Orbic TAB10R 4G User manual

2
Table 0f Contents
GettingStarted.........................................................................3
Installing a SIM card..............................................................5
Charging the Battery.............................................................6
PoweringON/OFF...................................................................7
Google Account .....................................................................8
Using On-Screen Gestures................................................9
Lock and Unlock the Device...........................................10
Camera........................................................................................11
Google™ Play Store.............................................................13
Installing Apps........................................................................13
Uninstalling Apps..................................................................14
Improving Accessibility.....................................................15
Connecting to Wi-Fi............................................................15
Specific Absorption Rate (SAR) Safety....................16
5GHz WiFi Notice.................................................................17
For our European Customers.........................................18
Support and More................................................................19

3
Getting Started
Thank you for choosing the Orbic TAB10R 4G.
This guide helps you to get started with your
Orbic TAB10R 4G for the first time.
The TAB10R 4G has built-in 4G capabilities,
that can be utilised to connect to the internet
anywhere and anytime.

4
Orbic TAB10R 4G Overview
NOTE : The screen images and icons here are for
reference only since the software constantly
evolves.
Charging Port Status Bar
Google
TM
Search Bar
Front Camera Power Key Volume Keys
Stylus
Rubber Bumpers
Back
App Shortcuts
Stylus Magnetic
Home Recent Apps

5
Installing a SIM Card
Pop out and swivel the rubber cap that is
protecting the SIM slot, insert the SIM tool in the
SIM pin hole to release the tray (as shown in the
figure below). Place the SIM card in the slot with
the gold contacts facing down, close the tray and
replace the rubber cover. Your Orbic TAB10R 4G
is now ready to be used.
The SIM tray also has a slot for microSD card that
can be inserted following the steps mentioned
above.
NOTE : The microSD card is sold seperately.

6
Charging the Battery
Before using Orbic TAB10R 4G, Orbic
recommends to fully charge the battery (100%).
1. Pop out and swivel the rubber protective cap.
Insert the smaller end (USB Type-C) into the
device and the larger end (USB Type-A) into
the charger adapter.
2. The adapter shall be installed near the Orbic
TAB10R 4G and shall be easily accessible.
Warning! Use only approved chargers with your
Orbic TAB10R 4G. Incompatible chargers that are
tampered with may damage the Orbic TAB10R 4G
and void the warranty.

7
Powering ON/OFF
To turn ON,
• Press and hold the Power/Lock button.
To turn OFF,
• Press and hold the Power/Lock button and
follow the prompts.

8
GoogleTM Account
Orbic TAB10R 4G uses your Google account to
fully utilise its Android features, including Gmail,
Google Cloud Storage, and the Google Play Store.
When you turn ON your device for the first time,
set up a connection with your existing Google
account, or create a new Google account.
To Sign in to your Google Account
1. Tap Home Key > Google Folder > Gmail .
2. Sign in to your account by entering the email
address and password.
To Create a New Account
1. Tap Home Key , swipe up for Apps >
Settings > Passwords & accounts.
2. Tap + Add Account.
3. Enter the email address and password.
4. Follow the prompts to setup your email
account.
GoogleTM, Google Play, AndroidTM are trademarks
of GoogleTM LLC.

9
Using On-Screen Gestures
Use the on-screen gestures to move around the
screen; open menus, select items, zoom in or out
on web pages, and more.
• Tap - To open an app, select a menu item,
press an on-screen button, or to enter a
character using the keyboard on the screen,
tap it with your finger.
• Touch and Hold - Touch and hold an item
or the screen for more than 2 seconds to
access available options.
• Drag - To move an item, touch and hold it
and drag it to the target position.
• Double Tap - Double-tap on a web page or
image to zoom in. Double-tap again to return.
• Swipe - Swipe to the left or right on the
screen to scroll left or right. Swipe upwards
or downwards to scroll through a web page
or a list of items.
• Spread and Pinch - Spread two fingers
apart on a web page, map, or image to zoom
in on a part. Pinch to zoom out.

10
Lock and Unlock the Device
To Lock the Screen
• Press the Power/Lock button. This action
prevents the accidental keypress.
To Unlock the Screen
• Press the Power/Lock button and swipe up
on the screen.

11
Camera
Taking photos
1. From the Home screen, tap .
2. Aim the camera at the subject using the
phone’s main display screen as a viewfinder.
3. Pinch the screen to zoom in or pinch open to
zoom out.
4. Before taking a photo, you can tap on the
screen icons to access various camera
options and settings, if required.
5. Tap to capture a photo.
NOTE : You can also use the volume keys to
capture a photo.

12
Recording videos
1. From the Home screen, tap .
2. Tap video on the screen to switch to the
video mode.
3. Aim the camera at the subject using the
phone’s main display screen as a viewfinder.
4. Pinch the screen to zoom in or pinch open to
zoom out.
5. Tap the button to start recording the
video.

13
6. Pinch the screen to zoom in or pinch open to
zoom out.
Google™ Play Store
Find and download your favorite apps, movies
and TV shows, music, books, magazines, and
games.
Installing the Apps
Your device comes preloaded with several
applications, and you can download many more
from the Play Store.
Play Store
The Play Store is an application that comes
preinstalled on Android™ devices.

14
To install applications from the Play Store
1. Search or browse for applications.
2. Select the desired app, download, and install.
3. Follow the on-screen instructions to
complete the installation.
4. You can also uninstall, update, and manage
your downloaded apps.
Uninstalling the Apps
1. Touch and hold the app icon that you want to
uninstall.
2. Tap App info, then select Uninstall and follow
the prompts to uninstall the app.
3. Tap OK to confirm or Cancel to stop the
uninstallation.
NOTE : Some of the preloaded apps on the
device cannot be uninstalled.

15
Improving Accessibility
Accessibility options are special features that
make using the Orbic TAB10R 4G easier for
people who are physically handicapped.
To set accessibility options
1. Tap Home key > swipe up for Apps >
Settings > Accessibility.
2. Tap a category and set the desired options.
Connecting to Wi-Fi
1. Tap Home key > swipe up for Apps >
Settings > Network and Internet >
Internet > Wi-Fi. Make sure the Wi-Fi is
turned ON.
2. Select a displayed network or tap Add
network.
3. Enter the network SSID and other required
information.
4. Tap Save.

16
Specic Absorption Rate (SAR)
Safety
This device has been designed to comply with
applicable safety requirements for exposure to
radio waves. These requirements are designed
for the safety of all persons and follow scientific
guidelines including safety margins.
• The radio wave exposure guidelines employ
a unit of measurement known as the Specific
Absorption Rate or SAR. Tests for SAR are
conducted using standardised methods,
with the device transmitting at its highest
certified power level in all used frequency
bands.
• This device is designed and manufactured
not to exceed emission limits for radio
frequency (RF) energy exposure.
• This device is in compliance with the
Specific Absorption Rate (SAR) for the
general population or uncontrolled exposure
limits (2.0W/kg and 4.0W/kg) specified in
Council Recommendation 1999/519/EC
and had been tested in accordance with the
measurement methods and procedures
specified in EN 62209-1:2016 and

17
EN 622092:2010+AMD1:2019.
• The highest SAR value for this model tested
for use when worn on the body is 1.47 W/kg
(10g).
• This device meets RF exposure guidelines
when used in the normal position at least
0 mm away from the body. When a carry
case, belt clip, or holder is used for body
worn operation, it should not contain metal
and should postion the product at least
5 mm away from your body. Ensure the
above seperation distance instructions are
followed.
5GHz Wi-Fi Notice (Europe and Japan)
The Wi-Fi funtion for Orbic TAB10R 4G is
restricted to indoor use only when operating in
the 5150 MHz to 5350 MHz frequency range.

18
For European Customers
Device transmission frequency and power
WWAN
Frequency Band Maximum Output Power (dBm)
WCDMA Band l/Vlll 23.70
LTE Band 1 24.50
LTE Band 3 24.50
LTE Band 7 23.50
LTE Band 8 24.50
LTE Band 20 24.50
LTE Band 28 24.50
LTE Band 40
Standard
Bluetooth Version EIRP Power (dBm)
EDR 9.16
LE 4.74
Frequency EIRP Power (dBm)
2.4~2.4835GHz 14.33
13.36
12.63
5.15~5.25GHz
5.725~5.825GHz
Wi-Fi
2.4G
Wi-Fi
5G
24.50
WLAN
BLUETOOTH

19
EU Regulatory Compliance - Orbic North
America LLC declares that Orbic TAB10R 4G is in
compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
For the declaration of conformity, visit orbic.us
Orbic GmbH
C/O
Collection Business Center
Dreischeibenhaus
D-40211 Düsseldorf
Model Code : RC10RLT-RW
Model Name : TAB10R 4G

20
BC
V4
Support and More
For how to use, or more tips and tricks on
getting the most out of your new Orbic
TAB10R 4G, check out the guides and
more information at -
orbic.us
