Open Grow GroLab PowerBot User manual

INSTALLATION
MANUAL
www.opengrow.pt
PowerBot

1
45
10

6 7
12
11

2 3
8 9
13

14
16
15

230VAC Power outlet
Internal fan inlet
RF antenna threaded port
Module reset buon
Manual acvaon push buons
Environmental sensor connecon outlet
Type-B USB outlet (Firmware updates)
Fuse threaded port
General module switch
Status signal display
Universal socket outlet
Perforaons for vercal mounng
RF communicaons antenna
1
2
3
4
5
6
7
8
9
10
11
12
13

14
15
16
INSTALLATION
Screw the communicaon antenna (13) into the
module port (3). For correct communicaon, turn
the antenna in order to posion it vercally
according to the direcon of the module.
Peripherals connecon
1
B-Type USB. Only Firmware update
Temperature/Moisture sensor
230VAC - 10A Power cord

Place the module on a firm surface, far from
flood-prone areas. It is recommended that the
module be mounted on a wall with the fixing
holes on the upper part.
Once the module has been mounted, connect
the power cable (16) to the module’s power
outlet (1) and the other end to the 230VAC.
outlet.

Connect the temperature and moisture sensor
(15) to the module’s outlet (6).
Place the sensor at the height of the plants
where you could monitor the environmental
state of the culvaon area correctly.
Never positon the sensor too close to a light
source or to moist soil as to generate false
environmental data.

Connect your peripherals to the module’s power
outlets (11). To correctly idenfy the posion in
which your peripherals are connected to the
module, it is recommended that they be connec-
ted in order, respecng the figure for each outlet.
Power outlet dedicated to the lighng
devices.
Power outlet dedicated to fan or
extracon systems.
Power outlet dedicated to the irrigaon
and water tank deposit maintenance
systems.
Outlet dedicated to any other type of
peripherals.
If you connect mulple devices to one outlet,
remember not to surpass the power limits,
which is for each outlet and in total per module:
2300W (230vAC - EU) / 1200W (120vAC - USA)

It includes four push buons (5), which will
enable acvang and deacvang manually each
of the outlets.
The figures (10) will light up independently,
acng as controls and indicang at each moment
which outlets are currently acve.

MAINTENANCE
Fuse Replacement
Remove the module’s power cord (16). Never
handle the fuse holder while the module is
connected to the power.
Turn the cover cap of the fuse holder
counter-clockwise with the help of a turnscrew
and remove the damaged fuse.
Replace the fuse with another with similar
features:
10A 250VAC 125VDC 3AB (Europe)
10A 125VAC (USA)
2

COMUNICACIONES
Connecon to GroNode
First, install GroNode and the control soware
successfully. Follow the procedures indicated in
the GroNode user manual.
Once GroNode has been connected to the
soware, access GroLab through the menu.
If the module has been successfully located
automacally by GroNode, it will appear on the
top menu.
If you have more modules of the same type, a list
of them will appear on the soware’s right side
menu. Add up to a total of four modules of each
type for each GroNode.
3

Problems or losses in
communicaon
GroNode was designed to communicate with the
other modules through radio frequency signals.
The range of acon is 25 metres indoors and 100
metres outdoors depending on space condions.
If the control soware does not find your module
or frequently loses communicaon it is possible
that you have exceeded the distance between
your modules and GroNode.
Some load-bearing walls and electronic devices
may interfere with the signal.
Check the configuraon panel to ensure the
modules are connected. A wireless signal icon
will indicate if your module has a signal.

If you detect that the signal has been interrup-
ted, with the module on, press the reset buon
(4) and wait a few seconds. Check the soware to
see if the communicaon has been re-establi-
shed.
If the problem persists, perform a test run by
placing the module next to GroNode and check
the status of communicaon in the soware. If
communicaon has been successfully re-establi-
shed, repeat this operaon at different distances
unl you detect the maximum communicaon
distance.
If GroNode does not detect your module even
when next to each other, contact our technical
support.
www.opengrow.pt
support@opengrow.pt

ACTUALIZACIONES
Firmware Updates
Keep in mind that some soware updates will
require updang your devices’ Firmware.
All updates will provide crucial improvements,
ensuring your system’s performance.
Connect the type-B USB cable (14) to your
device’s USB outlet (7) and follow the procedures
indicated in the firmware update manual availa-
ble through direct access to Guides on your
desktop.
4

ENTRIES


Installaon manuals available from the USB in
English, Spanish, French, German, Polish and
Russian.
Manuales de instalación disponibles desde el
USB en inglés, español, francés, alemán, polaco
y ruso.
Manuels d’installaon disponibles à parr de
l'USB en anglais, espagnol, français, allemand,
polonais et russe.
Installaonsanleitungen zur Verfügung vom
USB in Englisch, Spanisch, Französisch, Deutsch,
Polnisch und Russisch.
Instrukcje dostępne z USB w języku angielskim,
hiszpańskim, francuskim, niemieckim, polskim i
rosyjskim instalacji.
Инструкции по установке, доступные с USB
на английском, испанском, французском,
немецком, польском и русском языках.

Open Grow LDA guarantees the purchaser that the product is free from material
and/or manufacturing defects. Open Grow LDA’s liability is limited to the repair
or replacement of any defecve parts. Do not ship directly to Open Grow LDA
without first consulng with us to verify the procedure that should be followed.
Contact our technical services at support@opengrow.pt
All Open Grow LDA products have a 2-year guarantee except for consumables
(sensors and/or actuators of any type) and under normal use.
Aer the first 6 months the customer should prove that the breakdown is a
result of a manufacturing defect.
The loss of the “GroNode” module’s internal baery life as a result of its ageing
is not considered a manufacturing defect. Follow the replacement procedure
indicated in the user manual available on your applicaon or request more
informaon from the technical services.
A guarantee claim is non-transferable and only the original purchaser can
submit one. To enforce the guarantee the customer must always provide the
purchase invoice.
GUARANTEE DISCLAIMER:
Applicaon of the guarantee is excluded should the breakdown of the defecve
part or parts be a result of the product’s inadequate and/or negligent use.
Understood as inadequate and/or negligent use is any use other than the one
for which the product is meant and/or that is recommended in the instrucons
manual, not execung the maintenance operaons recommended in the
instrucons manual, carrying out operaons that are different from those
menoned and that compromise the quality of the product, modificaons that
are not performed by authorized repairers and/or with non-original or
non-approved parts.
Open Grow LDA reserves the right to update and/or modify the
content of its products at any me without prior warning. Check
out our condions at www.opengrow.pt
