Onkyo CR-N1 User manual
CR-N1
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LISTARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERSAPPEARAS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
SERVICE MANUAL
CD RECEIVER
Ref. No. 3687
092001
MODEL CR-N1
120V AC, 60Hz
230-240V AC, 50Hz
220-230V AC, 50/60Hz
(S)MDD,(S)MDT
(T)MPP,(S)MPA
(S)MGT,(S)MGR,(S)MGQ
Silver andTitanium model RC-454S
CR-N1
SPECIFICATIONS-1
Amplier
CD Player
USB
Power output
(U.S. & Canadian models)
2 x 6.5 watts min., RMS at 8 ohms, 50 Hz–20 kHz, with no more than 0.6%
total harmonic distortion (FTC)
2 x 9.5 watts min., RMS at 4 ohms, 50 Hz–20 kHz, with no more than 0.8%
total harmonic distortion (FTC)
2 x 15 watts at 4 ohms (EIAJ)
Power output
(Other models)
2 x 10 watts at 4 ohms, 1 kHz (DIN)
2 x 8.5 watts at 6 ohms, 1 kHz (DIN)
2 x 7 watts at 8 ohms, 1 kHz (DIN)
2 x 6.5 watts min., RMS at 8 ohms, 1 kHz, no more than 0.6% THD (FTC
rating)
2 x 15 watts at 4 ohms (EIAJ)
Dynamic power 2 x 15 watts at 4 ohms
2 x 9 watts at 8 ohms
Total harmonic distortion 0.4% at 5 watts output into 4 ohms, 1 kHz
IM distortion 0.4% at 5 watts output into 4 ohms, 1 kHz
Damping factor 25 at 4 ohms
50 at 8 ohms
LINE IN sensitivity and
impedance 500 mV, 47kohms
Frequency response 10 Hz–20 kHz, +3/–3 dB
Acoustic presence 1: +6.0 dB at 80 Hz
2: +10.0 dB at 80 Hz
Signal to noise ratio 95 dB (IHF-A)
Muting –50 dB
Signal readout system Optical non-contact
Reading rotation Approx. 500–200 rpm (constant linear velocity)
Linear velocity 1.2–1.4 m/s
Error correction system Cross interleave Reed Solomon code
D/A converter 1 bit
Digital lter 352.8 kHz, 8-times oversampling
Number of channels 2 (stereo)
Frequency response 5 Hz–20 kHz
Wow & utter Below threshold of measurability
Connection method USB (Universal Serial Bus) Ver 1.1
Sampling rate (input) 32/44.1/48 kHz compatible
Frequency response 5 Hz–20 kHz
CR-N1
SPECIFICATIONS-2
General
Specications and features are subject to change without notice.
Power supply and voltage specications depend on where the unit is purchased.
Tuning range
FM 87.9–107.9 MHz (200 kHz steps) (U.S. & Canadian model)
87.5–108.00 MHz (50 kHz steps) (Other area models)
AM
530–1710 kHz (10 kHz steps) (U.S. & Canadian model)
522–1611 kHz (9 kHz steps) (European & Australian
models)
531–1602 kHz (9 kHz steps) (Asian models)
Usable sensitivity FM
Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
11.2 dBf, 0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
17.2 dBf, 23.0 µV (75 ohms DIN)
AM 30 µV
50 dB quieting sensitivity FM Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture ratio FM 2.0 dB
Image rejection ratio FM 40 dB (U.S. & Canadian model)
85 dB (Other area models)
AM 40 dB
IF rejection ratio FM 90 dB
AM 40 dB
Signal to noise ratio FM Mono 73 dB, IHF
Stereo 67 dB, IHF
AM 40 dB
Selectivity FM 50 dB DIN
(±300 kHz at 40 kHz deviation)
AM suppression ratio 50 dB
Harmonic distortion FM Mono 0.2%
Stereo 0.3%
AM 0.7%
Frequency response FM 30 Hz–15.0 kHz (±1.5 dB)
Stereo separation FM 35 dB at 1 kHz
25 dB at 100 Hz–10.0 kHz
Stereo threshold FM 17.2 dBf, 2.0 µV (75 ohms)
Power supply
AC 120 V, 60 Hz, 39 W (U.S. & Canadian model, some Asian
models)
AC 230 V, 50 Hz, 32 W (European model)
AC 220 V, 50/60 Hz, 32 W (Other area models)
Dimensions (W x H x D) 203 x 270 x 234 mm
8" x 10-5/8" x 9-3/16"
Weight 4.2 kg (9.3 lbs)
Tuner
CR-N1
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
This set employs a laser. Therefore, be sure to follow carefully
the instructions below when servicing.
WARNING!!
SERVICE WARNING : DO NOT APPROACH THE
LASER EXIT WITH THE EYE TOO CLOSELY.
IN CASE IT IS NECESSARY TO CONFIRM LASER
BEAM EMISSION, BE SURE TO OBSERVE FROM
A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE
OPTICAL PICK-UP BLOCK.
Laser Diode Properties
Material: GaAS/GaALAs
Wavelength: 790nm
Emission Duration: continuous
Laser output: max. 0.5mW*
*This output is the value measured at a distance about 1.8mm
from the objective lens surface on the Optical Pick-up Block.
LASER WARNING LABEL
The label shown below are affixed.
1. Warning label 2. Class 1 label
"CLASS 1 LASER
PRODUCT"
LUOKAN 1
LASERLAITE
KLASS 1
LASER APPARAT
SERVICE PROCEDURE
1. Replacing the fuses
2. Safety-check out
(Only U.S.A. model)
After correcting the original service problem perform the
follwing safety check before releasing the set to the customer
Connect the insulating-resistance tester between the plug of
power supply cord and terminal GND on the back panel.
Specifications: More than 10Mohm at 500V
REF.NO. PART NO. DESCRIPTION
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse , For fuse rating, refer to
the marking adjest to the symbol.
1. Press and the hold down the VOLUME DOWN button ,
then press the DISPLAY button.
3. To initialize the unit
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
SERVICE PROCEDURES
5. Changing the AM band step
F901 252083 or
0.4A-SE-EAWK
252233 or
400MA-SE-TL250V or
252267
400MA-SE-TL250V <PP,GT,PA,GQ,GR>
252157 or
1.25A-UL/T-237 or
252251
1.25A-T/UL-ST2, Fuse <DD,DT>
NOTE:
<DD> : USA and Canadian model only
<PP> : European model only
<PA> : Australian model only
<DT> : Taiwanese model only
<GT> : Asian model only
<GR> : Chinese model only
<GQ> : Hong kong model only
2. After " All lighting " is displayed, the preset memory and each
mode stored in the memory, are initialized and will return to the
factory settings.
3. Press the STANDBY/ON button.
4. Unplug the AC plug from the wall outlet.
Refer to "SCHEMATIC DIAGRAM-1"
4. Notes at the connecting the measuring instrument
to the unit.
The power amplifier circuit of this unit is BTL system.
Therefore, in case check the output of speaker terminal,
take care not to connect the ground of the unit with the
minus terminal of speaker.
CR-N1
CHASSIS EXPLODEDVIEW
37
35 U7 U8
U9
U6
19
39 Q501 U13
39
37 23
79 80
37 37
23
21
17 49
49
47
37
U15
M2
P701
37
73
37
37 53
9
11
63
65
37 65
37
74
1
3
6
75
U5
U4
M2
U2
E702
U18 P908
U17 M5 M2
U10
P102
M8
M6
M3
M6
16
37
16
59 81
16
54
U11
M11
M19
M12
M10
M18 M17
M18
M14
M24 M23
M24
M24
M23
M22
M27
M2 M7
M1
M2
78
13
U20
P551 29
U19
37
37
27
49
43
U14
T901
33
F901
86
84
U16
71
P901
16
77
16 41
M33
U1
M19
M32
M19
M29
M29
M28
M16
7
5
5
U3
82
M15
M28
85
E703
4
CR-N1
NOTE: THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
NOTE:
<DD> : USA and Canadian model only
<PP> : European model only
<PA> : Australian model only
<DT> : Taiwanese model only
<GT> : Asian model only
<GR> : Chinese model only
<GQ> : Hong kong model only
<S> : Silver model only
<T> : Titanium model only
REF. NO. PART NO. DESCRIPTION
1 27111223A Front bracket
3 28198926 Facet, CD
4 28141446 Cushion, BU
5 838426088 2.6TTB+8B(BC), Self tapping screw
6 29110157 Tape, CU
7 27262664 Plate, F <S>
27262665 Plate, F <T>
9 27268044 Guide, DIS
11 28191931 Clear plate
13 27100404 Chassis
16 838430088 3TTB+8B(BC), Self tapping screw
17 27190266 KGLS-12RF, holder
19 27191156 KGLS-5RT, holder
21 27175390 Leg, base
23 28141468 Cushion
27 27130867 Bracket, PT
29 27190503A KGLS-8RF, holder
33 830440069 4TTC+6C(BC), Self tapping screw
35 27160487 Heat sink
37 838130088 3TTB+8B, Self tapping screw
39 801433 3SMS8W.SW+14B(BC), Self tapping screw
41 27300750 Bushing, #2271
43 28175273A Isolated plate, AC
47 28175275 Isolated plate, PT
49 880009 Plastic rivet, NRP-345
51 29110082 Tape, CROSS-8U
53 28325938 Knob, USB
54 28184828 Cover AS
59 28184812 Cover, R
63 28148495A Door AS, WINDOW
65 833126047 2.6TTP+4S, Pan head screw
71 27122870 Rear panel
73 27212328 Front panel, L <S>
27212330 Front panel, L <T>
74 27212329 Front panel, R <S>
27212331 Front panel, R <T>
75 28198927 Facet, USB
77 838430068 3TTB+6B(BC), Self tapping screw
78 29362285 Label
79 29362929 Spec label <PP,PA>
29362930 Spec label <DT>
29362931 Spec label <GT,GQ>
29363020 Spec label <GR>
29362928 Spec label <DD>
80 29362926A Label, EAN <GT,PA,GQ,GR,DT>
29362927A Label, EAN <PP>
81 29362939 Label, Warning
82 29360687 Label <PP,GT,PA,GQ,GR>
84 838430107 3TTB+10S(BC), Self tapping screw
85 28175278 Isolated plate, A <PP,GT,PA,GQ,GR>
86 260208 Binder, UL
88 29362938 Label, UD <DD>
89 29361786 Label <GT,GQ>
E703 27190540-1 Hoder, CLAMP
F901 252083 or 0.4A-SE-EAWK
252233 or 400MA-SE-TL250V or
252267 400MA-SE-TL250V, Fuse <PP,GT,PA,GQ,GR>
252157 or 1.25A-UL/T-237 or
252251 1.25A-T/UL-ST2, Fuse <DD,DT>
P102 204423022 NCFC4-23022, Flaxible flat cable
P551 2047151522 NCFC7-151522, Flaxible flat cable
P701 2045401512 NCFC5-401512, Flaxible flat cable
P901 253193HIT or AS-CEE or
253195MAR AS CEE, Power supply cord <PP,GT>
REF. NO. PART NO. DESCRIPTION
253197HIT AS-SAA, Power supply cord <,PA>
253198HIT AS-BS, Power supply cord <GQ>
253267KAW or AS-CCEE or
253285HIT or AS-CCEE or
253286VOL AS-CCEE, Power supply cord <GR>
253279HIT AS-UC-2#18 or
253280VOL AS-UC-2#18, Power supply cord <DD,DT>
EXPLODEDVIEW PARTS LIST-1
CR-N1
NOTE: THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
NOTE:
<DD> : USA and Canadian model only
<PP> : European model only
<PA> : Australian model only
<DT> : Taiwanese model only
<GT> : Asian model only
<GR> : Chinese model only
<GQ> : Hong kong model only
<S> : Silver model only
<T> : Titanium model only
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
P908 27190432 UA-0, holder
Q501 22241679 TDA8563AQ, IC
T901 2301541 NPT-1423D, Power transfomer <DD,DT>
2301542 NPT-1423P, Power transfomer <PP,PA>
2301543 NPT-1423G, Power transfomer <GT,GQ,GR>
U1 1A909580-1A
NADG-7280-1A, Microprocessor & CD PC board ass'y <DD>
1A909580-1B
NADG-7280-1B, Microprocessor & CD PC board ass'y <PP>
1A909580-1C
NADG-7280-1C, Microprocessor & CD PC board ass'y <DT>
1A909580-1E
NADG-7280-1E, Microprocessor & CD PC board ass'y <PA,GQ,GR>
1A909580-1F
NADG-7280-1F, Microprocessor & CD PC board ass'y <GT>
U2 1A909581-1A
NADIS-7281-1A, Display PC board ass'y <DD>
1A909581-1B
NADIS-7281-1B, Display PC board ass'y <PP>
1A909581-1C
NADIS-7281-1C, Display PC board ass'y <DT>
1A909581-1E
NADIS-7281-1E, Display PC board ass'y <PA,GQ,GR>
1A909581-1F
NADIS-7281-1F, Display PC board ass'y <GT>
U3 1A909582-1A
NADIS-7282-1A, USB mix volume PC board ass'y <DD>
1A909582-1B
NADIS-7282-1B, USB mix volume PC board ass'y <PP>
1A909582-1C
NADIS-7282-1C, USB mix volume PC board ass'y <DT>
1A909582-1E
NADIS-7282-1E, USB mix volume PC board ass'y <PA,GQ,GR>
1A909582-1F
NADIS-7282-1F, USB mix volume PC board ass'y <GT>
U4 1A909583-1A
NASW-7283-1A, CD control switch PC board ass'y <DD>
1A909583-1B
NASW-7283-1B, CD control switch PC board ass'y <PP>
1A909583-1C
NASW-7283-1C, CD control switch PC board ass'y <DT>
1A909583-1E
NASW-7283-1E, CD control switch PC board ass'y <PA,GQ,GR>
1A909583-1F
NASW-7283-1F, CD control switch PC board ass'y <GT>
U5 1A909584-1A
NASW-7284-1A, Audio control switch PC board ass'y <DD>
1A909584-1B
NASW-7284-1B, Audio control switch PC board ass'y <PP>
1A909584-1C
NASW-7284-1C, Audio control switch PC board ass'y <DT>
1A909584-1E
NASW-7284-1E, Audio control switch PC board ass'y <PA,GQ,GR>
1A909584-1F
NASW-7284-1F, Audio control switch PC board ass'y <GT>
U6 1A909585-1A
NAAF-7285-1A, D/A Converter PC board ass'y <DD>
1A909585-1B
NAAF-7285-1B, D/A Converter PC board ass'y <PP>
1A909585-1C
NAAF-7285-1C, D/A Converter PC board ass'y <DT>
1A909585-1E
NAAF-7285-1E, D/A Converter PC board ass'y <PA,GQ,GR>
1A909585-1F
NAAF-7285-1F, D/A Converter PC board ass'y <GT>
U7 1A909586-1A
NAAF-7286-1A, Headphone jack PC board ass'y <DD>
1A909586-1B
NAAF-7286-1B, Headphone jack PC board ass'y <PP>
1A909586-1C
NAAF-7286-1C, Headphone jack PC board ass'y <DT>
1A909586-1E
NAAF-7286-1E, Headphone jack PC board ass'y <PA,GQ,GR>
1A909586-1F
NAAF-7286-1F, Headphone jack PC board ass'y <GT>
U8 1A909587-1A
NAAF-7287-1A, Acoustic presence PC board ass'y <DD>
1A909587-1B
NAAF-7287-1B, Acoustic presence PC board ass'y <PP>
1A909587-1C
NAAF-7287-1C, Acoustic presence PC board ass'y <DT>
1A909587-1E
NAAF-7287-1E, Acoustic presence PC board ass'y <PA,GQ,GR>
1A909587-1F
NAAF-7287-1F, Acoustic presence PC board ass'y <GT>
U9 1A909588-1A
NAAF-7288-1A, USB mixing PC board ass'y <DD>
1A909588-1B
NAAF-7288-1B, USB mixing PC board ass'y <PP>
1A909588-1C
NAAF-7288-1C, USB mixing PC board ass'y <DT>
1A909588-1E
NAAF-7288-1E, USB mixing PC board ass'y <PA,GQ,GR>
1A909588-1F
NAAF-7288-1F, USB mixing PC board ass'y <GT>
U10 1A909589-1A
NAETC-7289-1A, CD mechanism connector PC board ass'y <DD>
1A909589-1B
NAETC-7289-1B, CD mechanism connector PC board ass'y <PP>
1A909589-1C
NAETC-7289-1C, CD mechanism connector PC board ass'y <DT>
1A909589-1E
NAETC-7289-1E, CD mechanism connector PC board ass'y <PA,GQ,GR>
1A909589-1F
NAETC-7289-1F, CD mechanism connector PC board ass'y <GT>
U11 1A909590-1A
NAETC-7290-1A, Open/close motor PC board ass'y <DD>
1A909590-1B
NAETC-7290-1B, Open/close motor PC board ass'y <PP>
1A909590-1C
NAETC-7290-1C, Open/close motor PC board ass'y <DT>
1A909590-1E
NAETC-7290-1E, Open/close motor PC board ass'y <PA,GQ,GR>
1A909590-1F
NAETC-7290-1F, Open/close motor PC board ass'y <GT>
U13 1A909592-1A
NAAF-7292-1A, Amplifier PC board ass'y <DD>
1A909592-1B
NAAF-7292-1B, Amplifier PC board ass'y <PP>
1A909592-1C
NAAF-7292-1C, Amplifier PC board ass'y <DT>
1A909592-1E
NAAF-7292-1E, Amplifier PC board ass'y <PA>
1A909592-1F
NAAF-7292-1F, Amplifier PC board ass'y <GT,GQ,GR>
EXPLODEDVIEW PARTS LIST-2
CR-N1
NOTE: THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
NOTE:
<DD> : USA and Canadian model only
<PP> : European model only
<PA> : Australian model only
<DT> : Taiwanese model only
<GT> : Asian model only
<GR> : Chinese model only
<GQ> : Hong kong model only
<S> : Silver model only
<T> : Titanium model only
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
1A909594-1B
NAPS-7294-1B, Standby transformer PC board ass'y <PP>
1A909594-1C
NAPS-7294-1C, Standby transformer PC board ass'y <DT>
1A909594-1E
NAPS-7294-1E, Standby transformer PC board ass'y <PA>
1A909594-1F
NAPS-7294-1F, Standby transformer PC board ass'y <GT,GQ,GR>
U16 1A909595-1A
NAETC-7295-1A, Speaker terminal PC board ass'y <DD>
1A909595-1B
NAETC-7295-1B, Speaker terminal PC board ass'y <PP>
1A909595-1C
NAETC-7295-1C, Speaker terminal PC board ass'y <DT>
1A909595-1E
NAETC-7295-1E, Speaker terminal PC board ass'y <PA>
1A909595-1F
NAETC-7295-1F, Speaker terminal PC board ass'y <GT,GQ,GR>
U17 1A909596-1A
NAETC-7296-1A, Open/close detection switch PC board ass'y <DD>
1A909596-1B
NAETC-7296-1B, Open/close detection switch PC board ass'y <PP>
1A909596-1C
NAETC-7296-1C, Open/close detection switch PC board ass'y <DT>
1A909596-1E
NAETC-7296-1E, Open/close detection switch PC board ass'y <PA>
1A909596-1F
NAETC-7296-1F, Open/close detection switch PC board ass'y <GT,GQ,GR>
U18 1A909533-1A
NAPS-7333-1A, Primary PC board ass'y <DD>
1A909533-1B
NAPS-7333-1B, Primary PC board ass'y <PP>
1A909533-1C
NAPS-7333-1C, Primary PC board ass'y <DT>
1A909533-1E
NAPS-7333-1E, Primary PC board ass'y <PA>
1A909533-1F
NAPS-7333-1F, Primary PC board ass'y <GT,GQ,GR>
U19 1A909534-1A
NAPS-7334-1A, Regulator PC board ass'y <DD>
1A909534-1B
NAPS-7334-1B, Regulator PC board ass'y <PP>
1A909534-1C
NAPS-7334-1C, Regulator PC board ass'y <DT>
1A909534-1E
NAPS-7334-1E, Regulator PC board ass'y <PA>
1A909534-1F
NAPS-7334-1F, Regulator PC board ass'y <GT,GQ,GR>
U20 240134
TFCE1U114A, Tuner unit <DD>
240135
TFCE1E512A, Tuer unit <PP,GT,PA,GT,GR,DT>
M1 24802050A Chassis, MECHA
M3 29110023 DF tape, W6
M5 24800048 DA23R, Mechanism unit
M7 24820057A Spring, MECHA
M8 29110082 Tape, CROSS-8U
M10 24840156 Bracket AS, M
M11 1A909602 Motor Ass'y
M13 24810084 Pulley
M14 24816037 RBR belt, I
M15 24810083 Gear, PULLEY
M16 24810080 Gear, A
M17 24810081 Gear, B
M27 24840152 Slider, A
M32 24840151 Bracket , PC
M12 833126047 2.6TTP+4S, Pan head screw
M22 24810082 Gear, C
M23 24810079 Gear, ARM
M28 24840154 Slider AS, B
M29 838130088 3TTB+8B, Self tapping screw
M2 838426088 2.6TTB+8B(BC), Self tapping screw
M6 24818048A Insulator
M18 24834040 Washer, B
M19 838130088 3TTB+8B, Self tapping screw
M33 838130068 3TTB+6B, Self tapping screw
M24 24840111 Special screw
U14 1A909593-1A
NAPS-7293-1A, Power supply PC board ass'y <DD>
1A909593-1B
NAPS-7293-1B, Power supply PC board ass'y <PP>
1A909593-1C
NAPS-7293-1C, Power supply PC board ass'y <DT>
1A909593-1E
NAPS-7293-1E, Power supply PC board ass'y <PA>
1A909593-1F
NAPS-7293-1F, Power supply PC board ass'y <GT,GQ,GR>
U15 1A909594-1A
NAPS-7294-1A, Standby transformer PC board ass'y <DD>
EXPLODEDVIEW PARTS LIST-3
CR-N1
SCHEMATIC DIAGRAM-1
CD MECHANISM
CONNECTOR
PC BOARD
U10
MICROPROCESSOR
& CD PC BOARD
U1
OPEN/CLOSE
DETECTION
SWITCH PC
BOARD
U17
OPEN/CLOSE MOTOR
PC BOARD
U11
A
1
2
3
4
5
BCDEFGH
P102A
P102B
P106
FE1
FE2
TE1
TE2
R170
10K
FOUCUS GAIN
ADJUST
Q701
MPD78045FGF-132-3B9
22
-VDISP71
10G 7
1G78 2G79 3G
80
4G 1
5G 2
6G 3
7G 4
8G 5
9G 6
ANGMUT51
AREA
24
AVDD
29
AVREF
30
AVSS 20
CDAUTOADJ56 CDCLK 9
CDDATA 11
CLOSE58
DSPMUT 13
FCE
39
FREQCAL
38
IC48
IN/OUT
25
K0
28
K1
27
LED154
LED259
MAIN_POWER 21
NC23
OPEN57
P160
P1069 P1170
P1272 P1373 P1474 P1575 P1676 P1777
P261 P362 P463 P564
P665 P766 P867 P968
PLLCE
40
POFF
31
POWERAMP
41
POWERCD53
RCLK
36
RDATA
37
RDSDATA42
RDSSCK45
REMIN47 RST 17
SCOR44
SD 19
SENS 15
SENS20 12
SIGNAL
26
SQCK 14
SQSO 16
STEREO 18
SYSIN46
TUMUTE50 USB-MIX49
USBPOWER43
VDD1 8
VDD252
VSS2
33
X1
34
X2
35
XLT 10XRST55
XT2
32
Q962
TC8106-H
1
2
3
45
6
7
8
P701A
Q103 LA6570
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1819
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
GND LD
MD
VR
T-
F-
F+
E
C
A
D
B
F
T+
VCC
VC
TRACKING
FOCUSING
Q152
TC7SET08F
1
24
VCC5
VEE3
Q702
TC74HCT7007
1
2
3
4
5
6
78
9
10
11
12
13
14
P104B
P104A
P105
P103B
P103A
Q101
CXA2542AQ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
BY MARK ARECRITICAL FOR SAFETY
IDENTIFIED
NOTE
THE COMPONENTS
REPLACEONLYWITH PART NUMBER SPECIFIED.
.
.VOLTAGE (MEASUREDWITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)
.ALL PNP TRANSISTORS ARE EQUIVALENT
.ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
.ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
.ELECTROLYTIC CAPACITORS ( )ARE IN F/WV.
.ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030-3pF 330-33pF 331-330pF 333-0.033uF
u
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
.THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
.
.
TO 2SA1015-GR UNLESS OTHERWISE NOTED.
P151
D703 UDZ5.1B
P952
P951
Q958
NJM2374A
1
2
3
45
6
7
8
Q961
MPC29M33HF
GIO
Q955
NJM78L05AU OR
MPC29L05
GIO
Q302
MPC29L05
NJM78L05UA OR
G
IO
Q554
BU1923F
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
P551
C703 30P
Q553
RN2403 OR
KRA103S
Q183
KRA103S
RN2403
T.P701 524.288KHZ
R963
220
1/2W
R964
220
1/2W
R957
0.22
1/2W
Q555
2SC2712
Q552
2SC3326
Q551
2SC3326
Q181
2SC3326
Q182
2SC3326
Q963
RN1402 OR
KRC102S
Q960
RN1402
KRC102S
Q957
RN1402 OR
KRC102S
Q703
RN1402
KRC102S
Q704
RN1402
KRC102S
X551
4.332MHZ
HC-49/U03
X701
4.194304MHZ
HC-49/U03
X151
16.9344MHZ
Q151
CXD3009Q
AIN166
AIN275
AOUT165
AOUT276
ASYI 37
ASYO 38
AVDD1 34
AVDD264
AVDD377
AVSS1 32
AVSS263
AVSS368
AVSS473
AVSS578
BCK 43
BCKI 44
BIAS 36
C2PO 50
C4M 52
CLKO14
CLOK9
CLTV 33
CNIN11
DATA7
DATO12
DOUT 53
EMPH 54
EMPHI55
EXCK 59
FILI 31
FILO 30
FOK18
GFS 49
LMUT2
LOUT167
LOUT274
LRCK 39
LRCKI
40
MDP
21
PCMD 41
PCMDI42
PCO 29
PWMI 22
RF 35
RMUT3SBSO 58
SCOR 57
SEIN10
SENS6
SPOA15 SPOB16
SQCK4SQSO5
SYSM62
TES1 24
TEST 23
V16M 27
VCKI 26
VCTL 28
VDD119
VDD2 46
VDD3
61
VDD4
80
VPCO 25
VSS11
VSS220
VSS3 45
VSS460
WFCK 56
XLAT8
XLON17
XLTO13 XPCK 48
XRST79
XTAI70 XTAO71
XTSL 51
XUGF 47
XVDD69
XVSS72
L955
221
NCH-1578
L101
100K
L151
BK1608LM252
L152
222
Q102
2SA1182
Q959
2SA1182
D551
1SS352
D958
1SS352
D959
1SS352
D101
1SS352
D956
CRS08
D955
1SS352
D102
CRS08
D103
CRS08 D104
U1BC44
D962
1SS352
D960
1SS352
D961
CRS08
P101A
S101
S1
C560
2.2/50
C551
22/16 C956
100/6.3
C960
2.2/50
C559
100/6.3
C126
100/6.3
C116
100/6.3
C967
220/6.3
C187
2.2/50
C713100/6.3
C710
47/50
C125
10/16
C955
470/16
C961
0.1F
5.5V
C963
100/25
C965
470/6.3
C966
10/16
C312
100/6.3
C129
220/6.3
C705
100/6.3
C128
220/6.3
C554
3.3/50
C553
3.3/50
C161
220/6.3
C186
22/50
C185
22/50
C163
470/6.3
C155
0.47/50
C130
100/6.3
C124
10/16
C105
4.7/50
C108
22/16
C109
3.3/50
C708
47/50
C557
223
C556
223
C137 N.C
C957
104
C142
104
C953
104
C952
104
C141
N.C
C561
104
C563
33PF
C562
33PF
C558
561
C168
104
C113
333
C701
104
C136
223
C135
223
C132
104
C131
103
C117
103
C118
103
C119
473
C157
104
C969
104
C169
103
C134
22PF
C133
104
C166
104
C714 104
C716
104
C715
223
C712
104
C711
223
C101
222
C968
105
C115
105
C153
223
C151
473
C152
152
C154
101
C156
103
C127
104
C120
471
C123
223
C122
104
C114
103
C112
103
C111
683
C110
153
C107
153
C106
333
C104
104 C103
104
C102 104
C962
104
C964
221
C121
223
C706
104
C704
33PF
C707
104
C159
18PF
C555
104
C552
101
C160
223
C162
104
C164
N.C
C183
681
C184
681
C182
151
C181
151
C165
104
C167
104
C158
18PF
C717
104
C702
104
C709
223
R562
680K
R563
3.3K
R564
1K
R566
1K
R567
1K R568
1K
R557
N.C
R558
680
R551
2.2K
R555
3.9K
R556
3.9K
R552
2.2K
R176
22
R140
10K R139
3.9K
R956
22K
R171
100
R565
0
R965
2.2K
R21
R22
R24
R25
R26
R27
R710
1.5K
R708
1.5K
R23
R119 22
R120 22
R177
39K
R134
10K
R133
5.6K
R135
2.2K
R132
10K
R127
100K R128
150K
R169
100
R101
27K R102
2.2K
R715
1K
R164
470
R312
10K
R121 47K
R122 47K
R131
4.7K
R175
5.6K
R147
12K
R143
10K
R142
8.2K
R144
4.7K
R141
10K
R145
10K
R146
10K
R148
27K
R150
22K
R719
10K
R172
22K
R174
22K
R173
22K
R742
560
R741
560
R126 47K
R966
10K
R732
100
R735
1K
R311
150
R961
22K
R958
10K
R959
1.5K R960
3.9K
R962
470
R149
10K
R118
1K
R117
1M
R116
12K
R138
12K
R137
39K
R111
82K
R136
39K
R105
150K
R744
560
R743
560
R720
10K
R747
***
R727
100
R729
1K
R724 470
R725 470
R726
470
R722
2.7K
R721
2.7K
R160
1M
R559
100K
R560
39K
R561
39K
R165
330
R194
N.C R193
N.C
R191
1K
R163
1K
R152
1K
R153
2.2K
R155
2.2K R154
2.2K
R167
390
R151
1K
R181
12K
R192
1K
R185
12K
R186
12K
R184
12K
R182
12K
R183
12K
R166
1M
R190
330
R188
220K
R187
220K
R189
330
R156
10K
R161
100K
R162
10K
R158
3.3K
R159
3.3K
R157
22K
R714
1K
R168
1.5K
R713
1.5K
R712
1.5K
R711
1.5K
R706
1.5K
R704
1.5K
R709
1K
R703
1K
R707
1K
R705
1K
R728
1K
R553
1.5K
R554
1.5K
R112
2.2K
R113
2.2K
R114
2.2K
R115
2.2K
R107
39K
R109
8.2K
R108
15K
R129
47K
R130
330K
R125 47K
R124 120K
R123 120K
R106
47K
R110
220K
R104
82K
R103
680K
R746
***
R733
10K
R734
1K
R717
1K
R718
22K
R737
N.C
R736
22K
R738
1K
R739
1K
R723
1K
P343D
P342C
P107A
P107B
P351A
M3
M2
M1
FOK
SENS2
SENS1
COUT
SLD TR-O
FC EFM
XRST
DATA
XLTO
CLK
MDP
ASYI
PCO
FILO
FILI
CLTV
EFM
BIAS
ASYO
FOK
SSTOP
CLK
T+ XLTO
F+ DATA
F- COUT
T- SENS1
CDCLK
PD XLT
LD CDDATA
SENS
3.3V SQSO
F-
F+
T+
T-
FC
TR-O
SLD
VC SQCK
F
B
D
A
C
E
SL+ XRST
SL-
SSTOP C
A
F
SP+ E
SP- D
B
3.3V
MDP
SCOR
VC OUT+5V
SSTOP
VC
SP+
SP- MDP
SL+
SL- +5V
T- CLOSE
T+ OPEN CD/L-OUT CD/L-OUT
F+
CDCLK
XLT
SENS2
CDDATA
SENS
SQSO
SQCK
F-
DGND
CD/R-OUT CD/R-OUT
TU-LOUT
OPENSW
TU-ROUT
USBPOWER
LD+ +5V
LD-
FC
TR RCLK
RDATA
FCE/STB
USBLED
POWER-OUTA
MAIN-POWER
A-MUT
10G
9G
8G
7G
6G
5G
4G STEREO
P14 SD
P15
STEREO
MAIN-POWER
RST
SD
4G
5G
6G
7G
8G
9G
10G
P13 A-MUT
P16 F1
P12 F2
P17 -VP
P11 POWER-OUTA
1G 3G
P10 2G POFF
2G 1G F1
P9 P17 +5MIC F2
3G P16 BUCKUP -VP
P8 P15 MAIN+B
RST
4G P14 POFF SUB+B
P7 P13
5G P12
P6
USBPOWER
POWER-A
A-MUT
F1
F2
-VP
6G P11
OPEN
CLOSE
+12V
CD-POWER
P5 P10
+5V
7G P9
P4
RCLK
RDATA
P8
8G P7
P3 P6
9G
P2
10G
P1 RDSDATA
F2 RDSSCK
F1
+5MIC STEREO
+5V RDS SD
TU-MUT TU-MUT
K1 K1 TU-R
K0 K0 TU-L
XRST
BUCKUP RDS
A-MUT +12V
OPEN +5V
CLOSE
+5V SIGNAL
TU-MUT
F1 F1
F2 F2
USBLED
-VP -VP RCLK
STBY-LED
RCLK RDATA
RDATA PLLCE
PLLCE
FCE/STB
SIGNAL
USBLED BLUE-LED USB-MIX
531-1602KHZ/9KHZ
CLOCK
ADJUST
DOOR
OPEN/CLOSE
NAETC-7296
MPP ONLY
RDS Circuit
10K
PA/PQ/GR
GT
3.3K
X
X
522-1611KHZ/9KHZ
522-1611KHZ/9KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
3.3K
3.3K
OPEN
5.6K
P
X522-1629KHZ/9KHZ76.0-108.0MHZ/50KHZ10KOPENJ
X530-1710KHZ/10KHZ87.9-107.9MHZ/200KHZ5.6K3.3KD
R746R747 RDSAMFM
TO NAAF-7292
P341B
P341A
TO NADIS-7282
or LA6576
NADG-7280
CD MECHANISM
DA23R
NAETC-7289
NAETC-7290
NAAF-7292
TO NAAF-7292
POWER IN
P951A
CONT-SIGNAL
P952A
TO NAAF-7292
AF-OUT
P351B
TO NAAF-7292
P151A
RFVC
FEO
Vc
TDFCT
FZC
TZC
ATSC
LPF1
TEO
Vee
E
F
PD2
PD1
PD
LD
RFTC
RF-M
RF-O
RF-I
CC1
CP
CB
CC2
FOK
SENS2
SENS1
C.OUT
XRST
XLT
DATA
CLK
Vcc
ISET
SL-M
SL-P
TA-M
FSET
TG2
TUG
SRCH
FE-M
SL-O
TA-O
FE-O
FLB
FGD
FDFCT
FE1
TUNER
UNIT
SLED MOTOR
SPINDLE MOTOR
LOADING
MOTOR
TO NADIS-7281
P701B
CR-N1
SCHEMATIC DIAGRAM-1
CD MECHANISM
CONNECTOR
PC BOARD
U10
MICROPROCESSOR
& CD PC BOARD
U1
OPEN/CLOSE
DETECTION
SWITCH PC
BOARD
U17
OPEN/CLOSE MOTOR
PC BOARD
U11
A
1
2
3
4
5
BCDEFGH
P102A
P102B
P106
FE1
FE2
TE1
TE2
R170
10K
FOUCUS GAIN
ADJUST
Q701
MPD78045FGF-132-3B9
22
-VDISP71
10G 7
1G78 2G79 3G
80
4G 1
5G 2
6G 3
7G 4
8G 5
9G 6
ANGMUT51
AREA
24
AVDD
29
AVREF
30
AVSS 20
CDAUTOADJ56 CDCLK 9
CDDATA 11
CLOSE58
DSPMUT 13
FCE
39
FREQCAL
38
IC48
IN/OUT
25
K0
28
K1
27
LED154
LED259
MAIN_POWER 21
NC23
OPEN57
P160
P1069 P1170
P1272 P1373 P1474 P1575 P1676 P1777
P261 P362 P463 P564
P665 P766 P867 P968
PLLCE
40
POFF
31
POWERAMP
41
POWERCD53
RCLK
36
RDATA
37
RDSDATA42
RDSSCK45
REMIN47 RST 17
SCOR44
SD 19
SENS 15
SENS20 12
SIGNAL
26
SQCK 14
SQSO 16
STEREO 18
SYSIN46
TUMUTE50 USB-MIX49
USBPOWER43
VDD1 8
VDD252
VSS2
33
X1
34
X2
35
XLT 10XRST55
XT2
32
Q962
TC8106-H
1
2
3
45
6
7
8
P701A
Q103 LA6570
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1819
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
GND LD
MD
VR
T-
F-
F+
E
C
A
D
B
F
T+
VCC
VC
TRACKING
FOCUSING
Q152
TC7SET08F
1
24
VCC5
VEE3
Q702
TC74HCT7007
1
2
3
4
5
6
78
9
10
11
12
13
14
P104B
P104A
P105
P103B
P103A
Q101
CXA2542AQ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
BY MARK ARECRITICAL FOR SAFETY
IDENTIFIED
NOTE
THE COMPONENTS
REPLACEONLYWITH PART NUMBER SPECIFIED.
.
.VOLTAGE (MEASUREDWITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)
.ALL PNP TRANSISTORS ARE EQUIVALENT
.ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
.ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
.ELECTROLYTIC CAPACITORS ( )ARE IN F/WV.
.ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030-3pF 330-33pF 331-330pF 333-0.033uF
u
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
.THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
.
.
TO 2SA1015-GR UNLESS OTHERWISE NOTED.
P151
D703 UDZ5.1B
P952
P951
Q958
NJM2374A
1
2
3
45
6
7
8
Q961
MPC29M33HF
GIO
Q955
NJM78L05AU OR
MPC29L05
GIO
Q302
MPC29L05
NJM78L05UA OR
G
IO
Q554
BU1923F
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
P551
C703 30P
Q553
RN2403 OR
KRA103S
Q183
KRA103S
RN2403
T.P701 524.288KHZ
R963
220
1/2W
R964
220
1/2W
R957
0.22
1/2W
Q555
2SC2712
Q552
2SC3326
Q551
2SC3326
Q181
2SC3326
Q182
2SC3326
Q963
RN1402 OR
KRC102S
Q960
RN1402
KRC102S
Q957
RN1402 OR
KRC102S
Q703
RN1402
KRC102S
Q704
RN1402
KRC102S
X551
4.332MHZ
HC-49/U03
X701
4.194304MHZ
HC-49/U03
X151
16.9344MHZ
Q151
CXD3009Q
AIN166
AIN275
AOUT165
AOUT276
ASYI 37
ASYO 38
AVDD1 34
AVDD264
AVDD377
AVSS1 32
AVSS263
AVSS368
AVSS473
AVSS578
BCK 43
BCKI 44
BIAS 36
C2PO 50
C4M 52
CLKO14
CLOK9
CLTV 33
CNIN11
DATA7
DATO12
DOUT 53
EMPH 54
EMPHI55
EXCK 59
FILI 31
FILO 30
FOK18
GFS 49
LMUT2
LOUT167
LOUT274
LRCK 39
LRCKI
40
MDP
21
PCMD 41
PCMDI42
PCO 29
PWMI 22
RF 35
RMUT3SBSO 58
SCOR 57
SEIN10
SENS6
SPOA15 SPOB16
SQCK4SQSO5
SYSM62
TES1 24
TEST 23
V16M 27
VCKI 26
VCTL 28
VDD119
VDD2 46
VDD3
61
VDD4
80
VPCO 25
VSS11
VSS220
VSS3 45
VSS460
WFCK 56
XLAT8
XLON17
XLTO13 XPCK 48
XRST79
XTAI70 XTAO71
XTSL 51
XUGF 47
XVDD69
XVSS72
L955
221
NCH-1578
L101
100K
L151
BK1608LM252
L152
222
Q102
2SA1182
Q959
2SA1182
D551
1SS352
D958
1SS352
D959
1SS352
D101
1SS352
D956
CRS08
D955
1SS352
D102
CRS08
D103
CRS08 D104
U1BC44
D962
1SS352
D960
1SS352
D961
CRS08
P101A
S101
S1
C560
2.2/50
C551
22/16 C956
100/6.3
C960
2.2/50
C559
100/6.3
C126
100/6.3
C116
100/6.3
C967
220/6.3
C187
2.2/50
C713100/6.3
C710
47/50
C125
10/16
C955
470/16
C961
0.1F
5.5V
C963
100/25
C965
470/6.3
C966
10/16
C312
100/6.3
C129
220/6.3
C705
100/6.3
C128
220/6.3
C554
3.3/50
C553
3.3/50
C161
220/6.3
C186
22/50
C185
22/50
C163
470/6.3
C155
0.47/50
C130
100/6.3
C124
10/16
C105
4.7/50
C108
22/16
C109
3.3/50
C708
47/50
C557
223
C556
223
C137 N.C
C957
104
C142
104
C953
104
C952
104
C141
N.C
C561
104
C563
33PF
C562
33PF
C558
561
C168
104
C113
333
C701
104
C136
223
C135
223
C132
104
C131
103
C117
103
C118
103
C119
473
C157
104
C969
104
C169
103
C134
22PF
C133
104
C166
104
C714 104
C716
104
C715
223
C712
104
C711
223
C101
222
C968
105
C115
105
C153
223
C151
473
C152
152
C154
101
C156
103
C127
104
C120
471
C123
223
C122
104
C114
103
C112
103
C111
683
C110
153
C107
153
C106
333
C104
104 C103
104
C102 104
C962
104
C964
221
C121
223
C706
104
C704
33PF
C707
104
C159
18PF
C555
104
C552
101
C160
223
C162
104
C164
N.C
C183
681
C184
681
C182
151
C181
151
C165
104
C167
104
C158
18PF
C717
104
C702
104
C709
223
R562
680K
R563
3.3K
R564
1K
R566
1K
R567
1K R568
1K
R557
N.C
R558
680
R551
2.2K
R555
3.9K
R556
3.9K
R552
2.2K
R176
22
R140
10K R139
3.9K
R956
22K
R171
100
R565
0
R965
2.2K
R21
R22
R24
R25
R26
R27
R710
1.5K
R708
1.5K
R23
R119 22
R120 22
R177
39K
R134
10K
R133
5.6K
R135
2.2K
R132
10K
R127
100K R128
150K
R169
100
R101
27K R102
2.2K
R715
1K
R164
470
R312
10K
R121 47K
R122 47K
R131
4.7K
R175
5.6K
R147
12K
R143
10K
R142
8.2K
R144
4.7K
R141
10K
R145
10K
R146
10K
R148
27K
R150
22K
R719
10K
R172
22K
R174
22K
R173
22K
R742
560
R741
560
R126 47K
R966
10K
R732
100
R735
1K
R311
150
R961
22K
R958
10K
R959
1.5K R960
3.9K
R962
470
R149
10K
R118
1K
R117
1M
R116
12K
R138
12K
R137
39K
R111
82K
R136
39K
R105
150K
R744
560
R743
560
R720
10K
R747
***
R727
100
R729
1K
R724 470
R725 470
R726
470
R722
2.7K
R721
2.7K
R160
1M
R559
100K
R560
39K
R561
39K
R165
330
R194
N.C R193
N.C
R191
1K
R163
1K
R152
1K
R153
2.2K
R155
2.2K R154
2.2K
R167
390
R151
1K
R181
12K
R192
1K
R185
12K
R186
12K
R184
12K
R182
12K
R183
12K
R166
1M
R190
330
R188
220K
R187
220K
R189
330
R156
10K
R161
100K
R162
10K
R158
3.3K
R159
3.3K
R157
22K
R714
1K
R168
1.5K
R713
1.5K
R712
1.5K
R711
1.5K
R706
1.5K
R704
1.5K
R709
1K
R703
1K
R707
1K
R705
1K
R728
1K
R553
1.5K
R554
1.5K
R112
2.2K
R113
2.2K
R114
2.2K
R115
2.2K
R107
39K
R109
8.2K
R108
15K
R129
47K
R130
330K
R125 47K
R124 120K
R123 120K
R106
47K
R110
220K
R104
82K
R103
680K
R746
***
R733
10K
R734
1K
R717
1K
R718
22K
R737
N.C
R736
22K
R738
1K
R739
1K
R723
1K
P343D
P342C
P107A
P107B
P351A
M3
M2
M1
FOK
SENS2
SENS1
COUT
SLD TR-O
FC EFM
XRST
DATA
XLTO
CLK
MDP
ASYI
PCO
FILO
FILI
CLTV
EFM
BIAS
ASYO
FOK
SSTOP
CLK
T+ XLTO
F+ DATA
F- COUT
T- SENS1
CDCLK
PD XLT
LD CDDATA
SENS
3.3V SQSO
F-
F+
T+
T-
FC
TR-O
SLD
VC SQCK
F
B
D
A
C
E
SL+ XRST
SL-
SSTOP C
A
F
SP+ E
SP- D
B
3.3V
MDP
SCOR
VC OUT+5V
SSTOP
VC
SP+
SP- MDP
SL+
SL- +5V
T- CLOSE
T+ OPEN CD/L-OUT CD/L-OUT
F+
CDCLK
XLT
SENS2
CDDATA
SENS
SQSO
SQCK
F-
DGND
CD/R-OUT CD/R-OUT
TU-LOUT
OPENSW
TU-ROUT
USBPOWER
LD+ +5V
LD-
FC
TR RCLK
RDATA
FCE/STB
USBLED
POWER-OUTA
MAIN-POWER
A-MUT
10G
9G
8G
7G
6G
5G
4G STEREO
P14 SD
P15
STEREO
MAIN-POWER
RST
SD
4G
5G
6G
7G
8G
9G
10G
P13 A-MUT
P16 F1
P12 F2
P17 -VP
P11 POWER-OUTA
1G 3G
P10 2G POFF
2G 1G F1
P9 P17 +5MIC F2
3G P16 BUCKUP -VP
P8 P15 MAIN+B
RST
4G P14 POFF SUB+B
P7 P13
5G P12
P6
USBPOWER
POWER-A
A-MUT
F1
F2
-VP
6G P11
OPEN
CLOSE
+12V
CD-POWER
P5 P10
+5V
7G P9
P4
RCLK
RDATA
P8
8G P7
P3 P6
9G
P2
10G
P1 RDSDATA
F2 RDSSCK
F1
+5MIC STEREO
+5V RDS SD
TU-MUT TU-MUT
K1 K1 TU-R
K0 K0 TU-L
XRST
BUCKUP RDS
A-MUT +12V
OPEN +5V
CLOSE
+5V SIGNAL
TU-MUT
F1 F1
F2 F2
USBLED
-VP -VP RCLK
STBY-LED
RCLK RDATA
RDATA PLLCE
PLLCE
FCE/STB
SIGNAL
USBLED BLUE-LED USB-MIX
531-1602KHZ/9KHZ
CLOCK
ADJUST
DOOR
OPEN/CLOSE
NAETC-7296
MPP ONLY
RDS Circuit
10K
PA/PQ/GR
GT
3.3K
X
X
522-1611KHZ/9KHZ
522-1611KHZ/9KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
3.3K
3.3K
OPEN
5.6K
P
X522-1629KHZ/9KHZ76.0-108.0MHZ/50KHZ10KOPENJ
X530-1710KHZ/10KHZ87.9-107.9MHZ/200KHZ5.6K3.3KD
R746R747 RDSAMFM
TO NAAF-7292
P341B
P341A
TO NADIS-7282
or LA6576
NADG-7280
CD MECHANISM
DA23R
NAETC-7289
NAETC-7290
NAAF-7292
TO NAAF-7292
POWER IN
P951A
CONT-SIGNAL
P952A
TO NAAF-7292
AF-OUT
P351B
TO NAAF-7292
P151A
RFVC
FEO
Vc
TDFCT
FZC
TZC
ATSC
LPF1
TEO
Vee
E
F
PD2
PD1
PD
LD
RFTC
RF-M
RF-O
RF-I
CC1
CP
CB
CC2
FOK
SENS2
SENS1
C.OUT
XRST
XLT
DATA
CLK
Vcc
ISET
SL-M
SL-P
TA-M
FSET
TG2
TUG
SRCH
FE-M
SL-O
TA-O
FE-O
FLB
FGD
FDFCT
FE1
TUNER
UNIT
SLED MOTOR
SPINDLE MOTOR
LOADING
MOTOR
TO NADIS-7281
P701B
CR-N1
SCHEMATIC DIAGRAM-2
DISPLAY
PC BOARD
U2
USB MIXVOLUME
PC BOARD
U3
CD CONTROL SWITCH
PC BOARD
U4
AUDIO CONTROL SWITCH
PC BOARD
U5
U9
HEADPHONE JACK PC BOARD
U7
USB MIXING PC BOARD
A
1
2
3
4
5
BCDEFGH
R345
P341B
P521
P371B
P523B
P522
SUBWOOFER
PREOUT
Q525
RN1441 Q526
RN1441
Q524
RN1441
Q523
RN1441
Q401 TC9459F
CK1
12
CS1
9 CS2 16
DATA 13
GND
11
L-A-GND
7
L-IN
4
L-LD1
5
L-LD26
L-OUT
2
NC1
3
NC2
8
NC310 NC4 15
NC5 17
NC6 22
R-A-GND 18
R-IN 21
R-LD1 20
R-LD2 19
R-OUT 23
STB 14
VDD 24
VSS
1
Q521
NJM4565M-D
5
6
4
7
Q373
NJM4565V
5
6
4
7
Q372
NJM4565V
5
6
4
7
Q371
NJM4565V
3
2
4
1
Q521
NJM4565M-D
38
21
Q373
NJM4565V
38
21
Q372
NJM4565V
38
21
Q371
NJM4565V
58
67R377
4.7K
R378
4.7K
R380
10K
R379
10K
R376
15K
R375
15K
R374
10K
R372
10K
R373
10K
R371
10K
R382
220K R381
220K
P751B
P751A
P752A
P752B
P753B
P753A
U751
SPS-446-1
P701B
Q754
RN1402
Q752
RN1402
Q753
RN1402
S761
S760
S759
S758
S762
S763
S764
S765
S757
S756
S751
S752
S753
S754
S755
Q751 10-BT-167GNYK
15
16
17
18
19
21
22
23
24
25
26
27
28
29
30
F11F1'2
F249 F2'50
G114
G105
G213 G312 G411 G510 G69G78G87G96
P146
P1037 P1136 P1235 P1334 P1433 P1532 P1631
P1720
P245 P344 P443 P542 P641 P740 P839 P938
D755
SEC1403C
D756
SEC1803C
D757
SEC1203C
D753
SEC1803C
D754
SEC1403C
D751
SEC1E01C
D752
SEC1E01C
C526
100/6.3
C525
100/6.3
C402
22/16
C401
22/16
C376
22/16
C375
22/16
C379
22/16
C380
22/16
C528
22/16
C527
22/16
C377
47/16
C378
47/16
C753
100/6.3
C530
104Z
C531
104Z
C524
101J
C523
101J
C522
101J
C521
101J
C374
330J
C373
330J
C372
330J
C371
330J
C532
104Z
C533
104Z
C751
104Z
C752
104Z
R765
150
R766
150
R767
150
R762
820
R761
470
R760
390
R771
10K
R768
1K
R769
1.8K
R770
3.9K
R538
1M
R539
33
R534
56K R533
56K
R537
1.2K
R532
33
R531
33
R536
5.6K
R530
100
R535
5.6K
R529
100
R526
470 R525
470
R528
5.6K
R527
5.6K
R524
100K R523
100K
R522
22K
R521
22K
R518
100K
R763
150
R764
1K
R759
3.9K
R751
56
R772
22K
R754
390
R755
470
R756
820
R757
1K
R758
1.8K
R752
56
R753
1K
USBL
LT
USBL
LT
P14
VOLL
P15
GND
P13
VOLR
-12
P16
+12
RT
P12
USBR
P17
+12
P11
-12
G1
CLK
P10
STB
G2
DATA
P9
RT
G3
P8
STB
G4
P7
CLK DATA
G5
USBR
P6
G6
P5
G7
P4
G8
P3
G9
P2
G10
P1
F2
+12V
F1
-12V SWOUT
GND
AMUTE
MIC+5V
HPL
DIS+5V
REM-SENS
K1
HPR
K0
HPSW
NADIS-7282
USB MIX
ON
ENERGY
SAVE
TO NADG-7280
P701A
TO NAAF-7292
P523A TO NAAF-7292
P371A
MIX LEVEL(USB)
TO NAAF-7292
NASW-7283
OPEN/CLOSE PLAY/PAUSE STOP
MEMORY
NASW7284
INPUT
NAAF-7288
SOCE/MIX
BLUE-LED
USB-LED
SEVE-LED
A.PRESENCE-LED
NAAF-7286
NADIS-7281
ACOUSTIC
PRESENCE
STANDBY/ON
USB
SOURCE
DIRECT
USB MIX
ENERGY
SAVE
FM MODE
DISPLAY
FF
FR
PHONES
ACOUSTIC
PRESENCE
VOLUME
UP
VOLUME
DOWN
CR-N1
SCHEMATIC DIAGRAM-2
DISPLAY
PC BOARD
U2
USB MIXVOLUME
PC BOARD
U3
CD CONTROL SWITCH
PC BOARD
U4
AUDIO CONTROL SWITCH
PC BOARD
U5
U9
HEADPHONE JACK PC BOARD
U7
USB MIXING PC BOARD
A
1
2
3
4
5
BCDEFGH
R345
P341B
P521
P371B
P523B
P522
SUBWOOFER
PREOUT
Q525
RN1441 Q526
RN1441
Q524
RN1441
Q523
RN1441
Q401 TC9459F
CK1
12
CS1
9 CS2 16
DATA 13
GND
11
L-A-GND
7
L-IN
4
L-LD1
5
L-LD26
L-OUT
2
NC1
3
NC2
8
NC310 NC4 15
NC5 17
NC6 22
R-A-GND 18
R-IN 21
R-LD1 20
R-LD2 19
R-OUT 23
STB 14
VDD 24
VSS
1
Q521
NJM4565M-D
5
6
4
7
Q373
NJM4565V
5
6
4
7
Q372
NJM4565V
5
6
4
7
Q371
NJM4565V
3
2
4
1
Q521
NJM4565M-D
38
21
Q373
NJM4565V
38
21
Q372
NJM4565V
38
21
Q371
NJM4565V
58
67R377
4.7K
R378
4.7K
R380
10K
R379
10K
R376
15K
R375
15K
R374
10K
R372
10K
R373
10K
R371
10K
R382
220K R381
220K
P751B
P751A
P752A
P752B
P753B
P753A
U751
SPS-446-1
P701B
Q754
RN1402
Q752
RN1402
Q753
RN1402
S761
S760
S759
S758
S762
S763
S764
S765
S757
S756
S751
S752
S753
S754
S755
Q751 10-BT-167GNYK
15
16
17
18
19
21
22
23
24
25
26
27
28
29
30
F11F1'2
F249 F2'50
G114
G105
G213 G312 G411 G510 G69G78G87G96
P146
P1037 P1136 P1235 P1334 P1433 P1532 P1631
P1720
P245 P344 P443 P542 P641 P740 P839 P938
D755
SEC1403C
D756
SEC1803C
D757
SEC1203C
D753
SEC1803C
D754
SEC1403C
D751
SEC1E01C
D752
SEC1E01C
C526
100/6.3
C525
100/6.3
C402
22/16
C401
22/16
C376
22/16
C375
22/16
C379
22/16
C380
22/16
C528
22/16
C527
22/16
C377
47/16
C378
47/16
C753
100/6.3
C530
104Z
C531
104Z
C524
101J
C523
101J
C522
101J
C521
101J
C374
330J
C373
330J
C372
330J
C371
330J
C532
104Z
C533
104Z
C751
104Z
C752
104Z
R765
150
R766
150
R767
150
R762
820
R761
470
R760
390
R771
10K
R768
1K
R769
1.8K
R770
3.9K
R538
1M
R539
33
R534
56K R533
56K
R537
1.2K
R532
33
R531
33
R536
5.6K
R530
100
R535
5.6K
R529
100
R526
470 R525
470
R528
5.6K
R527
5.6K
R524
100K R523
100K
R522
22K
R521
22K
R518
100K
R763
150
R764
1K
R759
3.9K
R751
56
R772
22K
R754
390
R755
470
R756
820
R757
1K
R758
1.8K
R752
56
R753
1K
USBL
LT
USBL
LT
P14
VOLL
P15
GND
P13
VOLR
-12
P16
+12
RT
P12
USBR
P17
+12
P11
-12
G1
CLK
P10
STB
G2
DATA
P9
RT
G3
P8
STB
G4
P7
CLK DATA
G5
USBR
P6
G6
P5
G7
P4
G8
P3
G9
P2
G10
P1
F2
+12V
F1
-12V SWOUT
GND
AMUTE
MIC+5V
HPL
DIS+5V
REM-SENS
K1
HPR
K0
HPSW
NADIS-7282
USB MIX
ON
ENERGY
SAVE
TO NADG-7280
P701A
TO NAAF-7292
P523A TO NAAF-7292
P371A
MIX LEVEL(USB)
TO NAAF-7292
NASW-7283
OPEN/CLOSE PLAY/PAUSE STOP
MEMORY
NASW7284
INPUT
NAAF-7288
SOCE/MIX
BLUE-LED
USB-LED
SEVE-LED
A.PRESENCE-LED
NAAF-7286
NADIS-7281
ACOUSTIC
PRESENCE
STANDBY/ON
USB
SOURCE
DIRECT
USB MIX
ENERGY
SAVE
FM MODE
DISPLAY
FF
FR
PHONES
ACOUSTIC
PRESENCE
VOLUME
UP
VOLUME
DOWN
CR-N1
SCHEMATIC DIAGRAM-3
AMPLIFIER
PC BOARD
U13
D/A
CONVERTER
PC BOARD
U6
REGULATOR
PC BOARD
U19
ACOUSTIC
PRESENCE
PC BOARD
U8
SPEAKERTERMINAL
PC BOARD
U16
PRIMARY
PC BOARD
U18
STANDBY
TRANSFORMER
PC BOARD
U15
A
1
2
3
4
5
BCDEFGH
ATTENTION
VA
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
AGAINST FIRE HAZARD, REPLACE
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
L901
NCH-3489
NCH-3567
T921
NPT-1398
*
Q307
NJU7200L33
GIO
JL903A
JL903B
P371A
TO NAAF-7288
P371B
E901
P151A
TO NADG-7280
Q152
JFJ1000
JL902A
P523A
TO NAAF-7286
P523B
P352
Q403
NJM4565M-D
3
2
4
1
Q403
NJM4565M-D
38
21
J1B J2B
J1A J2A
P911
P903B P902B
P902A
P903A
T.FUSE
T901 NPT-1423*
5
2
8
9
10
11
12
13
14
15
6
16
P951A
TO NADG-7280
P951
P952A
TO NADG-7280
P952
P401A
P401B
P301
+V 1
D+ 3
D- 2
GND4
X301
12MHZ
Q301 PCM2702E
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
16
17
18
19
20
21
22
23
24
25
26
27
28
P302B
P302A
P402A
P402B
JL902B
P341A
TO NADG-7280
P341B
P351B
TO NADG-7280
P351A
Q351 TC9273F-008
2
3
4
5
6
7
10
11
12
20
APH8
APL9
APW 21
CD 27
CL14 DATA 15
GND13
HIGH 19
MIX 17
SOURCE 22
STB 16
T-PLAY 24
T-REC 23
TUNER 26
USB 25
USB.M 18
VDD 28VSS1
L506
L508
L507
L505
S-0.4C
L505-L508
L305
BLM21P221SG
L304 BLM21P221SG
L323
L322
L321
BLM21P221SG
L321-L323
L303
L302
L301
BLM21B221SB
L301,L302,L303
P501
SPEAKERS
Q405
NJM4565M-D
5
67
Q341
NJM4565M-D 5
6
7
Q321
NJM2100
5
67
Q408
2SK246
Q410
2SK246
Q407
2SK246
Q409
2SK246
RL901
E LENT. POUR UNE PROTECTION PERMANENTE,N'UTILISER
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL
FOR CONTINUED PROTECTION AGAINST FIRE
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
P901
Q412
RN1441
Q411
RN1441
Q324
RN1441 Q323
RN1441
Q514
KTC3875
OR 2SC2712
Q509
KTC3875
OR 2SC2712
Q441
RN2402
Q508
KRA103S
OR RN2403
Q306
RN2403
OR KRA103S
Q303
KRA107S OR RN2407
R409
0
R541
R540
R515
R359
0
R941
0
R944
0
R368
0
R366
0
R367
0R942
0
R519
0
R365
0
R364 0
R346
0
R943
0
R911
*
R921
82
(1/2W)
R932
220 R930
220
R931
2.2K
R923
220(1/2W)
R922
220 (1/2W)
R363 1K
R362 1K
R361 1K
R444
10K
R443
10K
R358
22K
R357
22K
R354
1M
R353
1M
R442
220K
R356
22K
R355
22K
R352
2.2K
R351
2.2K
R343
22K
R342
22K
R517
2.2K
R512
100K R511
100
R513
10K
R514
1K
R514,R515,R540,R541
R516
10K
R505
8.2
R505-R508
(1/2W)
R507
R506
R508
R344
22K
R341
22K
R302 22
R303 22
R308
2.2K
R309
1K
R310
1K
R321
10K
R322
10K
R325
100K
R326
100K
R329
1K
R330
1K
R327
100K
R328
100K
R323
4.7K
R324
4.7K
R301
1.5K
R304
0
R305
1M
Q921
DTC123JS
OR KRC105M
Q510
KRC107S
OR RN1407
Q513
KRC107SOR RN1407
Q507
KRC107S
OR RN1407
Q305
RN1402
OR KRC102S
Q304
RN1404
OR KRC104S
C403
101J
C404
101J
Q405
NJM4565M-D
38
2
4
1
Q341
NJM4565M-D 3
8
2
4
1
Q321
NJM2100
38
2
4
1
JL901A
JL921A
JL501B
JL501A
P906B
P906A
JL901B
P904A
P905A
P904B
P905B
JL921B
C428
223J
C426
104J
C427
223J
C425
104J
C907
334
C906
334
C905
334
C904
104
Q902 79M12
GIO
Q901
78M12
GIO
Q501 TDA8563Q
1
2
3
4
5
6
7
8
9
10
11
12
13
Q903
2SA1015-GR
OR KTA1266-GR
D928
UDZ5.1B
D511
UDZ5.1B
D904
UDZ27B
R406
1K
R417
0
R412
2.2K
R411
2.2K
R420
0
R419
0R405
1K
R408
10K
R438
22K
R407
10K
R437
22K
R404
100K R403
100K
R907
3.3
(1/2W)
R424
1K
R423
1K
R416
270
R414
3.9K
R415 270
R413
3.9K
R430
680
R429
680
R428
1M
R432
68K
R426
1M
R427
1M
R425
1M
R431
68K
R504
4.7K
R503 4.7K
R904
3.3K
(1/2W)
R402
100
R401
100
R421
220K
R441
1K
R422
220K
R435
220K
R436
220K
R903
2.2
(1/2W)
R906
27K
R905
22
(1/2W)
R902
0.22
(1/2W)
R901
0.22
(1/2W)
R434
1K
R433
1K
R501
18K
R502
18K
C424
0.47/50
C423
0.47/50
C922
330/16
C441
2.2/50 C442
2.2/50
C920
2.2/50
C924
10/50
C693
100/6.3
C917
220/16
C918
220/16
C908
4700/25
C408
22/35
C432
22/16 C431
22/16
C343
22/16
C344
22/16
C504
10/50
C512
10/50
C321
10/16
C909
100/35
C911
4.7/50
C910
47/50
C916
100/16
C915
100/16
C914
470/25
C913
470/25
C407
22/35
C503
10/50
C511 470/25
C314
10/16
C313
100/6.3
C311
220/6.3
C310
47/16
C322 10/16
C327
22/16
C328
22/16
C307
47/16
C308
220/6.3
D901
RBV602 OR RS603M
D402
D404
D401
D403
D924
D922
D921 D923
D925
D927
D926
D908
D907D905
D906
D903
RL1N4003
D902
RL1N4003
C410
104
C409
104
C406
101J C405
101J
C919
104Z
C506
*
C508
*
C507
*
C505
*
C923
223Z
C901
103M/275VAC
C921
473Z
C692
104Z
C355
104Z
C352*
C354
*
C353*
C351
*
C341
470J
C912
223Z
C902
472M
472M/250VAC
C342
470J
C303
220J
C323
561J
C325
331J
C324
561J
C326
331J
C309
104Z
C306
104Z
C305
104Z
C302
104Z
C301
104Z
C304
220J
F901
FUSE
*
P901A
RDATA
RCLK
-12V
+12V
USBRT
RT
VOLR
GND
VOLL
LT
USBLT
CD/L-OUT
CD/R-OUT
TUL-OUT
TUR-OUT APL
APH
RT
APH HPSW
HPSW
+12V
-12V
AMUTE
GND
HPL
HPR
HPR
APL GND
VOLL
GND
HPL
AMUTE
-12V
+12V
USBRT
VOLR
MAIN+B
LT L+
L-
USBLT R-
R+
MAIN+B
AMUTE
POWER-OUTA
HPSW
FCE/STB
RDATA
RCLK
USBR
USBL
GND
USBL
USBR
GND
USBPOWER
+12V
-12V
F2
F1
MAIN-POWER
MAIN-POWER
POWER-OUTA
USBPOWER
USB+5V
USB-E
A-MUTE
POFF
F1
F2
-VP
MAIN+B
SUB+B
GND
+12V
POFF
-VP GND
SUB+B
101J
101J
101J
102J
102J
102J
FCE/STB
T921
NAAF-7292
NAAF-7285
NAPS-7294
+5V
+16V
+12V
-12V
-27V
AC
120V 60Hz
230V 50Hz
220V 50/60Hz
TYPE
P
D
G
3.3M
3.3M
TYPE
NO
NO
R911
DD
DT
GT,GR
PP,PA,PQ NPT-1423P
NPT-1423G
NPT-1423D
NPT-1423D
T400MAL250V
T400MAL250V
1.25A/125V
1.25A/125V
F901T901
NPT-1398G
NPT-1398P
NPT-1398D
NPT-1398D NO NO
C505-C508 C351-C354
FCE/STB
NAAF-7287
NAPS-7334
NAPS-7293
NAPS-7333
NAETC-7295
R+
R-
L-
L+
RCLK
RDATA
INPUT
OUTPUT
R
L
R
L
LINE
SIG GND
-R OUT
+R OUT
P GND
P GND
-L OUT
+L OUT
+V
+V
DIA
MODE
IN R
IN L
UP USB
DIGITAL
OUTPUT
OPTICAL
POWER
SUPPLY PC
BOARD
PC BOARD
U14
CR-N1
SCHEMATIC DIAGRAM-3
AMPLIFIER
PC BOARD
U13
D/A
CONVERTER
PC BOARD
U6
REGULATOR
PC BOARD
U19
ACOUSTIC
PRESENCE
PC BOARD
U8
SPEAKERTERMINAL
PC BOARD
U16
PRIMARY
PC BOARD
U18
STANDBY
TRANSFORMER
PC BOARD
U15
A
1
2
3
4
5
BCDEFGH
ATTENTION
VA
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
AGAINST FIRE HAZARD, REPLACE
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
L901
NCH-3489
NCH-3567
T921
NPT-1398
*
Q307
NJU7200L33
GIO
JL903A
JL903B
P371A
TO NAAF-7288
P371B
E901
P151A
TO NADG-7280
Q152
JFJ1000
JL902A
P523A
TO NAAF-7286
P523B
P352
Q403
NJM4565M-D
3
2
4
1
Q403
NJM4565M-D
38
21
J1B J2B
J1A J2A
P911
P903B P902B
P902A
P903A
T.FUSE
T901 NPT-1423*
5
2
8
9
10
11
12
13
14
15
6
16
P951A
TO NADG-7280
P951
P952A
TO NADG-7280
P952
P401A
P401B
P301
+V 1
D+ 3
D- 2
GND4
X301
12MHZ
Q301 PCM2702E
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
16
17
18
19
20
21
22
23
24
25
26
27
28
P302B
P302A
P402A
P402B
JL902B
P341A
TO NADG-7280
P341B
P351B
TO NADG-7280
P351A
Q351 TC9273F-008
2
3
4
5
6
7
10
11
12
20
APH8
APL9
APW 21
CD 27
CL14 DATA 15
GND13
HIGH 19
MIX 17
SOURCE 22
STB 16
T-PLAY 24
T-REC 23
TUNER 26
USB 25
USB.M 18
VDD 28VSS1
L506
L508
L507
L505
S-0.4C
L505-L508
L305
BLM21P221SG
L304 BLM21P221SG
L323
L322
L321
BLM21P221SG
L321-L323
L303
L302
L301
BLM21B221SB
L301,L302,L303
P501
SPEAKERS
Q405
NJM4565M-D
5
67
Q341
NJM4565M-D 5
6
7
Q321
NJM2100
5
67
Q408
2SK246
Q410
2SK246
Q407
2SK246
Q409
2SK246
RL901
E LENT. POUR UNE PROTECTION PERMANENTE,N'UTILISER
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL
FOR CONTINUED PROTECTION AGAINST FIRE
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
P901
Q412
RN1441
Q411
RN1441
Q324
RN1441 Q323
RN1441
Q514
KTC3875
OR 2SC2712
Q509
KTC3875
OR 2SC2712
Q441
RN2402
Q508
KRA103S
OR RN2403
Q306
RN2403
OR KRA103S
Q303
KRA107S OR RN2407
R409
0
R541
R540
R515
R359
0
R941
0
R944
0
R368
0
R366
0
R367
0R942
0
R519
0
R365
0
R364 0
R346
0
R943
0
R911
*
R921
82
(1/2W)
R932
220 R930
220
R931
2.2K
R923
220(1/2W)
R922
220 (1/2W)
R363 1K
R362 1K
R361 1K
R444
10K
R443
10K
R358
22K
R357
22K
R354
1M
R353
1M
R442
220K
R356
22K
R355
22K
R352
2.2K
R351
2.2K
R343
22K
R342
22K
R517
2.2K
R512
100K R511
100
R513
10K
R514
1K
R514,R515,R540,R541
R516
10K
R505
8.2
R505-R508
(1/2W)
R507
R506
R508
R344
22K
R341
22K
R302 22
R303 22
R308
2.2K
R309
1K
R310
1K
R321
10K
R322
10K
R325
100K
R326
100K
R329
1K
R330
1K
R327
100K
R328
100K
R323
4.7K
R324
4.7K
R301
1.5K
R304
0
R305
1M
Q921
DTC123JS
OR KRC105M
Q510
KRC107S
OR RN1407
Q513
KRC107SOR RN1407
Q507
KRC107S
OR RN1407
Q305
RN1402
OR KRC102S
Q304
RN1404
OR KRC104S
C403
101J
C404
101J
Q405
NJM4565M-D
38
2
4
1
Q341
NJM4565M-D 3
8
2
4
1
Q321
NJM2100
38
2
4
1
JL901A
JL921A
JL501B
JL501A
P906B
P906A
JL901B
P904A
P905A
P904B
P905B
JL921B
C428
223J
C426
104J
C427
223J
C425
104J
C907
334
C906
334
C905
334
C904
104
Q902 79M12
GIO
Q901
78M12
GIO
Q501 TDA8563Q
1
2
3
4
5
6
7
8
9
10
11
12
13
Q903
2SA1015-GR
OR KTA1266-GR
D928
UDZ5.1B
D511
UDZ5.1B
D904
UDZ27B
R406
1K
R417
0
R412
2.2K
R411
2.2K
R420
0
R419
0R405
1K
R408
10K
R438
22K
R407
10K
R437
22K
R404
100K R403
100K
R907
3.3
(1/2W)
R424
1K
R423
1K
R416
270
R414
3.9K
R415 270
R413
3.9K
R430
680
R429
680
R428
1M
R432
68K
R426
1M
R427
1M
R425
1M
R431
68K
R504
4.7K
R503 4.7K
R904
3.3K
(1/2W)
R402
100
R401
100
R421
220K
R441
1K
R422
220K
R435
220K
R436
220K
R903
2.2
(1/2W)
R906
27K
R905
22
(1/2W)
R902
0.22
(1/2W)
R901
0.22
(1/2W)
R434
1K
R433
1K
R501
18K
R502
18K
C424
0.47/50
C423
0.47/50
C922
330/16
C441
2.2/50 C442
2.2/50
C920
2.2/50
C924
10/50
C693
100/6.3
C917
220/16
C918
220/16
C908
4700/25
C408
22/35
C432
22/16 C431
22/16
C343
22/16
C344
22/16
C504
10/50
C512
10/50
C321
10/16
C909
100/35
C911
4.7/50
C910
47/50
C916
100/16
C915
100/16
C914
470/25
C913
470/25
C407
22/35
C503
10/50
C511 470/25
C314
10/16
C313
100/6.3
C311
220/6.3
C310
47/16
C322 10/16
C327
22/16
C328
22/16
C307
47/16
C308
220/6.3
D901
RBV602 OR RS603M
D402
D404
D401
D403
D924
D922
D921 D923
D925
D927
D926
D908
D907D905
D906
D903
RL1N4003
D902
RL1N4003
C410
104
C409
104
C406
101J C405
101J
C919
104Z
C506
*
C508
*
C507
*
C505
*
C923
223Z
C901
103M/275VAC
C921
473Z
C692
104Z
C355
104Z
C352*
C354
*
C353*
C351
*
C341
470J
C912
223Z
C902
472M
472M/250VAC
C342
470J
C303
220J
C323
561J
C325
331J
C324
561J
C326
331J
C309
104Z
C306
104Z
C305
104Z
C302
104Z
C301
104Z
C304
220J
F901
FUSE
*
P901A
RDATA
RCLK
-12V
+12V
USBRT
RT
VOLR
GND
VOLL
LT
USBLT
CD/L-OUT
CD/R-OUT
TUL-OUT
TUR-OUT APL
APH
RT
APH HPSW
HPSW
+12V
-12V
AMUTE
GND
HPL
HPR
HPR
APL GND
VOLL
GND
HPL
AMUTE
-12V
+12V
USBRT
VOLR
MAIN+B
LT L+
L-
USBLT R-
R+
MAIN+B
AMUTE
POWER-OUTA
HPSW
FCE/STB
RDATA
RCLK
USBR
USBL
GND
USBL
USBR
GND
USBPOWER
+12V
-12V
F2
F1
MAIN-POWER
MAIN-POWER
POWER-OUTA
USBPOWER
USB+5V
USB-E
A-MUTE
POFF
F1
F2
-VP
MAIN+B
SUB+B
GND
+12V
POFF
-VP GND
SUB+B
101J
101J
101J
102J
102J
102J
FCE/STB
T921
NAAF-7292
NAAF-7285
NAPS-7294
+5V
+16V
+12V
-12V
-27V
AC
120V 60Hz
230V 50Hz
220V 50/60Hz
TYPE
P
D
G
3.3M
3.3M
TYPE
NO
NO
R911
DD
DT
GT,GR
PP,PA,PQ NPT-1423P
NPT-1423G
NPT-1423D
NPT-1423D
T400MAL250V
T400MAL250V
1.25A/125V
1.25A/125V
F901T901
NPT-1398G
NPT-1398P
NPT-1398D
NPT-1398D NO NO
C505-C508 C351-C354
FCE/STB
NAAF-7287
NAPS-7334
NAPS-7293
NAPS-7333
NAETC-7295
R+
R-
L-
L+
RCLK
RDATA
INPUT
OUTPUT
R
L
R
L
LINE
SIG GND
-R OUT
+R OUT
P GND
P GND
-L OUT
+L OUT
+V
+V
DIA
MODE
IN R
IN L
UP USB
DIGITAL
OUTPUT
OPTICAL
POWER
SUPPLY PC
BOARD
PC BOARD
U14
CR-N1
SCHEMATIC DIAGRAM-1
CD MECHANISM
CONNECTOR
PC BOARD
U10
MICROPROCESSOR
& CD PC BOARD
U1
OPEN/CLOSE
DETECTION
SWITCH PC
BOARD
U17
OPEN/CLOSE MOTOR
PC BOARD
U11
A
1
2
3
4
5
BCDEFGH
P102A
P102B
P106
FE1
FE2
TE1
TE2
R170
10K
FOUCUS GAIN
ADJUST
Q701
MPD78045FGF-132-3B9
22
-VDISP71
10G 7
1G78 2G79 3G
80
4G 1
5G 2
6G 3
7G 4
8G 5
9G 6
ANGMUT51
AREA
24
AVDD
29
AVREF
30
AVSS 20
CDAUTOADJ56 CDCLK 9
CDDATA 11
CLOSE58
DSPMUT 13
FCE
39
FREQCAL
38
IC48
IN/OUT
25
K0
28
K1
27
LED154
LED259
MAIN_POWER 21
NC23
OPEN57
P160
P1069 P1170
P1272 P1373 P1474 P1575 P1676 P1777
P261 P362 P463 P564
P665 P766 P867 P968
PLLCE
40
POFF
31
POWERAMP
41
POWERCD53
RCLK
36
RDATA
37
RDSDATA42
RDSSCK45
REMIN47 RST 17
SCOR44
SD 19
SENS 15
SENS20 12
SIGNAL
26
SQCK 14
SQSO 16
STEREO 18
SYSIN46
TUMUTE50 USB-MIX49
USBPOWER43
VDD1 8
VDD252
VSS2
33
X1
34
X2
35
XLT 10XRST55
XT2
32
Q962
TC8106-H
1
2
3
45
6
7
8
P701A
Q103 LA6570
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1819
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
GND LD
MD
VR
T-
F-
F+
E
C
A
D
B
F
T+
VCC
VC
TRACKING
FOCUSING
Q152
TC7SET08F
1
24
VCC5
VEE3
Q702
TC74HCT7007
1
2
3
4
5
6
78
9
10
11
12
13
14
P104B
P104A
P105
P103B
P103A
Q101
CXA2542AQ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
BY MARK ARECRITICAL FOR SAFETY
IDENTIFIED
NOTE
THE COMPONENTS
REPLACEONLYWITH PART NUMBER SPECIFIED.
.
.VOLTAGE (MEASUREDWITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)
.ALL PNP TRANSISTORS ARE EQUIVALENT
.ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
.ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
.ELECTROLYTIC CAPACITORS ( )ARE IN F/WV.
.ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030-3pF 330-33pF 331-330pF 333-0.033uF
u
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
.THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
.
.
TO 2SA1015-GR UNLESS OTHERWISE NOTED.
P151
D703 UDZ5.1B
P952
P951
Q958
NJM2374A
1
2
3
45
6
7
8
Q961
MPC29M33HF
GIO
Q955
NJM78L05AU OR
MPC29L05
GIO
Q302
MPC29L05
NJM78L05UA OR
G
IO
Q554
BU1923F
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
P551
C703 30P
Q553
RN2403 OR
KRA103S
Q183
KRA103S
RN2403
T.P701 524.288KHZ
R963
220
1/2W
R964
220
1/2W
R957
0.22
1/2W
Q555
2SC2712
Q552
2SC3326
Q551
2SC3326
Q181
2SC3326
Q182
2SC3326
Q963
RN1402 OR
KRC102S
Q960
RN1402
KRC102S
Q957
RN1402 OR
KRC102S
Q703
RN1402
KRC102S
Q704
RN1402
KRC102S
X551
4.332MHZ
HC-49/U03
X701
4.194304MHZ
HC-49/U03
X151
16.9344MHZ
Q151
CXD3009Q
AIN166
AIN275
AOUT165
AOUT276
ASYI 37
ASYO 38
AVDD1 34
AVDD264
AVDD377
AVSS1 32
AVSS263
AVSS368
AVSS473
AVSS578
BCK 43
BCKI 44
BIAS 36
C2PO 50
C4M 52
CLKO14
CLOK9
CLTV 33
CNIN11
DATA7
DATO12
DOUT 53
EMPH 54
EMPHI55
EXCK 59
FILI 31
FILO 30
FOK18
GFS 49
LMUT2
LOUT167
LOUT274
LRCK 39
LRCKI
40
MDP
21
PCMD 41
PCMDI42
PCO 29
PWMI 22
RF 35
RMUT3SBSO58
SCOR 57
SEIN10
SENS6
SPOA15 SPOB16
SQCK4SQSO5
SYSM62
TES1 24
TEST 23
V16M 27
VCKI 26
VCTL 28
VDD119
VDD2 46
VDD3
61
VDD4
80
VPCO 25
VSS11
VSS220
VSS3 45
VSS460
WFCK 56
XLAT8
XLON17
XLTO13 XPCK 48
XRST79
XTAI70 XTAO71
XTSL 51
XUGF 47
XVDD69
XVSS72
L955
221
NCH-1578
L101
100K
L151
BK1608LM252
L152
222
Q102
2SA1182
Q959
2SA1182
D551
1SS352
D958
1SS352
D959
1SS352
D101
1SS352
D956
CRS08
D955
1SS352
D102
CRS08
D103
CRS08 D104
U1BC44
D962
1SS352
D960
1SS352
D961
CRS08
P101A
S101
S1
C560
2.2/50
C551
22/16 C956
100/6.3
C960
2.2/50
C559
100/6.3
C126
100/6.3
C116
100/6.3
C967
220/6.3
C187
2.2/50
C713100/6.3
C710
47/50
C125
10/16
C955
470/16
C961
0.1F
5.5V
C963
100/25
C965
470/6.3
C966
10/16
C312
100/6.3
C129
220/6.3
C705
100/6.3
C128
220/6.3
C554
3.3/50
C553
3.3/50
C161
220/6.3
C186
22/50
C185
22/50
C163
470/6.3
C155
0.47/50
C130
100/6.3
C124
10/16
C105
4.7/50
C108
22/16
C109
3.3/50
C708
47/50
C557
223
C556
223
C137 N.C
C957
104
C142
104
C953
104
C952
104
C141
N.C
C561
104
C563
33PF
C562
33PF
C558
561
C168
104
C113
333
C701
104
C136
223
C135
223
C132
104
C131
103
C117
103
C118
103
C119
473
C157
104
C969
104
C169
103
C134
22PF
C133
104
C166
104
C714 104
C716
104
C715
223
C712
104
C711
223
C101
222
C968
105
C115
105
C153
223
C151
473
C152
152
C154
101
C156
103
C127
104
C120
471
C123
223
C122
104
C114
103
C112
103
C111
683
C110
153
C107
153
C106
333
C104
104 C103
104
C102 104
C962
104
C964
221
C121
223
C706
104
C704
33PF
C707
104
C159
18PF
C555
104
C552
101
C160
223
C162
104
C164
N.C
C183
681
C184
681
C182
151
C181
151
C165
104
C167
104
C158
18PF
C717
104
C702
104
C709
223
R562
680K
R563
3.3K
R564
1K
R566
1K
R567
1K R568
1K
R557
N.C
R558
680
R551
2.2K
R555
3.9K
R556
3.9K
R552
2.2K
R176
22
R140
10K R139
3.9K
R956
22K
R171
100
R565
0
R965
2.2K
R21
R22
R24
R25
R26
R27
R710
1.5K
R708
1.5K
R23
R119 22
R120 22
R177
39K
R134
10K
R133
5.6K
R135
2.2K
R132
10K
R127
100K R128
150K
R169
100
R101
27K R102
2.2K
R715
1K
R164
470
R312
10K
R121 47K
R122 47K
R131
4.7K
R175
5.6K
R147
12K
R143
10K
R142
8.2K
R144
4.7K
R141
10K
R145
10K
R146
10K
R148
27K
R150
22K
R719
10K
R172
22K
R174
22K
R173
22K
R742
560
R741
560
R126 47K
R966
10K
R732
100
R735
1K
R311
150
R961
22K
R958
10K
R959
1.5K R960
3.9K
R962
470
R149
10K
R118
1K
R117
1M
R116
12K
R138
12K
R137
39K
R111
82K
R136
39K
R105
150K
R744
560
R743
560
R720
10K
R747
***
R727
100
R729
1K
R724 470
R725 470
R726
470
R722
2.7K
R721
2.7K
R160
1M
R559
100K
R560
39K
R561
39K
R165
330
R194
N.C R193
N.C
R191
1K
R163
1K
R152
1K
R153
2.2K
R155
2.2K R154
2.2K
R167
390
R151
1K
R181
12K
R192
1K
R185
12K
R186
12K
R184
12K
R182
12K
R183
12K
R166
1M
R190
330
R188
220K
R187
220K
R189
330
R156
10K
R161
100K
R162
10K
R158
3.3K
R159
3.3K
R157
22K
R714
1K
R168
1.5K
R713
1.5K
R712
1.5K
R711
1.5K
R706
1.5K
R704
1.5K
R709
1K
R703
1K
R707
1K
R705
1K
R728
1K
R553
1.5K
R554
1.5K
R112
2.2K
R113
2.2K
R114
2.2K
R115
2.2K
R107
39K
R109
8.2K
R108
15K
R129
47K
R130
330K
R125 47K
R124 120K
R123 120K
R106
47K
R110
220K
R104
82K
R103
680K
R746
***
R733
10K
R734
1K
R717
1K
R718
22K
R737
N.C
R736
22K
R738
1K
R739
1K
R723
1K
P343D
P342C
P107A
P107B
P351A
M3
M2
M1
FOK
SENS2
SENS1
COUT
SLD TR-O
FC EFM
XRST
DATA
XLTO
CLK
MDP
ASYI
PCO
FILO
FILI
CLTV
EFM
BIAS
ASYO
FOK
SSTOP
CLK
T+ XLTO
F+ DATA
F- COUT
T- SENS1
CDCLK
PD XLT
LD CDDATA
SENS
3.3V SQSO
F-
F+
T+
T-
FC
TR-O
SLD
VC SQCK
F
B
D
A
C
E
SL+ XRST
SL-
SSTOP C
A
F
SP+ E
SP- D
B
3.3V
MDP
SCOR
VC OUT+5V
SSTOP
VC
SP+
SP- MDP
SL+
SL- +5V
T- CLOSE
T+ OPEN CD/L-OUT CD/L-OUT
F+
CDCLK
XLT
SENS2
CDDATA
SENS
SQSO
SQCK
F-
DGND
CD/R-OUT CD/R-OUT
TU-LOUT
OPENSW
TU-ROUT
USBPOWER
LD+ +5V
LD-
FC
TR RCLK
RDATA
FCE/STB
USBLED
POWER-OUTA
MAIN-POWER
A-MUT
10G
9G
8G
7G
6G
5G
4G STEREO
P14 SD
P15
STEREO
MAIN-POWER
RST
SD
4G
5G
6G
7G
8G
9G
10G
P13 A-MUT
P16 F1
P12 F2
P17 -VP
P11 POWER-OUTA
1G 3G
P10 2G POFF
2G 1G F1
P9 P17 +5MIC F2
3G P16 BUCKUP -VP
P8 P15 MAIN+B
RST
4G P14 POFF SUB+B
P7 P13
5G P12
P6
USBPOWER
POWER-A
A-MUT
F1
F2
-VP
6G P11
OPEN
CLOSE
+12V
CD-POWER
P5 P10
+5V
7G P9
P4
RCLK
RDATA
P8
8G P7
P3 P6
9G
P2
10G
P1 RDSDATA
F2 RDSSCK
F1
+5MIC STEREO
+5V RDS SD
TU-MUT TU-MUT
K1 K1 TU-R
K0 K0 TU-L
XRST
BUCKUP RDS
A-MUT +12V
OPEN +5V
CLOSE
+5V SIGNAL
TU-MUT
F1 F1
F2 F2
USBLED
-VP -VP RCLK
STBY-LED
RCLK RDATA
RDATA PLLCE
PLLCE
FCE/STB
SIGNAL
USBLED BLUE-LED USB-MIX
531-1602KHZ/9KHZ
CLOCK
ADJUST
DOOR
OPEN/CLOSE
NAETC-7296
MPP ONLY
RDS Circuit
10K
PA/PQ/GR
GT
3.3K
X
X
522-1611KHZ/9KHZ
522-1611KHZ/9KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
87.5-108.0MHZ/50KHZ
3.3K
3.3K
OPEN
5.6K
P
X522-1629KHZ/9KHZ76.0-108.0MHZ/50KHZ10KOPENJ
X530-1710KHZ/10KHZ87.9-107.9MHZ/200KHZ5.6K3.3KD
R746R747 RDSAMFM
TO NAAF-7292
P341B
P341A
TO NADIS-7282
or LA6576
NADG-7280
CD MECHANISM
DA23R
NAETC-7289
NAETC-7290
NAAF-7292
TO NAAF-7292
POWER IN
P951A
CONT-SIGNAL
P952A
TO NAAF-7292
AF-OUT
P351B
TO NAAF-7292
P151A
RFVC
FEO
Vc
TDFCT
FZC
TZC
ATSC
LPF1
TEO
Vee
E
F
PD2
PD1
PD
LD
RFTC
RF-M
RF-O
RF-I
CC1
CP
CB
CC2
FOK
SENS2
SENS1
C.OUT
XRST
XLT
DATA
CLK
Vcc
ISET
SL-M
SL-P
TA-M
FSET
TG2
TUG
SRCH
FE-M
SL-O
TA-O
FE-O
FLB
FGD
FDFCT
FE1
TUNER
UNIT
SLED MOTOR
SPINDLE MOTOR
LOADING
MOTOR
TO NADIS-7281
P701B
CR-N1
SCHEMATIC DIAGRAM-2
DISPLAY
PC BOARD
U2
USB MIXVOLUME
PC BOARD
U3
CD CONTROL SWITCH
PC BOARD
U4
AUDIO CONTROL SWITCH
PC BOARD
U5
U9
HEADPHONE JACK PC BOARD
U7
USB MIXING PC BOARD
A
1
2
3
4
5
BCDEFGH
R345
P341B
P521
P371B
P523B
P522
SUBWOOFER
PREOUT
Q525
RN1441 Q526
RN1441
Q524
RN1441
Q523
RN1441
Q401 TC9459F
CK1
12
CS1
9 CS2 16
DATA 13
GND
11
L-A-GND
7
L-IN
4
L-LD1
5
L-LD26
L-OUT
2
NC1
3
NC2
8
NC310 NC4 15
NC5 17
NC6 22
R-A-GND 18
R-IN 21
R-LD1 20
R-LD2 19
R-OUT 23
STB 14
VDD 24
VSS
1
Q521
NJM4565M-D
5
6
4
7
Q373
NJM4565V
5
6
4
7
Q372
NJM4565V
5
6
4
7
Q371
NJM4565V
3
2
4
1
Q521
NJM4565M-D
38
21
Q373
NJM4565V
38
21
Q372
NJM4565V
38
21
Q371
NJM4565V
58
67R377
4.7K
R378
4.7K
R380
10K
R379
10K
R376
15K
R375
15K
R374
10K
R372
10K
R373
10K
R371
10K
R382
220K R381
220K
P751B
P751A
P752A
P752B
P753B
P753A
U751
SPS-446-1
P701B
Q754
RN1402
Q752
RN1402
Q753
RN1402
S761
S760
S759
S758
S762
S763
S764
S765
S757
S756
S751
S752
S753
S754
S755
Q751 10-BT-167GNYK
15
16
17
18
19
21
22
23
24
25
26
27
28
29
30
F11F1'2
F249 F2'50
G114
G105
G213 G312 G411 G510 G69G78G87G96
P146
P1037 P1136 P1235 P1334 P1433 P1532 P1631
P1720
P245 P344 P443 P542 P641 P740 P839 P938
D755
SEC1403C
D756
SEC1803C
D757
SEC1203C
D753
SEC1803C
D754
SEC1403C
D751
SEC1E01C
D752
SEC1E01C
C526
100/6.3
C525
100/6.3
C402
22/16
C401
22/16
C376
22/16
C375
22/16
C379
22/16
C380
22/16
C528
22/16
C527
22/16
C377
47/16
C378
47/16
C753
100/6.3
C530
104Z
C531
104Z
C524
101J
C523
101J
C522
101J
C521
101J
C374
330J
C373
330J
C372
330J
C371
330J
C532
104Z
C533
104Z
C751
104Z
C752
104Z
R765
150
R766
150
R767
150
R762
820
R761
470
R760
390
R771
10K
R768
1K
R769
1.8K
R770
3.9K
R538
1M
R539
33
R534
56K R533
56K
R537
1.2K
R532
33
R531
33
R536
5.6K
R530
100
R535
5.6K
R529
100
R526
470 R525
470
R528
5.6K
R527
5.6K
R524
100K R523
100K
R522
22K
R521
22K
R518
100K
R763
150
R764
1K
R759
3.9K
R751
56
R772
22K
R754
390
R755
470
R756
820
R757
1K
R758
1.8K
R752
56
R753
1K
USBL
LT
USBL
LT
P14
VOLL
P15
GND
P13
VOLR
-12
P16
+12
RT
P12
USBR
P17
+12
P11
-12
G1
CLK
P10
STB
G2
DATA
P9
RT
G3
P8
STB
G4
P7
CLK DATA
G5
USBR
P6
G6
P5
G7
P4
G8
P3
G9
P2
G10
P1
F2
+12V
F1
-12V SWOUT
GND
AMUTE
MIC+5V
HPL
DIS+5V
REM-SENS
K1
HPR
K0
HPSW
NADIS-7282
USB MIX
ON
ENERGY
SAVE
TO NADG-7280
P701A
TO NAAF-7292
P523A TO NAAF-7292
P371A
MIX LEVEL(USB)
TO NAAF-7292
NASW-7283
OPEN/CLOSE PLAY/PAUSE STOP
MEMORY
NASW7284
INPUT
NAAF-7288
SOCE/MIX
BLUE-LED
USB-LED
SEVE-LED
A.PRESENCE-LED
NAAF-7286
NADIS-7281
ACOUSTIC
PRESENCE
STANDBY/ON
USB
SOURCE
DIRECT
USB MIX
ENERGY
SAVE
FM MODE
DISPLAY
FF
FR
PHONES
ACOUSTIC
PRESENCE
VOLUME
UP
VOLUME
DOWN
CR-N1
SCHEMATIC DIAGRAM-3
AMPLIFIER
PC BOARD
U13
D/A
CONVERTER
PC BOARD
U6
REGULATOR
PC BOARD
U19
ACOUSTIC
PRESENCE
PC BOARD
U8
SPEAKERTERMINAL
PC BOARD
U16
PRIMARY
PC BOARD
U18
STANDBY
TRANSFORMER
PC BOARD
U15
A
1
2
3
4
5
BCDEFGH
ATTENTION
VA
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
AGAINST FIRE HAZARD, REPLACE
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
L901
NCH-3489
NCH-3567
T921
NPT-1398
*
Q307
NJU7200L33
GIO
JL903A
JL903B
P371A
TO NAAF-7288
P371B
E901
P151A
TO NADG-7280
Q152
JFJ1000
JL902A
P523A
TO NAAF-7286
P523B
P352
Q403
NJM4565M-D
3
2
4
1
Q403
NJM4565M-D
38
21
J1B J2B
J1A J2A
P911
P903B P902B
P902A
P903A
T.FUSE
T901 NPT-1423*
5
2
8
9
10
11
12
13
14
15
6
16
P951A
TO NADG-7280
P951
P952A
TO NADG-7280
P952
P401A
P401B
P301
+V 1
D+ 3
D- 2
GND4
X301
12MHZ
Q301 PCM2702E
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
16
17
18
19
20
21
22
23
24
25
26
27
28
P302B
P302A
P402A
P402B
JL902B
P341A
TO NADG-7280
P341B
P351B
TO NADG-7280
P351A
Q351 TC9273F-008
2
3
4
5
6
7
10
11
12
20
APH8
APL9
APW 21
CD 27
CL14 DATA 15
GND13
HIGH 19
MIX 17
SOURCE 22
STB 16
T-PLAY 24
T-REC 23
TUNER 26
USB 25
USB.M 18
VDD 28VSS1
L506
L508
L507
L505
S-0.4C
L505-L508
L305
BLM21P221SG
L304 BLM21P221SG
L323
L322
L321
BLM21P221SG
L321-L323
L303
L302
L301
BLM21B221SB
L301,L302,L303
P501
SPEAKERS
Q405
NJM4565M-D
5
67
Q341
NJM4565M-D 5
6
7
Q321
NJM2100
5
67
Q408
2SK246
Q410
2SK246
Q407
2SK246
Q409
2SK246
RL901
E LENT. POUR UNE PROTECTION PERMANENTE,N'UTILISER
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL
FOR CONTINUED PROTECTION AGAINST FIRE
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
P901
Q412
RN1441
Q411
RN1441
Q324
RN1441 Q323
RN1441
Q514
KTC3875
OR 2SC2712
Q509
KTC3875
OR 2SC2712
Q441
RN2402
Q508
KRA103S
OR RN2403
Q306
RN2403
OR KRA103S
Q303
KRA107S OR RN2407
R409
0
R541
R540
R515
R359
0
R941
0
R944
0
R368
0
R366
0
R367
0R942
0
R519
0
R365
0
R364 0
R346
0
R943
0
R911
*
R921
82
(1/2W)
R932
220 R930
220
R931
2.2K
R923
220(1/2W)
R922
220 (1/2W)
R363 1K
R362 1K
R361 1K
R444
10K
R443
10K
R358
22K
R357
22K
R354
1M
R353
1M
R442
220K
R356
22K
R355
22K
R352
2.2K
R351
2.2K
R343
22K
R342
22K
R517
2.2K
R512
100K R511
100
R513
10K
R514
1K
R514,R515,R540,R541
R516
10K
R505
8.2
R505-R508
(1/2W)
R507
R506
R508
R344
22K
R341
22K
R302 22
R303 22
R308
2.2K
R309
1K
R310
1K
R321
10K
R322
10K
R325
100K
R326
100K
R329
1K
R330
1K
R327
100K
R328
100K
R323
4.7K
R324
4.7K
R301
1.5K
R304
0
R305
1M
Q921
DTC123JS
OR KRC105M
Q510
KRC107S
OR RN1407
Q513
KRC107SOR RN1407
Q507
KRC107S
OR RN1407
Q305
RN1402
OR KRC102S
Q304
RN1404
OR KRC104S
C403
101J
C404
101J
Q405
NJM4565M-D
38
2
4
1
Q341
NJM4565M-D 3
8
2
4
1
Q321
NJM2100
38
2
4
1
JL901A
JL921A
JL501B
JL501A
P906B
P906A
JL901B
P904A
P905A
P904B
P905B
JL921B
C428
223J
C426
104J
C427
223J
C425
104J
C907
334
C906
334
C905
334
C904
104
Q902 79M12
GIO
Q901
78M12
GIO
Q501 TDA8563Q
1
2
3
4
5
6
7
8
9
10
11
12
13
Q903
2SA1015-GR
OR KTA1266-GR
D928
UDZ5.1B
D511
UDZ5.1B
D904
UDZ27B
R406
1K
R417
0
R412
2.2K
R411
2.2K
R420
0
R419
0R405
1K
R408
10K
R438
22K
R407
10K
R437
22K
R404
100K R403
100K
R907
3.3
(1/2W)
R424
1K
R423
1K
R416
270
R414
3.9K
R415 270
R413
3.9K
R430
680
R429
680
R428
1M
R432
68K
R426
1M
R427
1M
R425
1M
R431
68K
R504
4.7K
R503 4.7K
R904
3.3K
(1/2W)
R402
100
R401
100
R421
220K
R441
1K
R422
220K
R435
220K
R436
220K
R903
2.2
(1/2W)
R906
27K
R905
22
(1/2W)
R902
0.22
(1/2W)
R901
0.22
(1/2W)
R434
1K
R433
1K
R501
18K
R502
18K
C424
0.47/50
C423
0.47/50
C922
330/16
C441
2.2/50 C442
2.2/50
C920
2.2/50
C924
10/50
C693
100/6.3
C917
220/16
C918
220/16
C908
4700/25
C408
22/35
C432
22/16 C431
22/16
C343
22/16
C344
22/16
C504
10/50
C512
10/50
C321
10/16
C909
100/35
C911
4.7/50
C910
47/50
C916
100/16
C915
100/16
C914
470/25
C913
470/25
C407
22/35
C503
10/50
C511 470/25
C314
10/16
C313
100/6.3
C311
220/6.3
C310
47/16
C322 10/16
C327
22/16
C328
22/16
C307
47/16
C308
220/6.3
D901
RBV602 OR RS603M
D402
D404
D401
D403
D924
D922
D921 D923
D925
D927
D926
D908
D907D905
D906
D903
RL1N4003
D902
RL1N4003
C410
104
C409
104
C406
101J C405
101J
C919
104Z
C506
*
C508
*
C507
*
C505
*
C923
223Z
C901
103M/275VAC
C921
473Z
C692
104Z
C355
104Z
C352*
C354
*
C353*
C351
*
C341
470J
C912
223Z
C902
472M
472M/250VAC
C342
470J
C303
220J
C323
561J
C325
331J
C324
561J
C326
331J
C309
104Z
C306
104Z
C305
104Z
C302
104Z
C301
104Z
C304
220J
F901
FUSE
*
P901A
RDATA
RCLK
-12V
+12V
USBRT
RT
VOLR
GND
VOLL
LT
USBLT
CD/L-OUT
CD/R-OUT
TUL-OUT
TUR-OUT APL
APH
RT
APH HPSW
HPSW
+12V
-12V
AMUTE
GND
HPL
HPR
HPR
APL GND
VOLL
GND
HPL
AMUTE
-12V
+12V
USBRT
VOLR
MAIN+B
LT L+
L-
USBLT R-
R+
MAIN+B
AMUTE
POWER-OUTA
HPSW
FCE/STB
RDATA
RCLK
USBR
USBL
GND
USBL
USBR
GND
USBPOWER
+12V
-12V
F2
F1
MAIN-POWER
MAIN-POWER
POWER-OUTA
USBPOWER
USB+5V
USB-E
A-MUTE
POFF
F1
F2
-VP
MAIN+B
SUB+B
GND
+12V
POFF
-VP GND
SUB+B
101J
101J
101J
102J
102J
102J
FCE/STB
T921
NAAF-7292
NAAF-7285
NAPS-7294
+5V
+16V
+12V
-12V
-27V
AC
120V 60Hz
230V 50Hz
220V 50/60Hz
TYPE
P
D
G
3.3M
3.3M
TYPE
NO
NO
R911
DD
DT
GT,GR
PP,PA,PQ NPT-1423P
NPT-1423G
NPT-1423D
NPT-1423D
T400MAL250V
T400MAL250V
1.25A/125V
1.25A/125V
F901T901
NPT-1398G
NPT-1398P
NPT-1398D
NPT-1398D NO NO
C505-C508 C351-C354
FCE/STB
NAAF-7287
NAPS-7334
NAPS-7293
NAPS-7333
NAETC-7295
R+
R-
L-
L+
RCLK
RDATA
INPUT
OUTPUT
R
L
R
L
LINE
SIG GND
-R OUT
+R OUT
P GND
P GND
-L OUT
+L OUT
+V
+V
DIA
MODE
IN R
IN L
UP USB
DIGITAL
OUTPUT
OPTICAL
POWER
SUPPLY PC
BOARD
PC BOARD
U14
CR-N1
T901
S101
P103B
U19
TFCE1E512A
NAAF-7286
NAAF-7292
NAAF-7287 NAAF7288
NAETC-7296
NAPS-7334
NAAF-7285
NAPS-7333
NAPS-7294
NAPS-7293
NADG-7280
NAETC-7289
NAETC-7295
NAETC-7290 NASW-7283 NADIS-7282
NASW-7284
NADIS-7281
P523B
P521 P522
LR+-+-
P551
JL501C
Q501
Q152 P352
P151A
JL501A
P523A P402A
P401A
P371A
P341A
P351B P302A
P952A
Q901
JL903B
P902A
AC-H
AC-G
P903A P901A
P906B P904B P905B
P906A
P904A
P905A JL921B
T921
P102B
P105
RF
VC
P106
P103A
P701A P951 P952 P551
P342C
P343D P151
P351A
P903B P902B
F901
Q902
JL903A
JL901A
JL902A
P104B
P102A
P107A
P104A
P101A
P753A
P752B
P701B
P751A
P341B
P751B
P753A
VOL.UP
VOL.DOWN
A.PRESENCE
INPUT
Q751
U751
REMOTE SENSOR
MODE
SAVE
MEMORY DISPLAY
FR
FF
P752A
R345
USB_MIX
STANDBY
USB_MIX
OPEN/CLOSE
PLAY/PAUSE
STOP
P107B
DA23R
P401B
P402B P371B
P951
JL902B
JL901B
JL921A
P302B
P301
U2
U5
U4
U17
U10
U11
U20
U7
U16
U8 U9
U13
U1
U14
U3
U15
U6
U18
TUNER UNIT
HEADPHONE JACK
AMPLIFIER CIRCUIT
ACOUSTIC PRESENCE
CIRCUIT USB MIXING CIRCUIT
OPEN/CLOSE
DETECTION SWITCH
REGULATOR
D/A CONVERTER
CIRCUIT
PRIMARY
CIRCUIT
STANDBY TRANSFORMER
POWER SUPPLY
MICROPROCESSOR
&CD CIRCUIT
CD MECHANISM CONNECTOR
SPEAKER TERMINAL
OPEN/CLOSE MOTOR
CD CONTROL SWITCH
USB MIX VOLUME
AUDIO CONTROL SWITCH
DISPLAY CIRCUIT
SPEAKERS
PHONES SUB WOOFER
LINE
INPUT
OUTPUT
DIGITAL OPTICAL
OUTPUT
FL TUBE
CD MECHANISM
AC IN
UP USB
PC BOARD CONNECTION DIAGRAM
Other manuals for CR-N1
1
Table of contents
Other Onkyo Car Receiver manuals
Onkyo
Onkyo CR-B8 User manual
Onkyo
Onkyo CR-245BT User manual
Onkyo
Onkyo CS-345 User manual
Onkyo
Onkyo CR-515 CR-315 User manual
Onkyo
Onkyo CR-325 User manual
Onkyo
Onkyo CS-245BT User manual
Onkyo
Onkyo CR-305X User manual
Onkyo
Onkyo CR-505DA User manual
Onkyo
Onkyo CR-715 User manual
Onkyo
Onkyo C-701A User manual
