Onkyo HT-S780(B)/(S) User manual

HT-S780
SERVICE MANUAL
SERVICE MANUAL
7.1-CH HOME THEATER SYSTEM
Black and Silver models
MODEL HT-S780(B)/(S)
Ref. No. 3896
042005
120V AC, 60Hz
120V AC, 60Hz
230-240V AC, 50Hz
BMDD
BMDC
BMPA
---
120V AC, 60Hz
230-240V AC, 50Hz
---
SMDC
SMPA
- - - HT-R530 (AV Receiver) - - -
- - - - - - - - - - - - HTP-530 (7.1-channel speaker package) - - - - - - - - - - - -
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

HT-S780
PACKING PROCEDURE-1
RECEIVER SECTION
A631
A610
A601
(L & R)
A631
A656
A656
A626
A625
A812
A801
A802
A811
A820
A690
A804
A845
A847
A821
A631
A631
A631
A631
<R>
Front side
Right side
marking
Front side
marking
Left side
marking
Front side
marking
<L>
Large side
Small side

HT-S780
PACKING PROCEDURE-2
SPEAKER SECTION
FL
FR
C
SP04
SP04
SP04
SP12
SP04
SP04
SP04
SP04
SP04
SP12
SP12
SP04
SP12
SP01 : INNER
SP02 : OUTER
SP03
SP05
(Top)
SP06
(Center)
SP07
(Bottom)
SP08 : INNER
SP09 : OUTER
SP08 : INNER
SP09 : OUTER
SP10 : INNER
SP11 : OUTER
Upper side
marking
Upper side
marking
Upper side
marking
SKB-530(L)
SKB-530(R)
SKM-530S(L)
SKM-530S(R)
SKF-530F(R)
SKF-530F(L)
SKC-530C
Front side
SKW-530

HT-S780
PACKING PROCEDURE-3
OVERALL
HT-S780
HT-S780
TOP
L = 15 ft.
(22# 4.5 m)
(White / Black)
L = 15 ft.
(22# 4.5 m)
(Red / Black)
L = 30 ft.
(22# 9 m)
(Blue / Black)
L = 10 ft.
(22# 3 m)
(Green / Black)
SP15
SP15
SP13a-e
L = 10 ft.
(3 m)
(Black / RCA)
L = 30 ft.
(22# 9 m)
(Gray / Black)
SP16
L = 30 ft.
(22# 9 m)
(Brown / Black)
SP14
L = 30 ft.
(22# 9 m)
(Tan / Black)
Front side
Refer to "PACKING PROCEDURE-1"
Refer to "PACKING PROCEDURE-2"
Front side

HT-S780
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: [phone] Fax: [phone]
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone] http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone] http://www.eu.onkyo.com/
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]
ONKYO CORPORATION
http://www.onkyo.com/
HOMEPAGE
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: [phone] Fax: [phone]
http://www.ch.onkyo.com/

1/2 PAGE
HT-S780
PACKING PROCEDURE PARTS LIS
T
<Notes>
(B) : Black model
(S) : Silver model
<MDD> : USA model
<MDC> : Canadian model
<MPA> : Australian model
RECEIVER SECTION
(
HT-R530
)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PACKING A601 PAD (L & R / 1set) 1 29092256
PACKING A610 POLY BAG POLY BAG (850 x 650) 1 29100034-1A
PACKING A625 POLY BAG 250 x 300 x W300 1 29100218A
PACKING A626 POLY BAG 350 x 250 1 29100097-1A <MPA>
PACKING A631 TAPE NITTO NO.29 (Yellow) (1) 29110149
PACKING A656 LABEL (DES), 2sheets 1 29364127 (B), <MDD>
PACKING A656 LABEL (DES), 2sheets 1 29364128 (B), <MDC>
PACKING A656 LABEL (DES), 2sheets 1 29364130 (B), <MPA>
PACKING A656 LABEL (DES), 2sheets 1 29364129 (S), <MDC>
PACKING A656 LABEL (DES), 2sheets 1 29364131 (S), <MPA>
PACKING A690 SHEET (SETUP) 1 29095989
PACKING A801 INS MANUAL En (HT-R530) 1 29343939
PACKING A802 INS MANUAL U2FrEs (HT-R530) 1 29343940 <MDC>
PACKING A804 INS MANUAL U9 (RC-607M / 608M) 1 29344054A
PACKING A811 REMO CON RC-608M 1 24140608
PACKING A812 BATTERY R6/AA (UM-3) 2 3010054
PACKING A820 ANT COIL NMA-3057 1 232140
PACKING A821 FM ANT AS Type W 1 292191
PACKING A845 WRNTY CARD (ONKYO) 1 29365090C <MDD>
PACKING A845 WRNTY CARD (ONKYO) 1 29365090C <MDC>
PACKING A847 HANDBILL (DS-A1) 1 29380140 <MDD>
PACKING A847 HANDBILL (DS-A1) 1 29380140 <MDC>
SPEAKER SECTION
(
HTP-530
)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PACKING SP01 MIRAMAT SHEET L400 x W1950 x T0.5 (FOR SKW) 1 715-220004-00
PACKING SP02 PE BAG L1000 x W720 x T0.025 (FOR SKW) 1 700-820013-11
PACKING SP03 POLY BAG 300 x 100 (FOR AC CORD) 1 700-210001-11
PACKING SP04 TAPE (SEROHAN) NITTO NO.29 (Yellow) (1) 29110149
PACKING SP05 POLYFOAM TOP (TOP) 1 720-TS780T-00
PACKING SP06 POLYFOAM CENTER (CENTER) 1 720-TS780C-00
PACKING SP07 POLYFOAM BOTTOM (BOTTOM) 1 720-TS780B-00
PACKING SP08 MIRAMAT SHEET L310 x W1400 x T0.5 (FOR SKF) 2 715-220005-00
PACKING SP09 PE BAG L665 x W405 x T0.025 (FOR SKF) 2 700-820014-11
PACKING SP10 MIRAMAT SHEET L310 x W1400 x T0.5 (FOR SKC) 1 715-220005-00
PACKING SP11 PE BAG L665 x W405 x T0.025 (FOR SKC) 1 700-820014-11
PACKING SP12 PE BAG L440 x W320 x T0.025 (FOR SKM/SKB) 4 700-820012-11
PACKING SP13a CARTON BOX HT-S780 (B) / (HTP-530) 1 730-0S780B-10 (B), <MDD>
PACKING SP13b CARTON BOX HT-S780 (B) / (HTP-530) 1 730-1S780B-10 (B), <MDC>
PACKING SP13c CARTON BOX HT-S780 (B) / (HTP-530) 1 730S780AB-10 (B), <MPA>

2/2 PAGE
PACKING SP13d CARTON BOX HT-S780 (S) / (HTP-530) 1 730-0S780S-10 (S), <MDC>
PACKING SP13e CARTON BOX HT-S780 (S) / (HTP-530) 1 730-S780AS-10 (S), <MPA>
PACKING SP14 MIRAMAT SHEET L590 x W490 (Between Receiver and SP) 1 715-220007-00
PACKING SP15 PP TAPE W50 (1) 29110071 or
PACKING SP15 or PP TAPE W48 OPP TAPE (1) 29110148 or
PACKING SP15 or PP TAPE NITTO 3703 SUPER W50L100 (1) 29110176
PACKING SP16 CABLE SET SP CABLE / RCA CABLE / POLY BAG 1 319-HTS780-00
