Optimus Sports SCP-90 User manual

Cat. No. 14-1233
OWNER’S MANUAL
Please read before usin
g
this equipment.
SCP-90
AM/FM Stereo
Cassette Player
14-1233.fm Page 1 Friday, July 2, 1999 10:46 AM

2
FEATURES
Your Optimus SCP-90 AM/FM Stereo Cassette Play-
er is lightweight, portable, and easy to operate. It de-
livers excellent sound through the supplied in-ear
sports headphones or through your speakers, and in-
cludes these features:
All Weather Design — the sealed cassette compart-
ment protects your tape from wind, dust, and rain.
Auto-Stop — automatically stops tape playback at
the end of a tape side to protect the tape-handling
parts.
Bass Boost — provides richer, fuller bass sound.
Automatic Frequency Control Circuit — helps lock
FM tuning for drift-free reception.
Three Power Sources — let you power the SCP-90
from internal batteries, AC power, or vehicle battery
power.
©1998 Tandy Corporation.
All Rights Reserved.
Optimus and RadioShack are registered trademarks used by
Tandy Corporation.
14-1233.fm Page 2 Friday, July 2, 1999 10:46 AM

3
Removable Belt Clip — allows hands-free carrying
when you are on the go.
Note: You need two AA batteries, an AC adapter, or
a DC adapter to power the SCP-90. To listen to your
SCP-90, you can use the supplied in-ear sports
headphones (or other headphones) or a pair of am-
plified speakers (not supplied) with a 1/8-inch mini
plug. Your local RadioShack store carries a wide se-
lection of batteries and speakers.
14-1233.fm Page 3 Friday, July 2, 1999 10:46 AM

4
CONTENTS
Preparation ........................................................... 5
Connecting Power .......................................... 5
Using Batteries ........................................ 5
Using AC Power ...................................... 7
Using Vehicle Battery Power ................... 9
Connecting the Headphones or Speakers .... 12
Listening Safely ..................................... 13
Traffic Safety ......................................... 13
Using the Belt Clip ........................................ 14
Radio Operation ................................................. 15
Cassette Operation ............................................ 17
Playing a Cassette Tape ............................... 17
Tape Tips ...................................................... 21
Tape Quality .......................................... 21
Restoring Tape Tension and
Sound Quality ........................................ 21
Maintenance ....................................................... 23
Cleaning the Tape-Handling Parts ................ 24
FCC Information ........................................... 26
Specifications .................................................... 27
14-1233.fm Page 4 Friday, July 2, 1999 10:46 AM

5
PREPARATION
CONNECTING POWER
Using Batteries
To power the SCP-90 with batteries, you need two
AA batteries (not supplied). We recommend alkaline
batteries, such as RadioShack Cat. No. 23-557.
Follow these steps to install batteries.
1. Pull up the black
cassette compart-
ment latch and pull
open the cassette
compartment door.
2. Press the battery
compartment
cover’s tab in the
direction of the
arrow and lift off
the cover.
Illust.
Illust.
14-1233.fm Page 5 Friday, July 2, 1999 10:46 AM

6
3. Install the batteries over the ribbon, as indicated
by the polarity symbols (+ and –) marked inside
the compartment.
Cautions:
• Use only fresh batteries of the required size
and recommended type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or
rechargeable), or rechargeable batteries of
different capacities.
4. Replace the battery compartment cover, then
close the cassette compartment door and latch.
If the SCP-90 does not operate properly or if the
sound becomes weak or distorted, replace the batter-
ies.
Cautions:
• Always dispose of old batteries promptly and
properly.
14-1233.fm Page 6 Friday, July 2, 1999 10:46 AM

7
• Never leave dead, old, or weak batteries in the
SCP-90. Batteries can leak chemicals that can
corrode or damage electronic circuits.
• If you do not plan to power the SCP-90 with bat-
teries for several days, or if you plan to power it
using only an AC or DC adapter, remove the bat-
teries to protect the SCP-90 from possible bat-
tery leakage.
Using AC Power
To power the SCP-90 with standard AC power, you
need an optional AC adapter, such as RadioShack
Cat. No. 273-1654.
Cautions:
• The recommended AC adapter supplies 3 volts
and delivers at least 250 milliamps. Its center tip
is set to negative, and its barrel plug correctly fits
the SCP-90’s DC 3V jack. Using an adapter that
does not meet these specifications could dam-
age the SCP-90 or the adapter.
14-1233.fm Page 7 Friday, July 2, 1999 10:46 AM

8
• Always connect the adapter to the SCP-90’s DC
3V jack before you connect it to the AC outlet.
Then disconnect the adapter from the AC outlet
before disconnecting it from the SCP-90.
Follow these steps to power the SCP-90 from a stan-
dard AC outlet.
1. Set the adapter’s voltage switch to 3V.
2. Put the adapter’s
3.4 mm outer diam-
eter/1.3 mm inner
diameter barrel
plug onto the
adapter’s cord so it
reads –TIP.
3. Pull out the attached rubber plug from the SCP-
90’s DC 3V jack.
4. Insert the adapter’s
barrel plug into the
SCP-90’s DC 3V
jack.
Add
Illust.
Illust.
14-1233.fm Page 8 Friday, July 2, 1999 10:46 AM

9
5. Plug the adapter
into a standard AC
outlet.
Notes:
• Internal batteries (if installed) automatically dis-
connect when you plug the AC adapter into the
SCP-90.
• Disconnect the adapter and reinsert the jack’s
rubber plug when you are not using the SCP-90.
Using Vehicle Battery Power
To power the SCP-90 from your vehicle’s cigarette-
lighter socket, you need an optional DC adapter,
such as RadioShack Cat. No. 270-1560.
Illust.
14-1233.fm Page 9 Friday, July 2, 1999 10:46 AM

10
Cautions:
• The recommended DC adapter supplies 3 volts
and delivers at least 250 milliamps. Its center tip
is set to negative, and its barrel plug correctly fits
the SCP-90’s DC 3V jack. Using an adapter that
does not meet these specifications could dam-
age the SCP-90 or the adapter.
• Always connect the adapter to the SCP-90’s DC
3V jack before you connect it to the cigarette-
lighter socket. Then disconnect the adapter from
the cigarette-lighter socket before disconnecting
it from the SCP-90.
Follow these steps to power the SCP-90 from your
vehicle’s cigarette-lighter socket.
Illust.
14-1233.fm Page 10 Friday, July 2, 1999 10:46 AM

11
1. Set the adapter’s voltage switch to 3V.
2. Insert the adapter’s 3.4 mm outer diameter/1.3
mm inner diameter barrel plug into the adapter’s
cord so it reads –TIP.
3. Pull out the attached rubber plug from the SCP-
90’s DC 3V jack.
4. Insert the adapter’s barrel plug into the SCP-90’s
DC 3V jack.
5. Plug the adapter into the vehicle’s cigarette-
lighter socket.
Notes:
• If the SCP-90 does not operate properly when
you use DC power, be sure the cigarette-lighter
socket is clean and that the adapter’s plug is
pushed all the way into the socket.
• Internal batteries (if installed) automatically dis-
connect when you plug the adapter into the DC
3V jack.
• Disconnect the adapter and reinsert the jack’s
rubber plug when you are not using the SCP-90.
14-1233.fm Page 11 Friday, July 2, 1999 10:46 AM

12
CONNECTING THE
HEADPHONES OR SPEAKERS
To listen to your SCP-90, connect the supplied in-ear
sports headphones (or other headphones) or a pair
of amplified speakers (not supplied) with a 1/8-inch
mini plug.
Pull out the attached rubber plug from the SCP-90’s
PHONES jack, then plug in the headphones’ or speak-
ers’ 1/8-inch plug.
When you are not using your SCP-90 and head-
phones or speakers are disconnected, put the rubber
plug back into the PHONES jack to protect against
moisture and dust.
Illust.
14-1233.fm Page 12 Friday, July 2, 1999 10:46 AM

13
Listening Safely
To protect your hearing, follow these guidelines when
you use the headphones.
• Set the volume to the lowest setting before you
begin listening. After you begin listening, adjust
the volume to a comfortable level.
• Do not listen at extremely high volume levels.
Extended high-volume listening can lead to per-
manent hearing loss.
• Once you set the volume, do not increase it.
Over time, your ears adapt to the volume level,
so a volume levelthat does not cause discomfort
might still damage your hearing.
Traffic Safety
Do not wear headphones while operating a motor ve-
hicle or riding a bicycle. This can cause a traffic haz-
ard and can be illegal in some areas.
14-1233.fm Page 13 Friday, July 2, 1999 10:46 AM

14
Even though some headphones are designed to let
you hear some outside sounds when listening at nor-
mal volume levels, they still can present a traffic haz-
ard.
USING THE BELT CLIP
For hands-free carrying, slide the belt clip over your
belt.
To remove the belt clip, use a Phillips screwdriver to
loosen the screw holding the clip. Then lift off the clip.
To replace the belt clip, position it as shown, then re-
place and tighten the screw.
Illust.
14-1233.fm Page 14 Friday, July 2, 1999 10:46 AM

15
RADIO OPERATION
Important: Make sure you have connected head-
phones or speakers to the SCP-90.
1. Set RADIO OFF/TAPE/FM ST/AM to FM ST or AM
to turn on the radio.
2. Adjust VOLUME to the desired listening level.
3. Turn TUNING to select the desired station.
Illust.
Illust.
14-1233.fm Page 15 Friday, July 2, 1999 10:46 AM

16
Note: The AM antenna is built-in. Rotate the
cassette player to improve AM reception. For the
best FM reception, fully extend the headphones’
or speakers’ cord.
4. Set BASS BOOST to ON for an enhanced bass
effect. Set it to OFF for normal bass sound.
5. Set RADIO OFF/TAPE/FM ST/AM to RADIO OFF/
TAPE to turn off the radio.
Add
Illust.
14-1233.fm Page 16 Friday, July 2, 1999 10:46 AM

17
CASSETTE OPERATION
PLAYING A CASSETTE TAPE
1. Take up any slack in the tape by turning the cas-
sette’s hub with a pencil. Do not touch the
exposed tape.
2. Pull up the cassette compartment latch and pull
open the door.
Illust.
Illust.
14-1233.fm Page 17 Friday, July 2, 1999 10:46 AM

18
3. With its open edge facing up and the full reel to
the left, insert the cassette tape into the cassette
guide.
4. Close the door and the latch.
5. Set RADIO OFF/TAPE/FM ST/AM to RADIO OFF/
TAPE.
Illust.
Add
Illust.
14-1233.fm Page 18 Friday, July 2, 1999 10:46 AM

19
6. Press PLAY to start play.
7. Adjust VOLUME to the desired listening level.
Add
Illust.
Add
Illust.
14-1233.fm Page 19 Friday, July 2, 1999 10:46 AM

20
8. Set BASS BOOST to ON for an enhanced bass
effect. Set it to OFF for normal bass sound.
9. To stop playback, press STOP.
Notes:
• The SCP-90 automatically stops when the tape
reaches the end of that side during playback.
• To advance the tape quickly, press F.FWD. The
button locks down, and the tape fast forwards
until you press STOP. To rewind the tape, turn the
tape over and press F.FWD.
Add
Illust.
Add
Illust.
14-1233.fm Page 20 Friday, July 2, 1999 10:46 AM
