laerdal SimPad SkillReporter User manual

SimPad SkillReporter
www.laerdal.com
User Guide

2
Introduction
1
INTRODUCTION
SimPad is a wireless touchscreen device for use with Laerdal manikins.This version
is installed with SkillReporter software for Basic Life Support (BLS) training.To get
feedback on the CPR performance, use QCPR enabled manikins, either Resusci Anne
or Resusci Baby. SkillReporter has two modes, BLS Learner and BLS Instructor.
BLS Instructor
enables the instructor
to provide AED training.
Feedback can be displayed
from up to 6 manikins.
Adjust brightness, clock,
and more.
BLS Learner gives
feedback on CPR done
on a single manikin.
SkillReporter

2 3
Introduction 1
CONTENT
1 Introduction 2
Content 3
What’s in the box 4
2 Get Started 5
Charge the battery 5
Startup 5
3 Connect 6
Connectors 6
Connecting manikins 6
Connect to one manikin using USB cable 7
Connect using WiFi 7
Select manikins 8
Set up and select network 9
Laerdal Router 9
Edit manikin name 10
Can’t find a manikin? 10
4 SimPad SkillReporter 11
How to use SimPad SkillReporter 11
BLS Learner 12
BLS Instructor 13
Choose algorithm 14
Manage Learners 15
Event registration 17
Defibrillator features 18
Live feedback 20
Timeline 21
Results 22
BLS Settings 25
Get manikin information 26
5 Manikin Error State 27
Red light on Resusci Anne Manikin 27

4
Introduction
1
WHAT’S IN THE BOX
SimPad
Important Product Information
SimPad
SimPad to Manikin Cable
SimPad to PC Cable
SimPad Sleeve
Power Cable
Power Adaptor
User Guide for SkillReporter Important Product Information

5
Get Started 2
4
CHARGE THE BATTERY
Connect SimPad to the AC adapter and plug it into a wall outlet.
When the battery charges, the yellow LED flashes.
When the battery is fully charged, the yellow LED glows steadily.
If you start SimPad when the battery level is very low, the red LED flashes.
STARTUP
Press and hold down the Power button for half a second to switch on the SimPad.The
first startup can take a few minutes. You are prompted to set the time, date, language,
and device name.

6
Connect
3
CONNECTORS
USB port for
connection to
manikin or PC
Ethernet LAN
connection
Power adaptor
connection
CONNECTING MANIKINS
There are several ways to connect SimPad to the manikins.When connecting SimPad
to only one manikin, use either the USB cable or WiFi. No router is needed.
When connecting SimPad to more than one manikin (up to 6), use a WiFi connection
with a router. We recommend using the Laerdal Router as it simplifies the setup and
improves stability.

6 7
Connect 3
CONNECT TO ONE MANIKIN USING USB CABLE
The USB cable provides the most reliable connection when connecting SimPad to
one manikin.When using the USB cable, the manikin is powered by SimPad.To avoid a
quick battery discharge when the manikin is powered by SimPad, we recommend you
plug in the power adaptor.
CONNECT USING WIFI
For wireless use, make sure the manikin is in WiFi
mode, indicated by the green WiFi symbol on the
manikin’s control panel.The toggle button toggles
between cable,WiFi, and Bluetooth mode.
Toggle button

8
Connect
3
SELECT MANIKINS
If you start a session without having manikins connected, you are prompted to select
manikin(s). In BLS Learner you can only select one manikin.This happens automatically
if the manikin is connected through the USB cable, or if only one manikin is available.
In BLS Instructor you can choose up to 6 manikins.
Tap the manikin icon to
access this screen
Selected
Connected
Occupied (in use by another
SimPad)
Lost Connection

8 9
Connect 3
SET UP AND SELECT NETWORK
If you have selected more than one manikin (BLS Instructor), you are prompted to
choose a network.The network enables communication between several manikins and
SimPad.We recommend that you use the Laerdal Router (purchased separately) to
establish the network.
LAERDAL ROUTER
Let the router start up completely (approx. 2 minutes) before starting up SimPad and
the manikins. Also make sure the router switch is set to Router or AP, not Client. For
optimal performance, place the router above floor level. Do not reset or otherwise
change the router (i.e. password, configuration etc).To reboot, simply disconnect and
reconnect the power.To power the router, use only the included USB power supply
(5V). Using the SimPad power supply (12V) may cause permanent damage to the
router. A network from a Laerdal Router is listed as LaerdalNetMobile.
Router switch
Reset button (do not use)Power connector

10
Connect
3
EDIT MANIKIN NAME
The default manikin name is Resusci Anne or Resusci Baby. To keep track of multiple
manikins, give each one a unique name.
TIP: Switch on one manikin at the time and tap Edit name when the manikin appears
on the screen.Type a new name and put a corresponding name tag on the manikin.
Repeat this process for every new manikin.
Edit name
CAN’T FIND A MANIKIN?
If the manikin you want to use doesn’t appear on the list, make sure the manikin is
switched on and in WiFi mode, indicated by the green WiFi symbol on the control
panel on the manikin. Be patient - it might take up to 15 seconds to identify the
manikin. If the manikin still doesn’t appear, it may be connected to a different network
than SimPad.To make it available for selection, press and hold the manikin’s toggle
button. After two seconds a beep confirms that the manikin is reset. About 15 seconds
later the manikin appears on the list.
Connection problems may occur in areas with e.g. high WiFi traffic.
The most reliable connection for single manikin use is the USB cable. A cable connect-
ed manikin appears in the manikin list as preselected and connected.
Tap here to access the
manikin selection and
available networks.
Number of manikins
connected

11
SimPad SkillReporter 4
10
HOW TO USE SIMPAD SKILLREPORTER
SkillReporter has two modes optimized for learner and instructor use:
BLS Learner
BLS Instructor

12
SimPad SkillReporter
4
BLS LEARNER
BLS Learner gives feedback on CPR performance for learners using a single manikin.
You can choose between Practice and Assessment, and between CPR (single
rescuer or two-rescuer), Compressions Only, and Ventilations Only.
Practice CPR with
corrective feedback.
Test your performance
(with or without
feedback) and save your
results.
View results from the
previous session.
View results from the
saved sessions.

12 13
SimPad SkillReporter 4
BLS INSTRUCTOR
In BLS Instructor the interface is designed to help the instructor review learners’
performance on one or several manikins, register events, and control defibrillation
features*. Sessions can be saved and features for managing learners are available.
Monitor CPR classes
with up to 6 manikins.
You can have an
overview of all the
manikins or view details
one by one.
* Depending on manikin model.

14
SimPad SkillReporter
4
CHOOSE ALGORITHM
You can choose to practice CPR (both compressions and ventilations), Compressions
only, or Ventilations only. For CPR sessions, select either single rescuer or two-rescuer.
The difference between single rescuer and two-rescuer is in the scoring: participants in
two-rescuer sessions are allowed less no-flow time than single rescuers are.
To assign learner names
to connected manikins,
tap Learners.

14 15
SimPad SkillReporter 4
MANAGE LEARNERS
You can assign one or more learner names to each manikin.Tap Learner and assign
the names either before, during, or after a session.The names are stored for later
reference.View and edit the Learners list in BLS Settings.

16
SimPad SkillReporter
4
To manage a large group of learners, you can import a list of names to SimPad.
Connect SimPad to a computer, using the SimPad-to-PC cable that comes with
SimPad. SimPad appears as an external disk drive on your computer.
Create a document in “.txt” format named “class.txt” (using e.g. Notepad) that has one
learner name per line.Transfer the file into the folder named ‘’Learners’’ on the SimPad
drive.
Learners
class.txt
Logs
Scenarios
Themes

16 17
SimPad SkillReporter 4
EVENT REGISTRATION
In BLS Instructor, you can register Events such as Response Check and Call for help
during a session.These events are displayed in the timeline and stored in the session.
You can create your own events from BLS Settings > View Event Registrations.The
Event Registration feature can be disabled in BLS Settings.

18
SimPad SkillReporter
4
DEFIBRILLATOR FEATURES
When using Resusci Anne QCPR D you can give training using a live defibrillator.*
SimPad recognizes this manikin automatically and allows you to select heart rhythms.
Active Rhythm
When a new rhythm
is selected, it flashes
to indicate that it's a
pending rhythm.The
rhythm is activated upon
shock or when you
press the Activate now
button.
*You need a compatible adaptor cable to connect your defibrillator to the manikin.

18 19
SimPad SkillReporter 4
When using Resusci Anne AED you can give AED training with a Laerdal AEDTrainer
2 or 3. Enable this feature in BLS settings by selecting your AED trainer type.When
applicable training pads (Link Pads) are placed correctly on the manikin, SimPad can be
used as remote control for the AED trainer.

20
SimPad SkillReporter
4
LIVE FEEDBACK
COMPRESSIONS
Low rate
OK rate
High rate
Complete release
Correct depth
VENTILATION
OK volume Too little
volume
Too much
volume
Low rate
OK rate
High rate
