Optoma Ew1610 family Installation manual

English

Appendices

RS232 Commands

Pin no. Name I/O (From Projec-

tor Side

1TXD OUT

2 RXD IN

3 GND __

Pin no. Spec.

1N/A

2RXD

3 TXD

4 DRT

5 GND

6 DSR

7 RTS

8 CTS

9N/A

12345

6789

RS232 Connector

53 English

Appendices

RS232 Protocol Function List

RS232 Commands

Baud Rate: 9600

Data Bits: 8

Parity: None

Stop Bits: 1

Flow Control: None

UART16550 FIFO: Disable

Projector Return (Pass): P

Projector Return (Fail): F

XX=01-99, projector's ID,

XX=00 is for all projectors

SEND to projector

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Description

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX00 1 7E 30 30 30 30 20 31 0D Power ON

~XX00 2 7E 30 30 30 30 20 32 0D Power OFF

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX01 1 7E 30 30 30 31 20 31 0D Resync

~XX02 1 7E 30 30 30 32 20 31 0D AV Mute On

~XX02 2 7E 30 30 30 32 20 32 0D Off

~XX03 1 7E 30 30 30 33 20 31 0D Mute On

~XX03 2 7E 30 30 30 33 20 32 0D Off

~XX04 1 7E 30 30 30 34 20 31 0D Freeze

~XX04 2 7E 30 30 30 34 20 32 0D Unfreeze

~XX05 1 7E 30 30 30 35 20 31 0D Zoom Plus

~XX06 1 7E 30 30 30 36 20 31 0D Zoom Minus

~XX07 1 7E 30 30 30 37 20 31 0D Up (Pan under zoom)

~XX08 1 7E 30 30 30 38 20 31 0D Down (Pan under zoom)

~XX09 1 7E 30 30 30 39 20 31 0D Left (Pan under zoom)

~XX10 1 7E 30 30 31 30 20 31 0D Right (Pan under zoom)

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX20 1 7E 30 30 32 30 20 31 0D Display Mode Presentation

~XX20 2 7E 30 30 32 30 20 32 0D Bright

~XX20 3 7E 30 30 32 30 20 33 0D Movie

~XX20 4 7E 30 30 32 30 20 34 0D sRGB

~XX20 5 7E 30 30 32 30 20 35 0D User 1

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX21 n 7E 30 30 32 31 20 a0D Brightness n= -50 - +50

~XX22 n 7E 30 30 32 32 20 a0D Contrast n= -50 - +50

~XX23 n 7E 30 30 32 33 20 a0D Sharpness n= -50 - +50

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX24 n 7E 30 30 32 34 20 a0D Color Red Gain n= -50 - +50

~XX25 n 7E 30 30 32 35 20 a0D Green Gain n= -50 - +50

~XX26 n 7E 30 30 32 36 20 a0D Blue Gain n= -50 - +50

~XX27 n 7E 30 30 32 37 20 a0D Red Bias n= -50 - +50

~XX28 n 7E 30 30 32 38 20 a0D Green Bias n= -50 - +50

~XX29 n 7E 30 30 32 39 20 a0D Blue Bias n= -50 - +50

~XX30 n 7E 30 30 33 30 20 a0D Cyan n= -50 - +50

~XX31 n 7E 30 30 33 31 20 a0D Yellow n= -50 - +50

~XX32 n 7E 30 30 33 32 20 a0D Magenta n= -50 - +50

~XX33 1 7E 30 30 33 33 20 31 0D Reset

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX34 n 7E 30 30 33 34 20 a0D WhitePeaking n= 0 - 10

~XX35 1 7E 30 30 33 35 20 31 0D Degamma Film

~XX35 2 7E 30 30 33 35 20 32 0D Video

~XX35 3 7E 30 30 33 35 20 33 0D Graphics

~XX35 4 7E 30 30 33 35 20 34 0D PC

~XX36 1 7E 30 30 36 30 20 37 0D Image AI On

~XX36 2 7E 30 30 36 30 20 37 0D Off

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX36 1 7E 30 30 33 36 20 31 0D Color Temp. Warm

~XX36 2 7E 30 30 33 36 20 32 0D Medium

~XX36 3 7E 30 30 33 36 20 33 0D Cold

~XX37 1 7E 30 30 33 37 20 31 0D Color Space Auto

~XX37 2 7E 30 30 33 37 20 32 0D RGB

~XX37 3 7E 30 30 33 37 20 33 0D YUV

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX39 2 7E 30 30 33 39 20 32 0D Input Source DVI

~XX39 5 7E 30 30 33 39 20 35 0D VGA

~XX39 9 7E 30 30 33 39 20 39 0D S-Video

~XX39 10 7E 30 30 33 39 20 31 30 0D Video

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX60 1 7E 30 30 36 30 20 31 0D Format 4:3

~XX60 2 7E 30 30 36 30 20 32 0D 16:10 / l6:9

~XX60 5 7E 30 30 36 30 20 35 0D LBX

~XX60 6 7E 30 30 36 30 20 36 0D Native

~XX60 7 7E 30 30 36 30 20 37 0D Auto

~XX61 1 7E 30 30 36 30 20 37 0D PCMode On

~XX61 2 7E 30 30 36 30 20 37 0D Off

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX61 n 7E 30 30 36 31 20 a0D Overscan n= 0 – 12

~XX62 n 7E 30 30 36 32 20 a0D Zoom n= 0 – 100

~XX63 n 7E 30 30 36 33 20 a0D H Image Shift n= -50 - +50

~XX64 n 7E 30 30 36 34 20 a0D V Image Shift n= -50 - +50

~XX66 n 7E 30 30 36 36 20 a0D V Keystone n= -20 - +20

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX70 1 7E 30 30 37 30 20 31 0D Language English

~XX70 2 7E 30 30 37 30 20 32 0D German

~XX70 3 7E 30 30 37 30 20 33 0D French

~XX70 4 7E 30 30 37 30 20 34 0D Italian

~XX70 5 7E 30 30 37 30 20 35 0D Spanish

~XX70 6 7E 30 30 37 30 20 36 0D Portuguese

~XX70 7 7E 30 30 37 30 20 37 0D Polish

~XX70 8 7E 30 30 37 30 20 38 0D Dutch

~XX70 9 7E 30 30 37 30 20 39 0D Swedish

~XX70 10 7E 30 30 37 30 20 31 30 0D Norwegian/Danish

~XX70 11 7E 30 30 37 30 20 31 31 0D Finnish

~XX70 12 7E 30 30 37 30 20 31 32 0D Greek

~XX70 13 7E 30 30 37 30 20 31 33 0D Traditional Chinese

~XX70 14 7E 30 30 37 30 20 31 34 0D Simplified Chinese

~XX70 15 7E 30 30 37 30 20 31 35 0D Japanese

~XX70 16 7E 30 30 37 30 20 31 36 0D Korean

~XX70 17 7E 30 30 37 30 20 31 37 0D Russian

~XX70 18 7E 30 30 37 30 20 31 38 0D Hungarian

~XX70 19 7E 30 30 37 30 20 31 39 0D Czech

~XX70 20 7E 30 30 37 30 20 32 30 0D Arabic

~XX70 21 7E 30 30 37 30 20 32 31 0D Thai

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX71 1 7E 30 30 37 31 20 31 0D Projection Front-Desktop

~XX71 2 7E 30 30 37 31 20 32 0D Rear-Desktop

~XX71 3 7E 30 30 37 31 20 33 0D Front-Ceiling

~XX71 4 7E 30 30 37 31 20 34 0D Rear-Ceiling

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

1. There is a <CR> after all

ASCII commands.

2. 0D is the HEX code for

<CR> in ASCII code.

English

Appendices

SEND to projector

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Description

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX72 1 7E 30 30 37 32 20 31 0D Menu Location Top Left

~XX72 2 7E 30 30 37 32 20 32 0D Top Right

~XX72 3 7E 30 30 37 32 20 33 0D Centre

~XX72 4 7E 30 30 37 32 20 34 0D Bottom Left

~XX72 5 7E 30 30 37 32 20 35 0D Bottom Right

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX73 n 7E 30 30 37 33 20 a 0D Signal Frequency n= -5 - +5

~XX74 n 7E 30 30 37 34 20 a 0D Phase n= 0 - 31

~XX75 n 7E 30 30 37 35 20 a 0D H. Position n= -5 - +5

~XX76 n 7E 30 30 37 36 20 a 0D V. Position n= -5 - +5

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX77 n Security Security Timer Month/Day/Hour nnnnnn

~XX78 1 7E 30 30 37 38 20 31 0D Security Settings On

~XX78 2 7E 30 30 37 38 20 32 0D Off

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX79 n 7E 30 30 37 39 20 a 0D Projector ID n=00-99

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX80 1 7E 30 30 38 30 20 31 0D Mute On On

~XX80 2 7E 30 30 38 30 20 32 0D Off Off

~XX81 n 7E 30 30 38 31 20 a 0D Volume n=0-15

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX82 1 7E 30 30 38 32 20 31 0D Start Up Logo On

~XX82 2 7E 30 30 38 32 20 31 0D Off

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX83 1 7E 30 30 38 32 20 31 0D Screen Type 16:10

~XX83 2 7E 30 30 38 32 20 31 0D 16:9

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX100 1 7E 30 30 31 30 30 20 31 0D Source Lock On

~XX100 2 7E 30 30 31 30 30 20 32 0D Off

~XX101 1 7E 30 30 31 30 31 20 31 0D High Altitude On

~XX101 2 7E 30 30 31 30 31 20 32 0D Off

~XX102 1 7E 30 30 31 30 32 20 31 0D Information Hide On

~XX102 2 7E 30 30 31 30 32 20 32 0D Off

~XX103 1 7E 30 30 31 30 33 20 31 0D Keypad Lock On

~XX103 2 7E 30 30 31 30 33 20 32 0D Off

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX104 1 7E 30 30 31 30 34 20 31 0D Background Color Blue

~XX104 2 7E 30 30 31 30 34 20 32 0D Black

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX105 1 7E 30 30 31 30 35 20 31 0D Advanced Direct Power On On

~XX105 2 7E 30 30 31 30 35 20 32 0D Off

~XX106 n 7E 30 30 31 30 36 20 a0D Auto Power Off (min) n=0-180

~XX107 n 7E 30 30 31 30 37 20 a0D Sleep Timer (min) n=0-999

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX108 1 7E 30 30 31 30 38 20 31 0D Lamp Setting Lamp Hour

~XX109 1 7E 30 30 31 30 39 20 31 0D Lamp Reminder On

~XX109 2 7E 30 30 31 30 39 20 32 0D Off

~XX110 1 7E 30 30 31 31 30 20 31 0D Brightness Mode BRIGHT

~XX110 2 7E 30 30 31 31 30 20 32 0D STD

~XX111 1 7E 30 30 31 31 31 20 31 0D Lamp Reset Yes

~XX111 2 7E 30 30 31 31 31 20 32 0D No

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX112 1 7E 30 30 31 31 32 20 31 0D Reset Yes

~XX112 2 7E 30 30 31 31 32 20 32 0D No

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

READ from projector

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX121 1 7E 30 30 31 32 31 20 31 0D Input Source

~XX122 1 7E 30 30 31 32 32 20 31 0D Software Version

~XX123 1 7E 30 30 31 32 33 20 31 0D Display Mode

~XX124 1 7E 30 30 31 32 34 20 31 0D Power State

~XX125 1 7E 30 30 31 32 35 20 31 0D Brightness

~XX126 1 7E 30 30 31 32 36 20 31 0D Contrast

~XX127 1 7E 30 30 31 32 37 20 31 0D Aspect Ratio

~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature

~XX129 1 7E 30 30 31 32 39 20 31 0D Projection Mode

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SEND to emulate Remote

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX140 1 7E 30 30 31 34 30 20 31 0D Power

~XX140 3 7E 30 30 31 34 30 20 33 0D Remote Mouse Up

~XX140 4 7E 30 30 31 34 30 20 34 0D Remote Mouse Left

~XX140 5 7E 30 30 31 34 30 20 35 0D Remote Mouse Enter

~XX140 6 7E 30 30 31 34 30 20 36 0D Remote Mouse Right

~XX140 7 7E 30 30 31 34 30 20 37 0D Remote Mouse Down

~XX140 8 7E 30 30 31 34 30 20 38 0D Mouse Left Click

~XX140 9 7E 30 30 31 34 30 20 39 0D Mouse Right Click

~XX140 10 7E 30 30 31 34 30 20 31 30 0D Up/Page +

~XX140 11 7E 30 30 31 34 30 20 31 31 0D Left/Source

~XX140 12 7E 30 30 31 34 30 20 31 32 0D Enter (for projection MENU)

~XX140 13 7E 30 30 31 34 30 20 31 33 0D Right/Re-SYNC

~XX140 14 7E 30 30 31 34 30 20 31 34 0D Down/Page -

~XX140 15 7E 30 30 31 34 30 20 31 35 0D Keystone +

~XX140 16 7E 30 30 31 34 30 20 31 36 0D Keystone -

~XX140 17 7E 30 30 31 34 30 20 31 37 0D Volume -

~XX140 18 7E 30 30 31 34 30 20 31 38 0D Volume +

~XX140 19 7E 30 30 31 34 30 20 31 39 0D Brightness

~XX140 20 7E 30 30 31 34 30 20 32 30 0D Menu

~XX140 21 7E 30 30 31 34 30 20 32 31 0D Zoom

~XX140 22 7E 30 30 31 34 30 20 32 32 0D DVI

~XX140 23 7E 30 30 31 34 30 20 32 33 0D Freeze

~XX140 24 7E 30 30 31 34 30 20 32 34 0D AV Mute

~XX140 25 7E 30 30 31 34 30 20 32 35 0D S-Video

~XX140 26 7E 30 30 31 34 30 20 32 36 0D VGA

~XX140 27 7E 30 30 31 34 30 20 32 37 0D Video

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SEND from projector automatically

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Projector Return Description

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

when Standby/Warming/Cooling/Out of Range/Lamp Fail INFOn n : 0/1/2/3/4 =

Standby/Warming/Cooling/Out of Range/Lamp Fail

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

READ from projector

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Projector Return Description

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
