Open House ChannelPlus H511HHR User manual

The H511 channel injector creates a new channel to add to existing television channels.
The H511 is designed to work with an existing installation without the need to add additional hardware
such as a coax panel or additional coax wiring to the video source. The
H511 creates this new channel from a video signal it receives via a
single CAT-5 cable connected to one of its companion
products such as the H721 camera or H110 wall plate.
Two models are available:
The has the isolation required by the FCC
for a system with an antenna.
The has a 5-42MHz reverse channel to
support bidirectional cable systems (cable modems,
pay-per-view and interactive cable).
H511HHR
H511BID
ChannelPlus Channel Injector
1
2
3
1) Hook from the top
2) Swing into place
3) Push button to lock
OpenHouse modules attach from the top
tm
ChannelPlusmodel H616
TelephoneMaster Hub (4 linesx6phones)
TelephoneMaster Hub (4 lines x 6 phones)
Telephones
From
Telco
From
Telco
RJ31X
Out
Expansion
Ports
Expansion
Ports
R
T
R
T
4
R
T
R
T
3
R
T
R
T
2
R
T
R
T
1
350-079 power
supply (included)
Typical Installation
Things To Watch For:
Herringbone interference on modulator channel (diagonal lines):
Herringbone interference on many channels, including modulated channel (disappears when
you remove the CATV/antenna feed)
You may have chosen a
channel number that is not completely vacant. Distant UHF stations may not be watchable, but will
cause interference if you try to create a new channel at the same frequency. Also, cable companies
often have extra signals where there should be none. Try moving the modulator channel to another
number. You may have to add a low pass filter to remove the cable company noise. If the filter does
not work, try adding a DC-block to remove common mode interference.
: The RF amplifier can be overloaded by abnormally strong
signals. Often, you can cure the problem with a simple attenuator. Use a variable attenuator and try to
find a signal level where the interference just disappears. Sometimes, the problem is one station is far
stronger than the rest. In this case, attenuating all of the signals with a simple attenuator may cause
the desired stations to be weak (snowy). You must reduce the strength of the only offending station. A
common FM trap will help if the problem is a nearby FM tower. If the problem is a nearby TV station,
often the station management can provide suitable filters.
No picture
Weak ChannelPlus UHF channel
Audio volume is low
No color on ChannelPlus channels
… Check that the TV and the modulator are tuned to the same channel. For example, if
the modulator is broadcasting on UHF channel 16, make sure the TV is on UHF 16 rather than CATV
16. UHF 16 and CATV 16 are at different frequencies. Also ... Make sure the H511 and camera or
wall plate are wired properly - CAT-5 colors must match connector colors.
… If the TV has a separate UHF input, be sure that it is connected.
… The left and right audio inputs are combined for monaural. For proper audio
level, both right and left inputs must be used. If you have a mono source, connect it to both right and
left inputs using an RCA ‘Y’ connector.
… You may have chosen the incorrect cable standard. Not all
televisions can accommodate the 1.25MHz frequency difference between the H and I cable
standards. See the section on programming.
RF output
Power supply
performance
Video
65-125
(excluding 95-99)
channel ranges
model number
signal/noise 55 dB
-60 dBC
+12 dBmV nominal
105-125 VAC
-45dBC @ 12MHz
600mA
15 VDC
differential phase <4º
differential gain 4%
350-079
14-64
output level
input power
IM distortion
alternate channel
output voltage
output current
Programming the H511
DECLARATION OF CONFORMITY
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)
THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
FCC classifies this product under part 15 of its rules as a “television interface device”.
Systems designed using television interface devices have the following legal requirements:
1) The modulated channel signal strength may not exceed 15.56dBmV at any television.
2) If an antenna is used in the system, the modulated channel signal strength may not exceed -51dBmV at the
antenna input port.
Any system you design must comply with these regulations. As the installer, you are responsible. The H511 has
the necessary characteristics to comply with the above requirements as designed without additional accessories.
The H511HHR is suitable for use with an antenna or with CATV systems.
The H511BID is suitable for use with CATV systems only.
Installation requirements:
For the Installer:
Federal Regulation 47CFR15.115(b)(1)(i).
Federal Regulation 47CFR15.115(c)(4).
ChannelPlusmodel H511HHR
Channel Injector(single channel via CAT-5)
Channel Injector
CAT-5 video
Output
CATV
program
OUT
IN
532-230 5MHz to 1000MHz
OUT IN OUT IN OUT IN OUT IN
SPLITTER
COMBINER
R
TelephonesFrom
Telco
ChannelPlus model H801ChannelPlus model H801
Combo Hub (2 lines x 6 phones, 1input x 4 televisions)
R
T
2
R
T
1
To 4 TV
wall plates
From telephone
company To wall plates
Existing distribution
(H801 typical)
Connect H511 output to
distribution panel input.
(Coax jumper included)
Output
Program
CATV
/Ant Power
Channel Injector
CAT-5 video
To camera or wallplate
(H721 typical)
Remove antenna or incoming
cable from existing distribution
and connect to H511 input.
H511HHR
Connect to a camera or wall plate using only method:
1 Terminate cable with a CAT-5 jack and connect to the H511 using
supplied RJ45 jumper. (Also see example H628 manual).
2 Wire camera or wall plate directly to the 8 position terminal block
matching the CAT-5 wire colors to the colors on the terminal block.
Insert wires and tighten screws
one
.
1
2
2dB 2dBCATV/Ant input to output
RF gain
na -4dB
Output to CATV/Ant input
5-42MHz reverse channel
5-806MHz 54-806MHzFoward
Bandwidth
na 5-42MHzReverse
Max CATV/Ant
input (64 channels) 20dBmV
Press button
time
program
1
Press button
more times
program
2
Press button
more times
program
10
Wait for LED
(ready for next number.)
power
(press 10 to
enter a ‘zero’)
Wait for LED
(ready for next number.)
power
Enter the new
channel using
the
push button.
Program
Power the H511
last - make all
cable and CAT-5
connections first.
Program the new channel using the push button to enter channel digits into the
H511. This new channel should be an unused channel. It should have no interference or
trace of a picture - just “snow”. There must also be one unused channel both above and
below the selected channel to avoid interference. Below is a simple step by step example
of how to program a channel - cable channel :
Program
120
Cable HRC and IRC considerations:
Most cable services use standard or IRC frequency assignments. This is the default for the
H511. However, if the cable services use HRC or the TV appears to search for the “created
channel”, program the channel injector for HRC.
Entries 98 and 99 are for setting HRC or IRC only. They do not change the channel number.
For HRC enter a 98. Reset to IRC by entering 99.
CAT-5 Cable Length Limitations:
The length of the CAT-5 cable that runs between the H511 and the camera or wall plate is
limited. See the individual camera or wall plate manuals for these CAT-5 cable run limitations.
Specifications: typical @ 25 C ± 5 C
OO H511HHR H511BID
The color bar has two rows:
-Use top row for wiring with CAT-5
-Use bottom row for quad wire
The H511 was designed to work with CAT-5 wiring. Although the system will function with quad
wire, CAT-5 delivers the highest quality picture. CAT-5 allows the use of an automatic line length
sensor and picture compensator. Quad wire does not take advantage of this enhancement.
*
*
LED comes back on when
done. If an incorrect channel
is entered, LED will flash
quickly and return to the
previous setting.
UHF
CATV

multiplex
technology, inc.
®
***
3001 Enterprise Street, Brea, CA 92821-6213, U.S.A.
714-996-4100 800-999-5225 FAX [phone] www.channelplus.com
TM
ChannelPlus®
Channel Injector
Model H511HHR & H511BID
ChannelPlus Enclosures, Modules,
Accessories & Wall Plates
ChannelPlus model H628
Data Hub (8 cables, TIA-568A) Category 5 Compliant
OUT
IN
532-230 5MHz to 1000MHz
OUT IN OUT IN OUT IN OUT IN
SPLITTER
COMBINER
R
TelephonesFrom
Telco
ChannelPlus model H801
Combo Hub (2 lines x 6 phones, 1input x 4 televisions)
R
T
2
R
T
1
ChannelPlus model H616
Telephone Master Hub (4 lines x 6 phones)
Telephones
From
Telco
RJ31X
Out
Expansion
Ports
R
T
4
R
T
3
R
T
2
R
T
1
Starter systems
RF splitters and telephone punch
downs. When it is time to upgrade,
just snap this module out and
replace with one of more of the
more sophisticated units.
Data hubs
Termination blocks for the CAT-5 cables,
Ethernet hubs. Bring the Internet to any
room in the home. Or create a home data
network.
Telephone hubs
Connections for 1-4 phone lines to
every room. Starter hub adds RJ-
31X jack for security system dialer.
Coax panels
Distribute antenna or cable TV to every
room of the house. Some models include
bi-directional amplifiers for interactive cable
systems. Some models include
IR engines.
modulator
inputs and
AV modulators
(for service center)
Create a new TV channel for a front
door camera. Some models feature
Cat-5 input connections.
Warranty
Multiplex Technology, Inc. warrants this product to be free from defects in materials and workmanship
for a period of one year from the date of purchase or MTI will repair, or at its option, replace the
defective product. To obtain warranty service, call MTI for a return material authorization (RMA)
number and return the product prepaid to Multiplex Technology, Inc., 3001 Enterprise Street, Brea, CA
92821, Attention: Customer Service. Please put the RMA number on the outside of the carton.
Any implied warranty arising from the sale of the product including implied warranties of
merchantability and fitness for purpose are limited to the warranty stated above. MTI shall not be
responsible for losses or damages or expenses, whether direct, consequential or incidental arising
from the use of or the inability to use this product. Some states do not allow limitations on how long the
implied warranty lasts or the exclusion or limitation or incidental or consequential damages, so the
above limitations and exclusions may not apply to you. This warranty gives you specific legal rights,
and you may have other rights which may vary from state to state.
TM
Compatible
Service center
enclosures
A full line of OpenHouse compatible
enclosures, from simple, inexpensive
mounting plates to high capacity in-wall
cabinets. AC outlets can be mounted
inside the cabinets using a UL listed
accessory.
AV modulators
(for media center)
Create new TV channels for DVD, VCR,
or a satellite receiver. These modulators
sit in the media center. Some offer true
MTS stereo.
®
model 5445 quad digital modulator
pll frequency control
D
C
BA
program
select
Wall plates
Wall plate systems for all rooms. The typical room gets TV
and telephone. The Home office wall plate adds data ports.
The media center wall plate adds satellite feeds.
IR Accessories
Control video devices from any room.
New ChannelPlus products are added all the time.
Visit our website to learn more: www.channelplus.com
Wiring a house for OpenHouse
Typical Room Media Center Home Office
Good
Better
Best
1 Cat-5
1 RG-6
1 Cat-5
3 RG-6
1 Cat-5
2 RG-6
2 Cat-5
1 RG-6
2 Cat-5
2 RG-6
2 Cat-5
3 RG-6
3 Cat-5
3 RG-6
2 Cat-5
2 RG-6
3 Cat-5
3 RG-6
Good ...
Typical room - phone, TV
Media center - phone, satellite receiver, AV modulators
Home office - phone, TV,
Better …
Typical room - phone, TV, ethernet
Media center - phone, TV, satellite receiver, AV modulators
Home office -
Best …
cable modem
ethernet,
phone, TV, ethernet, cable modem
Typical room - phone, TV, ethernet, satellite receiver
Media center - phone, TV, ethernet, satellite receiver, AV modulators, hi-speed data
Home office - phone, TV, ethernet, satellite receiver, cable modem, hi-speed data
The cables in an OpenHouse run from the various rooms of the house
directly to the service center location.(This is known as ‘home run’
wiring.) Two types of wire are used for communication and
entertainment: Cat-5, 4-UTP (4 nshielded wisted airs) wire handles
data or 1 to 4 telephone lines. RG-6 coax handles television (antenna or
cable), satellite dish, cable modem, or AV modulator signals. (An AV
modulator creates new TV channels for front door camera, DVD player, a
VCR or a satellite receiver.)
We recommend the following pre-wire schemes . Run these wires from
the service center to the rooms indicated.
UTP
Multiplex Technology, Inc., Brea, CA 92821Multiplex Technology, Inc., Brea, CA 92821
600-170 Rev. C600-170 Rev. C
