Opitec Nesting Box 115.327 User manual

ø10
115.327
Nesting Box
Content Quantity Dimensions (mm) Designation Part no.
Wooden board 1 500x200x20 Back wall and roof 1
Wooden board 1 500x150x20 Side panels 2
Wooden board 1 150x150x20 Base board 3
Wooden strip 1 500x40x20 Mounting strip 4
Wooden board 1 210x150x20 Door 5
Round bar 1 100x10 Perch 6
Eye bolt 1 20 Opening handle 7
Schraubhaken 225 Door latch 8
Nagel 30 40x2 Nail 9
Tools required:
Scroll saw or
razor saw
Wood glue (wa-
ter resistant)
Pricker
Ruler Pencil
Hammer
Drill
Please Note
The OPITEC range of projects is not intended as play toys for young children. They are tea-
ching aids for young people learning the skills of Craft, Design and Technology. These pro-
jects should only be undertaken and operated with the guidance of a fully qualified adult.
The finished projects are not suitable to give to children under 3 years old. Some parts can be
swallowed. Danger of suffocation!
Sandpaper
Forstnerbohrer
Wood rasp

1 2
260
260
240
240
500
150
1a 2a
Instructions 115.327
Nesting Box
Information on species-appropriate nesting aid:
The supplied rough wood must not be sanded smooth and needs to stay rough. This is important for the fledged young birds to be able to leave the
nesting box. If the wood is smooth, they have nowhere to hold on to! For any possible waterproofing you should of course only use wood protection
that is non-toxic and odourless.
Size of entrance holes:
The diameter of the entrance hole determines which birds can use the box. A well-dimensioned
entrance hole protects the inhabitants from predators and the weather.
birds height entrance hole brut period Nesting Place
Blue Tit at least 1,5-3,5m ø 26-28mm April mixed forests, gardens
Great Tit at least 1,5-3,5 m ø 32-34mm March/April mixed & coniferous forests
Crested Tit at least 1,5-3,5 m ø 26-28mm April coniferous forests
Marsh Tit at least 1,5-3,5 m ø 26-28mm April/May mixed forests, gardens
Coal Tit at least 1,5-3,5 m ø 26-28mm March/April mixed forests, gardens
Flycatcher at least 1,5-3,5 m ø 32-34mm May forests, gardens, parks
Common Redstart at least 1,5-3,5 m ø 47 mm May edge of the woods,mixed
Nuthatch at least 1,5-3,5 m ø 32-47 mm April mixed forests, gardens
House Sparrow at least 1,5-3,5 m ø 32-34 mm April villages
Tree Sparrow at least 1,5-3,5 m ø 32-34 mm April villages, hedges, shrubs
Birds and matching entrance hole size:
Positioning of the nesting box:
It is important to make sure that the boxes are attached high enough to protect from predators. The entrance hole should be on the side pointing
away from the main weather direction and should be protected from direct sunlight. Nest boxes should be placed in autumn, because some types of
bird like to use them as sleeping places in winter.
Cleaning:
Nesting boxes need to be cleaned annually. This should be done in months when birds are not breeding. Only clean the nesting box with a brush and
hot water. Do not use cleaning products.
roof
1b
back wall
Measure 265mm on the wooden board (1) and mark. Cut out with the
scroll or razor saw. Clean up sawn edges with sandpaper.
2b
Measure 260mm diagonally oset on the wooden board (2) as shown
and mark on both sides. Draw a line to connect both marked points.
Then saw along the line with the scroll or razor saw. Clean up sawn
edges with sandpaper.
Side panels Side panels

3 4
56
2
Bevel edge!
7
Measure approx. 10mm from the bottom edge of the door and screw
the eye bolt (7) in centrally. Glue the round bar (6) into the ø10mm drill
hole as shown. Let the glue dry thoroughly.
6
8
5
8
Add the door (5) as shown and fasten on either side with a nail (9). Do
not glue in!
5
9
Side view
Instructions 115.327
Nesting Box
Measure and mark the drill holes with a pricker on the wooden board
(5). Drill the holes for the perch ø10mm with a suitable drill. Drill the
hole for the entrance hole with a suitable Forstner bit dependending
on the size required.
Now glue the back wall on with wood glue as shown in the drawing
and attach with seven nails.
Note: place the board for the door (5) as spacer between the side
panels.
Use a wood rasp or a belt sander to bevel the top edge of the back
panel to match the slope of the side panels. (see drawing!)
Adjust size according to
entrance hole diameter
Glue both side panels (2a+2b) to the base board (3) and attach from
both sides with three nails each. Let the glue dry thoroughly.
3
2a
2b
9
9

9
3
10
1a
9
4
Cord or wire
9
Put the roof (1a) in place and attach with wood glue and approx. five
to seven nails. See illustration!
Instructions 115.327
Nesting Box
Attach the wooden strip (4) with glue and at least two nails (9) to the
back panel of the nesting box. This strip is for attaching the nesting
box to a wall, a tree etc. You can add holes for screws or to attach a
wire or cord. You could also add a nail (9) at the same height on each
side and attach a cord or wire to hang the box up on a branch.
