Optibase MGW 1100 User manual
MGW 1100
IPTV Encoding and Streaming Platform
Version 5.5
November 2009
StockCheck.com
yUse the following safety guidelines to help protect your MGW x100 unit
from potential damage and to ensure your own personal safety.
yMake sure that only authorized personnel installs, connects and maintains
MGW x100 and its components.
When using MGW x100
yMGW x100 is heavy. Rack-mount or remove MGW x100 from a rack
with at least two people.
yBefore installing MGW x100, unplug the system to help prevent electric
shock or damage. Certain system board components continue to receive
power any time MGW x100 is connected to AC power.
yTo help prevent electric shock, plug the power cable into properly
grounded sources. Use only properly grounded extensions and adaptors as
the need arises.
yFor AC platforms, use only a UL Recognized power cord.
yTo connect DC platforms to external power supplies, use AWG12 wires.
yMake sure that MGW x100's chassis is properly grounded.
yMake sure that nothing rests on your MGW x100 power cable and that
the cables are not located where they can be stepped or tripped over.
yDo not spill food or liquids on your MGW x100 unit.
yDo not push any objects into free slots of your MGW x100 unit. Doing so
will damage your MGW x100 unit and can cause fire or electrical shock
by shorting out interior components.
yKeep your MGW x100 unit away from radiators and heat sources. Also,
do not block cooling vents. Avoid placing loose papers underneath your
MGW x100 unit. Do not place your MGW x100 unit in a closed-in wall
unit or on a bed, sofa, or rug.
yWhen you disconnect a cable, pull on its connector or on its strain relief
loop not on the cable itself. Some cables have a connector with locking
tabs; if you are disconnecting this type of cable, press in on the locking
Safety Instructions
StockCheck.com
•System Overview
System Overview 3
tabs before disconnecting the cable. As you pull connectors apart, keep
them evenly aligned to avoid bending connector pins. Also, before you
connect a cable, make sure that both connectors are correctly oriented and
aligned.
yESD Warning: Normal handling precautions should be taken to avoid
static discharge.
Note
yCertain specified modular components can be removed and replaced. If you try to
remove or replace a component other than specified, you will void your warranty.
yDo not try to open or replace parts of modular components, as this will void your
warranty. Modules (fan trays, power supplies) can only be replaced as an entire unit.
The replacement must be an Optibase spare part. Using parts other than Optibase
original spare parts can create hazards and will void the warranty.
yDepending on the power supplies installed, MGW x100 must be powered either by 100
- 240 V AC or dual 36-72 V DC. Connecting AC power supplies to a DC source or vice
versa will severely damage MGW x100 and possibly cause personal injury.
yMake sure that you never insert both DC and AC power supplies into the same
platform. This will severely damage MGW x100 and cause personal injury.
yDo not insert AC power supplies into DC powered platforms and vice versa. This may
damage MGW x100 and void the warranty.
StockCheck.com
Trademarks
Optibase is a trademark of Optibase Inc.
Microsoft, MS, and MS-DOS, Windows, Windows NT, Windows 2000 and
Windows XP are trademarks of Microsoft Corporation.
Java is a registered trademark of Sun Microsystems. Littlefuse is a registered
trademark of Littlefuse Inc.
IBM PC, XT, AT are registered trademarks of International Business
Machine Corporation.
Dolby®, Dolby® Digital, Dolby® Surround and the double-D symbol are
registered trademarks of Dolby Laboratories.
All other trademarks mentioned in this manual are the sole property of their
respective manufacturers.
Copyright
Optibase Inc., California. (c) 2008 Optibase Inc. All rights reserved.
Published 2009, Israel
MPEG Packaged Media Notice
Any use of this product other than consumer personal use in any manner that
complies with the MPEG-2 or the MPEG-4 standard for encoding video
information for packaged media is expressively prohibited without a license
under applicable patents in the MPEG-2 Patent portfolio or the MPEG-4
Patent portfolio respectively. The required license is available from MPEG
LA, L.L.C., 250 Steele Street, Suite 300, Denver Colorado 80206.
Notice
Information in this document is subject to change without notice. Optibase
Inc. and Optibase Ltd. assume no responsibility for any errors that may
appear in this manual. Companies, names and data used in examples herein
are fictitious unless otherwise noted. No part of this document may be copied
or reproduced in any form, or by any means, electronic or mechanical, for any
purpose, without the express written permission of Optibase Inc. Optibase
makes no warranties with respect to this documentation and disclaims any
implied warranties of merchantability or fitness for a particular purpose. From
Trademarks and Copyright
StockCheck.com
•System Overview
System Overview 5
time to time changes may occur in the file names and in the files actually
included on the distribution disks. Optibase makes no warranties that such
files or facilities, as mentioned in this
RoHS Compliance Statement
Optibase is committed to fully comply with the RoHS Directive, the
European Union Restriction of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment ("RoHS") Directive (2002/95/EC),
taking effect on July 1, 2006.
The RoHS directive prohibits the sale of electronic equipment containing
certain hazardous substances such as lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyls ("PBB") and polybrominated
diphenylethers ("PBDE") in the European Union.
WEEE Compliance Statement
The European Union adopted Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), with requirements that went into effect
August 13, 2005. WEEE is intended to reduce the disposal of waste from
electrical and electronic equipment by establishing guidelines for prevention,
reuse, recycling and recovery.
Optibase has already modified its practices and processes to conform to the
requirements in this important directive
StockCheck.com
