL 2 C20000006M160S

PCB CWT R309 R315 R321 R333 R339 R350 R,CHIP THICK 100-J,1/16W-1608REEL 6 C20001016M160S

PCB CWT

R302 R306 R307 R308 R318 R345

R348 R363 R372 R374 R403 R404

R411 R412

R,CHIP THICK 1K-J,1/16W-1608REEL 14 C20001026M160S

PCB CWT R304 R305 R310 R311 R365 R369 R,CHIP THICK 10K-J,1/16W-1608REEL 6 C20001036M160S

PCB CWT R325 R326 R373 R376 R,CHIP THICK 100K-J,1/16W-1608REEL 4 C20001046M160S

PCB CWT R349 R,CHIP THICK 1.2K-J,1/16W-1608REEL 1 C20001226M160S

PCB CWT R328 R330 R331 R332 R335 R346

R355 R356 R358 R362 R,CHIP THICK 150-J,1/16W-1608REEL 10 C20001516M160S

PCB CWT R344 R352 R,CHIP THICK 1.8K-J,1/16W-1608REEL 2 C20001826M160S

PCB CWT R351 R,CHIP THICK 18K-J,1/16W-1608REEL 1 C20001836M160S

PCB CWT R312 R,CHIP THICK 20K-J,1/16W-1608REEL 1 C20002036M160S

PCB CWT R324 R,CHIP THICK 22-J,1/16W-1608REEL 1 C20002206M160S

PCB CWT R329 R338 R419 R421 R,CHIP THICK 220-J,1/16W-1608REEL 4 C20002216M160S

PCB CWT R334 R407 R408 R,CHIP THICK 22K-J,1/16W-1608REEL 3 C20002236M160S

PCB CWT R323 R401 R402 R,CHIP THICK 220K-J,1/16W-1608REEL 3 C20002246M160S

PCB CWT R347 R,CHIP THICK 270-J,1/16W-1608REEL 1 C20002716M160S

PCB CWT R314 R336 R357 R,CHIP THICK 2.7K-J,1/16W-1608REEL 3 C20002726M160S

PCB CWT R366 R,CHIP THICK 330-J,1/16W-1608REEL 1 C20003316M160S

PCB CWT R327 R354 R371 R417 R423 R,CHIP THICK 3.3K-J,1/16W-1608REEL5C20003326M160S

PCB CWT R337 R360 R,CHIP THICK 390-J,1/16W-1608REEL 2 C20003916M160S

PCB CWT R343 R,CHIP THICK 3.9K-J,1/16W-1608REEL 1 C20003926M160S

PCB CWT R317 R319 R320 R359 R,CHIP THICK 47-J,1/16W-1608REEL 4 C20004706M160S

PCB CWT R340 R341 R361 R,CHIP THICK 470-J,1/16W-1608REEL 3 C20004716M160S

PCB CWT R405 R406 R409 R414 R,CHIP THICK 4.7K-J,1/16W-1608REEL 4 C20004726M160S

PCB CWT R303 R316 R,CHIP THICK 47K-J,1/16W-1608REEL 2 C20004736M160S

PCB CWT R342 R,CHIP THICK 560-J,1/16W-1608REEL 1 C20005616M160S

PCB CWT R367 R,CHIP THICK 680-J,1/16W-1608REEL 1 C20006816M160S

PCB CWT R353 R,CHIP THICK 6.8K-J,1/16W-1608REEL 1 C20006826M160S

PCB CWT R364 R368 R,CHIP THICK 820-J,1/16W-1608REEL 2 C20008216M160S

PCB CWT C417 C418 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 2 D010101167160S

PCB CWT C310 C311 C315 C319 C321 C324 C,CERAMIC CHIP HIK X7R)0.01UF-K/50V-1608REEL TDK 6 D011103777162S

PCB CWT IC302 IC,CPU MICRO PROCESS UPD78F0536GK(T)-UET-A QFP64 /CR601 1 J020780536000S FLASH

PCB CWT IC401 IC,LINEAR OP NJM2068M-SOP8P 1 22240051R2

PCB CWT IC301 IC,LINEAR-REGULATOR IL1117_5.0 SOT-223 5.0V 1A LOW DROPOUT 1 J126111750010S

PCB CWT Q301 Q307 SEMI,CHIP TR/PNP 2SA KRA101S R1,R2=4.7K 0.2W/SOT-23 REEL 2 J520010100010S

PCB CWT Q303 SEMI,CHIP TR/PNP 2SA KRA105S(PE) 0.2W/SOT-23 REEL 1 J520010500210S

PCB CWT Q302 Q304 Q305 Q306 Q308 Q309

Q310 Q311 Q312 Q313 Q314 Q315 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL 12 2216190R2

PCB CWT Q317 Q706 SEMI,CHIP TR/NPN 2SC KTC3875S 0.15W SOT-23 REEL 2 2216175R2

PCB CWT D302 D303 D304 D305 D306 D307

D312 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) 7 223283R2

PCB CWT D301 D,RECTIFIER CHIP 1SR154-400 TE25(SMD) 1 22380284R2

PCB CWT U02-2 P.C.B SUB ASSY A9377/CPP(ONKYO)/REMOTE 1 7028068122010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/REMOTE-AXIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/REMOTE-MANUAL 1

PCB CWT RMC601 MODULE,REMOCON NJL34H380A 38KHZ 10.2*16.6 P=2.54MM 1 241365

PCB CWT CP304 CN.WAFER 2.0MM 20010WR-03A00 DIP3P RIGHT ANGLE 1 L101200100320S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/REMOTE-RADIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/REMOTE-SMD 1

PCB CWT C609 C,CERAMIC CHIP HIK X7R)0.01UF-K/50V-1608REEL TDK 1 D011103777162S

PCB CWT U02-3 P.C.B SUB ASSY A9377/CPP(ONKYO)/POWER_S/W 1 7028068123010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER_S/W-AXIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER_S/W-MANUAL 1

PCB CWT S/W201 SW,PUSH SDDL-005-S(C-UL) 400G 1 G000122006070S !

PCB CWT CN224 CN,WIRE 300MM/2P 35191-02=CKM99050101-03 WH1617#22 7.92MM 1 L000301020100S !

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER_S/W-RADIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/POWER_S/W-SMD 1

PCB CWT U02-4 P.C.B SUB ASSY A9377/CPP(ONKYO)/H_P 1 7028068124010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/H_P-AXIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/H_P-MANUAL 1

6 / 6 ページ

PCB CWT P902 JACK,D6.5 PHONE (YUQIU) D6.5 SILVER 1 G402PJ619A01YS

PCB CWT CN901 CN,WIRE 2MM 320MM/3P 20010HS-03=CKM2002HV-03 RD2547#26 TUBE 1 L002321030040S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/H_P-RADIAL 1

PCB CWT C902 C903 C,FILM POLYESTER ST-0.001UF-J/100V-5RE 2 D02010206C060S

PCB CWT C901 C,FILM POLYESTER ST-0.1UF-J/100V-5RE 1 D02010406C060S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/H_P-SMD 1

PCB CWT L901 L902 L903 COIL,BEAD HB-1M1608-221JT CIM10J221NC 220 OHM 3 D340116082210S

PCB CWT U02-5 P.C.B SUB ASSY A9377/CPP(ONKYO)/VOLUME 1 7028068125010

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOLUME-AXIAL 1

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOLUME-MANUAL 1

PCB CWT VOLUME VR,ROTARY MOTOR 16MM RK16811MGA07-20KB (MOTOR :N16RGL20KB25M) 1 5142522

PCB CWT CP501 CN.WAFER 2.0MM 20010WS-05A00 DIP5P STRAIGHT 1 L101200100510S

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOLUME-RADIAL 1

PCB CWT C501 C502 C503 C504 C,FILM POLYESTER MI-0.022UF-J/50V-5RE ECQV1H223JL3 (PANASONIC) 4 374722234T

PCB CWT * P.C.B INS ASSY A9377/CWT(ONKYO)/VOLUME-SMD 1

PCB CWT R502 R,CHIP THICK 1K-J,1/16W-1608REEL 1 C20001026M160S

PCB CWT R501 R,CHIP THICK 470K-J,1/16W-1608REEL 1 C20004746M160S
