User's Manual
Dome IP Camera
V4.21
Please read this manual carefully before you
attempt to Install this product and retain it for your
future reference.

9
Physical Description
Dome IP Camera
Metal Mounting Kit
Status LED
Reset Button
SD Card Slot
Aviation Connect
Plug in
Built in
Microphone
LENS
Hardware Reboot & Restore
The Reset
button is used to restore the factory default settings.
Sometimes resetting the system can return the camera to normal
operation.
Restore - Press and release the reset button with a paper clip or thin
object. T
he LED light will be out, after few seconds it will relight again.
(Note: that all settings will be restored to factory default)
Status LED
The LED indicates the status of the Network Camera.
1) Green LED - Power is being supplied to the Network Camera.
2) Blinking Orange LED –
IP camera has been connected and data is
present.

10
Adapter Box General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is
used to connect external input / output devices. The pin definitions
are described below.
Pin No. Name Function Description
4 GND Ground This is a signal ground use for
DI and DO.
3 DI Digital
Input
Connect to GND to activate or
deactivate by software setting.
2 DO Digital
Output
With a maximum load of 1A
and maximum voltage of 60V
DV, this output has an
open-collector NPN Darlington
transistor with the emitter to
the GND pin.
If used with an external relay, a
diode must be
connected in
parallel with the load, for
protection against voltage
transients.
1 12V Power 12VDC ± 10%, max. 0.4A

11
DI/DO Diagram
Please refer to the following illustration for the connection method.

12
Installation Method
Please refer to the illustration and consider environment differences to appropriately mount the IP camera.
1) 2) 3)
Notes: This 2) 3) is extra mounting Kit and required to buy separately, please contact with
your dealer.

13
Installation steps for metal bracket
1) Take out the Installation Template (from the packing box), and stick it to the desired installation spot on your ceiling. Please mark down the 4
circles that show on the figure. (see picture below)

14
2) Screw down the metal bracket with the same position as the instruction figure, and drill the hole with at least 20mm diameter in specific
area.
Notes: this step is very important, and includes 2 key factors, 1. The centre line of the biggest circle should be on the same horizontal line as
the other circles. 2. The biggest circle should be between 20mm to 25mm in diameter.

15
3) Before you try to attach the Dome IP camera to the ceiling, take off the white plastic chips (at cable outlet), then push the cable down into
the gap between camera and plastic ring ( see the picture below), then feed the cable connector into the biggest hole, and align the microphone
hole with the mark circle.

16
4) Turn the camera 90 degrees (anticlockwise), using the microphone hole as reference.

17
Internet connection
Connected Via a router
Before setting up the Network Camera over the Internet, make sure
you have a router and follow the steps below.
1) Connect
your Network Camera behind a router, the Internet
environment is illustrated below.
Regarding how to obtain your IP address, please refer to Manually
Setting TCP/IP Settings for a Camera for details.
2) In this case, if the Local Area Network (LAN) IP address of your
Network Camera is 192.168.168.100, please forward the following
ports for the Network Camera on the router.
HTTP port
RTSP port
RTP port for audio
RTCP port for audio
RTP port for video
RTCP port for video
If you have changed the port numbers on the Network page, please
open the ports accordingly on your router. For information on how
to forward ports on the router, please refer to your router’s user’s
manual.
3) Find out the public IP address of your router provided by your ISP
(Internet Service Provider). Use the public IP and the secondary
HTTP port to access the Network Camera from the Internet. Please
refer to TCP/IP Setup for details.

18
Connected directly to a Computer
You can also connect the IP Cam directly to a computer. Please note
that in this mode you will not be able to view your IP Cam from
anywhere else apart from the computer you are currently using.
Connect one end of the network cable in to the IP Cam Network
Connection socket, and plug the other end in to a spare network
port on your computer.
Connect the included power adapter to the power port on the
camera and the other end into an electrical socket. Do not turn the
power on at this time.
You must then assign your computer an IP address so it can talk
easily to the camera.
For Windows system:
1.
Open the Control Panel and double click on “Network
Connections” then right click on your “Local Ar
ea Network”
connection, and click Properties. Be sure to select the Network icon
that corresponds to where you have plugged the IP Cam in to – so
this would not be listed as a Wireless, WiFi or Bluetooth Network.
2. Select “Internet Protocol (TCP/IP)” then click Properties.
3.
Take note of your current TCP/IP Settings and then click on “Use
the following IP settings”
4. In the “IP Address” Field type in the number 192.168.168.20
5. In the “Subnet Mask” type in 255.255.255.0
6. Leave “Default Gateway” setting blank
(The camera will
automatically assign itself this IP address when no DHCP server is
present)
7. Leave DNS server settings blank.
8. Click “OK” then “Close” to apply these settings.
9. Turn the power on to the IP Cam.
The Connectivity Status indicator on the front of the camera will
light up.

19
Viewing the camera from your mobile phone
The camera provides the ability to view the cameras monitored
through your mobile phone as a live video stream, it supports the
telecommunications standard of 3GPP streaming format. All 3G
enabled mobile devices and most 2G phones that support the
streaming standard of 3GPP are compatible. Otherwise, you also can
view the pictures even if your phone is not 3GPP compatible.
1) For example, if camera’s external IP address is 202.96.135.206 and
external port is 8151, then type http://202.96.135.206:8151/mobile
in your Internet browser address bar of mobile phone, the login
screen will appear:
2) To click the “Picture live” button if your mobile phone is not 3GPP
standard, then you can view the pictures which will refresh every 3
seconds.
3) To click the “3GPP stream live” if your mobile phone support 3GPP
standard, and the following screen will appear:
Notes: You have to click “Setting” button, make sure that the Mobile
stream is enabled and the RTSP authentication is disabled before you
view the 3GPP stream live.

20
Manually Setting TCP/IP Settings for a Camera
In most cases, this is not required as the router will assign the correct
settings to the camera. It is however useful if you want to setup the
TCP/IP settings of the camera before you connect to it, if DHCP is
disabled across your network, or if you have subnet network
problems.
1) Launch Camera Setup program to detect cameras on the local
network.
2) Click on “Setup” button and the following setup interface will pop
up.
3) Enter a unique name for the camera, the location (optional) and
leave the default port number as 80. “Obtain an IP address
automatically” and “Obtain DNS server address automatically” are
selected by default, if you are confident enough to enter your own
settings, you can do so by selecting “Use the following IP address” and
follow the guidelines on the next page.
4) To obtain the IP addresses specific to your network, click “Start”
then “Run” and type “cmd” in the text box and click “Ok”. The will
bring up the MS-DOS prompt and in this window type “ipconfig/all”
and press enter. A screen similar to the one below will be displayed.

21
5) Take Notes of the following:
a. IP Address
b. Subnet Mask
c. Default Gateway
d. DNS Servers (Both numbers with the first being the primary DNS
server and the second being the secondary DNS server)
6) Enter the details Noted in step 5 into the relevant fields.
Notes: The default IP address of the camera is 192.168.168.100This
can be changed to any IP address on your IP range.
For example if the IP address of your PC is 192.198.1.52
then the IP address of your camera should be unique and on the
same subnet
i.e. 192.198.1.X where X is any number between 1 and 255 except
52
Ensure the IP address you chose is not the same as other network
devices on your network as this will result in conflict and may cause
the device to not to work properly.
7) Once you’ve entered the details click “Apply” then “Exit”.

22
Program installation & Usage
The camera Setup utility can easily and quickly detect cameras
connected to your local network and list them on the Camera Setup
window; also you can use the camera Setup utility to assign an IP
address to each camera.
1) Insert the Installation CD into your CD-
ROM drive and the
installation screen should appear automatically (See image below). If
it does not, click “Start” then “Run”. In the text field enter
“D:\autorun.exe” (if “D:” is the letter of your CD-ROM Drive)
2) Click on “Install Camera Setup” and with the following screen Click
“Next”.
3) If you want to change the default folder click “Change” to replace
otherwise click “Next”.
4) Click “Install”to install IP Camera Software.
5) Click “Finish”to end the installation. You should now find an icon
on the desktop.

23
6) Double-click the Camera Setup icon on the Desktop to launch the
program. The Camera Setup utility should automatically find your
camera if is correctly connected (See image below).
Refresh -Click Refresh to search for cameras on the local network.
Setup -Select the required camera and click Setup to configure the
network settings for the camera.
Open -Select the required camera and click Open to access the
camera via a web browser.
Exit -Click Exit to exit the Camera Setup window.
Tips: Select and double click one of the cameras from the Device list, to
open the camera view via the web browser.

24
Launch the Program
1) Find Icon from the desktop and double click it,
2) Find IP Camera from the pop up window
3) Double click the relevant IP Camera item or click “Open” button, the
IP camera homepage will shows up with your default Internet explorer.
Login in
You could choose to click on the item Enter to access the picture
viewing interface or the item Setting to access the system setting
interface.
The dialog will appear. The default username and password for IP
Camera is:
Username: admin
Password: admin
Tips: The general users assigned by the administrator are not allowed
to enter the system Setting interface. They can only be permitted to
Enter the picture viewing interface.

25
User Interface
Home -takes you back to your Homepage.
Settings - will take you to the cameras internal settings.
Audio Upload - Press and release to start sending audio from your computer’s microphone to the camera
speakers.
Press and release to stop sending audio.
Volume----
Mute - Click the Mute button to mute the audio.
Slider -the slide block horizontally to adjust volume.
Image----
Snapshot -
Press the Snapshot button to capture a still image of the camera view. Click Save to store the
snapshot on your computer, the file is automatically assigned the data & time of the snapshot. Press Cancel to
exit.
Zoom -Click on the + button and the cursor turns to a magnifier. Move the magnifier to the desired location
and click on an image area. Press - button to return to the normal view.
Record-----
Recording - Press the Record button to record video and audio (if enabled). This will save the file in ASF
format on your PC.
Recording options -
Click this button to set the recoding parameters. You can set record path, video file size
and select whether to star recording automatically when motion is detected and the length of the recording in
seconds.
Size-----
Image size -There are three Image Size options: [640x480] [320x240] [160x120] Please Notes that this only
changes the image size being viewed not the image size the camera is transmitting and/or recording. To
change the transmitting/recording image size, please refer to the Stream Setup.

26
Network Camera Interface Setting
Change the passwords
1) Click on Settings from the home page. When connecting the
camera for the first time or after resetting it to its default
settings, the setup interface start page below will load.
It is recommended that you change the admin password in
order to avoid unauthorized access to the camera. To do this
follow the instructions by clicking on the underlined link “here”
to access administrator password editing page.
2) Type the password in both fields then click Save. Please take
Notes of the password. If you forget the password, the camera
will have to be reset to its default settings in order to gain
access to the settings page and this will also reset all other
settings you may have changed.

27
3) You are required to re-login with the changed password.
Notes: After successful login, the following page will appear.
