OPTOMA LAUNCHES FOUR NEW HIGH-BRIGHTNESS PROJECTORS
Company Heightens Commitment to Large Venue Market
ORLANDO, FL | June 12, 2013 | With the introduction of four new high-lumen projectors here
at InfoComm 2013, Optoma, a long-time leader in DLP projection, has signaled that it plans to
be an impact player in the large venue market . The four models, highlighted by the 7,000-
lumen, dual-lamp flagship EH7700, and including the 6,000-lumen X605, and two 5,000-lumen
models, the EH505 and W505, all showcase the company’s commitment with feature sets
designed to meet the installation and performance challenges in venues ranging from
auditoriums, to large conference rooms and lecture halls.
Note to editors: Links to hi-res images are at the end of this press release
“The large-venue market offers tremendous opportunity for Optoma,” said Jon Grodem,
Optoma’s senior director of product and marketing, “and it’s an area we’re now well positioned
to compete in, in terms of product selection, performance, reliability and channel support.”
Optoma’s WUXGA resolution, dual–lamp EH7700 represents the company’s first 7,000-
lumen model, and offers the ultimate flexibility and reliability. Both 350W P-VIP lamps can be
used together for maximum brightness and to provide redundancy. Alternatively a single lamp

Optoma Launches Four New High-Brightness Projectors Page 2
- MORE -
can be used in Relay Mode to maximize the lifespan of each individual lamp and minimize
service need.
Users can choose from any of the five motorized optional lenses to meet their needs,
and the projector provides full 360° mounting range along the vertical axis, again increasing
installation flexibility and allowing images to be projected just about anywhere, even on a
ceiling or floor. The EH7700 also supports image blending for use with multiple projectors, and
supports the most commonly-used control systems, including Crestron, Extron, AMX, PJ-Link
and Telnet LAN. The EH7700 is completely live-performance ready with a mechanical shutter
for situations where absolute darkness is required, safety mounting points and a flying frame
option. I/O connections include two HDMI (v1.3), two VGA-in and one VGA-out, RGBHV BNC,
YPbPr(3RCA) component, S-video and composite. Control ports include RJ45, RS-232C, and a
12V trigger.
With a suggested street price of $9,999, the EH7700 is scheduled for availability at the
end of July.
The new X605 adds depth to Optoma’s existing line of 6,000-lumen projectors. With its
XGA resolution and 10,000:1 contrast ratio, the X605 is Optoma’s brightest projector to support
full 3D through its HDMI 1.4a input, and it features a choice of three optional lenses, vertical
and horizontal lens shift, and two 3-watt speakers. In addition to HDMI, it also offers a DVI port
for digital connectivity, two VGA inputs and one VGA output for analog content, S-video,
composite video, component video, five BNC (RGBHV/YPbPr), two stereo mini jack audio-in,
two RCA stereo audio-in, audio-out, and two 12-volt triggers for added installation
convenience. RS-232 and RJ45 connections are available for command and control, and a USB
port allows for wireless presentation capability via an optional USB dongle.
The X605 will carry a street price of $2799 and will be available in August.
With the new 5,000-lumen EH505 and W505, Optoma has added a pair of projectors
with the power and features to satisfy most auditoriums and lecture halls, and priced to meet
most budgets as well. Both the EH505 (WUXGA resolution, $3,499) and the W505 (WXGA,
$2,799) feature one of the most comprehensive input panels and most advanced feature sets in
their class to ensure the projectors will satisfy your current and future needs.

Optoma Launches Four New High-Brightness Projectors Page 3
Additional features include a choice of three optional lenses, vertical and horizontal lens
shift and two 3-watt speakers. Inputs include HDMI 1.4a for full 3D and DVI for digital
connectivity, two VGA inputs and one VGA out for analog content, S-video, composite video,
component video, five BNC (RGBHV/YPbPr), two stereo mini jack audio-in, two RCA stereo
audio-in, and audio-out.They also provide two 12-volt triggers for added installation
convenience. RS-232 and RJ45 connections are available for command and control, and a USB
port allows for wireless presentation capability via an optional USB dongle. Both models will
be available in August.
All four new projectors carry Optoma’s 3-Year Express Service warranty, with one year
on lamp. For more information on all Optoma products, go to www.optomausa.com or call
888-289-6786.
EH7700 Left Front:
Links to images
https://roherpr.box.com/s/6j0qw2mon9rtyevlkl4k
EH7700 Head On: https://roherpr.box.com/s/sc0i50792cg5bmvuja0e
X605 Left Front: https://roherpr.box.com/s/e9an3aqj7j9rmt6fosfr
X605 Head on: https://roherpr.box.com/s/40bpcd0lottguo6wbka3
EH505 Left Front: https://roherpr.box.com/s/hpwhfdjkgtpanadb91qb
W505 Left Front: https://roherpr.box.com/s/uoaig8wt0qeg58au1c2v
About Optoma Technology, Inc.
Optoma Technology, Inc. is an award-winning developer of projection and digital display products for business,
education and home. The company manufactures multimedia projectors for mobile users, fixed installations,
classrooms and home theaters, as well as HD displays. Optoma products combine superior image processing
technologies with exceptional engineering and innovation to deliver images that are bright, crystal clear and finely
tuned for tone and color. Optoma products are sold through the company’s global network of Pro AV dealers,
major consumer electronics retailers and Internet resellers. For more information, visit www.optomausa.com.
©2013 Optoma Technology, Inc. Optoma names and logos are registered trademarks of Optoma Technology, Inc. Other product names
mentioned herein may be trademarks and/or registered trademarks of their respective companies and are hereby recognized.
# # #

Hi-Lumen Projectors
Image Sheet
InfoComm Booth #2788
EH7700 Front and Front Left
X605 Front Left W505, X505
Front Head On

- MORE -
News Release
FOR IMMEDIATE RELEASE INFOCOMM Booth # 2788
Contact:
Optoma Technology: Roher Public Relations:
Jon Grodem Torin Roher
t: 510.897.8517 t: 971-266-8870
e: [email protected] e: [email protected]
OPTOMA EXPANDS HIGH-END INSTALLATION PROJECTOR LINE
New Models to Attack Market “Sweet Spot”
ORLANDO, FL | June 12, 2013 |Optoma has introduced 6 new projectors here at InfoComm
2013 incorporating the latest DLP controller chip designs to deliver enhanced features and
maximum flexibility for installation in boardrooms, mid-sized conference rooms, and
classrooms. The six models, EH501, W501, X501, W401, X401, and EH300 offer best-in-class
features and distinguishing characteristics, including full 3D, intended to satisfy the
brightness/budget challenge facing installers and buyers today.
Note to editors: Links to hi-res images are at the end of this press release
“This group of projectors represents the true sweet spot for Optoma in terms of both
all-around performance and market demand,” said Jon Grodem, senior director of product and
marketing “There’s a preference for higher lumen products with broader feature sets because
they provide greater flexibility of room size and ambient light, and the new models will satisfy
many of these demands.”
All three 501-series projectors deliver a brilliant 4500-lumen brightness and a 10,000:1
contrast ratio for remarkably bright presentations, and clear, crisp text and brilliant, rich colors,

Optoma Expands High-End Installation Projector Line Page 2
- MORE -
as well as a best-in-class feature set. The EH501’s native 1080p resolution offers true HD (1920
x 1080), including full 1080p 3D via the HDMI 1.4 port, making it ideal for presentations that
include high definition content. The WXGA resolution W501 is made for presentations
requiring a true widescreen format, while the X501 meets the needs of those desiring an XGA
solution.
All three feature a comprehensive I/O panel and the most advanced feature sets in their
class. This includes HDMI 1.4 and DVI for digital connectivity, over-the-network presentation
capability, direct-from-USB-flash-drive presentation capability, wireless presentation capability
via an optional USB dongle, vertical lens shift, and discrete audio inputs including microphone
input for maximum installation convenience.
The EH501 will carry a street price of $1,699, the W501 a price of $1,599 and the X501
$1,499. All three models will be available at the end of June.
For those wanting high brightness at a slightly lower cost, Optoma’s W401 (WXGA) and
X401 (XGA) are designed to fit the bill. Both the W401, with 4200 Lumens, and the X401, with
4000 Lumens, provide a robust 15,000:1 contrast ratio to deliver rich, saturated colors and
sharp, bright images. Whisper quiet, both projectors offer extensive connectivity options for
maximum compatibility. Both are IP and RS-232C control system ready, both incorporate full
3D compatibility, both have a built-in 8-Watt audio system, and both offer superior lamp life to
minimize the cost of operation. Available at the end of July, the W401 will have an end-user
price of $1099, while the X401 will cost $999.
For installations that require 1080p and 3D but are constrained by the budget, Optoma’s
new EH300, priced at $1,299, could be the perfect solution. Rated at 3500 lumens,
incorporating an on-board, 16-watt stereo speaker system for robust audio, as well as an audio-
out for external audio support and RS-232C for LAN integration, the EH300 is a guaranteed to
deliver big bang for the buck while delivering any presentation or video with the greatest
impact.

Optoma Expands High-End Installation Projector Line Page 3
As with the other models above, the EH300 offers a complete set of connectivity ports,
including two HDMI v1.4a, two VGA-in, one VGA-out, a 3D VESA Port, a composite video, two
audio-in, one audio-out, an RS-232C, and a USB-B. The EH300 is slated for availability at the
end of June.
All six projectors carry Optoma’s 3-year Optoma Express Service, 1-year lamp. For more
information, including complete specs, go to www.optomausa.com or call 888-289-6786.
EH501 Front:
Links to Images
https://roherpr.box.com/s/ffbnpwssqkpj6cgc0f07
EH501 Front Left: https://roherpr.box.com/s/mmh17wno1jdkrkxmxa1u
W501/X501 Front Left: https://roherpr.box.com/s/oo7lmjr1s7ppummnctw5
W401/X401 Front Head On: https://roherpr.box.com/s/6ihosp76nocxw1v2st7c
W401/X401 Front Left: https://roherpr.box.com/s/lwtla5didllcx6m51q86
EH300 Front Left: https://roherpr.box.com/s/bacnqjlwfjynaxu7dde7
About Optoma Technology, Inc.
Optoma Technology, Inc. is an award-winning developer of projection and digital display products for business and
home. The company manufactures multimedia projectors for mobile users, fixed installations and home theaters,
as well as HD displays. Optoma products combine superior image processing technologies with exceptional
engineering and innovation to deliver images that are bright, crystal clear and finely tuned for tone and color.
Optoma products are sold through the company’s global network of Pro AV dealers, major consumer electronics
retailers and Internet resellers. For more information, visit www.optomausa.com.
©2013 Optoma Technology, Inc. Optoma names and logos are registered trademarks of Optoma Technology, Inc. Other
product names mentioned herein may be trademarks and/or registered trademarks of their respective companies and are
hereby recognized.
# # #

Conference/BoardRoom
Projector Image Sheet
InfoComm Booth #2788
501-Series Front Left
401-Series Front Left 401 Series Head On
501-Series Head On
EH300 Front LeftEH300 Head On

- MORE -
News Release
FOR IMMEDIATE RELEASE INFOCOMM Booth # 2788
Contact:
Optoma Technology: Roher Public Relations:
Jon Grodem Torin Roher
t: 510.897.8517 t: 971-266-8870
e: [email protected] e: [email protected]
OPTOMA EXPANDS LED ULTRA PORTABLE PROJECTOR LINE
WITH 1,000 and 550 LUMEN MODELS
ML1000 and ML550 Give Mobile Professionals Bright, Light Tools
ORLANDO, FL | June 12, 2013 | Optoma, the worldwide leader in LED projectors, has
introduced two new powerful models here at InfoComm 2013 that push the LED performance
envelope. Both the 1000-lumen ML1000 and the 550-lumen ML550, represent the latest in
lamp-free, feature-rich portable projectors that give the on-the-go professional a persuasive
presentation tool.
Note to editors: Links to hi-res images are at the end of this press release
“On-the-go pros always walk a fine line in that they have to balance their needs for
performance and convenience,” said Jon Grodem, Optoma’s senior director of product and
marketing. “The ML1000 and the ML550 are designed to help them confidently walk that line
with two levels of convenience that deliver uncompromising performance.”
The ML1000 is the ultimate travel companion for mobile professionals looking for a
light, full-featured ultra-portable projector powerful enough to meet challenging light
conditions. Weighing only 3 lbs and with a native WXGA resolution (1280 x 800), its 1000
lumens and 15,000:1 contrast ratio combine to produce the richest, most vibrant colors in this
class of product.

Optoma Expands Led Ultra Portable Projector Line Page 2
- MORE -
The ML1000 is also the first LED projector to incorporate a more intuitive touchpad
control panel. Said Grodem, “Optoma is committed to continuing its leadership role in LED
projection by offering innovative features available elsewhere not available elsewhere. This
touchpad is the latest example of that.”
With a full complement of connectivity options, so you can use the ML1000 with just
about any video source. A wireless USB adaptor is also included in case you want to access
your computer or your network wirelessly. ML1000 also includes an SD card port and pre-
loaded software that allow you to deliver PowerPoint presentations, view PDF documents,
display pictures, movies and more without the need of a computer or any other external
device. The ML1000’s new, innovative touchpad allows you to easily and intuitively control the
projector.
For road warriors wanting something a bit smaller and lighter, but still powerful
projector loaded with convenience features, the ML550 is a good bet to fit the bill. Weighing
less than one pound and delivering 550 lumens with a 10,000:1 contrast ratio, the ML550 offers
the same WXGA resolution, razor sharp focus and magnificent color accuracy found on the
ML1000. It includes HDMI, VGA, microSD card slot, and the same pre-loaded software to run
presentations and other documents independent of a computer. Wireless connectivity is also
available with the optional USB wireless adaptor.
The LED light sources on both projectors are rated to last more than 20,000 hours, so
you won’t have to worry about replacing a bulb at the most inconvenient time – such as when
you’re in the middle of a presentation. The ML1000 will be available in late July at a price of
$999, while the ML550 will be available in late June for $599.
Both projectors carry 1-year warranty. For more information on all Optoma products,
go to www.optomausa.com or call 888-289-6786.
ML550 Left Front:
Links to images
ML550 Rear Panel:
https://roherpr.box.com/s/b1tdz2obefheb0z06a34
https://roherpr.box.com/s/s8e7ufxcr7clponxdced
ML1000 Left Front: https://roherpr.box.com/s/93ots6hdt7o4wmoa1fw2

About Optoma Technology, Inc.
Optoma Technology, Inc. is an award-winning developer of projection and digital display products for business,
education and home. The company manufactures multimedia projectors for mobile users, fixed installations,
classrooms and home theaters, as well as HD displays. Optoma products combine superior image processing
technologies with exceptional engineering and innovation to deliver images that are bright, crystal clear and finely
tuned for tone and color. Optoma products are sold through the company’s global network of Pro AV dealers,
major consumer electronics retailers and Internet resellers. For more information, visit www.optomausa.com.
©2013 Optoma Technology, Inc. Optoma names and logos are registered trademarks of Optoma Technology, Inc. Other product names
mentioned herein may be trademarks and/or registered trademarks of their respective companies and are hereby recognized.
# # #

ML Projector
Image Sheet
InfoComm Booth #2788
ML550 Front and Front Left
ML1000
ML550 Back I/O Panel

- MORE -
News Release
FOR IMMEDIATE RELEASE INFOCOMM Booth # 2788
Contact:
Optoma Technology: Roher Public Relations:
Jon Grodem Torin Roher
t: 510.897.8517 t: 971-266-8870
e: [email protected] e: [email protected]
OPTOMA DEBUTS NEW FEATURE-RICH, FULL-3D LINE OF PROJECTORS FOR
THE BUDGET-CONSCIOUS USERS
Education, Small Boardrooms Targeted By Feature-Rich Line
ORLANDO, FL | June 12, 2013 | Optoma, a world leader in DLP projection, is introducing five new
feature-rich, affordable projectors here at InfoComm 2013 for budget-conscious users, such as
educators and entry-level projector customers. All five projectors – the W306ST, X306ST, W303,
X303 and S303 – deliver a minimum of 3000 lumens, offer full 3D capability, and come with Optoma’s
Express Service Warranty.
Note to editors: Links to hi-res images are at the end of this press release
“Optoma is dedicated to meeting the needs of users at all levels, and our new 303-series of
projectors demonstrates that commitment,” said Jon Grodem, Optoma’s senior director of product
and marketing. “No other company offers the breadth and depth of models to ensure that, and it
clearly differentiates Optoma from its competition.”
Two new short-throw projectors, the 3500-lumen, WXGA-resolution W306ST and its 3200-
lumen XGA partner, the X306ST, are the perfect solution for applications requiring easy-to-read text
and graphics with exceptional color reproduction from a short projection distance. Both projectors
come with a full complement of connectivity options: one HDMI, two VGA-in, one VGA-out,
composite video, two audio-in and one audio-out, one mic-in, one RS-232C, an RJ45 and a mini-USB
port. Both projectors also make use of Optoma’s Eco+ advancements to extend lamp life, and both

Optoma Offers New Projectors For The Budget-Conscious Users Page 2
come with Optoma’s well-known commitment to quality that ensures years of care-free operation.
Both the W306ST (street price $899) and the X306ST (street price $849) will be available in June.
For those need a powerful, reliable projector but who face severe budget restrictions and
don’t need all the bells and whistles found on higher-end models, Optoma’s 303-series delivers 3000
lumens, provides full 3D capability, and offers a range of features with reasonable pricing to meet just
about any need. All three offer a comprehensive connection panel to satisfy both current and future
needs, including one HDMI v1.4a, two VGA-in and one VGA-out, one S-video, composite video, two
audio-in and one audio-out, an RS-232C, and one USB-B port.
The W303 offers WXGA resolution at a street price of $599. The XGA-resolution X303 will
carry a street price of $499, and the SVGA S303 will sell for $399. All are available now.
For more information on all Optoma products, go to www.optomausa.com or call 888-289-
6786.
W306ST Front Right:
Links to Images
https://roherpr.box.com/s/o9lkofhupjt5t5ug1cme
X306ST Front Left:https://roherpr.box.com/s/j1y07x2da5nplb89nc58
W303/X303/S303
Front Right: https://roherpr.box.com/s/udjrwsk7634e7rz5cvfp
Front Left:https://roherpr.box.com/s/ndsmi4pxuhihdvnbolzr
Front Head on: https://roherpr.box.com/s/g76qqse4lmmwnhybdxs8
I/O Panel: https://roherpr.box.com/s/pluvit6xvbymkk86bigm
About Optoma Technology, Inc.
Optoma Technology, Inc. is an award-winning developer of projection and digital display products for business,
education and home. The company manufactures multimedia projectors for mobile users, fixed installations,
classrooms and home theaters, as well as HD displays. Optoma products combine superior image processing
technologies with exceptional engineering and innovation to deliver images that are bright, crystal clear and
finely tuned for tone and color. Optoma products are sold through the company’s global network of Pro AV
dealers, major consumer electronics retailers and Internet resellers. For more information, visit
www.optomausa.com.
©2013 Optoma Technology, Inc. Optoma names and logos are registered trademarks of Optoma Technology, Inc. Other product names
mentioned herein may be trademarks and/or registered trademarks of their respective companies and are hereby recognized.
# # #

Budget-Concious Projector
Image Sheet
InfoComm Booth #2788
W306ST/X306ST
Front Left
W306ST/X306ST
Front Right
W306ST/X306ST
Head On
303-Series Front Right303-Series Head On
