INSTRUCTION ABOUT ‘WEEE’ SYMBOL
English
I/B parenthesis to offer information for user.
User’s
Manual

Table of Contents
1. SAFETY WARNING
2. GENERAL FEATURES
3. HOW TO CONNECT YOUR RECEIVER
4. HARDWARE DESCRIPTION
5. QUICK START & INSTALLATION
6. WATCHING TV
7. ENU OPERATION
8. FIR WARE UPGRADE THROUGH TERRESTRIAL
9. TROUBLESHOOTING
10. TECHNICAL SPECIFICATIONS
2
4
5
7
11
14
18
29
30
31
Table of Contents

SAFETY WARNING 2
SAFETY WARNING 3
MAINS SUPPLY
: 100-240V AC 50/60Hz
Operate this product only from the type of power supply indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult your
local power company.
-Disconnect the product from the mains before you start any maintenance or
installation procedures.
OVERLOADING : Do not overload a wall outlet, extension cord or adapter as this
may result in electric fire or shock.
LIQUID : The product should not be exposed to liquid of any kind. In addition, no
objects filled with liquid should be placed on the apparatus.
CLEANING : Disconnect the product from the wall outlet before cleaning.
-Use a light damp cloth (no solvents) to dust the product.
VENTILATION : The slots on top of the product must be left uncovered to allow
proper airflow into the unit.
-Do not stand the product on soft furnishings or carpets.
-Do not stack electronic equipments on top of the product.
ATTACHMENTS : Do not use any unsupported attachments as these may be
hazardous or cause damage to the product.
CONNECTION TO THE AERIAL : Disconnect the product from the mains before
connecting or disconnecting the cable from the aerial. Failure to do so can damage
the aerial.
CONNECTION TO THE TV : Disconnect the product from the mains before
connecting or disconnecting the cable from the TV. Failure to do so can damage the
TV.
EARTHING : The aerial cable must be buried in the ground.
LOCATION : Place the product indoors to avoid exposing it to lightning, rain or sun.
-Do not place it near a radiator or heat register.
- ake sure it has more than 10 cm clearance from any appliances susceptible to
electromagnetic influences, such as a TV or a VCR.
This product has been manufactured to comply with international safety
standards. Please read the following safety precautions carefully.
. SAFETY
WARNING
-Do not block the openings with any object, and do not place the product on a
bed, sofa, rug, or other similar surface.
-If you place the product on a rack or a bookcase, ensure that there is adequate
ventilation and that you have followed the manufacturer’s instructions for
mounting.
-Do not place the product on an unstable cart, stand, tripod, bracket, or table
where it can fall. A falling product can cause serious injury to a child or adult, and
serious damage to the appliance.
LIGHTNING, STORM or NOT IN USE : Unplug the product from the wall outlet
and disconnect the antenna during a thunderstorm or when left unattended and
unused for long periods of time. This will prevent damage to the unit due to
lightning and power-surges.
EXTRANEOUS OBJECTS : Do not insert anything through the openings in the
unit, where they can touch dangerous voltage points or damage parts .
REPLACEMENT of PARTS : When replacement of parts is required, be sure the
service technician uses replacement parts specified by the manufacturer or those
that have the same characteristics as the original part. Unauthorized substitution
may result in additional damage to the unit.
Warning
To avoid damage of the power cord or plug;
-Do not modify or process the power cord or plug arbitrarily.
-Do not bend or twist the power cord.
- ake sure to disconnect the power cord holding the plug.
-Keep heating appliances as far as possible from the power cord in order to
prevent the cover vinyl from melting.
-The main plug shall remain readily operable.
To avoid electrical shock;
-Do not open the main body.
-Do not insert metal or inflammable objects inside the product.
-Do not touch the power plug with wet hands.
-Disconnect the power cord in case of lightning.
To avoid damage of product;
-Do not use the product when it is out of order. If you continue to use the product
when defective, serious damage can be caused to it. ake sure to contact your
local product distributor if the product is out of order.
-Do not insert metal or alien substance into the slots for the modules or
Smartcards.
It may cause damage to the product and reduce its life span.
The socket-outlet shall be installed near the equipment and shall be easily
accessible

GENERAL FEATURES 4
HOW TO CONNECT YOUR RECEIVER 5
- Fully compliant with PEG-2 & DVB
- Smart Card interface for embedded Conax
- Input frequency 145 ~ 863 Hz
- One input tuner with loop through IF signal
- Supports DVB-T modulation schemes: QPSK, 16-QA and 64-QA
- Implements non-hierarchical and hierarchical 2K and 8K system operation
- Auto scan
- Quick channel changing
- ax. 4000 channels (TV & radio) programmable
- User friendly 256 colors OSD & easy GUI
- Various OSD languages supported
- Supports EPG.
- Supports Teletext, Subtitle using OSD
- Radio channel background display
- Favorite Channel List programmable
- Parental Lock function
- 20-Step volume control
- Automatic detection of Forward Error Correction
- Window based S/W download program supported by RS232 serial port
- 4:3, 16:9, Letter Box.
- 7 Segment-4 Digit Display
- Three keys on the front panel (Power, Channel Up/Down)
(Volume Up/Down buttons are optional)
- Two SCART outputs for TV & VCR
- Three RCA outputs for Video, Audio L/R
- S/PDIF output for digital audio
- Timers
- Built-in Help System
) CONNECTING THE RECEIVER WITH ANTENNA
Connect the coaxial cable to “ANTENNA” terminal marked at the rear of the
receiver.
All cable connectors should be finger-tightened; do not use any kind of wrench
on the cable over connectors.
The cable should be 75 Ω impedance coaxial twisted at the end with an “IEC”
type connector.
2) CONNECTING THE RECEIVER TO TV
To connect the receiver with your television, connect the SCART connector
marked “TV” to the respective SCART port of the TV
3) CONNECTING YOUR VCR
To connect a VCR, the receiver is provided with a SCART terminal on the rear
marked "VCR." Using a SCART connector, the VCR can be connected to the
receiver.
3. HOW TO CONNECT YOUR RECEIVER
Please DO NOT plug in the main power supply cord until you
have finished all the connections.
2. GENERAL FEATURES

4) CONNECTING EXTERNAL AUDIO HI-FI SYSTEM
To connect any external Audio Hi-Fi system, the receiver is provided with two
RCA connectors at the rear, marked “Audio L and R” respectively to
connect the left and right audio.
In case of Audio Hi-Fi systems with digital audio input, please connect to
S/PDIF.
5) CONNECTING YOUR ANALOG RECEIVER
To facilitate users using analog receivers to view analog channels, the receiver
has been provided with a loop through terminal marked as “LOOP OUT”.
Connect the coaxial cable from this terminal to the RF input terminal of your
analog receiver.
By keeping the receiver in standby, you will be able to tune and view analog
channels from your analog receiver.
6
4. HARDWARE DESCRIPTION
4. A. FRONT PANEL
HARDWARE DESCRIPTION 7
) STANDBY BUTTON
Switches between operation and standby modes.
2) CH BUTTON
oves the TV/radio channel up or down.
3) VOL BUTTON(Option)
Increases or decreases TV/Radio Volume
4) INFRARED SENSOR
Receives the IR commands from the RCU. Do
not block the view of the sensor.
5) 7 SEGMENT DISPLAY
Displays the current channel number. While the
receiver is in standby mode, the display will show
the current time.
6) SMART CARD SLOT
A slot for a Smart Card.
Although some TV and radio channels are free to
air, most TV and radio/music channels are
available on a subscription basis and can only be
enjoyed via a Conditional Access component.
The Conditional Access component is a
removable Smart Card.
Please note that the gold chip on the Smart Card
should face downwards and inwards when you
insert it into the Smart Card Interface.
HOW TO CONNECT YOUR RECEIVER

HARDWARE DESCRIPTION 8
HARDWARE DESCRIPTION 9
4. B. REAR PANEL
) ANTENNA: Connects the aerial cable.
2) LOOP OUT : Connects to the RF IN of the TV or VCR using an RF cable.
3) RS-232C : Connects to the PC to update software.
4) VCR : Connects to the VCR or DVD using a VCR SCART cable.
5) TV : Connects to the TV using a TV SCART cable.
6) S/PDIF : Connects to the audio system using an S/PDIF cable. (digital audio)
7) AUDIO L/R : Connects to the TV or VCR using an RCA cable.
8) VIDEO : Connects to the TV or VCR using an RCA cable.
4. C. REMOTE CONTROL UNIT
: This button is used to toggle between normal and muted sound.
: The help button opens and closes built in help information.
: This is used to switch the receiver in and out of standby mode.
: Switches between TV- and Radio mode.
: Freeze the TV picture.
: The Teletext button opens and closes the Teletext for the current
channel.
: This button is used to easily input multiple digit TV channel numbers.
: These buttons are used to enter numerical values and to select a
specific channel directly by entering its number.
: The Options button is used to open and close a menu of temporary
viewing options (Like subtitling and language options) for the current
programme.
: Exits any open menu or information mode and goes back to watching
TV.
: The enu button opens the system main menu. Press again to hide the
menu.

HARDWARE DESCRIPTION 0
QUICK START & INSTALLATION
5. QUICK START & iNSTALLATION
: To go back one level at a time within menus or screens and save any
changes.
: Cursor up and down - Used to move up and down the highlight in
menues. While watching TV or listening to Radio, these buttons can be used to
go to the next or previous channel.
:Cursor left and right - Used to move left and right in menues. While
watching TV or listening to Radio, this button can also be used to adjust the
volume.
: The select button is used to confirm or select things. While watching TV, this
can be used to display a basic list of TV channels.
: Used to scroll the page up or down several lines, for example in the guide,
user's manual or channel lists.
: The Guide button shows the TV guide. Press again to hide the guide.
: The info button displays a short information (if transmitted) about the current
programme.
: This is the favourite button, to which you may assign quick access to a
favourite function of your choice.
.
①
①①
① Antenna TV/VIDEO Connection
Connect the antenna to the
ANTENNA of the receiver.
Connect the SCART cable or RCA
cable as shown in the illustration.
Connect the power cord to a wall
outlet.
Turn the power switch on.
Press the STAND BY button of the
receiver or the remote control unit.
②
②②
② Powering On
③
③③
③ Inserting Smart Card
Hold the Smartcard horizontally
with the electronic chip facing
down.
Insert the Smartcard into the slot.
5. A. System Connection

5. B. Setting Up
①
①①
① Language
②
②②
② Country
③
③③
③ Antenna
⑤
⑤⑤
⑤ Setting
Select the preferred menu language by using
the and buttons, and press to
continue. The selected language will also be
the main language for audio and subtitling.
•
At this view, you may change some settings
if needed:
• TV Format: Select the type of TV you have
(4:3 or 16:9) by using and . Use 16:9 if
you have a widescreen TV.
Select the country where this receiver well be
used.
The installation is completed. Press on
"Done!" to save all channels and settings and
start watching TV, or press and select
"Back" with if you want to go back and
change anything.
f you fail to automatic channel search, please refer to page 26, 5.C. Advaced
channel search in 7. Menu Operation.
QUICK START & INSTALLATION
2
3
QUICK START & INSTALLATION
⑥
⑥⑥
⑥ Done
Just wait for the channel search to finish (This
automated procedure may take several minutes
to complete). To interrupt the channel search,
press .
If no channels are found, verify that your
antenna cable is connected and that the
antenna is correctly aligned toward a digital TV
transmitter. You may re-start the channel search
by pressing .
④
④④
④ Search
When channel searching is done, select the "Next" menu item to continue to settings
Select if the active antenna power should be
on or off with and . Setting this to "On"
will feed +5 Volt to the antenna output. When
you are done, select the "Next" by
pressing .

6. WATCHING TV
This chapter describes how you watch TV and listen to radio using the receiver.
Thanks to the advantages of the digital TV transmissions, extra features are added to
the broadcast, such as information about the current and next programme and extra
options; like the ability to chose between different languages for the audio and
subtitling.
Note: Available options may vary, depending on the actual broadcast of the extra
material for the current programme.
The general principle is that one button press opens a function, pressing it again closes
it. This is valid for most functions, such as the information banner, the TV Guide and
the menu
6. A.
General watching
• Use the and buttons to go the next and previous channel respectively.
• Use the and buttons to adjust the volume, and the button to
toggle muted sound on / off.
• Use the number buttons to input a channel number.
Press the button to display the information banner about the current
programme. Press it again to hide the banner.
Pressing the button from when the banner is open, will go directly to the TV
Guide with the current programme opened in extended information mode. If you
press without an open information banner, you will be taken to the TV Guide
overview mode.
Note: Programme information will only be displayed if it is included in the current
transmission. Otherwise a "No information" message is shown.
6
.B. Options
Pressing the button will open the "Options" menu.
Depending on your current system settings, and what extra information is
currently broad-casted for the watched channel, more or less options are
displayed.
• Subtitle lang.: Select the preferred language for the subtitling and
programme information. To turn subtitles off, select "None" - If the
preferred language is not available, the first available language will be
used instead.
Note: A " " symbol indicates that the selected subtitling language is
for hearing impaired.
• Audio language: Some TV programmes send multiple audio tracks, for
example in two different languages. By selecting a preferred audio
language, the receiver can select the most suitable audio track for you.
If there are no audio tracks available that match your settings, another
language may be used instead.
• Zoom: This function helps you to adjust the TV picture to better suit
your type of TV. For a 4:3 type of TV, this is equal to what is commonly
known as Letterbox and Fullscreen format. However, if you have a 16:9
type of TV, this function can also be used to zoom the TV picture to fit
better.
Note: Only the TV picture format is changed, any subtitling or menues
are left unaffected.
• Channel List: Change to another list with the and button.
WATCHING TV
4
5
WATCHING TV

WATCHING TV 6
WATCHING TV
7
6.D. Digital Teletext
• Pressing will open the teletext pages mode, if teletext is transmitted at
the current channel.
• Use the 0..9 numeric buttons to enter a new page number.
• Use and to move a highlight focus between the page numbers
displayed on the screen, and open the highlighted page.
• To go to the next or previous transmitted teletext page, press or .
• To view more, optional teletext options, press .
• Exit the teletext mode by pressing .
• Browse text page history using and .
• Go to the index page (usually page 100) by pressing 0.
Note: The receiver also passes the teletext pages through to your TV. This
technique is known as VBI (vertical blank insertions). This means that you can
also use your TV's remote control to open and use the teletext pages, using the
built in teletext functions in the TV. VBI works with most new TV sets, but not all:
Try to adjust "Signal:" setting to "RGB" or "CVBS" in the "TV and Audio Settings"
menu.
Note: Some changes under "Options" are only valid for the programme you are
currently watching. If you leave the programme, the settings will be gone. To read
more about default options to these settings, please see the "System Configuration"
help chapter.
To close the "Options" menu, press .
6.C.
The TV Guide
• The Daily Guide conveniently shows all the TV programmes of a specific day
for one channel at a time. The buttons used to navigate between channels and
different time periods are described in the footer of the view.
• : ove
• :Change programme
• : TV/Radio
• :Show info
• : Prev Day
• : Next Day
• :New Timer
• :Timers
The TV guide starts empty and is filled with program information over a period of
time. When new information arrives, it is shown directly on screen. The time to
complete the process of fully filling the guide with data may take several minutes.
Depending on the TV network, you may not be able to watch a TV channel when
the guide is open, due to the fact that all TV guide information is broadcasted on a
special TV channel.
•
. Lock Channel: Sets a permanent lock on the current channel.
This option is only available if "Channel lock active:" is set to "On" in the "Parental
Control" menu.
If a locked channel is encountered it can be unlocked by pressing the button
and typing the PIN code. Please note that this is only a temporary unlock which is
reset when a another channel is selected.
To permanently remove the lock from a locked channel, see the "Parental Control"
menu.

7
. MENU O
PERATION
M
AIN MENU
After installing your antenna and receiver with appropriate connectors, plug in
the AC main power and turn on the receiver.
You can select the menu language,
text size, audio language, subtitle
language, extra subtitling using
“up/down” keys or and
button.
Press the “ ” key to confirm your
selection
The main menu is classified into several sub menus which will carry out the
various operations individually.
. User Preferences
Press the “ ” key of the RCU. You
will see the “ ain enu” on the TV
screen as follows.
You can move into the desired submenu
using the “up/down” keys .
Press the “ ” key to confirm your
selection.
The default factory PIN code is “0000”. Press the “ ” key or “ ” key to return to the
previous menu.
ENU OPERATION 8
ENU OPERATION 9
MENU STRUCTURE

ENU OPERATION 20
ENU OPERATION 2
You must give all lists a specific name.
Select a suitable name by using the
and buttons.
Select "Select channels" to enter a
view where you can select which
channels that should be included in the
favourite list.
Use and to move the focus
between the channels and to
include this channel to the current
favourite list. To exit the view, move the
focus to the menu on the right by
pressing and then select either
"Save" or "Cancel".
odifying existing lists works in the same way as when you create a new list: You can
change the name of the list, what channels are included and what order they appear in.
All defined lists are listed at the top of the "Favourite Lists" menu. To open a menu
where you have the options to delete or modify the properties for a favourite list (such as
the name or included channels) select it in the list and press the button.
If you want to delete a list, you can choose to either delete the one by one, or all at
once. Select "Delete" to delete the currently selected favourite list. If several lists are
defined, you can select "Delete all" to delete all lists. To avoid deletion by mistake, a
confirmation question will be displayed.
2. B. Modifying existing lists.
2. A.
Creating a new list.
You can create a new (or additional) favourite list by selecting "Create a new Favourite
List" from the menu. You can create multiple favourite lists.
2. FAVOURITE Lists
Favourite lists are used to create your own personal channel li
sts. The lists are a good
way to hide unwanted channels or to reorganize the order of the channels. All lists have
a name that identify them, and you can change the favourite list when watching TV by
using "Options" menu.
Select "Arrange channels" to reach a view where you can arrange the order of the
channels in the favourite list.
• To select between the channels, use the and buttons. To move the
selected channel to a new position, press . To exit the view, move the focus to
the menu on the right by pressing
and then select either "Save" or "Cancel".
Save - Select "Save" to store and activate all changes you have done in this menu.
• Menu language: Select the preferred language for the system menues.
• Text size: Select the size of typeface used for the text in menues, guide, etc. Hint:
A smaller typeface might be harder to read, but more text can fit on the screen. (Note:
This feature may not be available on all receiver software versions)
• Audio language: Some TV programmes send multiple audio tracks, for example in
two different languages. If there are no audio tracks available that match your settings,
another language may be used instead.
• Subtitle lang.: Select the preferred language for the subtitling and programme
information. To turn subtitles off, select "None":
Note: A " " symbol indicates that the selected subtitling language is for hearing
impaired.
• Extra subtitling: If this feature is turned on, extra subtitling may be displayed that is
more suitable for hearing impaired, if they are broad-casted for the current programme.

ENU OPERATION 22
ENU OPERATION 23
3. Parental Control
Timers are used to program the receiver to wake up at a certain time and tune to a
specified channel.
Timers are normally used to record a TV programme on the video recorder, or to
pre-program the receiver for other reasons (wake-up, etc). A set timer causes the
receiver to wake up from standby mode at the specified time and change the
channel to the specified one. Please note that the VCR must be programmed
separately.
If you use a timer to record a TV show to i.e. a video recorder (VCR), also remember
to program your video recorder in parallel at the same time as you have set the
timer in the receiver.
Note: If you use the SCART connector from the receiver to your VCR, most VCR's
should be set to record from 0 channel.
To open the "Parental Control" menu
you will be asked to enter your access
PIN code. All parental control features
work on a locking concept with the
PIN code as your entrance key.
The PIN code is set to 0000 at the
factory!
• Box lock active: Using this option the whole receiver may be blocked: To unlock
the receiver the PIN code must be entered. The receiver stays in an unlocked state
until it goes back to standby mode or is turned off.
• Channel lock active: If the channel lock feature is active, individual channels
may be marked as locked. To temporary unlock a locked channel, the button
can be pressed and the PIN code entered. Note: The channel stays in its unlocked
state until a channel change is done.
• Lock Channels: In the "Lock Channels" view, you can control which channels
should be locked by a PIN code.
• Age rating control: Toggle the age rating control on or off with and .
If you activate the age control, also specify a suitable age level under "Age Limit:".
• Age Limit: If a TV-program is shown on the selected TV-channel that has an
age limit above the setting, a PIN code will be required to watch it.
Be aware that not all Service Providers send the necessary codes for this
function to work. To increase or decrease the age setting, use and .
• Change PIN code: Use this function to change your PIN code to some
other four digit number.
• New PIN: Enter a new four digit PIN code by using the (0) to (9)
buttons on the remote control.
• Verify new PIN code: Re-enter the same new four digit PIN code
once again to verify that you got it right.
5. System Configuration
System Configuration menues are used to control the more advanced features of
the receiver, such as doing regional settings, channel searches and other system
settings.
4. Timer

ENU OPERATION 24
ENU OPERATION 25
5.A. TV and Audio Settings
• TV Format: Select the type of TV you have (4:3 or 16:9) by using
and . Use 16:9 if you have a widescreen TV.
• Signal: This setting only affects SCART-cable connected receivers. The "RGB"
mode usually gives a better and sharper picture, but some older TVs can only use
the "CVBS" mode.
The "RGB" mode usually require a special (fully connected) SCART cable. Some
receiver models also include the "S-Video" option. If this option is selected, the
picture may appear better, but require a S-Video compatible TV and cable to work.
• RF Channel: This setting is only affecting receivers equipped with an RF
antenna output contact. By using the and button, you can change the
outgoing RF channel number. This can be useful on olders televisions to get a
picture on a certain channel, or to improve picture quality.
5.B. Regional Settings
• Country: Select the country where this receiver will be used with and
.
This will affect the time zone settings.
 Clock adjustment : Select “ anual” or “Automatic” mode using and
key. If you want to change the time manually in time offset menu, please set
this “ anual” mode.
Time offset: If needed, adjust the time offset to fit your local time. Change
the time in 15 minute steps by using and .
In the "TV and Audio Settings" view
you can modify the properties of the
audio and video signals to suit your
TV and audio equipment.
Using the regional settings, you
may modify settings to suite your
geographical position or cultural
settings. Among other things, this
can be the date and time format.
• OSD Size: The "OSD Size:" setting can be used to specify how much of the TV
picture area the receiver can use for graphics and text. Older TV's usually show
less of the picture, while new ones display more. Example: If you have a modern
TV and select the "Large" setting, more information can be shown on the TV
screen, for example in the TV guide.
• Dolby Digital output: Select the audio format for digital audio output.
The factory setting is PC format. Note: If you have selected Dolby Digital
to On, and the sound for a TV programme is transmitted in Dolby™ Digital
format, no sound will be output to SCART or RCA-cables.

ENU OPERATION
ENU OPERATION 27
5.C. Channel Search
Channel searches are done to update your channel table. New channels may be found
when you do a channel search.
In the "Channel Search" menu, you can select "Advanced Channel Search" or
"Automatic Channel Search".
Automatic Channel Search
Advanced Channel Search
The "Advanced Channel Search" menu allows you to manually enter channel search
parameters that you might find in TV magazines or on the Internet. This can be useful
to find special type of channels that can only be found if the correct search settings are
known.
• Frequency: Specify the transponder frequency that you would like to search
by using the number buttons on the remote control. You can also use
and to move the input focus left and right, for example if you entered
the wrong number.
• Bandwidth: Enter the combined bandwidth setting that should be used in
the search by using and . The bandwidth is a measure of the
information capacity of the broadcast.
Select "Automatic Channel Search" if you
would like to do a normal channel search.
All found channels that are new will be
added to the "All channels" channel list.
ENU OPERATION
26


 Frequency: Specify the transponder frequency that you would like to search
by using the number buttons on the remote control. You can also use
and to move the input focus left and right, for example if you
entered the wrong number.


 Transm. Mode: Select the transmission mode that should be used in the
search by using and . The transmission mode can be either "2K"
or "8K", and is a measurement of the number of carrier waves in the
combined signal.


 Network Search: Select "Yes" if you want to the search to cover all
transponders that are connected to the specified network. Change between
"Yes" and "No" by using and buttons.


 Set to default values: To reset all values and settings in this view to their
default values, press .


 Start exact channel search: Select this item and press to start the
channel search using the specified parameters.
This is an exact search, it will only use the start Frequency and a Network
Search (If enabled in menu)
New channels
The setting for "New channels" affects the automatic reminders that appear if
the receiver detects new channels in the broadcast. In some regions and
areas, the reminder might erroneously appear even though there are no new
channels, due to differences in the digital TV broadcasts. The factory setting is
"Don't remind". To activate this feature, change to "Remind me". A technical
term for this feature is "NIT/SDT monitoring". (Note: This feature may not be
available on all receiver software versions)

ENU OPERATION 28
29
Channel Search Results
A channel search may take several minutes before it is completed. All new found
channels are listed on the screen and automatically added to the "All channels"
channel list.
You can stop the search at any time by selecting the "Stop the channel search"
menu item.
If the search is finished, you can start it again by selecting "Restart the channel
search".
5.E. Sys
5.E. Sys5.E. Sys
5.E. System Maintenance
tem Maintenancetem Maintenance
tem Maintenance
• The options under the "System aintenance" menu are used to upgrade your
receiver to a new software version (if broadcasted) or to re-install your system from
scratch.
• To upgrade the receiver software, select "Software Update" from the menu. New
software may include new or improved features for the receiver.
Note: It may take several minutes to upgrade the receiver - Never turn the
receiever off while upgrading. Also avoid to disconnect the antenna cable, or using
the remote control. Failure to upgrade the software may result in a damaged receiver
that must be sent for a service.
• To re-install the receiver, and start the complete installation procedure from
scratch, select "Reinstall" from the menu. If you do a reinstallation, all your previous
settings, including favourite channel lists, will be erased and set to factory default.
6. User's Manual
• The built-in user instructions can be read by selecting "User's anual" in
the main menu.
• To exit, press .
• Select chapter with and .
• Browse between the pages within the current chapter with and .
8. FIRMWARE UPGRADE THROUGH
TERRESTRIAL
Upon installing the new receiver, please make sure it detects the new
firmware with the following procedures.
1. Turn on the receiver.
2.Select [ ain enu  System Configuration  System aintenance 
Software Update]
3. As soon as the “ ” button is pressed, the receiver will detect the new
firmware.
FIR WARE UPGRADE THROUGH TERRESTRIAL
For the more detailed expalanation, please refrer to the 5.E System Maintance
in Menu opration
5.D. Smart Card
5.D. Smart Card5.D. Smart Card
5.D. Smart Card
Entering smart card settings will bring up a new menu where you can control your
smart card and its settings, for example see information about your subscription, age
levels and change the smart card PIN code.

30
TECHNICAL SPECIFICATIONS 3
9
. TROUBLE
SHOOTING
Type
Input Voltage
Power Consumption
. Power Supply
: S PS
: 100~240VAC 50/60 Hz
: ax 15 W
2. Tuner
OFDM Spectrum
Modulation Mode
Guard Interval Mode
Active Symbol Duration
FEC Decoder
3. Demodulator
System Decoding
Profile and Level
Input Rate
Video Formats
4. Video Decoder
: PEG-2 ISO/IEC 13818-2
: PEG-2 P@ L
: ax 100 B/s
: 4:3 (Normal) & 16:9 (Widescreen)
Input Frequency
Input Signal Level
Input Impedance
Connector Type
Channel Selection
IF Band Width
: 145 ~ 863 Hz
: -20 dBmV ~-75 dBmV
: 75 Ω Unbalanced
: ‘IEC’ Type Female
: PLL Frequency Synthesizer
: UHF/ 8 Hz, VHF/ 7 Hz
: 2K and 8K Carrier odes
: QPSK, 16QA , 64QA
: 1/32, 1/16/ 1/8, 1/4
: Active Symbol Duration
: 1/2, 2/3, 3/4, 5/6, 7/8
Does not display LED on the
front panel or the receiver has no
power.
No pictures on the screen
No sound
Remote control does not operate
Problem Solution
About the Receiver
Searching signal
Unrecognized Smart Card
Please insert your Smart Card
- Connect the cable properly.
- Check the signal strength by selecting [ ain
enu  System Configuration  System
aintenance  System Information  Signal
meter]
- Check the Smart Card.
- Insert the Smart Card.
On - Screen Error essages
- Connect the power cord to the power outlet
properly.
- Check if the receiver is in standby mode.
- Check if the video output port is firmly
connected to the TV.
- Check if you have selected the correct
channel or video output on your TV.
- Connect the audio cords properly.
- Check the volume level of the TV.
- Press the “ UTE” key.
- Point the remote control directly towards the
receiver.
- Check and replace batteries.
TROUBLESHOOTING
0.
TECHNICAL SPECIFICATIONS

5. Audio Decoder
6. Audio/Video Output
7. Demultiplexer
Signal
Connector Type
8. Serial Data Interface
ISO 78 6
9. Smart Card Interface
System Decoding
Audio Mode
Sampling Frequency
: RS-232, ax. 115200 bps
: 9 Pin D-Sub (male)
Conax Conditional Access System
0.Embedded Descrambler
: PEG-1 ISO/IEC 11172-3
Layer I & II
: ono, Dual, Stereo, Joint Stereo
: 32, 44.1, 48 KHz
TV SCART
VCR SCART
RCA Jack
S/PDIF
: CVBS, RGB, Audio L/R
: CVBS, Audio L/R
: CVBS, Audio L/R
: Digital Audio
: ISO/IEC 13818-1 Compliant
TECHNICAL SPECIFICATIONS 32
