Optoma Sign Show 7POP User manual

Operation
Manual
Before using this device,
please make sure the
instructions has been read
and understood especially
the “Safety” chapter.
Please keep this manual
in a good condition for
future reference.
Device number is
very important for
quality management.
Please check the
device number when
you buy this device.
Thank you for your purchase
Digital Signage Monitor
Sign Show 7POP

Preface Getting
start Set-up Install Adjustment Getting Help
2
Preface
Table of contents
Preface…………………………..2
Table of contents...........................2
Caution for Safety........... ..............4
Caution for correct usage ...........12
Terminology.................................14
The process of using the device.16
Getting start……………………17
Step 1: Accessories and tools....17
Step 2: Insert the SD memory
car ......................................... ...18
Step 3: Connect device with AC
adapter........................................19
Step 4: Format the SD memory
card.............................................20
Step 5: To update the configure file
and content files..........................23
Set-up…………………………..26
Before the set-up........................26
Buttons used for set-up ..............26
The outlook of selecting item......26
To make sure the setting content
of all content files........................27
Setting contents and items.........29
Constitution of setting screen.....31
Step 6: Set up the network and
online access..............................32
To access the device via a web
page............................................35
To upload contents using auto
download ....................................38
Step 7: Set the present time and
date.............................................39
Step 8: Select the replaying
contents (set to replay contents)41
Step9: Set the replay time..........43
To replay the contents at the
same time (timer setting)............43
To replay on the due day of every
week...........................................47
To replay on the due day of every
month .........................................51
To replay on the due period.......55
Install…………………………...59
Step 10: To install the device onto
the site........................................59
To install the device....................59
To paste the sticker of “ replay
from start” to the device .............60
Adjustment……………………..61
To adjust the brightness and
volume........................................61
To adjust the brightness.............61
To adjust the volume..................62
To use the button of “replay from
start”................................ ...........63
To turn on/ off the power by
manual........................................64
To turn on the power by manual 64
To turn off the power by manual 64
To edit the content files...............65
To change batteries for clock
button..........................................66
Packaging...................................67
Getting Help……………………68
Troubleshooting..........................68

3
Outlook of the operational manual
Outlook of symbols in the manual.
Caution: watch out for the operation.
Memo: limits of function and usage are written as reference.
About the contents of this manual.
zThis is a copyrighted material. Any use of this copy without proper permission is
forbidden.
zThe devices from other companies mentioned in the manual are trademark or
logo of other companies. The marks such as TM, ®, © are omitted in the manual.
zWindows and Windows Media are trademarks registered for Microsoft
Corporation and in America.
zAny change on design, condition and other contents may be made without
public announcement.
Show the reference page or reference item

Preface Getting
start Set-up Install Adjustment Getting Help
4
Caution for Safety
There are many signs written in the manual or shown in the device. These signs
are for the safety of customers, surrounding people and properties. Please pay
careful attention to these signs before you read this manual.
Warning: This signs means: should this sign be ignored or
mistaken, the possible death or injury may take place.
Caution: This signs means: should this sign be ignored or
mistaken, the possible injury to people or property
damages may take place.
The explanation of the signs:
zThe signs for watch-out (including warning):
General watch-out Caution for the
hands caught-in
Watch out the
electric shock
zThe signs for “don’t”(forbiddance)
Watch-out Do not use it at
the wet places
Do not touch it
with wet hands
Do not decompose
it
Do not touch it Do not soak it into
water
zThe signs for compulsory (forced)
Please plug off the
power
General
instruction

5
Warning
When abnormality takes place
If the following situations occur, please do not use the
device because fire or electric shock may take place.
•When smoke or strange smell occurs.
•When videos or the sounds can’t be played.
•When water or objects are get inside the device.
•When the cabinet is dropped and damaged.
•When the power cord is damaged, such as cord line
exposure or disconnection.
As the above situations take place, please immediately
turn off the power and unplug the plug.
If the smoke occurs, please stop all actions and take the
device back to the stores.
Please do not repair the device by yourself, as it might be
dangerous.
About the power
Please do not plug into the DC power on ships or boats
because it may cause fire and electric shock.
Please do not plug into the DC24V power at truck or bus
because it may cause fire and electric shock.
The total voltage can’t exceed the capacity that is displayed
at AC outlet because it may cause fire and electric shock.
The voltage provided by AC outlet of this device is limited.

Preface Getting
start Set-up Install Adjustment Getting Help
6
Caution for Safety (continued)
Warning
About handling
Do not remove the rear cover or remodel the device
If the supply voltage inside is high, fire or electric shock
may break out.
Please return the device to stores for inner part
examination and repair.
Do not place this device on an unstable place
Please do not place this device on an unstable or inclined
place because the device may fall on the ground and
become damaged.
Do not cover the vent
If the vent is covered, the inner part may be filled with
heat and fire may take place. Therefore, please pay
attention to the following situations.
•Do not place the device in a closet or a bookcase
•Do not place carpet or cloth on the device
•Do not place table cloth on the device
•Do not place the device on the sideway or upside
down.
Please do not insert any objects into the device
Fire or electric shock may occur if metals or any
combustible materials are inserted in the vent or card
output. Watch the little kids particularly when they are
operating the device.
Do not place container with liquid inside near the
devices (ex: vase, cup, cosmetic or medicine jar)
If liquid enters the device, fire or electric shock may take
place.
Do not use the device at wet places such as a
restroom
If water enters the device, fire or electric shock may take
place.
Moreover, be careful when using the device at a raining or
a snowing day or at shore or waterside.
Do not touch the power plug when the thunder takes
place
It may cause electric shock.

7
About power cord
Do not use the power cord with devices other than
Sign Show 7POP
Do not use the power cord with devices other than Sign
Show 7POP, because it may cause fire or electric shock.
Do not damage the electric cord
Do not damage the power cord, because it may cause fire
or electric shock.
•Do not modify the power cord.
•Do not twist, distort or pull the power cord.
•Do not put the device or heavy objects over the power
cord.
•Do not put the power cord close to thermal objects.
Do not let dust or metals get into the power plug or
outlet plug.
Fire or electric shock may take place because of heat or
short circuit. Please unplug the outlet plug and dry it with
cloth every half-year.
About button battery
Please put the button battery at the place beyond the
reach of little kids.
Do not allow kids to take out battery from devices (or
battery charger) when the devices are used.
If kids mistakenly eat the button battery, please see a
doctor immediately.

Preface Getting
start Set-up Install Adjustment Getting Help
8
Caution for Safety (continued)
Caution!
About power cord, power plug
and AC adapter
Please use the exclusive AC adapter, or fire or electric
shock may break out.
Please disconnect all links with machines and then
connect the power plug, or fire or electric shock may
break out. Moreover, please connect AC adapter to the
device with DC plug, and then plug into outlet of wall.
Please do not pull the cord of the power plug
If the power cord is dragged or pulled, the cord may be
damaged and cause fire and electric shock. Please hold
the plug and pull it.
Please do not plug power into outlet which has slack,
because heat may take place and then the fire occurs. Go
to selling stores or hardware stores to exchange the
outlet.
When pulling out the power cord, please pull it from
the outlet of the wall, or it may cause electric shock.
Please pull the power cord from the outlet of the wall.
When intended to pull out the power cord, please pull the
plug.
Please pull the DC plug after pulling out the power
plug.
Make sure to pull out the power plug before pulling out the
DC plug.

9
About handling
Do not put the device in the following places because
it may cause fire or electric shock.
•The place with dust or wetness
•The place with smoke or heated air , such as close to
humidifying or cooking place.
•The place close to heat appliances
•Window-closed automobiles or places with direct
sunray.
•The place close to windows, which may easily have
water drop.
Do not put heavy objects onto the device
Putting heavy objects or big objects onto the device may
cause unbalance and falling, which results in damage.
Do not sit or being hanged over the devices,
because it can cause injury when falling. Be careful for
the little kids particularly.
Please unplug the power if not using the device for a long
time
For safety and energy saving, please unplug the power.
Do not plug or unplug the power with wet hands,
because it may cause electric shock
Please put packaging box at places beyond the reach
of the little kids
It may cause asphyxia or hurts if kids play the packaging
box
Please do not use the device when there is warped
sound
Speakers may get heated and cause fire.

Preface Getting
start Set-up Install Adjustment Getting Help
10
Caution for Safety (continued)
Caution!
About moving
Do not move this device when there are objects onto
it.
If the objects fall down, people may get hurt.
When moving the device, please unplug the power or
connecting cord.
If moving the device without unplug, fire or electric shock
may take place.
About maintenance
Please take the device to stores for inner part
cleaning once for every 2 to3 years
If the device is used without cleaning the dust, the fire
may take place. In particular, great effects can be seen
when cleaning out the dust before plum rain period.
When maintaining the device, please unplug the power,
or it may cause electric shock.

11
About falling-proofing
In order to prevent falling, please take the following
measures
People may get hurt because of falling caused by
earthquake.
Please make use of the stand hole at back side and fix
the device to the wall or pillar firmly. Make sure to choose
the firm place.
* Please make good use of marketing devices, such as
wire or screws.
About volume
Please turn on the power after turn down the volume
(a case of mechanized volume)
If the volume keeps high, it may cause sudden sound,
which can lead to listening injury.
Before turn off the power, please turn down the
volume (a case of digital volume)
If the volume keeps high, turning on the power may cause
sudden sound, which can lead to listening injury.
About button battery
Please do not dump the used batteries
If the battery is dumped without insulation or dumped
together with other metal with electric conductivity, fire or
fracture may take place.
When dumping the battery, please paste tape of
insulation to two terminals or one terminal, and then dump
it as incombustible trash.

Preface Getting
start Set-up Install Adjustment Getting Help
12
Places for safekeeping or use of
device
Please do not put the device at
the following places
Because it may cause
malfunction
•Place beyond the permission
operating temperature
(0℃~40℃)
•Place beyond the permission
operating humidity (10%~80%)
•Place with high magnetic force
such as transformer or motor
•Place close to transceiver or cell
phones with high
electromagnetic wave.
•Place with a lot of dust
•Place with violent shaking
•Place close to windows which
easily have water drop
•Place with radioactive rays, X
rays or lethal gas
About security function
The security function can set up for the
purpose of mistake-proof.
For more detailed, please ask the
stores or the contact windows which
are written on back cover.
This function is based on the standard
of class A of VCCI. The function may
cause electromagnetic wave when
using at home. In this case, It is
demanded so that users take
appropriate measures
About installing
Please install the device close to
the outlet
Please install the device close to
the outlet so that it is easier to plug
or unplug the power. If the power is
plugged, the power becomes “on”
or “standby.” The power can not be
completely turned off only by
button.
Please leave some space from
wall or other machinery when
installing the device.
The inner part will be filled with
heat , which may cause the fire.
Please take notice for the following
situations.
•Please leave more than 5cm
from the wall.
•Please leave some space
between the device and other
machinery.
•When installing the device in the
shelter, please leave 5 cm from
upper and rear side respectively.
Caution for correct usage

13
About handling
Do not excessively use the
device
The reciprocal heat or sounds can
cause malfunction or damages,
which can lead to fire.
Do not put any containers with
water, such as vase or cup
because it may cause fire or
electric shock
Do not insert any object inside
because it may cause fire or
electric shock.
Please use the devices at place
with proper light in order to
protect the eyes.
If looking at the screen for a long
time in a place with improper light, it
may cause eye tiredness.
Do not use the device as the
screen shakes due to the
surrounding or installment
situation because it may cause
falling of eyesight.
Please turn off the power when
inserting the memory card.
Please make sure to turn off the
power when inserting SD memory
card into the device
The warranty doesn’t cover the
malfunction caused by memory
card and contents. Moreover,
any copyright about contents is
not the responsibility of out
company.
Do not paste any label or sheet
onto the memory card because it
may cause damage to the devices
About energy saving
Please unplug the power for safety
and energy saving if not using the
device for a while.
About maintenance
Please turn off the power and
wipe the dirt with soft cloth.
When the device gets serious dirt,
please use dry cloth with neural
and diluted cleanser to wipe it.
About moving
Please unplug the electric cord
when moving the device
Please make sure to turn off the
power and unplug the power from
electric out when moving the device.
If the cord is damaged, fire or
electric shock may occur.
About power cord, AC adapter
The accessory’s AC adapter can
not be used for the device other
than SIGN SHOW 7POP.
Do not put heavy object over
electric cord.
Do not put the cord under the
device. If the cord is damaged, it
may cause fire and electric shock.
Use only the provided AC
adapter attachment to the device.
If the voltage is abnormal, it may
cause fire or electric shock.
About MP3 file
The device can not be used for
DRM files (with download license).
Once using DRM file in the device,
un expectation malfunction may
take place.

Preface Getting
start Set-up Install Adjustment Getting Help
14
<Front View>
3 4
2
1
<Base View with cover removed>
6 7 85
<Rear View>
9
Speakers
The sound can be played from SD
memory card
Power light/ timer light
The light will be on for the following
situation:
Power on Green light
Timer set on for
operation Orange light
Timer set on for stand by Red light
Set button/ “replay from start”
button
Press this button to confirm
settings.
Press this button to replay
contents in SD memory
card. (to see page 55)
7-type TFT LCD panel
For displaying the menu and image
files, which are saved at SD
memory card.
LAN Port
For connecting to networks.
SD card slot
To insert the SD memory card.
(to see page 19)
USB terminal
To connect with USB.
DC input terminal
To connect with attached AC
adapter. (to see page 20)
Terminology
10 11
12
13
14
Remove the base cover for
access.

15
Attention light
To light up the rear piece of the
device.
The battery cover
Remove battery cover at the
following situation:
To alter the set-up by
button
To change the batteries
UButton
To set up the menu, it is
used moving the cursor up
(to see page 25)
To show the picture again, it is
used to make it brighter.
(to see page 60)
VButton
To set up the menu, it is
used for moving the cursor
below (to see page 25)
To show the picture again, it is
used to make it darker.
(to see page 60)
YButton
To set up the menu, it is
used to moving the cursor
right.
(to see page 25)
To show the picture again, it is
used to make the volume louder.
(to see page 60)
ZButton
To set up the menu, it is
used for moving of the
cursor left (to see page
25)
To show the picture again, it is
used to make the volume lower.
(to see page 60)

Preface Getting
start Set-up Install Adjustment Getting Help
16
The process of using the device
Step 1
Please prepare the accessories and tools
you need --------------------------------------------------- page 17
T
Step 2
Please insert the SD memory card into the
device ----------------------------------------------------- page 18
T
Step 3
Please connect the AC adapter with the device -page 19
T
Step 4
Please format the SD memory card-----------------page 20
T
Step 5
Please place content files in the USB drive-------page 23
T
Step 6
Please set up the network and online access----page 31
T
Step 7
Please set up the present time-----------------------page 38
T
Step 8
Please select the content files to be displayed---page 40
T
Step 9
Please set up the replaying time
T
•Replay at the same time of every day-------page 42
•Replay at the same day of every week -----page 46
•Replay at the same day of every month----page 50
•Replay for the fixed period---------------------page 54
Step
10 Please install the device -------------------------------page 58
Completion
Preparing Setting up Installing

17
Getting start
Step 1: Accessories and tools
Accessories included with the device
Things to prepare
Memo:
•USB memory has to save the contents which are made by CD-R. If there isn’t
any file, it can’t be transmitted into SD memory card.
•If the accessory is not enough, please ask the selling stores and sorry for the
inconvenience.
Necessaries for
Must read it
Quick
Start
Guide
Quick Start Guide * 1
A
C Adapter and power cord * 1
N
ecessaries for installing
Simple stand*1 screws packaged
with stand(M3)*2 sticker of “replay from start”*1
sticker of “replay
from start”
Content files
SD memory
card CD-R ( UM, Layout editor ) USB memory
with content
files
Tool
Screwdrive
r

Preface Getting
start Set-up Install Adjustment Getting Help
18
1. Take off the rear cover: remove
the screws by using the
screwdriver
Memo:
•The screws have a function of
missing-proof, please do not take
them off the rear cover
2. Insert the SD memory card into
the device
Please put the label side of SD
memory card as down side
Please insert into SD card slot
Memo:
•When taking out the SD memory
card, please make sure to unplug the
power and push the memory card to
the depth.
* When taking out the SD memory
card, please must turn off the power
* When the power is off, the power
light will become red or off.
Step 2: Insert the SD memory card
•Please insert the SD memory card into the device
•Please make sure to unplug the power before insert the SD memory (56
page)
Screwdrive
r
Screws
attached on
Back cove
r
ups
id
e
SD memory card
SD memory card
SD card slot
Power li
g
ht

19
Step 3: Connect device with AC adapter
•When connecting device with AC adapter, the power will be on
•When plugging the DC plug into the DC terminals, please turn the DC plug
sideways as the following picture.
Please insert into AC
outlet
DC terminal
DC plug

Preface Getting
start Set-up Install Adjustment Getting Help
20
Notice:
•Formatting an used SD memory card
will erase all the saved files.
•The SD memory card will be
unusable by computers if formatting
is done on this device.
Buttons used for formatting
•Up, down, left, right button
•Button for “replay from start”( use
“set button” for the following
mention)
<The front of the device >
1.To show the menu screen
Turn on the power, and then press the
right button and left button
simultaneously for 2 seconds.
<Menu screen>
2. To display the system screen
Select the “system” by using the up or
down button, and then press the set
button.
< System screen>
Step 4: Format the SD memory card
Before using your SD card for the first time, a format may be required.
Up button
Down button
Right button
Left button
<state of taking off the battery cell
Set button
