Opale-Parmo Trike XL User manual

Opale-Paramodels.com
Opale Aero System SARL - 23 rue de la Motte
62250 MARQUISE - France
[e-mail] [phone]
2016
v2.0 User’s manual
Trike XL
Thanks for reading this manual before rst use.

Opale-Paramodels.com
Opale Aero System SARL - 23 rue de la Motte
62250 MARQUISE - France
[e-mail] [phone]
Trike XL Trike XL
Thanks for having chosen an Opale-Parmodels product. We truly believe this remote-controlled paraglider is
going to give you hours of enjoyment and will enable you to go through new outstanding piloting experiences.
This user’s guide content includes all the information you need to get your wing in ight and to ensure you will
take good care of it. A good knowledge of your equipment will allow you to safely obtain most of its perfor-
mances for your greatest pleasure! Thanks for giving this manual to the new owner in case you decided to sell
your radio-controlled paraglider.
Best regards,
The Opale-Paramodels Team
Safety Information
You should be properly insured according to the country regulation you are using our equipment
in.
You hereby accept the inherent risk of ying radio-controlled models.
Using our equipment in a bad way may increase risks. Neither Opale-Paramodels nor any other
seller
will be liable for any damage caused by any accident whatever the circumstances are. The way our
equipment is used is incumbent upon the nal user, including towards the law.
Contents
Trike Composition 3
Specications 3
Assembly 4
Servos dans Brakes settings 6
Mounting of the pilot Tom (optional) 11
FAQ Questions/Answers 14
Warranty
The Trike XL is guaranteed against any manufacturing defect.
If, while using, the pilot cut or damage a bridle, tear any part of the wing,repair and replacement of dam-
aged parts are not taken in account by the warranty and the user will be charged for it.
2

Opale-Paramodels.com
Opale Aero System SARL - 23 rue de la Motte
62250 MARQUISE - France
[e-mail] [phone]
Trike XL
Backpack composition
Specications
Dimensions: 77x60x65cm
Minimum mass in order of ight : 12kg
Maximum mass in order of ight : 22kg
Matérials: Stelle/ Glassber with Epoxy resin.
Painting: Chrome / Epoxy
Wheels: Wheel rim with tire and inner tube, rotatably mounted on the wheel
Servomotors : 24kg.cm under 6v
Motorization: Recommended power from 2000 to 3000W
Propeller : 19 inches maximum
3

Opale-Paramodels.com
Opale Aero System SARL - 23 rue de la Motte
62250 MARQUISE - France
[e-mail] [phone]
Trike XL Trike XL
Assembly
Battery holder installation on the central girder. Use
4xCHC M4-50 + 4xM4 nut-lockings.
By the mean of a cutter, remove the painting that is in
the surface of the trike.
Position the front fork. This one must accomodate
without any diculty. If not, remove by mean of a
cutter the painting that is at the other extremity of
the passage of the axis.
Then, use a H M10-50 screw with ring and nut-lock-
ing.
Then mount the two rear wheels by mean of H M12-
60 screws.
4

Opale-Paramodels.com
Opale Aero System SARL - 23 rue de la Motte
62250 MARQUISE - France
[e-mail] [phone]
Trike XL
Mount the front wheel with the help of the axis and
the spacers included.
Fix the 2 servomotors on the platinum by mean of
8xCHC M3-12 with nut-lockings and silent-blocks.
Install the top part with the help of 2x Hexagonal
Head screws M4-12 and nut-lockings. Please do not
tighten the set.
Slide the axis in the top part.
