High-denition performance—
Clear, widescreen images draw in
audiences and add impact to video
and picture content
Ideal for large rooms—Bright images
and high contrast ratio guarantee
color excellence and ne detail
Built for business—Presentation-
friendly IR remote features USB
mouse function and laser pointer
Ready for remote control—Supports
Crestron RoomView for management
and control via RJ45 connection
Environmentally-friendly design –
Consumes <1 watt of power in
standby mode
The Optoma TH1060P, a native 1080p
high-denition DLP projector, delivers
clear widescreen images to ensure
that your audience experiences the
full impact of your message. Bright
enough for use in large conference
rooms and classrooms, the Optoma
TH1060P includes a wide range
of analog and digital connectivity
options for your high-resolution output
sources. The Crestron RoomView®
user-friendly interface lets you easily
monitor, manage and control the
Optoma TH1060P remotely via
RJ45 connectivity.
CONNECTIVITY (May require optional accessories)
BRING YOUR AUDIENCE TO THE BIG SCREEN
DIGITAL
CAMERAS
CAMCORDERS
GAME
CONSOLES
TABLETS
SMART
PHONES
COMPUTERS SET TOP BOXES
BLU-RAY/DVD PLAYERS
DATA SERIES PROJECTOR
TH1060P
HD

DATA SERIES PROJECTOR — TH1060P
OPTICAL/TECHNICAL SPECIFICATIONS
Display Technology Single 0.65” DC2 DMD DLP Technology by
Texas Instruments
Native Resolution HD (1920 x 1080)
Brightness 4500 ANSI lumens
Contrast Ratio 2500:1 (full on/full off)
Displayable Colors 1.07 Billion
Lamp Life and Type* 3000/2000 Hours (STD/bright)
300W P-VIP
Projection Method Front, rear, ceiling mount, table top
Keystone Correction ±15° Vertical
Uniformity 85%
Aspect Ratio 16:9 Native, 4:3 compatible
Throw Ratio 1.59 to 1.91:1 (distance/width)
Projection Distance 3.28’ to 32.8’ (1.0 to 10m)
Image Size (Diagonal) 23.6” to 300” (0.6 to 7.62m)
Projection Lens F=2.5-2.76, f=23.5-28.2mm, 1.2x manual
zoom and focus
Offset 115%
Audio 3-watt speaker
Noise Level (STD/Bright) 28dB/30dB
Remote Control IR remote mouse control
Operating Temperature 41 to 104°F (5 to 40°C), 85% max humidity
Power Supply AC input 100-240V, 50-60Hz,
auto-switching
Power Consumption 380 watts (bright), 320 watts (STD),
<1 watt (standby)
COMPATIBILITY SPECIFICATIONS
Computer Compatibility HD, UXGA, WXGA, SXGA+, SXGA, XGA,
SVGA, VGA resized, VESA, PC and
Macintosh compatible
Video Input Compatibility NTSC, PAL, SECAM, SDTV (480i),
EDTV (480p), HDTV (720p, 1080i/p)
Vertical Scan Rate 50 to 85Hz
Horizontal Scan Rate 15, 31 to 90 KHz
User Controls Complete on-screen menu, adjustments in
23 languages
I/O Connection Ports Two HDMI, VGA-in, VGA-out, component,
S-video, composite video, stereo RCA
audio-in, stereo audio-out, RS-232, USB,
RJ45 and 12V trigger
Loop Through (Audio, VGA) Monitor: D-Sub 15 pin VGA output
(functional in both normal and standby
modes)
PHYSICAL SPECIFICATIONS
Security Kensington® Lock Port, security bar and
keypad lock
Weight 7.8 lbs (3.53kg)
Dimensions 12.8” x 4.29” x 10.19” (326 x 109 x 259 mm)
*Lamp life is dependent upon many factors, including lamp mode, display mode,
usage, environmental conditions and more. Lamp brightness can decrease over
time.
** 3D content can be viewed with active LCD shutter glasses or RF glasses when
projector is used with compatible 3D player. Please visit www.optoma.com for
more information. www.OptomaUSA.com
Copyright © 2012 Optoma Technology, Inc. DLP® and the DLP logo are registered trademarks of
Texas Instruments. All other trademarks are the property of their respective owners. All specications
subject to change at any time. The Optoma Express Program is only valid in the U.S.
Warranty
Three-year Optoma Express Repacement Service, One-year on lamp
What Comes in the Box
AC power cord, VGA to VGA cable, remote control, batteries for remote,
carrying case, lens cap, multilingual CD-ROM user’s manual, quick start card
and warranty card
Optional Accessories
HDMI cable, ceiling mount, VGA to component cable, S-video cable,
composite video cable, RS-232 cable and Panoview™ Series screens
Lamp: BL-FS300C
Mount: BM-5001U
Remote: BR-5033L
Case: BK-4013
UPC: 796435 41 719 2
4.29”
12.8”
10.19”
USB
Component Video
RJ-45
Composite Video
RCA Audio-in L/R 3W speaker
Audio-out/in
S-video
RS-232 IR
VGA / SCART / YPbPr
VGA-out HDMI-1 HDMI-2
