Karbon 300 Product Manual

Revision History

Revision History
Date
First release of Karbon 300 manual
05/15/2019
Updated DIO Circuit Diagram
07/29/2019
Updated part number for 3-pin CAN bus terminal block connector
08/20/2019



1 - System Overview 4
1.1 - Accessories 4
1.2 - Product Specifications 5
1.3 - Exterior Features and Dimensions 7
1.3.1 - Karbon 300 Dimensions 7
1.3.2 - Front I/O 7
1.3.3 - Side I/O 7
1.4 - Motherboard Overview 8
1.4.1 - System Block Diagram 8
1.4.2 - Motherboard Features 9
2 - I/O Definitions 10
2.1 - Serial Ports 10
2.2 - DIO 11
2.2.1 - DIO Connection Diagram 11
2.3 - LEDs 12
2.4 - Automotive Ignition Power Sensing (IGN) 12
2.5 - CAN Bus 13
2.5.1 - CAN Bus Connection Diagram 13
2.6 - LAN 13
3 - Mounting Instructions 14
3.1 - Wall Mount 14
3.2 - DIN Rail Mounting 14
3.3 - Wall (Shock and Vibration) Mounting 15
3.4 - VESA Mounting 15
4 - Microcontroller 16
4.1 - Overview 16
5 - Power Management 16


5.1 - Wake-Up Events 16
5.2 - Protection Circuitry 17
1 - System Overview
1.1 - Accessories
●3-pin Power Terminal Block Connector (Dinkle PN: 2ESDVM-03P)
●3-pin CAN bus Terminal Block Connector (Dinkle PN: EC350V-03P)
●10-pin DIO Terminal Block Connector (Dinkle PN: EC350V-10P)
●M.2 and mPCIe expansion card screws

If you purchased additional items such as mounting brackets, power supplies or antennas,
they will be located in the system box or within the outer shipping carton.
All drivers and product guides can be found on the corresponding product page. For more
information on accessories and additional features, visit the Karbon 300 pages at:
US: https://www.onlogic.com/k300/
EU: https://www.onlogic.com/eu-en/k300/


1.2 - Product Specifications
Karbon 300 Series
K300-E3940-4-P
K300-E3930-4P-P
K300-E3950-8-P
K300-E3950-8P-P
Processor
Intel Atom x5-E3930 Dual-core
Intel Atom x7-E3950 Quad-core
Memory
4GB Onboard LPDDR4
8GB Onboard LPDDR4
Integrated Graphics
Intel HD Graphics 500
Intel HD Graphics 505
Bottom I/O
3x GbE LAN
1x GbE LAN
2x PoE LAN
3x GbE LAN
1x GbE LAN
2x PoE LAN
2x Full-size DisplayPort
Top I/O
2x Serial RS-232/422/485
3-pin Power input
4x Antenna holes
Front I/O
Power button
1x 3.5 mm Audio jack (mic-in, line-out)
8-bit Isolated DIO
4x USB 3.0 Type A
8x Status LEDs
3-pin CAN bus 2.0B
Nano-SIM slot (4FF)
Storage
M.2 2280 M-key (PCIe x2, SATA)
Expansion
Full-length mPCIe slot (PCIe, SATA)
M.2 2230 E-key (PCIe, USB)
Special Features
OnLogic Microcontroller (MCU)
Onboard TPM 2.0 (Nuvoton NPCT750)
Automotive Ignition Power Sensing
SuperCap backup for RTC battery
Operating Systems
Windows 10, Ubuntu 18.04
LAN Controllers
Intel Ethernet Controller 1210-IT


Voltage Input
9~36 VDC
Dimensions
56 x 154 x 119 mm
Mounting
Wall mount (edge and bottom)
DIN Rail mount (edge and bottom)
VESA mount (bottom)
Environment
Operating Temperature: -25°C ~ 70°C
Operating Humidity: 0 ~ 90%
Storage Temperature: -40°C ~ 85°C
Storage Humidity: 0 ~ 90%
Certifications
FCC 47 CFR Part 15
EN 55024
EN 55032
EN 62368-1
2011/65/EU (RoHS 2 Directive)
WEEE Directive (2012/19/EU)
IEC 60068-2-27
IEC 60068-2-64


1.3 - Exterior Features and Dimensions
1.3.1 - Karbon 300 Dimensions
1.3.2 - Front I/O
1.3.3 - Side I/O
 Right Left


1.4 - Motherboard Overview
1.4.1 - System Block Diagram
System
Memory
Manufacturer
Part Number
Quantity
Total Capacity
K300-E3930-4-P
LPDDR4
Samsung
K4F6E304HBMGCJ
2
4 GB
K300-E3930-4P-P
LPDDR4
Samsung
K4F6E304HBMGCJ
2
4 GB
K300-E3950-8-P
LPDDR4
Samsung
K4FBE3D4HMMGCJ
2
8 GB
K300-E3950-8P-P
LPDDR4
Samsung
K4FBE3D4HMMGCJ
2
8 GB


1.4.2 - Motherboard Features
Item
Function Description
A1
Power button
A2
3.5 mm Audio jack
A3
4 x USB 3.0 Type A ports
A4
3-pin CAN bus
A5
8-bit isolated DIO (10-pin)
A6
2 x Full-size DisplayPort
A7
1 x RJ45 GbE LAN port
2 x RJ45 GbE LAN ports with optional PoE (30W total)
A8
3-pin power input (9 ~ 36 VDC)
A9
2 x Serial RS-232/422/485 ports
A10
Full-size mPCIe
A11
M.2 2280 M-key for NVMe or SATA storage
A12
M.2 2230 E-key for Wi-Fi or WAN card


2 - I/O Definitions
2.1 - Serial Ports

The serial port mode and voltage between Off/5V/12V on Pin 9 on Karbon 300 can be selected in the
BIOS configuration. The serial ports support RS-232, RS-422, and RS-485 configurations. Refer to the
BIOS manual for configuration instructions.

Pin
RS-232
RS-422
RS-485
1
DCD
TX-
TX-/RX-
2
RX
TX+
TX+/RX+
3
TX
RX+
NC
4
DTR
RX-
NC
5
GND
NC
NC
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
RI/PWR
NC/PWR
NC/PWR

NC = Not Connected



2.2 - DIO
The Karbon 300 DIO terminals are optically isolated. This means that the terminal is separated from
other motherboard features for protection. In addition, the DIO requires external power from a
9-36VDC source through Pin 1 to function.




Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
GND
In 4
In 3
In 2
In 1
Out 4
Out 3
Out 2
Out 1
Power

2.2.1 - DIO Connection Diagram


2.3 - LEDs
LED
On
Off
Blink
Pulse
HDD
-
-
Internal
storage drive
activity
-
Power
Device is on
Device is off
Device is
asleep
-
Automotive
Ignition
Ignition input to
device is on
Ignition input to
device is off
-
-
Watchdog
Internal MCU is
not functioning
normally
Internal MCU is
not functioning
normally
Firmware
bootloader
is active
Internal MCU is
functioning
normally
LEDs 1-4
Currently
selected
user mode
Currently selected
user mode
-
-
2.4 - Automotive Ignition Power Sensing (IGN)
The K300 3-pin power input terminal offers automotive ignition sensing. The ignition sensing timing
for power on and off delays can be modified through OnLogic’s microcontroller (MCU) using serial
commands. These commands allow setting the delay on startup after ignition is detected, the delay
until soft and hard shutdown when ignition is lost, and enabling/disabling ignition sensing. For more
information on ignition power sensing, and instructions on using these serial commands from
Windows or Linux, visit our Karbon series technical support site. 

Pin
Definition
1
GND
2
Ignition
3
9~36 VDC Input


2.5 - CAN Bus
See Section 4 for information on how to drive the CAN bus.

Pin
Definition
1
CAN H
2
CAN L
3
GND
2.5.1 - CAN Bus Connection Diagram
2.6 - LAN
The dual LAN ports on Karbon 300 are PoE enabled for models K300-E3930-4P-P and
K300-E3950-8P-P. When PoE is disabled the LAN ports function as standard GbE ports. The single
LAN ports on all Karbon 300 models are standard GbE ports.
LED
Color
State
Condition
Link
-
Off
LAN link is not
established
Green
On
LAN link is
established
Blinking
LAN activity
occurring
Speed
-
Off
10 Mb/s data rate
Green
On
100 Mb/s data
rate
Yellow
On
1000 Mb/s data
rate


3 - Mounting Instructions
3.1 - Wall Mount

Step 1: Mark and prep holes in surface for mounting
Step 2: Attach wall mount brackets to chassis
Step 3: Fasten system to surface

3.2 - DIN Rail Mounting
Step 1: Attach wall mounting brackets to the chassis
Step 2: Attach DIN Rail mounting brackets to the chassis
Step 3: Clip system to the DIN Rail
 DIN Rail Edge Mounting    DIN Rail Back Mounting


3.3 - Wall (Shock and Vibration) Mounting
Step 1: Attach wall mounting brackets to the chassis
Step 2: Mark and prep holes in surface for mounting
Step 3: Fasten system to surface
3.4 - VESA Mounting
Step 1: Install four VESA screws into the display/surface
Step 2: Attach VESA bracket to the chassis
Step 3: Hang combined system and bracket to the display/surface


4 - Microcontroller
4.1 - Overview
The microcontroller on Karbon 300 controls several systems, including:
●Automotive ignition power sensing
●CAN bus
●DIO
●Status LEDs
●Power management and wake-up
●DisplayPort CEC and persistent EDID
A segment is exposed for user control via two serial ports. By reading and writing to these serial
ports, the user can send and receive CAN messages, read/set the DIO state, and select from a number
of configuration options. One port is dedicated to K300’s CAN bus, while another doubles as a serial
terminal and the DIO interface. Any configuration settings may be saved to non-volatile memory. This
means that upon a long power-off, the MCU settings will be retained.
To learn more about how to use the Karbon series MCU and Pykarbon interface tools, visit our Karbon
Series technical support site.
5 - Power Management
5.1 - Wake-Up Events
Karbon 300 supports multiple power states. The wake-up events can be configured in the MCU and
BIOS. This section describes the power management functions you can perform and gives
information on protection circuitry for power adapters.

Wake-Up Event
From ACPI State
Comments
Power Button
VR-Disabled, S5, S4, S3
Ignition
VR-Disabled, S5, S4, S3
Must be enabled in MCU.
Digital Input
S5, S4, S3
Must be enabled in MCU.
Requires external reference power source.
LAN
S5, S4, S3
Must be enabled per port and generally in BIOS.
USB
S3
RTC Alarm
S5
Wake from S5 must be enabled in BIOS.


5.2 - Protection Circuitry
Parameter
Value
Nominal operating voltage (Rated DC value of input)
9~36VDC
Undervoltage protection trip DC level (system turns off)
8.1V
Overvoltage protection trip DC level (system turns off)
42.5V
Maximum safe DC voltage (system not damaged)
50V
Minimum safe reverse voltage (system not damaged)
-40V
Ignition pin safe working voltage range (system not damaged)
-20~50V
These DC levels specified are the absolute max values for the pins for function and safety of the
system. The protection circuitry allows for brief transient voltages above these levels without the
system turning off (transients up to 50V for <30 ms).
A TVS protection on the input allows protection for:
●5000W peak pulse power capability at 10/1000µs waveform, repetition rate (duty cycles):
.01%
●IEC-61000-4-2 ESD 30kV(Air), 30kV (Contact)
●EFT protection in accordance with IEC 61000-4-4


