OPTIMUM Maschinen OPTidrill B 34H User manual

GB
Operating manual
Version 1.1.3
Upright drilling machine
Part no. 3020333
Part no. 3020335

Version 1.1.3 - 2020-07-212 Original operating instructions
B34H | B34HV
GB
B34H_B34HV_GBIVZ.fm
Table of contents
1 Safety
1.1 Rating plates.................................................................................................................................................. 6
1.2 Safety instructions (warning notes)................................................................................................................ 7
1.2.1 Classification of hazards.................................................................................................................. 7
1.2.2 Other pictograms.............................................................................................................................. 7
1.3 Intended use.................................................................................................................................................. 8
1.4 Reasonably foreseeable misuses.................................................................................................................. 9
1.4.1 Avoiding misuses........................................................................................................................... 10
1.5 Possible dangers caused by the geared drill............................................................................................... 10
1.6 Qualification of personnel............................................................................................................................ 11
1.6.1 Target group................................................................................................................................... 11
1.6.2 Authorized persons........................................................................................................................ 12
1.7 Operator positions ....................................................................................................................................... 12
1.8 Safety measures during operation............................................................................................................... 13
1.9 Safety devices ............................................................................................................................................. 13
1.10 Safety check................................................................................................................................................ 13
1.11 EMERGENCY-STOP push button............................................................................................................... 14
1.12 Drilling table................................................................................................................................................. 15
1.13 Separating protective devices...................................................................................................................... 15
1.13.1 Protective cover of the V-belts....................................................................................................... 15
1.13.2 Drill chuck protection...................................................................................................................... 15
1.14 Personnel protective equipment.................................................................................................................. 16
1.15 Safety during operation................................................................................................................................ 17
1.16 Safety during maintenance.......................................................................................................................... 17
1.16.1 Disconnecting and securing the geared drill.................................................................................. 17
1.17 Using lifting equipment ................................................................................................................................ 17
1.17.1 Mechanical maintenance work....................................................................................................... 18
1.18 Accident report............................................................................................................................................. 18
1.19 Electrical system.......................................................................................................................................... 18
1.20 Inspection deadlines.................................................................................................................................... 18
2 Technical data
2.1 Electrical connection.................................................................................................................................... 19
2.2 Coolant pump .............................................................................................................................................. 19
2.3 Drilling capacity............................................................................................................................................ 19
2.4 Spindle seat................................................................................................................................................. 19
2.5 Drilling table................................................................................................................................................. 19
2.10 Emissions .................................................................................................................................................... 20
2.6 Required space............................................................................................................................................ 20
2.7 Speeds......................................................................................................................................................... 20
2.8 Environmental conditions............................................................................................................................. 20
2.9 Operating material....................................................................................................................................... 20
2.11 Dimensions B34H........................................................................................................................................ 22
2.12 Dimensions B34HV...................................................................................................................................... 23
3 Delivery, interdepartmental transport and unpacking
3.1 Notes on transport, installation and unpacking............................................................................................ 24
3.1.1 General risks during internal transport........................................................................................... 24
4 Assembly
4.1 Scope of delivery......................................................................................................................................... 25
4.1.1 Available optional machine accessories ........................................................................................ 25
4.2 Installation and assembly ............................................................................................................................ 25
4.2.1 Requirements to the installation site.............................................................................................. 25
4.2.2 Mounting of base and drill column ................................................................................................. 25
4.2.3 Mounting the drilling table.............................................................................................................. 27
4.2.4 Fitting the drill head........................................................................................................................ 29
4.3 Installation.................................................................................................................................................... 29
4.4 Fixing........................................................................................................................................................... 30
4.4.1 Installation drawings....................................................................................................................... 31
4.5 First commissioning..................................................................................................................................... 31

Version 1.1.3 - 2020-07-21 3Original operating instructions
B34H | B34HV GB
B34H_B34HV_GBIVZ.fm
4.5.1 Warming up the machine................................................................................................................32
4.5.2 Power supply ..................................................................................................................................32
5Operation
5.1 Control and indicating elements...................................................................................................................33
5.2 Safety...........................................................................................................................................................34
5.2.1 Control panel B34H ........................................................................................................................34
5.2.2 Drill depth stop................................................................................................................................35
5.2.3 Control panel B34 H Vario..............................................................................................................35
5.3 Switching on the machine B34H ..................................................................................................................37
5.4 Switching on the machine B34HV................................................................................................................37
5.5 Switching off the machine B34HV................................................................................................................37
5.6 Digital drilling depth display..........................................................................................................................37
5.6.1 Design.............................................................................................................................................38
5.6.2 Malfunctions....................................................................................................................................38
5.7 Speed change..............................................................................................................................................39
5.7.1 Speed table B34 H..........................................................................................................................40
5.7.2 Speed table B34HV ........................................................................................................................40
5.8 Disassembly, assembly of drill chucks and drill bits.....................................................................................41
5.8.1 Mounting drill chuck B34H / B34HV................................................................................................41
5.8.2 Quick action drill chuck...................................................................................................................41
5.8.3 Disassembly with the integrated drill drift B34H / B34HV..............................................................42
5.9 Cooling.........................................................................................................................................................43
5.10 Before starting work .....................................................................................................................................44
5.11 During work..................................................................................................................................................45
6 Determining the cutting speed and the speed
6.1 Table cutting speeds / infeed .......................................................................................................................46
6.2 Speed table..................................................................................................................................................46
6.3 Examples to calculatory determine the required speed for your drilling machine ........................................48
7 Maintenance
7.1 Safety...........................................................................................................................................................49
7.1.1 Preparation.....................................................................................................................................49
7.1.2 Restarting .......................................................................................................................................50
7.2 Inspection and maintenance ........................................................................................................................50
7.3 Repair...........................................................................................................................................................54
7.3.1 Customer service technician...........................................................................................................54
8 Ersatzteile - Spare parts
8.1 Ersatzteilbestellung - Ordering spare parts..................................................................................................55
8.2 Hotline Ersatzteile - Spare parts Hotline ......................................................................................................55
8.3 Service Hotline.............................................................................................................................................55
8.4 Bohrkopf B34H - Drilling head B34H............................................................................................................56
8.5 Bohrkopf 1 von 5 - Drilling head 1 of 5.........................................................................................................57
8.6 Bohrkopf 2 von 5 - Drilling head 2 of 5.........................................................................................................58
8.7 Ersatzteilzeichnung Bohrkopf 3 von 5 - Parts drawing drilling head 3 of 5 ..................................................59
8.8 Bohrkopf 4 von 5 - Drilling head 4 of 5.........................................................................................................60
8.9 Bohrkopf 5 von 5 - Drilling head 5 of 5.........................................................................................................61
8.9.1 Bohrfutterschutz - Drilling chuck protection ....................................................................................62
8.9.2 Säule und Bohrtisch - Column and drilling table.............................................................................63
8.10 Maschinenschilder - Machine labels B34H ..................................................................................................64
8.11 Schaltplan - Wiring diagram B34 H ..............................................................................................................69
8.11.1 Ersatzteilliste elektrische Bauteile - Spare parts electrical components - B34H.............................70
8.12 Ersatzteilzeichnung B34HV - Explosion drawing B34HV.............................................................................71
8.13 Bohrkopf B34HV - Drilling head B34HV.......................................................................................................71
8.14 Bohrkopf 1 von 5 - Drilling head 1 of 5.........................................................................................................72
8.15 Bohrkopf 2 von 5 - Drilling head 2 of 5.........................................................................................................73
8.16 Bohrkopf 3 von 5 - Drilling head 3 of 5.........................................................................................................74
8.17 Bohrkopf 4 von 5 - Drilling head 4 of 5.........................................................................................................75
8.18 Bohrkopf 5 von 5 - Drilling head 5 of 5.........................................................................................................76
8.19 Bohrfutterschutz - Drilling chuck protection..................................................................................................77
8.20 Säule und Bohrtisch - Column and drilling table ..........................................................................................78
8.21 Maschinenschilder - Machine labels B34HV................................................................................................79
8.21.1 Ersatzteilliste - Spare part list - B34HV...........................................................................................79

Version 1.1.3 - 2020-07-214 Original operating instructions
B34H | B34HV
GB
B34H_B34HV_GBIVZ.fm
8.22 Schaltplan - Wiring diagram B34 H Vario 1- 2............................................................................................. 85
8.22.1 Schaltplan - Wiring diagram B34 H Varo 2-2................................................................................. 86
8.22.2 Ersatzteilliste elektrische Bauteile - Spare parts electrical components B34HV............................ 87
9 Malfunctions
10 Appendix
10.1 Copyright ..................................................................................................................................................... 90
10.2 Terminology/Glossary.................................................................................................................................. 90
10.3 Change information operating manual......................................................................................................... 90
10.4 Liability claims for defects / warranty........................................................................................................... 91
10.5 Note regarding disposal / options to reuse: ................................................................................................. 91
10.5.1 Decommissioning........................................................................................................................... 92
10.5.2 Disposal of the packaging of new devices..................................................................................... 92
10.5.3 Disposing of the old device............................................................................................................ 92
10.5.4 Disposal of electrical and electronic components..........................................................................92
10.5.5 Disposal of lubricants and coolants................................................................................................ 93
10.6 Disposal via municipal collection................................................................................................................. 93
10.7 Storage........................................................................................................................................................ 93
10.8 Product follow-up......................................................................................................................................... 94

Version 1.1.3 - 2020-07-21 5Translation of the original instructions
B34H | B34HV GB
_preface_GB.fm
Preface
Dear customer,
Thank you very much for purchasing a product made by OPTIMUM.
OPTIMUM metal working machines offer a maximum of quality, technically optimum solutions
and convince by an outstanding price performance ratio. Continuous enhancements and pro-
duct innovations guarantee state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get
familiar with the machine. Please also make sure that all persons operating the machine have
read and understood the operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, opera-
tion and maintenance of the machine. The continuous observance of all notes included in this
manual guarantee the safety of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information
for its economic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which
the operator must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the
current state of construction of your machine. Being the manufacturer we are continuously see-
king for improvements and renewal of the products. Therefore, changes might be performed
without prior notice. The illustrations of the machine may be different from the illustrations in
these instructions with regard to a few details. However, this does not have any influence on
the operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors
are reserved !
Your suggestion with regard to these operating instructions are an important contribution to
optimising our work which we offer to our customers. For any questions or suggestions for
improvement, please do not hesitate to contact our service department.
If you have any further questions after reading these operating instructions and you are
not able to solve your problem with a help of these operating instructions, please
contact your specialised dealer or directly the company OPTIMUM.
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D-96103 Hallstadt
Fax (+49)0951 / 96555 - 888
Email: [e-mail]
Internet: www.optimum-machines.com

Safety
Version 1.1.3 - 2020-07-216 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
1 Safety
Glossary of symbols
This part of the operating instructions
explains the meaning and use of the warning notices included in these operating instructi-
ons,
defines the intended use of the geared drill,
points out the dangers that might arise for you or others if these instructions are not obser-
ved,
informs you about how to avoid dangers.
In addition to these operation instructions, please observe
the applicable laws and regulations,
the legal regulations for accident prevention,
the prohibition, warning and mandatory signs as well as the warning labels on the geared
drill.
Always keep this documentation close to the geared drill.
INFORMATION
If you are unable to solve a problem using these operating instructions, please contact us for
advice:
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D-96103 Hallstadt
email: [e-mail]
1.1 Rating plates
gives further advice
calls on you to act
enumerations
Optimum Maschinen
Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
302 0335
290 kg
2,2kW
230 V ~50 Hz
B 34 HV
5000 U/min
20
NO.
SN
Year
J
Master Labels
DE
GB
ES
FR
IT
CZ
DK
FI
GR
HU
NL
PL
PT
RU
SLO
TR
Säulenbohrmaschine
Søjleboremaskine
Pylväsporakone
Wiertarki
Bormașină
Upright drilling machine
Taladro
Perceuse
Trapano a colonna
Sloupová vrtačka
Επιδαπεδειο Δραπανο
Asztali fúrógép
Boormachine
Máquina de perfuração
Steberni vrtalni stroj
Sütunlu Matkap optimum-maschinen.de
Master Labels
Optimum Maschinen
Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
302 0333
274 kg
1,5/2,2kW
400 V ~50 Hz
B 34 H
4800 U/min
20
NO.
SN
Year
J
DE
GB
ES
FR
IT
CZ
DK
FI
GR
HU
NL
PL
PT
RU
SLO
TR
Säulenbohrmaschine
Søjleboremaskine
Pylväsporakone
Wiertarki
Bormașină
Upright drilling machine
Taladro
Perceuse
Trapano a colonna
Sloupová vrtačka
Επιδαπεδειο Δραπανο
Asztali fúrógép
Boormachine
Máquina de perfuração
Steberni vrtalni stroj
Sütunlu Matkap optimum-maschinen.de

Safety
Version 1.1.3 - 2020-07-21 7Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
1.2 Safety instructions (warning notes)
1.2.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (ideogram) and the warning signs for each specific danger and its
(possible) consequences.
1.2.2 Other pictograms
Ideogram Warning alert Definition / consequence
DANGER! Threatening danger that will cause serious injury or death to people.
WARNING! A danger that might cause severe injury to the staff or can lead to death.
CAUTION!
Danger of unsafe procedure that might cause injury to the staff or property
damages.
ATTENTION!
Situation that could cause damage to the geared drill and products and
other types of damage.
No risk of injury to people.
Information
Application tips and other important or useful information and notes.
No dangerous or harmful consequences for people or objects.
In case of specific dangers, we replace the pictogram by
or
general danger by a warning of injury of hands, hazardous
electrical voltage, rotating parts.
Warning of danger of
slipping! Warning risk of stumbling! Warning hot surface! Warning biological hazard!
Warning of automatic
start-up! Warning tilting danger! Warning of suspended loads! Caution, danger of explosive substances!

Safety
Version 1.1.3 - 2020-07-218 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
1.3 Intended use
WARNING!
In the event of improper use of the geared drill
there may be a risk to the staff,
the machine and other material property of the operating company will be endange-
red,
the correct function of the geared drill may be affected.
The geared drill is designed and manufactured to be used in a non-explosive environment. The
geared drill is designed and manufactured for holes in cold metals or other non flammable
materials or that not constitute a health hazard using a rotating filing-stripping tool that has a
number of grooves for collecting the filings.
If the geared drill is used in any way other than described above, modified without authoriza-
tion of Optimum Maschinen Germany GmbH, then the geared drill is being used improperly.
We will not be held liable for any damages resulting from any operation which is not in accor-
dance with the intended use.
We expressly point out that the guarantee or CE conformity will expire due to any constructive
technical or procedural changes which had not been performed by the company Optimum
Maschinen Germany GmbH.
It is also part of intended use that you
observe the limits of the geared drill,
the operating manual is observed,
the inspection and maintenance instructions are observed.
 Technical data on page 19
WARNING!
Extremely severe injuries.
It is forbidden to make any modifications or alternations to the operation values of the
geared drill. They could endanger the staff and cause damage to the geared drill.
ATTENTION!
If the geared drill is not used as intended or if the safety directives or the operating
instructions are ignored the liability of the manufacturer for any damages to persons or
objects resulting hereof is excluded and the claim under guarantee is becoming null and
void!
Activation forbidden! Use ear protection! Read the operating
instructions before
commissioning!
Disconnect the mains plug!
Use protective glasses! Use protective gloves! Use protective boots! Use protective suit!

Safety
Version 1.1.3 - 2020-07-21 9Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
1.4 Reasonably foreseeable misuses
Any other use as the one determined under the "Intended use" or any use beyond the descri-
bed use shall be deemed as not in conformity and is forbidden.
Any other use has to be discussed with the manufacturer.
It is only allowed to process metal, cold and non-inflammable materials with the geared drill.
In order to avoid misuses it is necessary to read and understand the operating instructions
before the first commissioning.
The operators must be qualified.
INFORMATION
The drilling machine B34HV for regulating the speed is built according to the standard EN
61800-3 class C2.
WARNING!
This machine is not intended for use in residential buildings, in which the power supply
is provided via a public low voltage supply system. In these areas it may possibly be
difficult to guarantee electromagnetic compatibility due to lead bound as well as emitted
interferences.
Overview of the EMC categories:
Categorie C1
required limit values Class B Group 1 according to EN 55011
Categorie C2
Required limit values class A Group 1 according to EN 55011, Installation by EMC experts
and warning: “This is a product of category C2 according to EN 61800-3. This product may
cause radio interference in a residential area. In this case, it may be necessary for the ope-
rator to take appropriate action.“
Categorie C3
Required limit values class A group 2 according to EN 55011, whereby these limit values
are below those of class A group 1, plus warning: „This type is not suitable for connection to
a public low-voltage network supplying residential buildings. When connecting to a public
low voltage network, radio frequency interference is expected. "
Machine B34HV
Categorie C1 C2 C3 C4
Environment Residential area Business area
Industrial area Industrial area
Voltage / Current < 1000 V > 1000 V
EMC knowledge no requirement Installation and commissioning by an EMC expert

Safety
Version 1.1.3 - 2020-07-2110 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
1.4.1 Avoiding misuses
Use of suitable cutting tools.
Adapting the speed adjustment and feed to the material and workpiece.
Clamp workpieces firmly and vibration-free.
ATTENTION!
The workpiece is always to be fixed by a machine vice, jaw chuck or by another
appropriate clamping tool such as for the clamping claws.
WARNING!
Risk of injury caused by workpieces flying off.
Clamp the workpiece in the machine vice. Make sure that the workpiece is firmly clamped in the
machine vice resp. that the machine vice is firmly clamped on the machine table.
Use cooling and lubricating agents to increase the durability of the tool and to improve the
surface quality.
Clamp the cutting tools and workpieces on clean clamping surfaces.
Sufficiently lubricate the machine.
Correctly adjust the bearing clearance and the guidings.
It is recommended:
Insert the drill in a way that it is exactly positioned between the three clamping jaws of the
quick action chuck.
When drilling make sure that
the suitable speed is set depending on the diameter of the drill,
the pressure must only be such that the drill can cut without load
in case of too strong pressure the drill will get worn early or even might break resp. get jam-
med in the hole. If the drill gets jammed immediately stop the main motor by pressing the
emergency stop button,
for hard materials, e.g. steel, use commercial cooling / lubricating agents,
generally always drive the turning spindle out of the workpiece.
1.5 Possible dangers caused by the geared drill
The geared drill is state-of-the-art.
Nevertheless, there is a residual risk as the geared drill operates with
at high speeds,
rotating parts,
with electrical voltages and currents.
We have used construction resources and safety techniques to minimize the health risk to per-
sons resulting from these hazards.
If the geared drill is used and maintained by the staff who are not duly qualified, there may be a
risk resulting from incorrect or unsuitable maintenance of the geared drill.
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
strictly follow these operating instructions.
In the event of improper use
there may be a risk to the staff,
there may be a risk to the machine and other material values,

Safety
Version 1.1.3 - 2020-07-21 11Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
the correct function of the geared drill may be affected.
Always disconnect the geared drill if cleaning or maintenance work is being carried out, or is no
longer in use.
WARNING!
The geared drill may only be used with the safety devices activated.
Disconnect the geared drill immediately whenever you detect a failure in the safety
devices or when they are not mounted!
All additional devices installed by the operator have to be equipped with the prescribed
safety devices.
This is your responsibility being the operating company!
 Safety devices on page 13
1.6 Qualification of personnel
1.6.1 Target group
This manual is addressed to
the operating companies,
the users,
the staff for maintenance works.
Therefore, the warning notes refer to both operation and maintenance of the geared drill.
Determine clearly and explicitly who will be responsible for the different activities on the
machine (operation, maintenance and repair).
Unclear responsibilities constitute a safety risk!
Always disconnect plug of the geared drill from the electrical power supply. This will prevent it
from being used by unauthorized staff.
The qualifications of the staff for the different tasks are mentioned below:
Operator
The operator is instructed by the operating company about the assigned tasks and possible
risks in case of improper behaviour. Any tasks which need to be performed beyond the opera-
tion in the standard mode must only be performed by the operator if it is indicated in these
instructions and if the operating company expressively commissioned the operator.
Electrical specialist
Due to his professional training, knowledge and experience as well as his knowledge of respec-
tive standards and regulations the electrical specialist is able to perform works on the electrical
system and to recognise and avoid any possible dangers himself.
The electrical specialist is specially trained for the working environment in which he is working
and knows the relevant standards and regulations.
Specialist staff
Due to their professional training, knowledge and experience as well as their knowledge of rele-
vant regulations the specialist staff is able to perform the assigned tasks and to recognise and
avoid any possible dangers themselves.
Instructed persons
Instructed persons were instructed by the operating company about the assigned tasks and any
possible risks in case of improper behaviour.

Safety
Version 1.1.3 - 2020-07-2112 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
1.6.2 Authorized persons
WARNING!
Inappropriate operation and maintenance of the geared drill constitutes a danger for the
staff, objects and the environment.
Only authorized staff may operate the geared drill!
Persons authorized to operate and maintain should be trained technical staff and instructed by
the ones who are working for the operating company and for the manufacturer.
The operating company must
Obligations of the
operating
company
train the staff,
instruct the staff in regular intervals (at least once a year) on
- all safety standards that apply to the machine,
- the operation,
- accredited technical guidelines,
check staff‘s state of knowledge,
document the trainings/instructions,
require staff to confirm participation in training/instructions by means of a signature,
check whether the staff is working safety- and risk-conscious and observe the operating
instructions.
The operator must
Obligations of the
operator
have obtained a training regarding the handling of the geared drill,
know the function and mode of action,
before taking the machine in operation
- have read and understood the operating manual,
- be familiar with all safety devices and instructions. Additional
requirements
regarding the
qualification
For work on the following parts there are additional requirements:
Electrical parts or operating agents: shall only be performed by an electrician or under the
guidance and supervision of an electrician.
Before starting work on electrical parts or operating agents, following measures are to be
performed in the following order.
Disconnect all poles.
Secure against switching on.
Check if the machine is zero potential.
1.7 Operator positions
The operator’s position is in front of the geared
drill.

Safety
Version 1.1.3 - 2020-07-21 13Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
Abb.1-1: Operator positions
1.8 Safety measures during operation
CAUTION!
Risk due to inhaling of health hazardous dusts and mist.
Dependent on the material which need to be processed and the used auxiliaries dusts
and mist may be caused which might impair you health.
Make sure that the generated health hazardous dusts and mist are safely sucked off at
the point of origin and is dissipated or filtered from the working area. To do so, use a
suitable extraction unit.
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Before processing inflammable materials (e.g. aluminium, magnesium) or using
inflammable auxiliary materials (e.g. spirit) it is necessary to take additional preventive
measures in order to safely avoid health risks.
1.9 Safety devices
Use the geared drill only with properly functioning safety devices.
Stop the geared drill immediately if there is a failure on the safety device or if it is not functio-
ning for any reason.
It is your responsibility!
If a safety device has been activated or has failed, the geared drill must only be used if you
have removed the cause of the failure,
have verified that there is no danger resulting for the staff or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other persons working on the geared drill. The possible consequences are
injuries may occur due to workpiece or parts of workpieces flying off,
contact with rotating parts,
a fatal electrocution,
The geared drill includes the following safety devices:
an EMERGENCY STOP push button,
a drilling table with T-slots to fix the workpiece or a vice,
a protective cover for the pulleys with positioning switch,
a drill chuck guard, in order to prevent interference with the rotating tool.
WARNING!
The separating protective equipment which is made available and delivered together
with the machine is designed to reduce the risk of workpieces or fractions of them which
being expelled, but not to remove them completely. Always work carefully and observe
the limit values of your chipping process.
1.10 Safety check
Check the geared drill before each start-up or at least once per shift. Inform the person respon-
sible immediately of any damage, defect or change in operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),

Safety
Version 1.1.3 - 2020-07-2114 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
once a week (with the machine in operation),
after every maintenance and repair work.
Check that prohibition, warning and information signs and the labels on the geared drill
are legible (clean them, if necessary),
are complete (replace if necessary).
INFORMATION
Use the following table in order to organize the checks.
1.11 EMERGENCY-STOP push button
CAUTION!
Also after actuating the
EMERGENCY-STOP switch,
the drilling spindle is
turning - depending on the
previously selected speed -
for a few seconds more.
Abb.1-2: Emergency stop
General check
Equipment Check OK
Protective covers Mounted, firmly bolted and not damaged
Signs,
Markings Installed and legible
Date: checked by (signature):
Functional check
Equipment Check OK
EMERGENCY-STOP
push button After actuating an EMERGENCY STOP push button the geared drill must be switched off.
Limit switch protective
cover
V-belt
The geared drill must not be switched on, if the protective cover
of the V-belts is opened. An opening of the protective cover
during machine operating turns off the machine.
Drill chuck protection The geared drill must only be switched on, if the drill chuck
protection is closed. The engine must switch off when the drill
chuck protection is opened during operation.
Date: checked by (signature):
EMERGENCY-
STOP
push button

Safety
Version 1.1.3 - 2020-07-21 15Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
1.12 Drilling table
Seats for T-slots are atta-
ched to the drilling table.
WARNING!
Risk of injury due to
workpieces flying off at
high speed. Securely fix the
workpiece on the drilling
table.
Abb.1-3: Drilling table
1.13 Separating protective devices
1.13.1 Protective cover of the V-belts
A protective cover for the belt pul-
leys is mounted on the drilling
head. A switch is integrated in the
protective cover which monitors
that the cover is closed.
INFORMATION
You cannot start the machine if the
protective cover is not closed.
Abb.1-4: Protective cover
1.13.2 Drill chuck protection
Adjust the protective equipment to
the correct height before you start
working.
To do so, detach the clamping screw,
adjust the required height and re-
tighten the clamping screw.
A switch is integrated in the fixture of
the spindle protection which moni-
tors that the cover is closed.
Holding fixture for
inserted tongues
Protective
cover
Clamping screw
Drill chuck
protection

Safety
Version 1.1.3 - 2020-07-2116 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
INFORMATION
You cannot start the machine if the drill chuck protection is not closed.
Abb.1-5: Drill chuck protection
1.14 Personnel protective equipment
For certain work individual protection gear as protective equipment. This includes:
Safety helmet,
Protective goggles or face guard,
Protective gloves,
Safety shoes with steel toe caps,
Ear protection.
Before starting work, make sure that the prescribed individual protection gear is available in the
workplace.
CAUTION!
Dirty or contaminated personnel protective equipment can cause diseases.
Clean your individual protection gear
after each use,
regularly, at least once a week.
Personal protective equipment for special works
Protect your face and eyes: Wear a safety helmet with facial protection when performing works
where your face and eyes are exposed to hazards.
Use protective gloves when handling pieces with sharp edges.
Use safety shoes when you assemble, disassemble or transport heavy components.

Safety
Version 1.1.3 - 2020-07-21 17Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_1.fm
1.15 Safety during operation
We specially point out the specific dangers when working with and on the geared drill.
WARNING!
Before switching on the geared drill make sure that there are no
no dangers generated for persons,
not cause damage to equipment.
Avoid any risky working practices:
Make sure, your work does not endanger anyone.
The instructions mentioned in these operating instructions have to be strictly observed
during assembly, operation, maintenance and repair.
Do not work on the geared drill, if your concentration is reduced, for example, because you
are taking medication.
Observe the accident prevention regulations issued by your Employers Liability Insurance
Association or other competent supervisory authority, responsible for your company.
Inform the supervisor about all endangerments or errors.
Stay at the geared drill until all movements have come to a complete standstill.
Use the prescribed personnel protective equipment. Make sure to wear a well-fitting work
suit and, if necessary, a hairnet.
Do not use protective gloves when drilling or milling.
1.16 Safety during maintenance
Inform the operators in good time about any maintenance and repair works.
Report all safety relevant changes and performance details of the geared drill. Document all
changes, have the operating manual changed accordingly and train the machine operators.
1.16.1 Disconnecting and securing the geared drill
Switch off the geared drill with the main switch and secure the main switch with a padlock
against unauthorised switching-on or switching-on by accident.
All machine parts as well as any dangerous voltages are switched off. Excepted are only the
positions which are marked with the adjoining pictogram.
1.17 Using lifting equipment
WARNING!
The use of unstable lifting and load suspension gear that might break under load can
cause severe injuries or even death.
Check that the lifting and load suspension gear
they have sufficient load carrying
and that it is in perfect condition.
Observe the accident prevention regulations issued by your Employers Liability
Insurance Association or other competent supervisory authority, responsible for your
company.
Fasten the loads properly. Never walk under suspended loads!

Safety
Version 1.1.3 - 2020-07-2118 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_1.fm
1.17.1 Mechanical maintenance work
Remove or install protection and safety devices before starting any maintenance work and re-
install them once the work has been completed.This includes:
Covers,
Safety indications and warning signs,
earth (ground) connections.
Check if they are working properly!
1.18 Accident report
Inform your superiors and Optimum Maschinen Germany GmbH immediately in the event of
accidents, possible sources of danger and any actions which almost led to an accident (near
misses).
There are many possible causes for "near misses".
The sooner they are notified, the faster the causes can be eliminated.
1.19 Electrical system
Have the machine and/or the electric equipment checked regularly. Immediately eliminate all
defects such as loose connections, defective wires, etc.
A second person must be present during work on live components to disconnect the power in
the event of an emergency. Disconnect the machine immediately if there is a malfunction in the
power supply!
Comply with the required inspection intervals in accordance with the factory safety directive,
operating equipment inspection DGUV, formerly BVG.
The operator of the machine must ensure that the electrical systems and operating equipment
are inspected with regards to their proper condition, namely,
by a qualified electrician or under the supervision and direction of a qualified electrician,
prior to initial commissioning and after modifications or repairs, prior to recommissioning
and at certain intervals.
The deadlines must be set so that arising, foreseeable defects can be detected in time.
The relevant electro-technical rules must be followed during the inspection.
The inspection prior to initial commissioning is not required if the operator receives confirma-
tion from the manufacturer or installer that the electrical systems and operating equipment com-
ply with the accident prevention regulations, see conformity declaration.
Permanently installed electrical systems and operating equipment are considered constantly
monitored if they are continually serviced by qualified electricians and inspected by means of
measurements in the scope of operation (e.g. monitoring the insulation resistance).
1.20 Inspection deadlines
Define and document the inspection deadlines for the machine in accordance with the Factory
Safety Act and perform an operational risk analysis in accordance with the Work Safety Act.
Also use the inspection intervals in the maintenance section as reference values.

Technical data
Version 1.1.3 - 2020-07-21 19Translation of the original instructions
B34H | B34HV GB
B34H_B34HV_GB_2.fm
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data..
2.1 Electrical connection B34H B34HV
Connection 400V ~50 Hz
1.5 kW / 2.2 kW 230V ~50 Hz 2.2 kW
2.2 Coolant pump B34H B34HV
Motor power - 230V ~50 Hz
40 W
2.3 Drilling capacity B34H B34HV
Drilling capacity in steel [mm] 34
Working radius [mm] 285
Sleeve travel [mm] 160
2.4 Spindle seat B34H B34HV
Spindle seat MT4
2.5 Drilling table B34H B34HV
Table size [mm]
Length x Width of the working surface
T-slot size [mm] 14
Maximum distance [mm]
Spindle - table 790
Maximum distance [mm]
spindle - stand 1275
Working surface stand [mm]
Length x Width of the working surface 390 x 390
400,00
420,00
344,00
324,00

Technical data
Version 1.1.3 - 2020-07-2120 Translation of the original instructions
B34H | B34HV
GB
B34H_B34HV_GB_2.fm
2.10 Emissions
The generation of noise emitted by the drilling machine is 76 dB(A) at idle speed according DIN
ISO 8525.
If the drilling machine is installed in an area where various machines are in operation the acou-
stic influence (immission) on the operator of the radial drilling machine may exceed 80 dB(A).
INFORMATION
This numerical value was measured on a new machine under proper operating conditions.
Depending on the age respectively on the wear of the machine it is possible that the noise
behaviour of the machine changes.
Furthermore, the factor of the noise emission is also depending on manufacturing influencing
factors, e.g. speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is the emission level and not necessarily a safe working level.
Though there is a dependency between the degree of the noise emission and the degree of the
noise disturbance it is not possible to use it reliably to determine if further precaution measures
are required or not.
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
Other noise sources, e.g. the number of machines,
Other processes taking place in the proximity and the period of time during which the ope-
rator is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
2.6 Required space B34H B34HV
Height [mm] 2500
Depth [mm] 1700
Width [mm] 1500
Weight [kg] 260 275
2.7 Speeds B34H B34HV
Spindle speeds [ min -1 ] 145 - 4800 40 - 5000
Number of stages 2 x 9 9
2.8 Environmental conditions B34H B34HV
Temperature 5 - 35 °C
Relative humidity 25 - 80 %
2.9 Operating material B34H B34HV
Toothed rack commercial lubricating grease
Column, blank steel parts Acid-free lubricant, e.g. machine oil,
engine oil
Coolant lubricant UNIMET ASF 192, Mineral 1:10 (approx. 4,5 liters)
