Opticon H-29 User manual
H-29
H-29EU
Mobile
Computer
Quick Start
Guide
Conrm what is in the Box
- H-29/H-29EU
A mobile computer with a barcode scanning feature.
- USB cable
Charge/Communication cable & quick charge
compliant power adapter.
- Battery box
With rechargeable battery.
- Hand strap
- Quick Start Guide
Provides product information and instructions.
* The number of accessories may differ depending on
the product configuration. If any of the accessories
are damaged or missing, please contact your local
representative.
General View
Charging Instructions
Battery Installation
The H-29(EU) battery pack is initially not fully charged.
After installing the battery pack, please charge it via
the USB cable or via the charging cradle. By default, the
battery pack is not installed in the H-29(EU) at the factory
to avoid damage caused by excessive draining.
Annual replacement of the battery pack can avoid
possible risks or abnormalities and ensures maximum
performance. Do not store fully charged or (almost)
empty batteries for long periods of time. We recommend
charging the spare battery pack every two to three
months to keep its charge at a moderate level to
maximize battery life.
Please remove the hand strap first when opening the
battery compartment. Push the battery cover lock switch
to open position then remove the battery cover. Please
make sure that the battery contacts are properly aligned
with the contacts of the terminal. Close the battery cover
and push the cover lock switch to lock.
Front View Back View
Top View Bottom View
Keypad
1. Battery slot
2. Battery pack
3. Battery cover
1. Logo and indicator area
2. Android function key area
(Back, Home, Menu key)
1. Battery contact
2. SIM card slot (H-29EU model)
3. Micro SD card slot
4. Battery cover lock switch
5. Hand strap hook
6. Speaker
7. Flash LED
8. Camera
1. Scan Window 1. Cradle IO connect
1. Enter
2. Back space
3. → Key
4. ↓ Key
5. Scan key
6. ↑ Key
7. ← Key
8. Esc
9. Ta b
10. Orange change
11. Blue change
12. * Key
13. # Key
1. Earphone connector
2. Power button
3. Scan button
4. Volume up
5. Volume down
6. Scan button
7. USB connector
CAUTION
RISK OF EXPLOSION IF
BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED
BATTERIES ACCORDINGTO
LOCAL REGULATIONS
BC
Charging Time
The required charging time depends on the actual
application running on the H-29(EU) and the condition of
the battery pack.
The H-29(EU) is shipped with a Lithium-ion battery but not
fully charged. Please fully charge it before the 1st time use.
Charging via USB Cable
Use the provided USB charge & communication cable
together with the quick charge compliant power adapter
to charge the H-29(EU).
Charging via Charging Cradle
Connect the cradle with a power adapter to a power
outlet. Place the H-29(EU) on the cradle for charging.
H-29
H-29EU
Mobile
Computer
Quick Start
Guide
Conrm what is in the Box
- H-29/H-29EU
A mobile computer with a barcode scanning feature.
- USB cable
Charge/Communication cable & quick charge
compliant power adapter.
- Battery box
With rechargeable battery.
- Hand strap
- Quick Start Guide
Provides product information and instructions.
* The number of accessories may differ depending on
the product configuration. If any of the accessories
are damaged or missing, please contact your local
representative.
General View
Charging Instructions
Battery Installation
The H-29(EU) battery pack is initially not fully charged.
After installing the battery pack, please charge it via
the USB cable or via the charging cradle. By default, the
battery pack is not installed in the H-29(EU) at the factory
to avoid damage caused by excessive draining.
Annual replacement of the battery pack can avoid
possible risks or abnormalities and ensures maximum
performance. Do not store fully charged or (almost)
empty batteries for long periods of time. We recommend
charging the spare battery pack every two to three
months to keep its charge at a moderate level to
maximize battery life.
Please remove the hand strap first when opening the
battery compartment. Push the battery cover lock switch
to open position then remove the battery cover. Please
make sure that the battery contacts are properly aligned
with the contacts of the terminal. Close the battery cover
and push the cover lock switch to lock.
Front View Back View
Top View Bottom View
Keypad
1. Battery slot
2. Battery pack
3. Battery cover
1. Logo and indicator area
2. Android function key area
(Back, Home, Menu key)
1. Battery contact
2. SIM card slot (H-29EU model)
3. Micro SD card slot
4. Battery cover lock switch
5. Hand strap hook
6. Speaker
7. Flash LED
8. Camera
1. Scan Window 1. Cradle IO connect
1. Enter
2. Back space
3. → Key
4. ↓ Key
5. Scan key
6. ↑ Key
7. ← Key
8. Esc
9. Ta b
10. Orange change
11. Blue change
12. * Key
13. # Key
1. Earphone connector
2. Power button
3. Scan button
4. Volume up
5. Volume down
6. Scan button
7. USB connector
CAUTION
RISK OF EXPLOSION IF
BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED
BATTERIES ACCORDINGTO
LOCAL REGULATIONS
BC
Charging Time
The required charging time depends on the actual
application running on the H-29(EU) and the condition of
the battery pack.
The H-29(EU) is shipped with a Lithium-ion battery but not
fully charged. Please fully charge it before the 1st time use.
Charging via USB Cable
Use the provided USB charge & communication cable
together with the quick charge compliant power adapter
to charge the H-29(EU).
Charging via Charging Cradle
Connect the cradle with a power adapter to a power
outlet. Place the H-29(EU) on the cradle for charging.
H-29
H-29EU
Mobile
Computer
Quick Start
Guide
Conrm what is in the Box
- H-29/H-29EU
A mobile computer with a barcode scanning feature.
- USB cable
Charge/Communication cable & quick charge
compliant power adapter.
- Battery box
With rechargeable battery.
- Hand strap
- Quick Start Guide
Provides product information and instructions.
* The number of accessories may differ depending on
the product configuration. If any of the accessories
are damaged or missing, please contact your local
representative.
General View
Charging Instructions
Battery Installation
The H-29(EU) battery pack is initially not fully charged.
After installing the battery pack, please charge it via
the USB cable or via the charging cradle. By default, the
battery pack is not installed in the H-29(EU) at the factory
to avoid damage caused by excessive draining.
Annual replacement of the battery pack can avoid
possible risks or abnormalities and ensures maximum
performance. Do not store fully charged or (almost)
empty batteries for long periods of time. We recommend
charging the spare battery pack every two to three
months to keep its charge at a moderate level to
maximize battery life.
Please remove the hand strap first when opening the
battery compartment. Push the battery cover lock switch
to open position then remove the battery cover. Please
make sure that the battery contacts are properly aligned
with the contacts of the terminal. Close the battery cover
and push the cover lock switch to lock.
Front View Back View
Top View Bottom View
Keypad
1. Battery slot
2. Battery pack
3. Battery cover
1. Logo and indicator area
2. Android function key area
(Back, Home, Menu key)
1. Battery contact
2. SIM card slot (H-29EU model)
3. Micro SD card slot
4. Battery cover lock switch
5. Hand strap hook
6. Speaker
7. Flash LED
8. Camera
1. Scan Window 1. Cradle IO connect
1. Enter
2. Back space
3. → Key
4. ↓ Key
5. Scan key
6. ↑ Key
7. ← Key
8. Esc
9. Ta b
10. Orange change
11. Blue change
12. * Key
13. # Key
1. Earphone connector
2. Power button
3. Scan button
4. Volume up
5. Volume down
6. Scan button
7. USB connector
CAUTION
RISK OF EXPLOSION IF
BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED
BATTERIES ACCORDINGTO
LOCAL REGULATIONS
BC
Charging Time
The required charging time depends on the actual
application running on the H-29(EU) and the condition of
the battery pack.
The H-29(EU) is shipped with a Lithium-ion battery but not
fully charged. Please fully charge it before the 1st time use.
Charging via USB Cable
Use the provided USB charge & communication cable
together with the quick charge compliant power adapter
to charge the H-29(EU).
Charging via Charging Cradle
Connect the cradle with a power adapter to a power
outlet. Place the H-29(EU) on the cradle for charging.
Documentation
Documentation, drivers and software updates for the
H-29(EU) are available at:www.opticon.com
Opticon Sensors Europe BV
Opaallaan 35, 2132 XV Hoofddorp, the Netherlands.
© Copyright Opticon. All rights reserved. This information
is subject to change without prior notice.
For availability, contact your local representative.
SD / SIM Card Installation (H-29EU model)
1. Turn off the H-29EU or put it in battery swap mode
2. Remove the battery cover
3. Remove the battery pack by pulling the tab on the end
of the battery
4. Lift the retaining door
5. Please see the back view
6. Insert the micro SD card into the left slot
7. Insert the SIM card into the right slot
8. Insert the battery pack into the battery compartment
9. Restore the battery cover and lock the battery cover
lock switch
Barcode Data Capture
To scan a barcode label:
1. Point the scan window at the barcode.
2. Tap scan on the screen or press one of the scan buttons
on the H-29(EU). The imager will project a green
aiming bar. The green aiming bar is used to position the
barcode or object within the field of view of the imager.
3. Ensure the entire barcode is within the width area
formed by the green aiming bar, then either wait for
the timeout or release the scan key to capture the
image. A white beam will illuminates the barcode to
capture and decode it.
FCC Compliance for H-29
This Device complies with Part 15 of the FCC rules,
operation is subject to the following two conditions.
(1) This device may not cause harmful interference and,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation if this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
General Safety Rules
Please read this Guide thoroughly and carefully before you start using
this device. Use only the components and accessories supplied by the
manufacturer for H-29(EU) you are using.
Do not attempt to disassemble H-29(EU), as it does not contain parts that
can be repaired by the user. Any tampering will void the warranty. When
replacing the battery pack or at the end of life of H-29(EU) disposal must be
performed in compliance with the laws in force in your jurisdiction. Do not
submerge H-29(EU) in any liquid (water, detergent, etc).
For Safe Use Concern, Please Pay Special Attention on the Following Notices:
The manufacturer has taken safety as first priority during design stage. To
avoid any potential accident, please be cautious on the following alert points:
• Please do not stock this device under conditions of high temperature
which will cause the battery to become hot, fire, or broken etc. leading to
failure and safety concerns.
• When the charging time is noticed longer than standard required
(CHARGING LED, RED, is still ON), please stop charging immediately.
• Please charge this device in place without any water-spray or moisture.
• Ensure that the AC adapter can freely dissipate its heat, don’t cover the AC
adapter with objects, such as curtains.
• Never use damaged AC adapters, immediately replace it with a new
approved AC adapter.
• Please do not put any heavy weight on top of this device as it might cause
device enclosure crack then lead to cutting injury.
• Please do not use wet hand to pull out the AC adapter which might cause
electric shock.
• Please do not use H-29(EU) AC adapter on any other different devices.
• Please do not put the device into water which may cause short-circuit or fire.
• Please do not put this device in place close to open fire.
• If the power or USB cable is seriously twisted or broken, please stop using
immediately or it may cause electric shock, short-circuit, or fire.
• Please stop using immediately when there is any unusual smell or overheat
during charging or operation.
• Please stop using immediately when there is any liquid or dew on the device.
• Please do not use the AC adapter outdoor. Please do not wrap the AC
adapter with cloth which will block heat dissipation and will cause electric
shock or fire.
• Except charging, please remove the AC adapter plug from the wall AC
outlet socket or it will cause fire accident.
Important Notices When Using
• Before replacing battery pack due to failure, shortened life, or any other
unusual behavior, please confirm if the device has been used correctly and
there has no user operation issue involved.
• It is possible there will be some missed data or interference encountered
during the wireless transmission. It is not a situation can be controlled by
the manufacturer.
• Please do not use any alcohol, benzene, organic solvent, cleaner liquid, or
steel-wool on the surface of this device.
• Please do not scratch the surface of Scan Window in any way as which will
cause problem on barcode scanning.
Audio Safety
To prevent possible hearing damage, do no listen at high volume for long periods.
European Union Regulatory Notes
Hereby, Opticon Sensors Europe B.V. declares that the radio equipment type H-29(EU)
is in compliance with Directive 2014/53/EU. The WiFi operating in the bands 5150 –
5350 MHz shall be restricted to indoor use for countries listed in the table below:
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
The full text of the Declaration of Conformity is available at the following internet
address: https://opticon.com/product/h-29/
SAR Compliance (H-29EU) SAR Compliance (H-29)
SAR Information (for EU): SAR Information (for EU):
Head: 0.328 W/kg@ 10g (CE) Head: 0.288 W/kg@ 10g (CE)
Body: 1.600 W/kg@ 10g (CE) Body: 0.320 W/kg@ 10g CE)
Body - worn Operation
This device was tested for typical body-worn operations. A minimum separation
distance must be maintained between the user’s body and the handset, including the
antenna: 0.5 cm to comply with the RF exposure requirements in Europe third-party
belt-clips, holsters and similar accessories used by this device should not contain any
metallic components. Body-warn accessories that do not meet these requirements
may not comply with RF exposure requirements and should be avoided.
Power and Frequency Ranges
H-29EU
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
GSM GSM 900 880~915 MHz 32dBm
GSM 1800 1710~1785 MHz 30.5dBm
WCDMA WCDMA Band I 1920~1980 MHz 24dBm
WCDMA Band VIII 880~915 MHz 24dBm
LTE LTE Band 1 1920~1980 MHz 23dBm
LTE Band 3 1710~1785 MHz 23dBm
LTE Band 7 2500~2570 MHz 23dBm
LTE Band 8 880~915 MHz 23dBm
LTE Band 20 832~862 MHz 23dBm
LTE Band 38 2570~2620 MHz 24dBm
LTE Band 40 2300~2400 MHz 23dBm
other NFC 13.56 MHz
GPS 1575.42 MHz
H-29
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
other NFC 13.56 MHz
Documentation
Documentation, drivers and software updates for the
H-29(EU) are available at:www.opticon.com
Opticon Sensors Europe BV
Opaallaan 35, 2132 XV Hoofddorp, the Netherlands.
© Copyright Opticon. All rights reserved. This information
is subject to change without prior notice.
For availability, contact your local representative.
SD / SIM Card Installation (H-29EU model)
1. Turn off the H-29EU or put it in battery swap mode
2. Remove the battery cover
3. Remove the battery pack by pulling the tab on the end
of the battery
4. Lift the retaining door
5. Please see the back view
6. Insert the micro SD card into the left slot
7. Insert the SIM card into the right slot
8. Insert the battery pack into the battery compartment
9. Restore the battery cover and lock the battery cover
lock switch
Barcode Data Capture
To scan a barcode label:
1. Point the scan window at the barcode.
2. Tap scan on the screen or press one of the scan buttons
on the H-29(EU). The imager will project a green
aiming bar. The green aiming bar is used to position the
barcode or object within the field of view of the imager.
3. Ensure the entire barcode is within the width area
formed by the green aiming bar, then either wait for
the timeout or release the scan key to capture the
image. A white beam will illuminates the barcode to
capture and decode it.
FCC Compliance for H-29
This Device complies with Part 15 of the FCC rules,
operation is subject to the following two conditions.
(1) This device may not cause harmful interference and,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation if this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
General Safety Rules
Please read this Guide thoroughly and carefully before you start using
this device. Use only the components and accessories supplied by the
manufacturer for H-29(EU) you are using.
Do not attempt to disassemble H-29(EU), as it does not contain parts that
can be repaired by the user. Any tampering will void the warranty. When
replacing the battery pack or at the end of life of H-29(EU) disposal must be
performed in compliance with the laws in force in your jurisdiction. Do not
submerge H-29(EU) in any liquid (water, detergent, etc).
For Safe Use Concern, Please Pay Special Attention on the Following Notices:
The manufacturer has taken safety as first priority during design stage. To
avoid any potential accident, please be cautious on the following alert points:
• Please do not stock this device under conditions of high temperature
which will cause the battery to become hot, fire, or broken etc. leading to
failure and safety concerns.
• When the charging time is noticed longer than standard required
(CHARGING LED, RED, is still ON), please stop charging immediately.
• Please charge this device in place without any water-spray or moisture.
• Ensure that the AC adapter can freely dissipate its heat, don’t cover the AC
adapter with objects, such as curtains.
• Never use damaged AC adapters, immediately replace it with a new
approved AC adapter.
• Please do not put any heavy weight on top of this device as it might cause
device enclosure crack then lead to cutting injury.
• Please do not use wet hand to pull out the AC adapter which might cause
electric shock.
• Please do not use H-29(EU) AC adapter on any other different devices.
• Please do not put the device into water which may cause short-circuit or fire.
• Please do not put this device in place close to open fire.
• If the power or USB cable is seriously twisted or broken, please stop using
immediately or it may cause electric shock, short-circuit, or fire.
• Please stop using immediately when there is any unusual smell or overheat
during charging or operation.
• Please stop using immediately when there is any liquid or dew on the device.
• Please do not use the AC adapter outdoor. Please do not wrap the AC
adapter with cloth which will block heat dissipation and will cause electric
shock or fire.
• Except charging, please remove the AC adapter plug from the wall AC
outlet socket or it will cause fire accident.
Important Notices When Using
• Before replacing battery pack due to failure, shortened life, or any other
unusual behavior, please confirm if the device has been used correctly and
there has no user operation issue involved.
• It is possible there will be some missed data or interference encountered
during the wireless transmission. It is not a situation can be controlled by
the manufacturer.
• Please do not use any alcohol, benzene, organic solvent, cleaner liquid, or
steel-wool on the surface of this device.
• Please do not scratch the surface of Scan Window in any way as which will
cause problem on barcode scanning.
Audio Safety
To prevent possible hearing damage, do no listen at high volume for long periods.
European Union Regulatory Notes
Hereby, Opticon Sensors Europe B.V. declares that the radio equipment type H-29(EU)
is in compliance with Directive 2014/53/EU. The WiFi operating in the bands 5150 –
5350 MHz shall be restricted to indoor use for countries listed in the table below:
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
The full text of the Declaration of Conformity is available at the following internet
address: https://opticon.com/product/h-29/
SAR Compliance (H-29EU) SAR Compliance (H-29)
SAR Information (for EU): SAR Information (for EU):
Head: 0.328 W/kg@ 10g (CE) Head: 0.288 W/kg@ 10g (CE)
Body: 1.600 W/kg@ 10g (CE) Body: 0.320 W/kg@ 10g CE)
Body - worn Operation
This device was tested for typical body-worn operations. A minimum separation
distance must be maintained between the user’s body and the handset, including the
antenna: 0.5 cm to comply with the RF exposure requirements in Europe third-party
belt-clips, holsters and similar accessories used by this device should not contain any
metallic components. Body-warn accessories that do not meet these requirements
may not comply with RF exposure requirements and should be avoided.
Power and Frequency Ranges
H-29EU
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
GSM GSM 900 880~915 MHz 32dBm
GSM 1800 1710~1785 MHz 30.5dBm
WCDMA WCDMA Band I 1920~1980 MHz 24dBm
WCDMA Band VIII 880~915 MHz 24dBm
LTE LTE Band 1 1920~1980 MHz 23dBm
LTE Band 3 1710~1785 MHz 23dBm
LTE Band 7 2500~2570 MHz 23dBm
LTE Band 8 880~915 MHz 23dBm
LTE Band 20 832~862 MHz 23dBm
LTE Band 38 2570~2620 MHz 24dBm
LTE Band 40 2300~2400 MHz 23dBm
other NFC 13.56 MHz
GPS 1575.42 MHz
H-29
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
other NFC 13.56 MHz
Documentation
Documentation, drivers and software updates for the
H-29(EU) are available at:www.opticon.com
Opticon Sensors Europe BV
Opaallaan 35, 2132 XV Hoofddorp, the Netherlands.
© Copyright Opticon. All rights reserved. This information
is subject to change without prior notice.
For availability, contact your local representative.
SD / SIM Card Installation (H-29EU model)
1. Turn off the H-29EU or put it in battery swap mode
2. Remove the battery cover
3. Remove the battery pack by pulling the tab on the end
of the battery
4. Lift the retaining door
5. Please see the back view
6. Insert the micro SD card into the left slot
7. Insert the SIM card into the right slot
8. Insert the battery pack into the battery compartment
9. Restore the battery cover and lock the battery cover
lock switch
Barcode Data Capture
To scan a barcode label:
1. Point the scan window at the barcode.
2. Tap scan on the screen or press one of the scan buttons
on the H-29(EU). The imager will project a green
aiming bar. The green aiming bar is used to position the
barcode or object within the field of view of the imager.
3. Ensure the entire barcode is within the width area
formed by the green aiming bar, then either wait for
the timeout or release the scan key to capture the
image. A white beam will illuminates the barcode to
capture and decode it.
FCC Compliance for H-29
This Device complies with Part 15 of the FCC rules,
operation is subject to the following two conditions.
(1) This device may not cause harmful interference and,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation if this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
General Safety Rules
Please read this Guide thoroughly and carefully before you start using
this device. Use only the components and accessories supplied by the
manufacturer for H-29(EU) you are using.
Do not attempt to disassemble H-29(EU), as it does not contain parts that
can be repaired by the user. Any tampering will void the warranty. When
replacing the battery pack or at the end of life of H-29(EU) disposal must be
performed in compliance with the laws in force in your jurisdiction. Do not
submerge H-29(EU) in any liquid (water, detergent, etc).
For Safe Use Concern, Please Pay Special Attention on the Following Notices:
The manufacturer has taken safety as first priority during design stage. To
avoid any potential accident, please be cautious on the following alert points:
• Please do not stock this device under conditions of high temperature
which will cause the battery to become hot, fire, or broken etc. leading to
failure and safety concerns.
• When the charging time is noticed longer than standard required
(CHARGING LED, RED, is still ON), please stop charging immediately.
• Please charge this device in place without any water-spray or moisture.
• Ensure that the AC adapter can freely dissipate its heat, don’t cover the AC
adapter with objects, such as curtains.
• Never use damaged AC adapters, immediately replace it with a new
approved AC adapter.
• Please do not put any heavy weight on top of this device as it might cause
device enclosure crack then lead to cutting injury.
• Please do not use wet hand to pull out the AC adapter which might cause
electric shock.
• Please do not use H-29(EU) AC adapter on any other different devices.
• Please do not put the device into water which may cause short-circuit or fire.
• Please do not put this device in place close to open fire.
• If the power or USB cable is seriously twisted or broken, please stop using
immediately or it may cause electric shock, short-circuit, or fire.
• Please stop using immediately when there is any unusual smell or overheat
during charging or operation.
• Please stop using immediately when there is any liquid or dew on the device.
• Please do not use the AC adapter outdoor. Please do not wrap the AC
adapter with cloth which will block heat dissipation and will cause electric
shock or fire.
• Except charging, please remove the AC adapter plug from the wall AC
outlet socket or it will cause fire accident.
Important Notices When Using
• Before replacing battery pack due to failure, shortened life, or any other
unusual behavior, please confirm if the device has been used correctly and
there has no user operation issue involved.
• It is possible there will be some missed data or interference encountered
during the wireless transmission. It is not a situation can be controlled by
the manufacturer.
• Please do not use any alcohol, benzene, organic solvent, cleaner liquid, or
steel-wool on the surface of this device.
• Please do not scratch the surface of Scan Window in any way as which will
cause problem on barcode scanning.
Audio Safety
To prevent possible hearing damage, do no listen at high volume for long periods.
European Union Regulatory Notes
Hereby, Opticon Sensors Europe B.V. declares that the radio equipment type H-29(EU)
is in compliance with Directive 2014/53/EU. The WiFi operating in the bands 5150 –
5350 MHz shall be restricted to indoor use for countries listed in the table below:
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
The full text of the Declaration of Conformity is available at the following internet
address: https://opticon.com/product/h-29/
SAR Compliance (H-29EU) SAR Compliance (H-29)
SAR Information (for EU): SAR Information (for EU):
Head: 0.328 W/kg@ 10g (CE) Head: 0.288 W/kg@ 10g (CE)
Body: 1.600 W/kg@ 10g (CE) Body: 0.320 W/kg@ 10g CE)
Body - worn Operation
This device was tested for typical body-worn operations. A minimum separation
distance must be maintained between the user’s body and the handset, including the
antenna: 0.5 cm to comply with the RF exposure requirements in Europe third-party
belt-clips, holsters and similar accessories used by this device should not contain any
metallic components. Body-warn accessories that do not meet these requirements
may not comply with RF exposure requirements and should be avoided.
Power and Frequency Ranges
H-29EU
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
GSM GSM 900 880~915 MHz 32dBm
GSM 1800 1710~1785 MHz 30.5dBm
WCDMA WCDMA Band I 1920~1980 MHz 24dBm
WCDMA Band VIII 880~915 MHz 24dBm
LTE LTE Band 1 1920~1980 MHz 23dBm
LTE Band 3 1710~1785 MHz 23dBm
LTE Band 7 2500~2570 MHz 23dBm
LTE Band 8 880~915 MHz 23dBm
LTE Band 20 832~862 MHz 23dBm
LTE Band 38 2570~2620 MHz 24dBm
LTE Band 40 2300~2400 MHz 23dBm
other NFC 13.56 MHz
GPS 1575.42 MHz
H-29
Radio Type Description Frequency Maximum
Output
Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm
Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm
WLAN 2.4GHz 2400~2483.5 MHz 17dBm
5GHz 5150~5350 MHz 21dBm
5470~5725 MHz 22dBm
other NFC 13.56 MHz
Table of contents
Other Opticon PDA manuals
