Opel MOVANO User manual

OPEL MOVANO
Owner's Manual

Introduction .................................... 2
In brief ............................................ 6
Keys, doors and windows ............ 19
Seats, restraints ........................... 36
Storage ........................................ 58
Instruments and controls ............. 66
Lighting ........................................ 85
Climate control ............................. 92
Driving and operating ................. 103
Vehicle care ............................... 128
Service and maintenance .......... 162
Technical data ........................... 165
Customer information ................ 184
Index .......................................... 186
Contents

2Introduction
Introduction

Introduction 3
Vehicle specific data
Please enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and
maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology,
safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this
Owner's Manual.
When this Owner's Manual refers to a
workshop visit, we recommend your
Opel Service Partner.
All Opel Service Partners provide
first-class service at reasonable
prices. Experienced mechanics
trained by Opel work according to
specific Opel instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual
■ This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
■ The "In brief" section will give you
an initial overview.
■ The table of contents at the
beginning of this manual and within
each section shows where the
information is located.
■ The index will enable you to search
for specific information.
■ This Owner's Manual depicts left-
hand drive vehicles. Operation is
similar for right-hand drive vehicles.
■ The Owner's Manual uses the
factory engine designations. The
corresponding sales designations
can be found in the section
"Technical data".
■ Directional data, e.g. left or right, or
front or back, always relate to the
direction of travel.
■ The vehicle display screens may
not support your specific language.
■ Display messages and interior
labelling are written in bold letters.
Danger, Warnings and
Cautions
9Danger
Text marked 9 Danger provides
information on risk of fatal injury.
Disregarding this information may
endanger life.

4Introduction
9Warning
Text marked 9 Warning provides
information on risk of accident or
injury. Disregarding this
information may lead to injury.
Caution
Text marked Caution provides
information on possible damage to
the vehicle. Disregarding this
information may lead to vehicle
damage.
Symbols
Page references are indicated with 3.
3 means "see page".
We wish you many hours of
pleasurable driving.
Adam Opel AG

Introduction 5

6In brief
In brief
Initial drive information
Vehicle unlocking
Unlocking with key
Turn the key in the driver's door lock.
Open the doors by pulling the
handles.
Unlocking with remote control
Press button c to unlock the front
doors. Press again to unlock entire
vehicle.
Open the doors by pulling the
handles.
Press button G; only the load
compartment and sliding side doors
are unlocked.
Radio remote control 3 19, Central
locking system 3 20, Anti-theft
alarm system 3 28.

In brief 7
Seat adjustment
Seat positioning
Pull handle, slide seat, release
handle.
Seat position 3 37, Seat adjustment
3 38.
9Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.
Seat backrests
Pull lever, adjust inclination and
release lever. Allow the seat to
engage audibly.
Seat position 3 37, Seat adjustment
3 38.
Seat height
Lever motion
up = seat higher
down = seat lower
Seat position 3 37, Seat adjustment
3 38.

8In brief
Head restraint adjustment
Press release catch, adjust height,
engage.
Head restraints 3 36.
Seat belt
Pull out the seat belt and engage in
belt buckle. The seat belt must not be
twisted and must fit close against the
body. The backrest must not be tilted
back too far (maximum approx. 25 °).
To release belt, press red button on
belt buckle.
Seat position 3 37, Seat belts
3 44, Airbag system 3 46.
Mirror adjustment
Interior mirror
To reduce dazzle, adjust the lever on
the underside of the mirror housing.
Interior mirror 3 32.

In brief 9
Exterior mirrors
Manual adjustment
Swivel mirror in required direction.
Exterior mirrors 3 30.
Electric adjustment
Select the relevant exterior mirror and
adjust it.
Convex exterior mirrors 3 30,
Electric adjustment 3 30, Folding
exterior mirrors 3 31, Heated
exterior mirrors 3 31.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is
fully locked.
Do not adjust steering wheel unless
vehicle is stationary and steering
wheel lock has been released.
Airbag system 3 46, Ignition
positions 3 104.

10 In brief
Instrument panel overview

In brief 11
1Fixed air vents .................... 101
2Headlight range
adjustment ........................... 86
Ultrasonic parking assist ..... 121
Traction control system ...... 116
Electronic stability program 117
3Side air vents ..................... 101
4Light switch .......................... 85
Turn and lane-change
signals .................................. 87
High beam and low beam,
headlight flash ...................... 86
Sidelights .............................. 85
Automatic light control .......... 85
Exit lighting ........................... 90
Front fog lights ..................... 87
Rear fog light ........................ 88
5Instruments .......................... 71
Transmission display ............ 73
Driver Information Centre ...... 80
6Horn ..................................... 67
Driver airbag ........................ 47
7Remote control on
steering wheel ....................... 66
Cruise control ..................... 118
8Windscreen wiper,
windscreen washer system .. 67
Trip computer ........................ 82
9Coin tray ............................... 58
10 Power outlet ......................... 69
11 Centre air vents .................. 101
12 Front passenger airbag ......... 47
Storage compartment .......... 58
13 Glovebox .............................. 59
14 Cupholders ........................... 59
15 Climate control system ......... 92
16 Cigarette lighter .................... 70
Power outlet ......................... 69
17 Gear lever, Manual
transmission ........................ 110
Manual transmission
automated ........................... 111
18 Cruise control and speed
limiter ................................. 118
Manual transmission
automated,
Winter and Laden modes .... 113
Idle speed control ............... 104
Stop-start system ................ 105
19 Ignition switch with
steering wheel lock ............ 104
20 Steering column controls ..... 67
21 Steering wheel adjustment ..66
22 Bonnet release lever .......... 129
23 Auxiliary heater ..................... 97
24 Storage compartment .......... 58
Fuse box ............................ 145

12 In brief

In brief 13
Exterior lighting
Turn light switch:
7= Off
0= Sidelights
9 P= Headlights
AUTO =Automatic light control:
Headlights are switched
on and off automatically.
>= Front fog lights
r= Rear fog lights
Lighting 3 85, Headlight warning
device 3 82.
Front and rear fog lights
Turn light switch:
>= Front fog lights
r= Rear fog lights
Headlight flash, high beam and
low beam
Pull lever.
High beam 3 86, Headlight flash
3 86.

14 In brief
Turn and lane-change signals
lever up = right turn signal
lever down = left turn signal
Turn and lane-change signals
3 87.
Hazard warning flashers
Operated with the ¨ button.
Hazard warning flashers 3 87.
Horn
Press j.

In brief 15
Washer and wiper systems
Windscreen wiper
0=off
P= timed interval wiping or
automatic wiping with rain
sensor
1= slow
2= fast
Windscreen wiper, automatic wiping
with rain sensor 3 67, Wiper blade
replacement 3 135.
Windscreen washer
Pull lever.
short
pull
= wiper swipes once and
washer fluid is sprayed
onto the windscreen
long
pull
= wiper swipes for a few
strokes and washer fluid is
sprayed onto the
windscreen
Windscreen washer 3 67, Wiper
blade replacement 3 135, Washer
fluid 3 132.
Climate control
Heated rear window, heated
exterior mirrors
Heating is operated by pressing the
Ü button.
Heated exterior mirrors 3 31,
Heated rear window 3 34.

16 In brief
Demisting and defrosting the
windows
■Air distribution to V.
■ Set temperature control to warmest
level.
■ Set fan speed to highest level.
■ Cooling AC on.
■Press button Ü.
Climate control system 3 92.
Vehicles with Electronic climate
control, press button V.
Temperature and air distribution are
set automatically and the fan runs at
a high speed.
Electronic climate control system
3 94. Transmission
Manual transmission
Reverse: with the vehicle stationary,
depress clutch pedal and then pull up
the collar on the selector lever and
engage the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then repeat
gear selection.
Manual transmission 3 110.

In brief 17
Manual transmission automated
N=neutral
o= drive
+= higher gear
-= lower gear
A/M =switch between automatic
and manual mode
R= reverse gear
Manual transmission automated
3 111.
Starting off
Check before starting off
■Tyre pressure and condition 3 147,
3 183.
■ Engine oil level and fluid levels
3 130.
■ All windows, mirrors, exterior
lighting and number plates are free
from dirt, snow and ice and are
operational.
■ Proper position of mirrors, seats
and seat belts 3 30, 3 37,
3 45.
■ Brake function at low speed,
particularly if the brakes are wet.
Starting the engine
■ Turn key to position A
■ move the steering wheel slightly to
release the steering wheel lock
■ operate clutch and brake
■ do not operate accelerator pedal
■ turn the key to position M for
preheating and wait until control
indicator ! extinguishes in the
Driver Information Centre
■ turn key to position D and release
Starting the engine 3 104.

18 In brief
Stop-start system
If the vehicle is at low speed or in
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
■ Depress the clutch pedal
■ shift the selector lever to N
■ release the clutch pedal
An Autostop is indicated when Ï
illuminates green in the instrument
cluster.
To restart the engine, depress the
clutch pedal again.
Stop-start system 3 105.
Parking
■Always apply parking brake without
pressing release button. Apply as
firmly as possible on a downhill
slope or uphill slope. Depress foot
brake at the same time to reduce
operating force.
■ Switch off the engine. Turn the
ignition key to position St and
remove it. Turn the steering wheel
until the steering wheel lock is felt
to engage.
■ If the vehicle is on a level surface or
uphill slope, engage first gear
before switching off the ignition. On
an uphill slope, turn the front
wheels away from the kerb.
If the vehicle is on a downhill slope,
engage reverse gear before
switching off the ignition. Turn the
front wheels towards the kerb.
■ Lock the vehicle and activate the
anti-theft alarm system 3 28 with
button e on the remote control.
■ Do not park the vehicle on an easily
ignitable surface. The high
temperature of the exhaust system
could ignite the surface.
■ Close the windows.
■ The engine cooling fans may run
after the engine has been switched
off 3 129.
■ After running at high engine speeds
or with high engine loads, operate
the engine briefly at a low load or
run in neutral for approx.
30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 19, Laying the vehicle
up for a long period of time 3 128.
