Orava SW-300 User manual

SW-300
Instruction manual
Electric towel dryer
EN
SW-300
Please read this manual carefully before using the device and
keep it for future reference.

2EN
Intended use of the device
The device is designed exclusively for drying or heating towels and
some types of clothing, e.g. laundry, to the extent specified in the
technical and operating parameters and functions, safety and user
instructions and external influences of the operating environment.
ORAVA electrical appliances are manufactured according to the
knowledge of the current state of technology and recognized safety
and technical rules. Nevertheless, incorrect and unprofessional use
or use contrary to the intended purpose may create a risk of injury or
endanger the life of the user or a third party, resp. damage to equipment
and other property.
GENERAL SAFETY INSTRUCTIONS AND WARNINGS
• This document contains important safety instructions and warnings for
safe, correct and economical operation of the electrical equipment. Its
compliance helps the user avoid risks, increase reliability and product
life.
• In this document, the general term product is used in text parts such as:
electrical equipment - any device used for the production, conversion,
transmission, distribution or use of electricity.
• From the point of view of the purpose of using electricity, the concept
of electrical equipment in the strict sense of the word will include the
following categories:
- household electric appliances,
- information and communication equipment,
- consumer electronics,
- lighting equipment,
- electrical and electronic tools,
- toys and equipment for sporting and recreational purposes,
- medical devices (aids),
- monitoring and control devices,
- vending machines.

3EN
1.1 General safety instructions
• Before operating the unit, we recommend that you carefully read the
instruction manual and operate the equipment in accordance with the
instructions!
• The safety instructions and warnings in this manual do not cover all
the possible conditions and situations that may arise when using
the device. The user must understand that a factor that cannot be
incorporated into any of the products is personal responsibility and
caution. These factors must therefore be ensured by users serving this
device.
• Failure to follow the safety instructions and warnings is forbidden by the
manufacturer for any damage to health or property!
• Keep the instruction manual as close to the device as possible
throughout its service life. Always keep the instruction manual together
with the appliance for future use and use by new users.
• Use the appliance only for the intended purpose and in the manner
specified by the manufacturer.
• The appliance is intended for home and similar indoor use without
special focus.
• This appliance is intended, in addition to domestic use, for the following
uses:
- in shops, offices and other similar work environments;
- in economic buildings;
- in hotels, motels and other residential environments;
- in bed and breakfast establishments.
• It is not a professional device for commercial use.
• Do not change the technical parameters and features of the device by
unauthorized modification or modification of any part of the device.
• The manufacturer is not responsible for damages caused during
transportation, misuse, damage or destruction of the equipment due to
adverse weather conditions.
1.2 Safety of the operating environment
• Do not use the device in an industrial environment or outside
environment!
• Do not expose the appliance to:
- sources of excessive heat or open flame,
- dripping or splashing water,
- vibration and excessive mechanical stress,
- insects, animals and plants,
- aggressive and chemical substances.
• The operating environment of the device must always be in accordance
with the basic characteristics set out.

4EN
• Features of the operating environment:
1. Ambient temperature: +5 ÷ +40 ° C
2. Humidity: 5 ÷ 85%
3. Altitude: ≤ 2 000 m
4. Occurrence of water: intermittent condensation of water or occurrence
of water vapor
5. Occurrence of foreign bodies: quantity and type of dust are insignificant
6. Protection degree: min. IP20 (device protected from touching
dangerous parts by hand and non-waterproof)
• This degree of protection is not indicated on the product and on the
technical parameters in the operating instructions.
• If the protection class of the product is different from IPX0, this
information is then displayed on the label of the appliance or in the
technical data of the operating instructions.
• Other characteristics of the domestic operating environment
(mechanical stress - strain and vibrations, occurrence of plant, animals,
weather effects ...) are negligible in terms of effect on the correct and
safe use of electrical equipment.
1.3 Electrical safety
• Before connecting the appliance to the power supply for the first time,
make sure that the voltage on the appliance label corresponds to that of
the household electrical socked.
• The electric appliance is designed to power from 1/N/PE ~ 230 V 50 Hz.
• The electrical safety of the appliance is guaranteed only if it is properly
connected to the mains.
• Electrical protection class I equipment is equipped with a protection
against electric shock by means of protective earthing of inanimate
parts, which can become dangerous when the device is malfunctioning.
Always connect such devices to properly installed mains sockets that
are equipped with earthing conductors and have a properly grounded
earthing conductor.
All electrical equipment is equipped with a three-wire power supply.
• Class II electrical equipment is protected against electric shock by
double insulation or by enhanced insulation of hazardous live electrical
parts. Device of protection class II it must not be equipped with means
to connect protective earthing.
All electrical equipment is equipped with two-wire power supply.
• Class III electrical equipment is a device that is powered by a small
safe voltage source (battery or accumulator) and does not present any
danger to the user from electrical shock.
• In order to provide increased safety against the risk of electric
shock due to the use of electrical appliances by laypersons, it is
recommended to install the power supply circuit for sockets with a rated
current not exceeding 20 A RCD with a rated operating current not
exceeding 30 mA.
To ensure the safety and correctness of the electrical installation,
consult with a qualified electrician.

5EN
• Only use a power cord with a plug (mains lead) supplied with the device
and compatible with a wall socket. Using another cable may result in
fire or electric shock.
• Always connect an electrical appliance to an easily accessible mains
socket. In the event of an operating fault, the appliance must be
switched off as soon as possible and disconnected from mains supply.
• The power cord and mains plug must always be easily accessible for
safe disconnection of the electrical appliance from the power supply.
• Do not pull off the power cord by pulling the cable. Disconnect the
power cord by pulling the plug behind the power cord plug.
• If you use an extension cord, make sure that the total rated power of
all devices connected to the extension cord does not exceed the max.
current load on the extension cable.
• If you need to use an extension cord or power supply block, make sure
that the extension cord or power pack is plugged into a power socket,
and not to another extension cord or power supply. The extension
power cord or power supply block must be designed for grounded
electrical plugs and connected to a properly grounded electrical socket.
• The power plug of the appliance must be compatible with the mains
socket. Never use any adapters or modify the socket in any other way.
Do not use inappropriate or damaged sockets!
• To avoid electrical shock, plug the power cables into properly grounded
electrical sockets. If the device is equipped with a 3-pole plug, do not
use adapters that do not have a grounding element or remove the
grounding element from the plug or adapter.
• Do not bend, crush or otherwise expose the power cord of the
appliance to mechanical stress or external heat sources. Damage to the
power cord may result in electric shock.
• When the power cord is damaged, disconnect the appliance from the
mains and do not use it again.
• If the power cord is damaged, it must be replaced by the manufacturer,
its service department or a similarly qualified person to avoid the risk of
electric shock.
• Regularly check and maintain the electrical appliance as well as the
power cord and power socket. Disconnect the power plug regularly and
clean it if necessary. Pollution by dust or other substances may cause
disruption of the insulating state and consequently fire.
• Do not expose the appliance to water or moisture. The ingress of water
into the appliance increases the risk of electric shock.
If the power cord is wet or the water has penetrated the water,
disconnect it immediately from the mains. If the appliance is plugged
into a mains socket and if possible, turn off the power circuit before
attempting
unplug the power. If you are pulling wet wires from a live power source,
be very careful.
• If the electrical equipment is installed (connecting) the protective covers
are dismantled, the electrical parts must not be accessible to the user
when the installation is finished.

6EN
1.4 Safety of persons
• This appliance is intended for use and operation by persons without
electrotechnical qualification - lay people, according to the instructions
specified by the manufacturer.
• Device operation includes activities such as switching on and off, user
manipulation and setting of operating parameters, visual or auditory
inspection of the equipment, and user cleaning and maintenance.
• This appliance can be used by children under the age of 8 and
persons with reduced physical, sensory or mental capabilities or lack
of experience or knowledge when supervised or instructed to use the
appliance safely and understand the dangers involved.
• Children may not play with the appliance.
• Cleaning and maintenance for users may not be performed by children
unattended.
• Always keep the appliance out of reach of children during use and
operation. Be sure to download the appliance even for a freely
accessible power cord.
• Always be careful when operating the electric appliance! Do not use
an electric appliance if you are overly tired, under the influence of
medication or narcotic drugs that reduce attention and focus.
• Inattention during operation may result in serious injury.

7EN
1.5 Cleaning, maintenance and repairs
• Observe the normal user cleaning and maintenance of the appliance
in the recommended way. Do not use solvents or harsh cleaners for
cleaning. Pollution and visible stains from finger contact, respectively.
The hands can be cleaned using detergent detergents specially
designed to clean household appliances.
• If you do not use the appliance, clean it or disconnect the appliance
from the power supply when the appliance is faulty.
• Electrical appliances that are cleaned after use and are not intended
to be completely or partly immersed in water or other liquid, protect
against the effects of dripping and / or splashing water and before
immersion.
• Electric household appliances, like all other technical devices, are
subject to the surrounding environment and natural wear. Since the
legal framework of regular maintenance is not laid down for lay-in
electrical household appliances, the manufacturer recommends that the
user have the appliance checked and cleaned at least once a year by a
specialist workshop.
• By doing so, it is possible to achieve safety, operational reliability and
increased service life.
• Do not disassemble the electric appliance! The appliance works with
a dangerous voltage. For this reason, always switch off the appliance
and disconnect it from the mains supply during user maintenance. In
the event of a fault, please have the repair serviced by an authorized
service center.
• Before calling a service:
1. Turn the appliance off and on to make sure the fault reappears.
2. If the malfunction of the appliance still persists after these
operations, call the nearest specialist service center.
• Never repair the electric appliance yourself!
• Unauthorized, unqualified and improper use of an electric appliance
may result in electric shock or other serious injury.
• Only carry out the warranty or post-warranty repair of an electrical
appliance to an authorized qualified person(*).
(*)Competent qualified expert: the sales department of the manufacturer or importer or
the person qualified and authorized to carry out this type of activity with the ability to
avoid all risks.

8EN
Special safety instructions.
Read carefully!
• The electrical equipment is designed and manufactured in such a way
as to enable safe operation and use by persons without professional
qualifications. Despite all the measures taken by the manufacturer for
safe use, operation and use, there are certain residual risks and the
associated hazards.
• The following symbols and their meanings have been used on the
device and in the accompanying documentation to warn of possible
dangers:
This symbol alerts users to the fact that the device operates on
hazardous electrical voltage. Do not remove the protective covers
on the device.
Failure to observe the safety instructions for the use and
operation of the device may result in:
Danger of electric shock! Danger of serious injury or death!
This symbol alerts users to the risk of failure to observe the
safety instructions when using and operating the equipment:
Danger of serious injury or death!
Danger of equipment damage or other property damage!
Transport/Carrying
• When transporting and carrying, be careful when moving to avoid
tipping the device over.
• Only transport/transport the device after a thorough inspection of the
area and the route, which must be unobstructed.
• Never carry the device while it is in operation. Do not carry the device
while it is connected to the mains.
• Carry the device by firmly grasping the solid parts of its body.
• When carrying, make sure that your hands and the device are not wet
or slippery.
Danger of serious injury or death!
There is a risk of damaging the device!
Unpacking/Packaging
• Unpack the device and accessories before putting them into operation
and dispose of all parts of the packaging materials, labels and tags.
Keep packaging materials in a safe place or keep them out of the reach
of children and incompetent persons.
Danger of serious injuries!
Danger of suffocation!

9EN
Inspection/Commissioning
• We recommend performing initial and subsequent regular inspections
of the device.
• Never use the device if it is incomplete, damaged or any part of it has
been damaged during use.
• Do not use non-original and incomplete parts of the device and its
accessories.
There is a risk of electric shock!
Danger of electrical short circuit!
• Do not switch on the device unless it is completely and correctly
assembled and ready for use. For stand-alone devices, make sure that
the feet are mounted correctly.
• Complete and correct assembly of the device must be performed in
accordance with the manufacturer‘s instructions.
• Never clean the appliance (its electric unit with heater) and the mains
cord with plug in such a way that liquid could flow into the appliance.
• Clean these parts only with a damp cloth and wipe them dry or allow
them to dry.
• Only clean the appliance when it is switched off and unplugged.
• Use the device only with original accessories that are intended for use
with the type.
Location/Installation
• Only place the device on level and stable surfaces with a firm structure.
• Always make sure that the place where you want to place the device
has sufficient space, mechanical strength and stability.
• Do not use or place the device:
- on unstable surfaces or substrates,
- on uneven and dirty surfaces,
- on the tight edge of surfaces or pads,
- near containers with water or other liquids.
• Do not insert or allow foreign bodies to enter the openings of the device
covers.
• Do not cover the air vents of the covers. Air ventilation ensures correct,
reliable and safe operation of the device.
There is a risk of electric shock!
There is a risk of fire!
Warning!
• Place the appliance out of the reach of children.
• Do not allow children to handle the device. The appliance can tip over
children and cause serious injuries.
• Mechanical damage (cracking or breaking of parts and covers) of the
device can cause serious injury.
Danger of serious injuries!
There is a risk of damage to the device or other property damage!

10EN
• Do not place or use the device near containers containing water. Do not
remove the device if it falls into the water. First pull the mains plug out
of the mains socket and only then remove the appliance from the water.
In such cases, take the device to a specialist garage for inspection to
ensure that it is safe and working properly.
There is a risk of electric shock!
Danger of electrical short circuit!
Operation/Supervision
Warning!
• Use the appliance only to dry or heat towels and parts of clothing.
• Do not use the appliance to heat rooms.
• Only use the device in the working position. Use the device only in
places where there is no risk of it tipping over.
• You can support the stability of the appliance by ensuring that the
towels and clothing parts are evenly distributed on both sides of the
radiators.
• Do not switch on the device unless it is completely and correctly
assembled and ready for use. For free-standing devices, make sure that
the support legs are mounted correctly.
• Complete and correct assembly of the device must be performed in
accordance with the manufacturer‘s instructions.
• Keep the device under supervision during use and operation!
• This unit is not intended to be operated by means of a programmer,
external timer or remote control, as there is a risk of fire if it is covered
or placed incorrectly.
• Do not use the device in an explosive atmosphere in the presence of
flammable substances and their vapors, mists or dusts, and in
atmospheric conditions, where after ignition the flue gas spreads in a
simple way through the air.
There is a risk of fire!
Warning!
• The device must not be left unattended while it is connected to the
mains.
There is a risk of electric shock!
• Before each connection of the device to the mains, make sure that the
control knob (main switch) is in the „0“ (off) position.
• Do not turn the machine on or off by plugging or unplugging the power
cord.
• In normal use, always connect the appliance to the mains first and then
switch it on with the main switch.
• After use, turn off the machine with the main power switch, and then
unplug the power cord from the AC outlet.
• Do not use the device if the main power switch does not work on the
device.
• The device is under dangerous voltage when the mains supply is
connected.
There is a risk of electric shock!
Danger of serious injuries!

11EN
• The device contains parts that become very hot during operation.
• Do not touch the heated surfaces of the device with your hands or any
part of your body.
Warning! After switching off the device, the heated surfaces remain
warm for some time. Before any further handling of the device
- postponement, resp. storage, always wait for the appliance to cool
down completely.
• Never leave the device freely accessible or store it with a freely
accessible power cord. Children could pull the appliance by the power
cord.
Danger of serious injuries!
• Never overload the device beyond the limits set by the technical
parameters!
• Always divide the operating mode (operating / activity time and breaks)
of the device into the recommended operating intervals and follow
these instructions.
• If you notice any abnormalities (smell, smoke ...) while using the
appliance, switch off the appliance immediately and disconnect it from
the mains. Have the device checked by a specialist garage.
• Only fold and unfold the individual parts, clean and carry the device if
the device is switched off, sufficiently cool and disconnected from the
mains.
• If any safety part / component (mechanical, electrical) is part of the
device, never deactivate this part / component! Do not use the device if
the safety part / component is damaged or non-functional!
• Never underestimate the possible dangers and take extra care !!!

12EN
Description of parts and accessories
heating parts
safety on/off switch
with indicator light
power cord
legs
wall
mount
screws
Wall mounting

13EN
Characteristic properties
The device has the following characteristics and functions:
• solid and stable construction
• on/off switch with indicator light in the protective housing
• heat-resistant feet
• wall brackets
Commissioning
1. After unpacking the dryer, mount the feet on the device or mount the
dryer on the wall.
2. Prior to commissioning, make sure that the power cord is not wrapped
around the device. Allow the device to acclimatize to ambient
temperature before first use.
3. Plug the power cord into an electrical outlet that is rated on the type
plate.
4. Hang the towels on the radiators.
Warning!
Always use the appliance with towels attached to the radiators.
5. Use the on/off switch to turn on the device.
The indicator light turns on. After a few minutes, the device is warmed
up to an operating temperature not exceeding 50 ° C.
on/off switch
6. If necessary, check or fold the towels.

14EN
Turn off the device
1 Switch the device off with the on / off switch. The device switches off
and the indicator light goes out.
2 Unplug the power cord from the electrical outlet.
3 Before storing the appliance, allow the appliance to cool completely on
a non-flammable surface in such a position that the radiators do not
come into contact with any other surface.
Cleaning
• Before each cleaning, first switch off the appliance, disconnect it from
the mains and allow it to cool down completely.
• Wipe the device with a clean, soft cloth. Do not use any harsh powder
cleaners or solvents such as alcohol or thinner.
If the device is heavily soiled, you can dampen the cloth in lukewarm
water with a mild detergent solution.
• Do not wash the appliance under running water, in the dishwasher or
immerse it in water.
Technical parameters
Power supply: 230 V~ 50 Hz
Power consumption: 140 W
Dimensions (W x H x D): 55,7 x 84 x 11,5 cm (on the wall)
55 x 85 x 35 cm (with legs)
Weight: 1,6 kg
Package Contents: dryer (1)
instructions for use (1)
screws (12)
feet (2)
wall bracket (4)
spacers (dowels) (4)
We reserve the right to make changes!
