Opus OP13 User manual

USER
MANUAL

OP 13 USER MANUAL | version 1.0

CONTENTS
opuscamper.com.au 01
Contents Page 1
My OP13 Hybrid Caravan Page 2
Vehicle Ide cation Number (VIN) Page 3
Spec cations Page 4
Dimensions Page 6
Hitching & Trailer Electrics Page 7
Brake Set Up Page 8
Setting Up your Caravan Page 9
Water System Page 12
Gas System Page 15
240 Volt Mains Power Page 16
12 Volt Power Page 17
Care & Maintenance Page 20
Internal Features Page 21
Torque guide Page 28
Warranty Page 24
Notes Page 29
Service Schedule Page 27
OP 13 USER MANUAL | version 1.0

CLAIM: By receiving this handbook, you confirm that you will/have read and agree to all the terms
and conditions contained within and that you understand the correct way to use, maintain and care
for your OP13.
IMPORTANT: Please go to https://www.opuscamper.com.au/warranty/ to register and
activate your warranty before you read on.
My OP13 Hybrid Caravan
opuscamper.com.au 02
OWNER:
ADDRESS:
MODEL:
VIN:
BUILD
DATE:
ATM:
TARE:
MAX PAY
LOAD:
TYRE
SIZE:
DEALER:
OP 13 USER MANUAL | version 1.0

opuscamper.com.au 03
VEHICLE IDENTIFICATION
NUMBER (VIN)
OP 13 USER MANUAL | version 1.0

OP 13 USER MANUAL | version 1.0
6" Hot dip galvanised chassis
Aluminium Frame. Aluminium composite body with checker
plate. One piece walls, Floor & roof
Chassis
Construction
1. King Size Bed
2. Ensuite
3. Lounge Area with Table
4. Cupboard, Bench & Sink
5. Tall Cupboard
Internal
6. Fridge Slide
7. Slide Out Kitchen
8. Pantry
9. Fold-Out Table
opuscamper.com.au 04
SPECIFICATIONS - OP13
Metallic Grey
King Size Bed
Innerspring Mattress
LED strip lighting, LED reading lamps, LED clearance and tail
lamps, LED grab handle
Hot & Cold mixer tap at kitchen
Thetford shower/toilet with cassette toilet and 1 piece moulded
shower floor
Truma Aventa Air Conditioner
CD/DVD/MP3/USB/SD/BT Stereo with 2 int/ext speakers
Soft close cabinetry
Colour
Bed Set Up
Mattress
LED Lighting
Tap Set Up
Ensuite
Sound System
Air Conditioner
Cabinetry
Features

OP 13 USER MANUAL | version 1.0
Plumbing
Truma gas & electric hot water system
1x SEAFLO pump
1.5mm plate
Gas & Hot Water
Water Pumps
Water Tank Guard
External
Step
Jack
4 x wind down stabiliser legs
External stainless steel kitchen with 4 burner AGA approved stove
External slide out pantry, external sliding fridge tray
Pull-out aluminium step
Wind out awning
Ranger RV skylights
Kojack hydraulic jack
Stabiliser Legs
Slide Out Kitchen
Storage
Awning
Skylights
Heavy duty Ironman shock absorbers
ARK XO750 Jockey Wheel
DO35 3.5T articulated hitch
Electric brakes with adjustable handbrake and electric
break away switch
2x16 inch alloy wheels with 265/75R16 mud terrain tyres & 2x
spare wheels
2x120L, with stone guard
2x4.5kg adjustable holder
1 x 67L grey water tank with stone guard
Suspension
Jockey Wheel
Coupling
Brake System
Wheels/Tyres
Gas Bottle Holder
Fresh Water Tanks
Grey Water Tank
SPECIFICATIONS - OP13
opuscamper.com.au 05
Electrical
1x pop up bathroom vents
Roof Vents
12V & 240V
5x 100 watt solar panels
2x 105Ah Lithium Batteries
20A AC-DC Charger & 5A DC-DC Charger
7 PIN flat plug & Anderson plug
12V television with TV antenna
12V distribution panel with water & battery meters
12V outlets internal and external
Power Supply
Solar Panels
Battery
Battery Charger
Towing Wiring
Switchboard
TV
Power Outlets

OP 13 USER MANUAL | version 1.0
DIMENSIONS - OP13
opuscamper.com.au 06
2220mm WIDTH
6154mm LENGTH
2670mm
ATE TARE
2670mm HEIGHT
ATE TARE
6620mm
3040mm

OP 13 USER MANUAL | version 1.0
opuscamper.com.au 07
HITCHING & TRAILER
ELECTRICS
About your Coupling
7 PIN
The OPUS® is fitted with a 7-pin flat plug that
connects all the exterior trailer lighting and the
electric brakes to the towing vehicle. A standard
7 pin plug is required on your tow vehicle for this
to connect to.
ANDERSON PLUG
The OPUS® is also fitted with a standard 50 Amp
Anderson Plug which is connected to the caravan
batteries via 5 Amp DC-DC charger. If you have an
Anderson plug on your towing vehicle that is
connected to your vehicle battery, then you can
attach these two together whilst towing.
About your Electrical Plugs
The OPUS® OP13 comes as standard with
DO35 articulated off-road coupling. When
hitching the OPUS® to your towing vehicle
you must ensure that someone is close to
the trailer handbrake in order to maintain
control of the trailer, particularly when
manoeuvring on uneven ground or a slope.
IMPORTANT
Wheel nuts should be checked after
first 100km and then every 1000km.
IMPORTANT Disconnect these plugs when the engine of the towing vehicle is
notrunning, as it will continue to draw current and you may end
up with a flat battery on your towing vehicle.
This should not be used as solar input.

OP 13 USER MANUAL | version 1.0
opuscamper.com.au 08
BRAKE SET UP
About your brakes
The OPUS® is fitted with electric brakes. Your
tow vehicle will need an electric brake controller
fitted in order to tow the caravan and operate
the electric brakes safely.
Before towing, check that the caravan brakes
are on. Refer to your vehicles brake controller
user manual. To test brakes, connect to running
car and use the electric brake controller manual
override switch/button/lever.
As part of the regular service check you
should have completed by an accredited
industry service agent, the brakes will be
checked and maintained.
IMPORTANT
Failure to tow with a brake controller
in your vehicle is both dangerous and
illegal and will void warranty.

OP 13 USER MANUAL | version 1.0opuscamper.com.au 09
Setting Up your Caravan
1.Once you have positioned your OPUS® on level
ground in the desired location, engage the
handbrake. Levelling ramps may be required
(not supplied).
STEP 1STEP 3
Using the leg winder supplied, gently lower
corner steady legs until each touches the ground
with enough pressure to stop any rocking.
STEP 4
4.Enter the caravan and push the lift
arms at either end to lift the roof, securing
them in the upright position with the latch.
STEP 5
5.Unlatch and fold down the spare wheels.
STEP 2
Raise or lower jockey wheel to level
your caravan lengthways.
Initial Steps
IMPORTANT
Corner steady legs are only to
steady the caravan, NOT to be
used to level or lift it.

OP 13 USER MANUAL | version 1.0
Setting Up Your Caravan
opuscamper.com.au 10
Unlatch both jerry can holders and place them
as shown.
STEP 6
Unfold the rear floor and wall fit into place.
STEP 9
Unlatch the rear door from outside and
lift the door outwards.
STEP 7
Unlatch and unfold fully each side panel.
STEP 8
Initial Steps
IMPORTANT
Make sure to latch & lock the
rear panel properly in both ends.

OP 13 USER MANUAL | version 1.0
Awning Setup
opuscamper.com.au 11
IMPORTANT
1Start unwinding the awning as
shown using winding stick located in
the front tunnelboot.
3Take out awning legs from both sides. 4Adjust the awning height using thumb
screw in the awning leg.
2Unwind the awning completely
as shown.
Slideout hinge of the awning leg as shown in the second photo
before put them down in the floor

OP 13 USER MANUAL | version 1.0
Water System
opuscamper.com.au 12
Hot water is provided via the hot water system on the driver side underneath the king bed.
The OPUS® is fitted with a grey water tank. All external kitchen, internal sink and the ensuite are
directly connected to grey water tank. Grey water tank gauge is located in the main switch board.
Drain for the grey water tank located in the driver side as shown below.
The OPUS® is fitted with two freshwater tanks. Each tank has its own lockable fill point on the driver
side of the van and is plumbed to a 12v switchable water pump located on the circuit board. The pump
supplies water to the slide-out kitchen, internal sink and ensuite.
IMPORTANT
Regularly check water seals in
wet areas.

Switching on gas operation
Hot Water Service
opuscamper.com.au 13
Remove the cowl cover which
is located in driver side of the OPUS®.
Make sure the hot water system connected to gas.
Select water heater mode using the switch located
under driver side lounge.
Make sure pump switch turned on in the
main switch board.
The OPUS® is fitted with a hot water service
operated on gas or/and electricity. For faster
heating up period the appliance can be
simultaneously operatedwith gas and
electrical power.
IMPORTANT
Please refer to hot water system
user manual for instructions
OP 13 USER MANUAL | version 1.0

Hot Water Service
opuscamper.com.au 14
Electrical Operation (240V)
Remove the cowl cover which is located in
driver side of the OPUS®.
Make sure hot water system plugged in
and switch is turned on. Switch is located
under bed next to battery compartment.
Make sure pump switch turned on in
the main switch board.
OP 13 USER MANUAL | version 1.0

opuscamper.com.au 15
The OPUS® is fitted with a mount for two 4.5kg gas bottles inside front driver side tunnel boot
compartment. The bottle is to be connected to gas regulator and must be turned off when the
gas is not in use.
PLEASE refer to the information located on the rear of your
OPUS® gas certificate.
STEP 1
To install a gas cylinder, ensure the gas cylinder is
placed correctly with J-clamp, continue with
attaching the gas hose to bottle ensuring that’s
been tightened so no leaks occur.
STEP 2
The gas tap/valve on the top of the gas bottle can now be opened.
STEP 4
Turn on the yellow gas tap (situated underneath the rear of the OPUS behind each of the gas
outlets unit) by turning 90°.
STEP 5
Lift up lid of the gas hob, turn on one of the burners (push in, hold the knob down until flame is lit
and stays on. Keep pressing the button until the gas has had time to fill up the system and the
burner will ignite.
STEP 6
Ensure that the gas bottle valve is closed prior to packing up the OPUS® for transit or storage. The
OPUS® has two gas outlet bayonet fittings. At each point there is an on/off valve located right
behind the gas outlet. Each valve must be turned off when not in use.
The outlet on the driver’s side is a gas BBQ (not supplied) while the outlet on the passenger side is to
supply the 4 burner cook top in the slide-out kitchen. This hose is fitted to the cook top and is located
under the sink. Both points should have the protective plugs inserted when not in use.
When the gas is not in use the shut off valve and gas bottle should be in the off/closed position.
Gas fumes inside a caravan could result in unconsciousness, brain damage or even death. Follow safe
operating procedures with gas at all times:
•Ensure good ventilation throughout, at ALL times
•Do not use any other gas systems than those provided with the OPUS®
•Always turn off the shut off valve IMMEDIATELY after use.
STEP 7
Once kitchen has been pulled out full you can fit the gas bayonet hose to the outlet. This is a
simple push and twist to install.
STEP 3
Gas System
Safe operating procedures for your gas system
E.g. like getting a gas
bottle and attaching it to
your BBQ at home. First
connect the gas hose onto
the cylinder. It is advisable
to keep an adjustable
spanner with jaw opening
up to 30mm for this use.
OP 13 USER MANUAL | version 1.0

opuscamper.com.au 16
The main 15Amp power input is found on the
driver’s side of the OPUS®. There are 4x internal
and 1x External 240V power points. Under the bed
storage area there are 3 240V power points one for
battery charger, one for the heater and one spare.
The OPUS® comes fitted with a
240-volt power system.
The main circuit breaker and
RCD is in the main switch board.
In the seating area behind the TV
point there is another 240V outlet.
240V - Safe operating procedures
240 Volt Mains Power
IMPORTANT Take extra care when using the sockets, do not cause a hazard.
The external power point is located on the
passenger side of the OPUS® behind the kitchen.
OP 13 USER MANUAL | version 1.0

opuscamper.com.au 17
In the front toolbox / fridge compartment
there is a standard 12V fridge socket.
The OPUS® has many 12V outlets - they are a combination of standard 12V sockets, mini 12V sockets,
USB sockets and switches.
12 Volt - Safe operating procedures
12 Volt Power
IMPORTA
You will find their location as follows:
In the same area there is a small switch
and LED work light.
Inside the OPUS® there are two 12V mini sockets
next to TV point. These are for the 12V LED
light kit (optional extra).
Both sides of the upper tunnel boot
storage area there is a LED work light
with a small switch.
OP 13 USER MANUAL | version 1.0

opuscamper.com.au 18
Next to the picnic table there is
a twin 12V USB socket.
12 Volt Power
Externally at the rear passage side next to the
kitchen slide-out there are two additional
12V mini sockets and a standard 12V socket.
Next to the main door you will find four
switches for LED floor lights and annexe
lights around the caravan.
The two mini sockets are designed to
operate the 12V LED light on the kitchen
and a small annexe light.
OP 13 USER MANUAL | version 1.0
