ORATOR PA101 User manual
USER MANUAL
ORATOR
Portable PA
Speaker
PA101
Readthismanualcarefullytoensuresafeoperationand
to get excellent acoustics from the speaker.
Troubleshooting:
A. Speaker:
1. No function light & no sound.
Ensure the power button is turned on.
Ensurethe power adapter is properly connectedto wall power & plug
properlyinserted to speaker.
Ensure the battery is charged.
2. Function light is on but no sound.
Make sure the cable inputs are properly connected into correct sockets.
Make sure you have selected the correct input/mode.
Check that output device is operating OK if external device.
B. Wireless Microphone
1 .The Receiver is turned on but the indicator light is not lit?
Make sure if the DC power cable is properly fiitted into the power socket &
the DC cable is firmly fitted into the Receiver.
2. When you turn on both the Receiver & Microphone, the RF light does not
comeon.
TheRF light should come on whenboth transmitter & receiver are
on & the frequencies are matched. Check the power indicator light is
on in the Receiver & the Transmitter is not showing “Low Battery”. If
OK, then check that the frequency is matched & reset if necessary.
3. When you speak into the Microphone, no sound is heard from theAmplifier/
Speaker.
Make sure the volume on the Receiver is turned up, and check that
the audio (6.3mm) cable is properly installed.
4 .The audio output signal is not very good.
Checkthat you have installed theantennae.
Check that the Transmitter battery is not too low..
Check that the Receiver is within range & not obstructed by too
many solid objects.
Perhaps there is a strong interference in your area & you need to
changefrequency.
5. The quality of the sound is not good.
Check that the Transmitter battery is not too low..
Perhaps there is a strong interference in your area & you need to
changefrequency.
DearCustomer,
Congratulations on yourpurchaseofthe ORATOR PA101speaker.Thisspeaker
incorporatesthelatestfeaturesincludingAustralianapprovedUHFwireless
microphonetechnology, MP5 DVD player, MP3Player, Bluetooth,FM Radio,
80WRMSof power output, rechargeable battery & plenty of connections for input
toandoutputfrom the speaker. It is powered by a low voltagepoweradapterfor
maximum safety.
Safety/Warning Notes:
For any service and repair, contactABI as per the details below. Do
not attempt to remove the amplifier or to replace any parts without
firstcontactingABIoranauthorisedserviceagent.
To prevent fire or electric shock, do not expose this speaker or the
powersupply to rain or moisture.
If you connect to an external battery, ensure the terminal cables are
connectedpositivetopositive&negativetonegative,oryouwill
damage some electronic components & the internal 12V fuse.
Tomaximise the life of your rechargeable battery, the battery should
berechargedat least every 3 months. If left uncharged, the battery
lifemaybe seriously damaged.
How to Use Bluetooth Function:
1.Turnthespeaker on.
2.Press“Mode” (7) button until “Bluetooth” displayed.
3. In Bluetooth setup on your transmitter device (phone, etc), select “BT Speaker”.
4.The speaker will “beep” when thebluetooth connection is successful.
5. You can now start streaming your music.
MP3 Player Operation:
Note there are 2 x MP3 players included. The player in the top right of the
Amplifier panel (8) is recommended and is controlled by controls 7. Note that the
music format MUST be MP3 or the player will not work. The second MP3 player
(26) included in the DVD can also be used, but is controlled via DVD controls
(14).
For any service or operation queries, contact ABI or your local ORATOR Dealer.
Battery Replacement:
The battery is located in the compartment at the bottom of the rear of the
speaker, under the Amplifier panel. Simply press the latch lock to open. The
battery is then easily accessible. When replacing the battery, ensure that the
same battery type is used, & that the positive (red) & negative (black) terminal
connectionsarecorrectlyreplaced.
Specifications of the PA101:
Speaker Unit: 1 x 10” bass + 1 x 3” treble
RMSOutput: 80W
Impedance: 8 ohms
FrequencyResponse: 50Hz - 20 kHz
Separation: >48 dB
S/N ratio: > 92 dB
Inputs: 2xMicrophone(6.3mm)
1 x Guitar (6.3mm)
Line In (2 x RCA)
WirelessUHFMicrophone(builtinreceiver)
MP3 (USB or SD)
Bluetooth(builtinreceiver)
FMradio(builtinreceiver)
DVD, DVD, SVCD, MP4, WMA, VCD, DVCD, CD,
JPG
Outputs: Video(Yellow RCA)
Audio (2 x RCA)
Power: 15V 4A
Battery: 12V7Ah
WirelessMicrophone: UHF, 100 selectable frequencies, PLL,
range520 - 694 MHz, 32 MHz switching bandwidth,
100kHzchannelgrid,30mWRF power output.
DiversityReceiver.
Care of the Speaker/Accessories Management:
We have included a dust cover for use with the PA101. This is designed to cover
the speaker when not in use, to protect the speaker from any dust.Also your
accessories(poweradapter,wirelessmicrophone&remotecontrol)canbe
stored in the pocket of the cover to ensure the accessories are together with the
speaker.
Moving/Mounting the Speaker:
The PA101 has a pull up handle & wheels for easy transport; a handle for lifting,
& a 35mm mounting socket under the base of the speaker. Tripods stands & wall
mount brackets are available to suit thissocket, for easy speaker mounting.
RearPanelofthePA101 Speaker:
1. Guitar Volume
2. Microphone (cable) Volume
3. Echo Volume
4. Bass Volume
5. Treble Volume
6.Main Volume
7.Repeat:AUX/MP3/FM/
Bluetooth
MP3 Next Song
MP3 Play
MP3 Prev Song
Mode:Aux/MP3/FM/Bluetooth
8.USB/SD Input
9. Audio Input
10. Audio Output
11. Video Output
12. Mode Switch:SD/USB/FM
13. Eject Button(EJ)
14.REW/UPSEARCH/Select Station
Play/Pause
FWD/DOWN SEARCH/Select Station
15. DVD Player Power on/off
16. Channel Switching
17. UHF Micro Power on/off
18. Speaker Power on/off
19. DC Power Input 12V
FM Radio Operation:
The FM radio is incorporated into the DVD. To operate the radio, select FM on
themodebutton(12).Usebuttons13or14or move up/down through channel
station frequencies to select the FM station you want.A long press will search
until it finds a station & will then stop.
Additional Speaker:
Ifyouwantto add an additional speaker for extra volume output, we
recommended the passive ORATOR PA10 speaker that is manufactured for this
purpose.ThePA10 isconnected using the audio output (10) connectors.
Audio Input:
If you want to input audio from another audio player, such as an external DVD or
music player, use the audio input (9) connectors.
Microphone (cable) Input:
ThePA101 is fitted with 2 microphoneinput connectors (MIC1 and MIC2) that
enableyoutoconnecttraditionalcable microphones. The input volume can be
controlled by the M. VOL (2) control knob.
Guitar (cable) Input:
The PA101 is fitted with a guitar input connector (GT1) that allows you to
connect an electric guitar. The input volume can be controlled by the
GUITAR.VOL(1)controlknob.
EchoFunction:
The PA101 is fitted with an echo function that is normally only used for music
(karaoke)operation.If used for normal speech, the audio can sound a little
distorted so we recommend the control being left at -.
Audio Control:
ThePA101 has 3 controlknobs for basic audio functions. The VOLUME (6)
controlis the Master Output volume controlling theoutput volume. Bass (4) and
Treble (5) controls allow you to create the balance between Bass & Treble in the
output that you desire. For normal operation, it is recommended that both are
centred(12 o’clock position).
Battery Operation:
There are 3 LED lights next to the MIC input connectors that display the status
of the battery. The top white LED shows that the battery is being charged. The
centre red LED shows that the battery needs charging & the bottom green light
shows that the battery is adequately charged. Ensure that the battery is charged
at least every 3 months to maximise the life of the battery.
20. Guitar Input
21. Microphone Input
22. DC 12V Input
23. DVD Volume -/+
24. MP3/MP5 Switch
25. EQ Setting
26.DVD PlayerUSB/SD Input
27. UHF MicAntenna
28. Wireless Mic Volume
1. Band: Change radio band
2. Power button
3. Playing time settings
4. Pause
5. Setup: Displays setup menu
6. Cursor buttons in menu mode
7. Volume +/-
8. Changes audio mode
9. Pregram tracks/chapters to play
10. Select playback control
11. Change subtitle language
12. Selects segment to repeat
13. On screen display
14. Autostore radio stations
15. Mute
16. Change from disc to radio
17. Skip track/chapters
18. Zooms the picture
19. Input button
20. In discs, changes tracks
21. Numeric buttons
22. Selects 10th digit
23. Shows disc title
24. Changes view angle
25. Random play
26. Slows play speed.
DVD Remote Functions:
Wireless Microphone Operation:
Frequency: The new ORATOR wireless UHF microphone system has been
re-designed tomeettheAustralian Government’snewlaws,commencingJan1
2015, relating to legal frequencies that can be used for wireless microphones in
Australia. The system has the choice of 100 frequencies, all within the legal
520-694MHzrange.Theactualfrequencybeingused is displayed on your
microphonedisplayscreen.
Frequency Selection: The UHF band is not only used for wireless
microphones.Otherequipmentoperatinglocallyonthesame frequency may
causeinterference.DigitalTV is the most common problem for microphones and
as the frequencies used by TV channels varies by location, a frequency that
may work well in one area, may be subject to interference elsewhere. Usually,
once you select a frequency that works well in your area, it shouldn’t need
changingunlessyouaremovingaroundthecountry.
Microphone System Operation:Thereceivermodulein the
speaker has an on/off switch. It also has an input volume control
knob,connectorfortheaerial, frequency channel display screen,
and 3 small buttons with Up, Down & IR labels. There are also 2
small LEDs, one labelled RF & 1 labelled IR (see pic). The RF
lightwillbelit when the microphone & receiver are “paired” on the
samefrequency.Tochangefrequency&then “pair”withthe
microphone,presstheUpor Down buttons to move to another
frequencyasrequired,then press the IR button. The screen will
displayadashedline.ThemicrophoneIRreceiver(smallclear
areabelowpowerbutton)mustbe held close to the Receiver IR
LED.Thesystem should now be paired. The microphone must be
in position quickly, so if the pairing does not work (if the RF LED
is not bright), then try again.
Microphone Operation: Themicrophone is battery operated. Press the Power
buttonto turn on/off.Thefrequency will be displayed on the screen.Toreplace
thebattery, remove the bottom black cover by turning the coveranticlockwise.
The microphone uses 2 xAAbatteries.
DVD MP5 Operation:
1. This DVD player is compatible with DVD, SVCD,
MP4, WMA, VCD, DVCD, CD and JPG formats.
The operation of the DVD is the same as other
commonDVDplayers.
2.Using the DVD requires additional batteryuse
and it will reduce the operation time of the battery
speaker, comparedtomicrophoneonly, bluetooth
or MP3 use.
3.Video(11) and audio (10) outputconnectorsare
available so that the DVD can be be seen & heard
onanotherdevice(LEDTV, projector, etc) if
required.
DVDRemote
